Navigation

Use the navigation arrows (
the screens. Use the ESCAPE button (
the previous screen or selection and use the ENTER but-
ton ( ) to confirm a selection.

Screens

There are six screen types which contain all available
pages as shown in Figure
sub-pages containing additional information or settings to
modify.
04/19/21
Status:
Stopped With Alarm
Protected Hours
A
Figure 2-4. Home Screen
A
Engine Screen
B Power Screen
C
Setting Screen
D Dealer Screen
E
Info Screen
F Alarm Screen
NOTE: The Dealer Screen can only be accessed using
credentials.
NOTE: Any data or values shown on the screens
throughout this manual are for reference only.

Wizard Screens

The Wizard Screens are displayed at controller startup.
See Figure 2-5. Use page 1 to set the language for the
screens.
Technical Manual Power Zone 410 Controller
) to navigate between
) to go back to
2-4. Each page may contain
01:06PM
368
E
D
C
B
Install Wizard
Set Language
Figure 2-5. Wizard Screen (Page 1)
See Figure 2-6. This screen will display only if the unit is
not activated. Use page 2 to activate the unit or choose to
run in MANUAL mode (
run the unit in AUTO mode (
F
Activate
Activate Me (ENTER)
or press ESC to run
012978
in manual only.
Figure 2-6. Wizard Screen (Page 2)
See Figure 2-7. This screen will display only if the unit is
not activated. Use page 3 to enter the unit serial number
and activation code. See the unit Owner's Manual to
locate the unit serial number. The activation code can be
obtained at www.activategen.com.
Activate
To activate go to
www.activategen.com
SN
Code
Figure 2-7. Wizard Screen (Page 3)
General Information
English
) only. Activation is required to
).
xxxxxxxxxx
xxxxx
012979
012980
012981
