Front Panel - Ruijie RG-CS83 Series Hardware Installation And Reference Manual

Hardware Installation and Reference Guide
Fan
Temperature
Alarming
EMI Certification
Safety Regulation
Compliance
Dimensions
(W x D x H)
Weight
Appearance
The front panel of the RG-CS83-12GT4XS-P switch provides 12 10/100/1000Base-T Ethernet ports (PoE+ Capable), four
10GE SFP+ ports, one Console port and one USB port. The back panel has an AC power plug.
Figure 1-1 RG-CS83-12GT4XS-P Switch Appearance

Front Panel

Figure 1-1 Front Panel of RG-CS83-12GT4XS-P
Fan Speed Control (manual configuration not supported)
Fan Fault Alarming
Supported
GB/T 9254.1
GB 4943.1
442mm × 220mm × 43.6mm (17.4in x 8.66in x 1.72in )
3kg (6.61 lbs.) (The product information label is on the bottom of the switch.)
3
