Internal Alarms/Warnings
E-Code Displayed Alarm
3917 Engine Oil Tem-
perature 1
4003 Engine Fuel Shut-
off 1 Control
4004 Engine Fuel Shut-
off 1 Control
4100 Engine Position
Sensor
4101 Engine Position
Sensor
4102 Engine Position
Sensor
4103 Engine Position
Sensor
4104 Engine Position
Sensor
4200 Engine Timing
Sensor
4201 Engine Timing
Sensor
4202 Engine Timing
Sensor
4203 Engine Timing
Sensor
4204 Engine Timing
Sensor
4300 O2 Sensor
4301 O2 Sensor
4302 O2 Sensor
4303 O2 Sensor
4304 O2 Sensor
4315 O2 Sensor
4317 O2 Sensor
4400 Engine Knock 1
4401 Engine Knock 1
4402 Engine Knock 1
4403 Engine Knock 1
34
Alarm/Warning Description
High Oil Temp—Data valid but below normal operating range; least severe
W
level.
Fuel System Fault—Voltage above normal range; shorted to high source.
A
A Fuel System Fault—Voltage below normal range; shorted to low source; open
circuit.
A Crankshaft Sensor Fault—Data valid but above normal operating range; high
severe level.
A Crankshaft Sensor Fault—Data valid but below normal operating range; high
severe level.
A Crankshaft Sensor Fault—Data erratic, intermittent, or incorrect.
A Crankshaft Sensor Fault—Voltage above normal range; shorted to high
source.
A Crankshaft Sensor Fault—Voltage below normal range; shorted to low source;
open circuit.
A Crankshaft Sensor Fault—Data valid but above normal operating range; high
severe level.
Crankshaft Sensor Fault—Data valid but below normal operating range; high
A
severe level.
Crankshaft Sensor Fault—Data erratic, intermittent, or incorrect.
A
A Crankshaft Sensor Fault—Voltage above normal range; shorted to high
source.
A Crankshaft Sensor Fault—Voltage below normal range; shorted to low source;
open circuit
A Check O2 Sensor—Data valid but above normal operating range; high severe
level.
A Check O2 Sensor—Data valid but below normal operating range; high severe
level.
Check O2 Sensor—Data erratic, intermittent, or incorrect.
A
A Check O2 Sensor—Voltage above normal range; shorted to high source.
A Check O2 Sensor—Voltage below normal range; shorted to low source; open
circuit.
W Check O2 Sensor—Data valid but above normal operating range; least severe
level.
W Check O2 Sensor—Data valid but below normal operating range; least severe
level.
A Engine Knock Sensor Fault—Data valid but above normal operating range;
high severe level.
A Engine Knock Sensor Fault—Data valid but below normal operating range;
high severe level.
A Engine Knock Sensor Fault—Data erratic, intermittent, or incorrect.
Engine Knock Sensor Fault—Voltage above normal range; shorted to high
A
source.
