Notes:
4. Conversion times are accumulative and depend on the total number of analog inputs configured.
For example, if only one analog input (fast mode) is configured, the conversion time will be 30ms; however,
if two analog (normal mode) and two RTD inputs are configured, the conversion time will be
100ms + 100ms + 300ms + 300ms = 800ms.
5. The analog value can indicate faults as shown below:
Value: 12-bit
-1
4096
32767
RTD Inputs
RTD Type
Temperature coefficient 
Input range
Isolation
Conversion method
Resolution
Conversion time
Input impedance
Auxillary current for PT100
Full-scale error
Linearity error
Status indication
Cable length
Notes:
6. The analog value can indicate faults as shown below:
Value Possible Cause
32767 Sensor is not connected to input, or value exceeds permissible range
-32767 Sensor is short-circuited
Thermocouple Inputs
Input range
Isolation
Conversion method
Resolution
Conversion time
Input impedance
Cold junction compensation
Cold junction compensation error
Absolute maximum rating
Full-scale error
Linearity error
Warm-up time
Status indication
18
Value: 14-bit Possible Cause
-1 Deviates slightly below the input range
16384 Deviates slightly above the input range
32767 Deviates greatly above or below the input range
PT100
0.00385/0.00392
-200 to 600C/-328 to 1100F. 1 to 320Ω.
None
Voltage to frequency
0.1C/0.1F
300ms minimum per channel. See Note 4 above
>10MΩ
150μA typical
±0.4%
±0.04%
Yes. See Note 6
Up to 50 meters, shielded
See Note 7
None
Voltage to frequency
0.1C/ 0.1F maximum
100ms minimum per channel. See Note 4 above
>10MΩ
Local, automatic
±1.5C/±2.7F maximum
±0.6VDC
±0.4%
±0.04%
½ hour typically, ±1C/±1.8F repeatability
Yes. See Note 6 above
