General Information
See Figure 2-31. Use page 5 to modify I/O Extender pre-
heat mode, preheat time, and wire setting.
Dealer Edit:
I/O Ext. Config.
Preheat Mode
Preheat Time
Select Wire Setting
Figure 2-31. Edit Settings (Page 5)
See Figure 2-32. I/O Ext. Config. sub-page can be used
for the special units that have the Generac I/O extender.
Once the function is enabled, each input or output can be
associated to a pre-defined function.
Dealer Edit:
I/O Ext. 1
Digital Inputs
Digital Outputs
Figure 2-32. I/O Ext. Config. Sub-Page
See 2-33. Use page 6 to modify low oil pressure
Figure
warning, alarm, and hold off time, modify parameter
group, voltage code, and high fuel warning, low fuel
warning and alarm.
Dealer Edit:
Low Oil Pressure
Parameter Group
Voltage Code
Fuel Level Indicators
Figure 2-33. Edit Settings (Page 6)
14
See Figure 2-34. Use page 7 to enable or disable AMF
(Auto Mains Failure) mode, and switch between 1 and 2
wire actuation.
Dealer Edit:
AMF Mode
1/2 Wire Actuation
Ground Fault
013005
Figure 2-34. Edit Settings (Page 7)
See Figure 2-35. Use page 8 to reset the controller, per-
form a factory reset, update ECU (Engine Control Unit)
firmware, and save or load a configuration to or from a
USB drive.
Dealer Edit:
Reset Controller
Factory Reset
Update ECU Firmware
Save/Load Config.
013067
Figure 2-35. Edit Settings (Page 8)
"Test" Sub-Pages
See Figure 2-36. Use page 1 to test digital inputs and
outputs, and view analog channels.
Dealer Test:
Digital Inputs
Digital Outputs
Analog Channels
013006
Figure 2-36. Test (Page 1)
