LOGICDATA DMIclassic Series Operating Manual page 21

DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 21
CODE MESSAGE
1 Firmware Error
2 Motor Over Current
3 DC Over Voltage
8 Impulse Detection Timeout
11 Speed cannot be achieved
12 Power Stage Overcurrent
13 DC Under Voltage
14 Out of Sync
15 Strain Gauge is defective
17 Error during pairing sequence
18 Parameterization or firmware of diffe-
rent Actuators in the Table System are
incompatible.
19 Too many / too few Actuators connected Connect the correct number of Actuators
REQUIRED ACTIONS
Disconnect the Power Unit from the
Mains. Then, disconnect System from the
Power Unit. Reconnect the system again,
then operate the DM System as normal.
Release all Keys and wait for 5 seconds.
Then, try again.
Release all Keys and wait for 5 seconds.
Then, try again.
Perform a Position Reset Procedure (see
System Manual)
Release all Keys and wait for 5 seconds.
Then, try again.
Release all Keys and wait for 5 seconds.
Then, try again.
Release all Keys and wait for 5 seconds.
Then, try again.
Release all Keys and wait for 5 seconds.
Then, try again.
Release all Keys and wait for 5 seconds.
Then, try again.
Contact LOGICDATA if the problem
persists. Do not operate the DM System if
components are broken.
Disconnect the Power Unit from the
Mains. Then, disconnect System from the
Power Unit. Reconnect the system again,
then operate the DM System as normal.
If this fails, perform a factory reset (see
DM System Manual).
Re-paramaterize the Actuators. Contact
LOGICDATA for further information.
(as specified in setup).
