7. The device can also measure voltage within the range of -5 to 56mV, at a resolution of 0.01mV.
The device can also measure raw value frequency at a resolution of 14-bits (16384). Input ranges are shown
in the following table:
Type Temp. Range
mV -5 to 56mV
200 to 1820˚C (300 to 3276˚F)
B
-200 to 750˚C (-328 to 1382˚F)
E
-200 to 760˚C (-328 to 1400˚F)
J
-200 to 1250˚C (-328 to 2282˚F)
K
Digital Outputs
Number of outputs
Output type
Isolation
Type of relay
Output current
(resistive load)
Rated voltage
Minimum load
Life expectancy
Response time
Contact protection
Notes:
8. Outputs 4, 5, 6, and 7 share a common signal.
Transistor Outputs
Number of outputs
Output type
Galvanic Isolation
Maximum output current
(resistive load)
Rated voltage
Maximum delay OFF to ON
Maximum delay ON to OFF
HSO freq. range with resistive
load
Maximum ON voltage drop
Short-circuit protection
Voltage range
Notes:
9. Outputs 0, 1, 2 and 3 share a common 0V signal.
The 0V signal of the output must be connected to the controller's 0V.
Unitronics
4 relay. See Note 8
SPST-NO (Form A)
By relay
Tyco PCN-124D3MHZ or compatible
3A maximum per output
8A maximum total per common
250VAC / 30VDC
1mA, 5VDC
100k operations at maximum load
10ms (typical)
External precautions required (see Increasing Contact Life Span in the
product's Installation Guide)
4 npn (sink). See Note 9
N-MOSFET, (open drain)
None
100mA per output
24VDC
1s
10s
5Hz-200kHz (at maximum load resistance of 1.5kΩ)
1VDC
None
3.5V to 28.8VDC
Type Temp. Range
-200 to 1300˚C (-328 to 2372˚F)
N
0 to 1768˚C (32 to 3214˚F)
R
0 to 1768˚C (32 to 3214˚F)
S
-200 to 400˚C (-328 to 752˚F)
T
