Intended use
Documents which also apply
3.3.1

Part of the complete documentation

This document is part of the complete documentation and valid only in combination with all other
parts of these instructions! Read and observe the operating instructions for all system
components, especially the safety instructions!
The illustration shows a general example of a welding system.
Item Documentation
A.1 Control
A.2 Power source
A.3 Cooling unit
A.4
Transport vehicle
A.5 Welding torch
A.6
Remote control
A Complete documentation
14
Figure 3-1
099-00T405-EW501
14.02.2022
