Hardware Installation and Reference Guide
1.2 RG-CS83-24GT4XS
Specifications
Model
CPU
BOOTROM
Flash Memory
SDRAM
SFP Module Type
Built-in Power Supply
SFP+ Port
RTC
PoE
Power Consumption
Ambinet Noise
Operating
Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Operating Height
Fan
Temperature
Alarming
EMI Certification
RG-CS83-24GT4XS
Dual-core CPU with the clock speed of 1.0GHz
16MB
512MB
1GB
SFP+ Port:
SFP Modules and SFP BIDI Modules
SFP+ Modules, SFP+ Cables and SFP+ BIDI Modules.
See Chapter 7 for details.
The module types may update without prior notification. Please contact Ruijie Networks
for details.
When up to two SFP+ optical modules are configured with a maximum distance of 80
km (49.71 miles), the operating temperature range is 0º C to 45 º C (32º F to 113º F).
When three or four SFP+ optical modules are configured with a maximum distance of
80 km (49.71 miles), the operating temperature range is 0º C to 40º C (32º F to 104º F).
AC Input
Rated Voltage Range: 100 V AC to 240 V AC
Maximum Voltage Range: 90 V AC to 264 V AC
Frequency: 50 Hz/60 Hz
Rated Current Per Circuit: 0.6 A
10GBase-R Capable
1000Base-X Capable
Supported
Not supported
<25W
＜20 dB (A)
0º C to 45º C (32º F to 113 º F) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the
maximum operating temperature decreases by 1° C (1.8° F) every time the altitude increases
by 220 m (721.78 ft.).
-40º C to 70º C (-40º F to 158º F)
10% to 90% RH (non-condensing)
5% to 95% RH (non-condensing)
0 to 5000 m (3.11 miles) above the sea level
No fans
Supported
GB/T 9254.1
