1.1 RG-CS83-12GT4XS-P

Specifications

Model
CPU
BOOTROM
Flash Memory
SDRAM
SFP Module Type
Built-in Power Supply
SFP+ Port
RTC
PoE
Power Consumption
Ambient Noise
Operating
Temperature
Storage Temperature
Operating Humidity
Operating Height
Storage Humidity
RG-CS83-12GT4XS-P
Dual-core CPU with the clock speed of 1.0GHz
16MB
512MB
1GB
SFP+ Port:
SFP Modules and SFP BIDI Modules
SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
See Chapter 7 for details.
The module types may update without prior notification. Please contact Ruijie Networks
for details.
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 6 A
10GBase-R Capable
1000Base-X Capable
Supported
All RJ45 ports are PoE+ capable and each port provides up to 30 W of power.
The maximum power is 370W.
The PoE+ port is compliant with both the PoE (IEEE802.3af) and PoE+ (IEEE802.3at)
standards.
The maximum number of PoE devices supported by the switch is determined by the
available PoE consumption of the switch and the actual PoE consumption of each
device.
The PoE port is compliant with Alternative A.
Without PoE Load: < 35 W
With PoE Full Load: < 405 W
32 dB(A)
0º C to 45º C (32º F to 113 º F) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the
maximum operating temperature decreases by 1° C (1.8° F) every time the altitude increases
by 220 m (721.78 ft.).
-40º C ~ 70º C
10% ~ 90% RH
0~5000m
5% ~ 95% RH
