Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
(+) 12V:
Red/White, pin 1
1
A3
12
White VESCM
Connector A3
(above driver's kick)
D2D Port
(+) 12V Input
(-) Ground (-) Ground
(-) AC Tach Output
(-) Hood Pin Input
(+) Ignition Input/Output
(+) Starter Output
Brake connector
(red connector at
driver kick)
12 10 9 8
14 13 11
17 16 15
7 6 5 4 3 2 1
(+) Brake:
Black/Red, pin 1
5 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key)
©2023 Directed. All rights reserved.
13 38
63
HS CAN 3 High:
1
Green,pin 16
HS CAN 3 Low:
Orange/Brown,
73
37 62
pin 17
A1
12
37
Black VESCM
Connector A1
(above driver's kick)
Hood Pin
Parking Lights:
Red/White, pin 8
CUT
6
10
8
Red Connector
(at parking
5
1
3
light switch)
(+) Parking Lights:
Gray/Yellow, pin 3
Twisted pair
(in driver kick, door harness)
HS CAN 3 Low: Orange/Brown
HS CAN 3 High: Green
13 38 63
Alternative: HS CAN 3 wires
OR
73
62
HS CAN 1 High: Tan/Black: 3
HS CAN 1 Low: Tan: 4
HS CAN 3 High: Orange/Green: 5
HS CAN 3 Low: Orange/Brown: 6
(+) Parking Light Output: Brown: 7
Parking lights Interrupt (vehicle side): Yellow: 8
Parking Lights Interrupt (conn. side): Orange/Yellow: 9
Key Wrap: Orange/Red: 10
Key Wrap: Yellow/Red: 11
Key Wrap: Brown/Red: 12
(-) PTS 2 Output: Black/White: 1
(-) PTS 1 Output: Green/Black: 2
(AC) Tach Output: Violet/White: 5
(+) Ignition Status Output: Gray/Black: 7
(-) PTS 1:
Violet, pin 3
PTS Switch
(black connector
at start/stop button)
(-) PTS 2:
Violet/Blue, pin 6
OBDII
1
Diagnostic Connector
9
HS CAN 1 Low:
Orange/Brown, pin 14
1 2 3
4 5 6
).
XKD2D65
HS CAN 1 High:
Red, pin 6
8
16
(+) 12V
TX
(-) Ground
RX
