Ruijie RG-CS83 Series Hardware Installation And Reference Manual page 22

Hardware Installation and Reference Guide
Storage Temperature
Operating Humidity
Operating Height
Storage Humidity
Fan
Temperature
Alarming
EMI Certification
Safety Regulation
Compliance
Dimensions
(W x D x H)
Weight
Appearance
The front panel of the RG-CS83-48GT4XS-P switch provides 48 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports,
one Console port and one USB port. The back panel has an AC power plug.
Figure 1-36 RG-CS83-48GT4XS-P Switch Appearance
-40º C to 70º C (-40º F to 158º F)
10% to 90% RH (non-condensing)
0 to 5000 m (3.11 miles) above the sea level
5% to 95% RH (non-condensing)
Fan Speed Control (manual configuration not supported)
Fan Fault Alarming
Supported
GB/T 9254.1
GB 4943.1
442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.)
3 kg (6.61 lbs.) (The product information label is on the bottom of the switch.)
18
