Vision™PLC+HMI
Order Information
Item
V130-33-TRA22
V130-J-TRA22
V350-35-TRA22
V350-J-TRA22
V430-J-TRA22
You can find additional information, such as wiring diagrams, in the product's installation guide
located in the Technical Library at www.unitronics.com.
Power Supply
Item
Input voltage
Permissible range
Max. current
consumption
npn inputs
pnp inputs
Notes:
1. To calculate the actual power consumption, subtract the current for each unused element from the maximum
current consumption value according to the values below:
V130/J
V350/J/V430J
*If the analog outputs are not configured, then subtract the higher value.
Digital Inputs
Number of inputs
Input type
Galvanic isolation
Nominal input voltage
Input Voltage
pnp (source)
npn (sink)
Input Current
Input impedance
Response Time
Input Cable length
Normal digital Input
16
PLC with Classic panel, Monochrome display 2.4"
PLC with Flat panel, Monochrome display 2.4"
PLC with Classic panel, Color touch display 3.5''
PLC with Flat panel, Color touch display 3.5''
PLC with Flat panel, Color touch display 4.3''
V130-TRA22
V130J-TRA22
24VDC
20.4VDC to 28.8VDC with less than 10% ripple
See Note 1
245mA@24VDC
200mA@24VDC
Backlight Ethernet
card
10mA 35mA
20mA 35mA
12. See note 2
See note 2
None
24VDC
Normal digital input
0-5VDC for Logic '0'
17-28.8VDC for Logic '1'
17-28.8VDC for Logic '0'
0-5VDC for Logic '1
I0, I1: 5.4mA@24VDC
I2-I11: 3.7mA@24VDC
I0, I1: 4.5KΩ
I2-I11: 6.5KΩ
10ms typical, when used as normal digital input
Up to 100 meters
Vision™PLC+HMI Installation Guide
V130-33-TRA22/V130-J-TRA22
V350-35-TRA22/V350-J-TRA22
V430-J-TRA22
Technical Specifications
V350-TRA22
V350J-TRA22
270mA@24VDC
230mA@24VDC
Relay Outputs
(per output)
5mA
5mA
High Speed Input. See Note
3
0-3VDC for Logic '0'
20.4-28.8VDC for Logic '1'
20.4-28.8VDC for Logic '0'
0-3VDC for Logic '1
V430J-TRA22
270mA@24VDC
230mA@24VDC
All Analog Outputs,
voltage/current
48mA/30mA*
48mA/30mA*
