Hardware Installation and Reference Guide
Function
System Status LED
LED Mode LED
10GE SFP+ Port LED
10/100/1000Base-T Ethernet
Port LED
RJ45 port PoE status LED
LED Mode Button：
The LED Mode button is used to switch the LED mode. The green LED Mode indicator indicates the switching status.
Press the LED Mode button, and the LED Mode indicator will turn yellow, indicating the PoE status. Press the LED
Mode button again, the indicator switches to indicating the switching status.
If you want to switch the LED mode, press the button for over two seconds.
Panel ID Color
Off
Blinking
Green (3
Hz)
Blinking
Green (10
Hz)
Status
Solid
Green
Solid
Yellow
Solid Red
Solid
green
LED Mode
Solid
yellow
Off
Solid
13F-16F Green
Blinking
Green
Off
Solid
1-12 Green
Blinking
Green
Off
Solid
Green
1-12
Blinking
Green(3
Hz)
Status
System is not powered on.
System is being initialized. Continuous blinking
indicates a fault.
System is being located.
System is operating normally.
The temperature at the air intake and exhaust
vents exceeds the threshold.
1. The temperature at the air intake and exhaust
vents well exceeds the threshold.
2. The system is not functioning properly.
The LED indicates the switching status.
The LED indicates the PoE power supply status.
No link is detected for this port.
The port has made a successful 1/10 Gbps link.
The port is sending and receiving traffic at 1/10
Gbps.
No link is detected for this port.
The port has made a successful 10/100/1000
Mbps link.
The port is sending and receiving traffic at
10/100/1000 Mbps.
PoE is not enabled.
PoE is enabled. The port is operational.
The port has a PoE fault of overload.
