Analog Control Board (ACB)
Figure 129 - ACB and DPM Replacement
The ACB is the hub for all control-level signals external to the drive. The drive
routes analog I/O, external fault signals (through the XIO board), DPI
communication modules, remote I/O, terminal interface, printers, modem,
and other external communication devices through this board.
Rockwell Automation Publication 7000-UM202H-EN-P - November 2023
Chapter 3
Control Component Definition and Maintenance
ANALOG
CONTROL
BOARD
Analog Control Board
(ACB)
151
