Unitronics Vision V130-J Series User Manual page 17

Vision™PLC+HMI
High Speed Input
High speed inputs
Frequency, HSC
Driver type
Cable length (max.)
Frequency, Shaft-encoder
Driver type
Cable length (max.)
Duty cycle
Resolution
Notes:
2. V130/V350/V130J/V350J/V430J-TRA22 models comprise a total of 12 inputs.
All 12 inputs may be used as digital inputs. They may be wired in a group via a single jumper
as either npn or pnp.
In addition, according to jumper settings and appropriate wiring:
- Inputs 5 and 6 can function as either digital or analog inputs.
- Input 0 can function as a high-speed counter, as part of a shaft-encoder,
or as normal digital inputs.
- Input 1 can function as either counter reset, normal digital input, or as part of a shaft-encoder.
- If input 0 is set as a high-speed counter (without reset), input 1 can function
as a normal digital input.
- Inputs 7-8 and 9-10 can function as digital, thermocouple, or PT100 inputs; input 11 can also serve as the
CM signal for PT100.
3. If you configure an input as high-speed, you can use an end-device that comprises push-pull drive type.
In this case, the high-speed input voltage ratings for npn/pnp apply.
Analog Inputs
Number of inputs
Input type
Input range
Input impedance
Maximum input rating
Galvanic isolation
Conversion method
Normal mode
Resolution, except 4-20mA
Resolution, at 4-20mA
Conversion time
Fast mode
Resolution, except 4-20mA
Resolution, at 4-20mA
Conversion time
Full-scale error
Linearity error
Status indication
Unitronics
Up to 50 meters, shielded, see Frequency table below
Specifications below apply when wired as HSC/shaft-encoder. See Note 2
pnp/npn
10m 95kHz maximum
25m 50kHz maximum
50m 25kHz maximum
pnp/npn
10m 35kHz maximum
25m 18kHz maximum
50m 10kHz maximum
40-60%
32-bit
2, according to wiring as described above in Note 2
Multi-range inputs: 0-10V, 0-20mA, 4-20mA
0-20mA, 4-20mA
37Ω
30mA, 1.1V
None
Voltage to frequency
14-bit (16384units)
3277 to 16383 (13107 units)
100ms minimum per channel. See Note 4
12-bit (4096 units)
819 to 4095 (3277 units)
30ms minimum per channel. See Note 4
±0.4%
±0.04%
Yes. See Note 5
Push-pull
200kHz maximum
200kHz maximum
200kHz maximum
Push-pull
100kHz maximum
100kHz maximum
100kHz maximum
0-10VDC
12.77kΩ
±15V
