DMICLASSIC FAMILY - OPERATING MANUAL // PAGE 18

6.2 REQUIRED COMPONENTS

1x
2x (DMIclassic B) or
3x (DMIclassic C)
Tool
Tool
INFO Screw specifications for DMIclassic B
The mounting points have a width of 4.3 mm. The Mounting Screws should hold
the Handset safely and securely in place. Exact specifications can be provided by
LOGICDATA on request.
INFO Screw Specifications for DMIclassic C
The Mounting Screws are provided by LOGICDATA with the Handset. These are 16
mm in length, with a 3 mm thread and 8 mm head diameter.

6.3 PROCESS

NOTICE
DMIclassic C handset is equipped with a sliding mechanism and should always be
mounted in the retracted position.
1. Place the Handset into the rails of the sliding plate (applicable only for DMIclassic C).
2. Position the Handset in the desired position under the table top and mark the position of the
Mounting Points. For DMIclassic C ensure that the Handset is in the retracted position and
does not protrude from the edge of the Table Top.
3. Drill the holes for the Mounting Screws into the Table Top at the marked points.
4. Use the screwdriver and Mounting Screws to attach the Handset to the Table Top at the drilled holes.
NOTICE
The required tightening torque depends on the material of the Table Top. Do not
exceed 2 Nm.

6.4 COMPLETING ASSEMBLY

After the DMIclassic Family handset is attached to the Table Top, you must connect the Cable to the Power
Hub. Refer to the manual for your chosen Power Hub for instructions.
DMIclassic Family handset
Mounting Screws
(for DMIclassic B supplied by Reseller)
Drill or Drilling Machine
Screwdriver
