Directed DIRECTECHS DB3 Installation Manual

Smart key for 2024 volkswagen jetta gli
Hide thumbs Also See for DIRECTECHS DB3:
Table of Contents

Advertisement

Quick Links

Download this manual
Functions compatible with the 2024 Volkswagen Jetta GLI (Smart Key)
*Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro.
* Odometer
Accessory Activation
Arm Factory Security
Brake Status (foot brake)
Disarm Factory Security
Door Lock Control
Door Locks Status
Door Unlock
Driver Priority Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Driver Door Pin
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
2024 Volkswagen Jetta GLI (Smart Key)
FOB Control
Fuel level/EV battery level
Heated Seats Activation
Ignition Activation
Ignition Status
Parking Lights Control
RAP Shut Down (Retained ACC Power)
Rear Window Defogger Activation
Remote Start Ready
Remote Start Takeover
SmartStart
Start (Crank) Activation
Tach / RPM Output
Trunk / Hatch Release
Universal RF Bypass- Key Req'd
403.VW18
v2.05

Advertisement

Table of Contents
loading

Related Manuals for Directed DIRECTECHS DB3

Summary of Contents for Directed DIRECTECHS DB3

  • Page 1 403.VW18 v2.05 2024 Volkswagen Jetta GLI (Smart Key) Functions compatible with the 2024 Volkswagen Jetta GLI (Smart Key) *Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro. * Odometer FOB Control Accessory Activation Fuel level/EV battery level Arm Factory Security Heated Seats Activation...

  • Page 2: Table Of Contents

    Contents Introduction Pre-installation and application warnings Wiring diagram Immobilizer interface with OEM immob. receiver Locating components in the vehicle Vehicle connections Module programming Connecting the module LED diagnostics and troubleshooting Soft reset Hard reset Feature programming Feature and option list Limited one year consumer warranty Quick Reference Guide (customer copy)

  • Page 3: Introduction

    This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs Mobile application for smartphones. Refer to “Connecting the module” for more information. 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 4: Pre-Installation And Application Warnings

    The tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D. [3] Immo. bypass: Refer to the "Immobilizer Interface" section for more information about key wrap. 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 5: Wiring Diagram

    PTS Switch (at parking (black connector light switch) at start/stop button) (+) Brake: (+) Parking Lights: (-) PTS 2: Black/Red, pin 1 Gray/Yellow, pin 3 Violet/Blue, pin 6 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 6: Immobilizer Interface With Oem Immob. Receiver

    Not all OEM remotes can be inserted in 556U because of their size. Make sure the key will fit, otherwise it is recommended to use a different method. 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.
  • Page 7 - Connect with OEM Immobilier Ring as shown in the above diagram. - When possible, use valet key for key wrap. if blade key is used, battery must be removed. 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 8: Locating Components In The Vehicle

    Locating components in the vehicle 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 9: Vehicle Connections

    Violet/Brown No Connection No Connection H2/10 Yellow/Black No Connection No Connection H2/11 Orange/Black No Connection No Connection H2/12 Blue/Red (-) W2W Only - Hood Output Remote Starter 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.
  • Page 10 VESCM above driver kick, black 46 pin plug, pin 14 Brown/Green Tachometer [2] Junction Connector, engine driver side front, black 14 pin plug, pin 8 Blue/White (2.0L) 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 11: Module Programming

    When the configuration is completed, the LED will turn ON solid green for 3 seconds, then turn OFF. Press the PTS one time (1x) to turn the ignition OFF. You have successfully completed the module programming sequence. 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 12: Connecting The Module

    (D2D) (10-pin) (14-pin) W2W installation If required: Connect the 10-pin and 12-pin harnesses to the module, then connect the 14-pin harness to the module. (12-pin) (10-pin) (14-pin) 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 13: Led Diagnostics And Troubleshooting

    5 times to skip this step. Flashes red x 11 BCM programming. Failed to program the BCM. Click Unlock on the OEM remote to solve the problem. Flashes red x 12 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.
  • Page 14 The smart key was not detected, which prevents the system from shutting down the vehicle. Flashes red x 3 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down. Flashes red x 4 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 15: Soft Reset

    Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the LED starts & to flash orange and red. Solid Flashes Release the programming button. The LED turns ON solid red. & Solid Release 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 16: Feature Programming

    To exit feature programming, press and hold the programming button for 3 seconds or ensure there is no activity on the interface for 30 seconds. The LED will turn ON orange for 2 seconds to confirm the end of the programming sequence. 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 17: Feature And Option List

    Temperature Level 2. Med When Heated Seats are activated, they will be set to MEDIUM. 3. Low When Heated Seats are activated, they will be set to LOW. 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 18: Limited One Year Consumer Warranty

    This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.

  • Page 19: Quick Reference Guide (Customer Copy)

    3 possible ways you can send commands to your vehicle, using the: in Park (P). • Factory remote. • Aftermarket remote. Press the Remote Start button on the transmitter.* • Directed SmartStart application via your smartphone. & Parking lights The parking lights will flash once to indicate the vehicle is Press...
  • Page 20 Notes 403.VW18 2.05 2024 Volkswagen Jetta GLI (Smart Key) ©2023 Directed. All rights reserved.
