Belt Influence Compensation Bic; Control For Point Of Discharge Cpd - Schenck process Intecont Plus Belt Weigher Operating Manual

VBW
Note: Monitor service value "Belt Drift Tr" indicating
the deviation of mid sensor and thus of belt from
sensor position in cm.
Example: Belt drift = 0.20 cm: Parameter N08
"Sensor Offset" = - 0.20 cm indicates belt slip 0.00 cm.
8. If necessary, determine event classes of belt slip
and drift messages (Parameters N09...N17).
Note: Normally, the default values can be used
in actual practice.
9. Check messages.
Note: To check, adapt Parameter N08
"SensorOffset" accordingly and remember to
reset value to default.

Belt Influence Compensation BIC

The automatic Belt Influence Compensation BIC is
designed to monitor and correct the belt influence. As
is with belt run monitoring, a sensor and a sensor area
are required. To commission BIC, first start belt run
monitoring.
Note: Perform initial commissioning without active
BIC.
Features
After start of the belt influence compensation, the
influence of the conveyor belt on measurement will be
compensated after approx. 10 belt circuits.
Prerequisites:
·
Belt run monitoring commissioned
·
Belt run monitoring started.
To start BIC, set Parameter N05 "BIC Active" to "YES"
.
Commissioning
BV-H2214 GB 92
Upon measurement at the point of discharge, the
measuring point of the weighing platform is shifted to
the point of material discharge using a delay element.
The amount discharged is measured direct.
Note: If CPD is active, Automatic Belt Influence
Compensation BIC should be started as well.
Prerequisites:
·
·
To start CPD, set Parameter N01 "CPD Active" to
"YES" .
Technische
Redaktion PDE-RD
INTECONT PLUS

Control for Point of Discharge CPD

Length ratio from mid platform to material discharge
point and total conveyor belt length is known.
Length ratio in percent is entered into Parameter
N02 "Platf.Dis.Length".
