Analog Outputs
Number of outputs
Output range
Resolution
Conversion time
Load impedance
Galvanic isolation
Linearity error
Operational error limits
Notes:
10. Note that the range of each I/O is defined by wiring, jumper settings, and within the controller's software.
Graphic Display Screen
Item
LCD Type
Illumination backlight
Display resolution
Viewing area
Colors
Screen Contrast
Touchscreen
'Touch' indication
Screen brightness control
Virtual Keypad
Keypad
Item
Number of keys
Key type
Slides
20
2
0-10V, 4-20mA. See Note 10
12-bit (4096 units)
Both outputs are updated per scan
1kΩ minimum—voltage
500Ω maximum—current
None
±0.1%
±0.2%
V130-TRA22
V130J-TRA22
STN, LCD display
White LED
128x64 pixels
2.4"
Monochrome
Via software
(Store value to SI 7,
values range: 0 to 100%)
None
None
Via software
(Store value to SI 9,
0 = Off, 1 = On)
None
V130-TRA22
V130J-TRA22
20 keys,including 10
user-labeled keys
Metal dome, sealed membrane switch
Slides may be installed in
the operating panel
faceplate to custom-label
the keys. Refer to V130
Keypad Slides.pdf.
A complete set of blank
slides is available by
separate order
Vision™PLC+HMI Installation Guide
V350-TRA22
V350J-TRA22
TFT, LCD display
White LED
320x240 pixels
3.5"
65,536 (16-bit)
Fixed
Resistive, analog
Via buzzer
Via software
(Store value to SI 9, values range: 0 to 100%)
Displays virtual keyboard when the application requires
data entry.
V350-TRA22
V350J-TRA22
5 programmable function keys
Slides may be installed in
the operating panel
faceplate to custom-label
the keys. Refer to V350
Keypad Slides.pdf.
Two sets of slides are
supplied with the
controller: one set of
arrow keys, and one
blank set.
V430J-TRA22
TFT, LCD display
White LED
480x272 pixels
4.3"
65,536 (16-bit)
Fixed
Resistive, analog
Via buzzer
V430J-TRA22
None
