Hardware Installation and Reference Guide
The RG-CS83-48GT4XS switch has a built-in power supply module. The back panel has an AC power plug.
Cooling
The RG-CS83-48GT4XS switch adopts a left-to-right and front-to-right airflow to ensure normal operation. Maintain a
minimum clearance of 100 mm (3.94 in.) around the device for air circulation.
Figure 1-15 Airflow Direction
LED
Function
System Status LED
10GE SFP+ Port LED
10/100/1000Base-T Ethernet
Port LED
Panel ID Color
Off
Blinking
Green (3
Hz)
Blinking
Green (10
Hz)
Status
Solid
Green
Solid
Yellow
Solid Red
Off
Solid
49F to 52F Green
Blinking
Green
Off
1F to 48F
Solid
Green
Status
System is not powered on.
System is being initialized. Continuous blinking
indicates a fault.
System is being located.
System is operating normally.
The temperature at the air intake and exhaust
vents exceeds the threshold.
1. The temperature at the air intake and exhaust
vents well exceeds the threshold.
2. The system is not functioning properly.
No link is detected for this port.
The port has made a successful 1/10 Gbps link.
The port is sending and receiving traffic at 1/10
Gbps.
No link is detected for this port.
The port has made a successful 10/100/1000
Mbps link.
16
