Vision™ OPLC™
V130-33-B1/V130-J-B1
V350-35-B1/V350-J-B1
V430-J-B1
General Description
All of the controllers covered in this guide are micro-OPLCs, rugged programmable logic controllers that
comprise built-in operating panels.
Item
Screen
Keypad
Function Keys
Com Port, Built-in
RS232/485
USB device,
mini-B
Com Ports, separate
order, user-installed
* V430J comprises both RS232/485 and USB ports; note that only one channel may be used at a time.
S tandard Kit Contents
1 B
Item
Controller
Terminal Blocks
Battery (installed)
Slides
(2 sets of key labels)
Mounting Brackets
Rubber Seal
Programming cable
+ RS232 adapter
USB
programming cable
Unitronics
Installation Guide
V130-B1
V130J-B1
2.4"
Yes
None
Yes
None
The user may install a CANbus port (V100-17-CAN), and one of the following:
•
RS232/RS485 port (V100-17-RS4/V100-17-RS4X)
•
Ethernet (V100-17-ET2)
•
Profibus Slave (V100-17-PB1)
V130-B1
V130J-B1
None
3.5" Color Touch
Yes
Yes
None
None
Yes
Yes
Yes
Yes (2 parts)
Yes
Yes
None
V350-B1
V350J-B1
None
Yes
Yes
None
V350-B1
V350J-B1
Yes
V430J-B1
4.3" Color Touch
Yes*
Yes*
V430J-B1
None
Yes (4 parts)
None
Yes
1
Advertisement
Table of Contents
Related Manuals for Unitronics Vision OPLC V130-33-B1
Summary of Contents for Unitronics Vision OPLC V130-33-B1
- Page 1 S tandard Kit Contents V130-B1 V350-B1 V430J-B1 Item V130J-B1 V350J-B1 Controller Terminal Blocks Battery (installed) Slides None None (2 sets of key labels) Mounting Brackets Yes (2 parts) Yes (4 parts) Rubber Seal Programming cable None + RS232 adapter None programming cable Unitronics...
- Page 2 All examples and diagrams are intended to aid understanding, and do not guarantee operation. Unitronics accepts no responsibility for actual use of this product based on these examples. Please dispose of this product according to local and national standards and regulations.
- Page 3 4. Tighten the bracket’s screws against the panel. Hold the bracket securely against the unit while tightening the screw. 5. When properly mounted, the controller is squarely situated in the panel cut-out as shown in the accompanying figures. V130/V350/V130J/V350J Unitronics...
- Page 4 To avoid damaging the wire, do not exceed a maximum torque of 0.5 N·m (5 kgf·cm). Do not use tin, solder, or any substance on stripped wire that might cause the wire Caution strand to break. Install at maximum distance from high-voltage cables and power equipment. Unitronics...
- Page 5 To maximize system performance, avoid electromagnetic interference by: Mounting the controller on a metal panel. Connect each common and ground connection directly to the earth ground of your system. For ground wiring uses the shortest and thickest possible wire. Unitronics...
- Page 6 To do so, remove the RS485 connector (pins 1 & 6) from the PLC and connect a standard RS232 programming cable. Note that this is possible only if DTR and DSR signals of RS232 are not used (which is the standard case). Unitronics...
- Page 7 ** Causes the unit to function as an end unit in an RS485 network USB Port The USB port is not isolated. Caution Make sure that the PC and the controller are grounded to same potential. The USB port may be used for programming, OS download, and PC access. Unitronics...
- Page 8 Vision™ OPLC™ Installation Guide Opening the Controller (V130/V350/V130J/V350J Only) Before performing these actions, touch a grounded object to discharge any electrostatic charge. Avoid touching the PCB board directly. Hold the PCB board by its connectors. 1. Turn off the power supply, disconnect, and dismount the controller. 2.
