Dealer Screen - Generac Power Systems Power Zone 410 Technical Manual

See Figure 2-25. Use page 4 to change the LCD display
brightness and contrast.
User Edit
Set LCD Brightness
Set LCD Contrast
Figure 2-25. Setting Screen (Page 4)

Dealer Screen

The Dealer Screen and sub-pages require credentials to
access and contain settings that can be modified by the
user. To modify a page setting see
ting.
See Figure 2-26. The Dealer Screen contains sub-pages
to edit settings, test, calibrate, and gateway.
Dealer Menu
Edit Settings
Test
Calibrate
Gateway
Figure 2-26. Dealer Screen
"Edit Settings" Sub-Pages
See Figure 2-27. Use page 1 to modify startup delay,
return delay, utility loss volts, and utility pickup volts.
Dealer Edit:
Startup Delay
Return Delay
Util Loss Volts
Util Pickup Volts
Figure 2-27. Edit Settings (Page 1)
Technical Manual Power Zone 410 Controller
012999
Modify a Page Set-
013000
013001
See Figure 2-28. Use page 2 to modify crank pause
time, cooldown time, warmup time, and run hours.
Dealer Edit:
Crank Pause Time
Cooldown Time
Warmup Time
Run Hours
Figure 2-28. Edit Settings (Page 2)
See Figure 2-29. Use page 3 to modify battery voltage,
reset maintenance, reset the low coolant temperature
warning, and select fuel.
Dealer Edit:
Select Batt. Voltage
Reset Maintenance
Low Coolant Temp.
Select Fuel
Figure 2-29. Edit Settings (Page 3)
See 2-30. Use page 4 to enable or disable the
Figure
theft alarm and dual fuel.
Dealer Edit:
Enable Theft Alarm
Enable Dual Fuel
Figure 2-30. Edit Settings (Page 4)
General Information
013002
013003
013004
13
