Danfoss VLT AQUA Drive FC 200 Operating Instructions Manual page 93

6 How to Programme the Low Harmonic Drive
[2157] Ext. 3 Reference [Unit]
[2158] Ext. 3 Feedback [Unit]
[2159] Ext. Output [%]
[2230] No-Flow Power
[2580] Cascade Status
[2581] Pump Status
[2791] Cascade Reference
[2792] % Of Total Capacity
[2793] Cascade Option Status
0-21 Display Line 1.2 Small
Option:
[1662] * Analog input 53
6
0-22 Display Line 1.3 Small
Option:
[1614] * Motor Current
0-23 Display Line 2 Large
Option:
[1615] * Frequency
0-24 Display Line 3 Large
Option:
[1652] * Feedback [Unit]
0-37 Display Text 1
Range:
0 N/A* [0 - 0 N/A]
0-38 Display Text 2
Range:
0 N/A* [0 - 0 N/A]
92
The value of the reference for extended Closed Loop Controller 3
The value of the feedback signal for extended Closed Loop Controller 3
The value of the output from extended Closed Loop Controller 3
The calculated No Flow Power for the actual operating speed
Status for the operation of the Cascade Controller
Status for the operation of each individual pump controlled by the Cascade Controller
Reference output for use with follower drives.
Readout parameter to show the system operating point as a % capacity of total system capacity.
Readout parameter to show the status of the cascade system.
Function:
Select a variable for display in line 1, middle position.
The options are the same as those listed for par. 0-20
Function:
Select a variable for display in line 1, right position.
The options are the same as those listed for par. 0-20
Function:
Select a variable for display in line 2.
The options are the same as those listed for par. 0-20
Function:
The options are the same as those listed for par. 0-20
Select a variable for display in line 2.
Function:
In this parameter it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If to be displayed permanently select Display Text 1 in par. 0-20
Line 1.1 Small , par. 0-21 Display Line 1.2 Small , par. 0-22 Display Line 1.3 Small , par. 0-23 Display
Line 2 Large or par. 0-24 Display Line 3 Large . Use the
◀ ▶
character. Use the and buttons to move the cursor. When a character is highlighted by the
▲
cursor, it can be changed. Use the
can be inserted by placing the cursor between two characters and pressing
Function:
In this parameter it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If to be displayed permanently select Display Text 2 in par. 0-20
Line 1.1 Small , par. 0-21 Display Line 1.2 Small , par. 0-22 Display Line 1.3 Small , par. 0-23 Display
Line 2 Large or par. 0-24 Display Line 3 Large . Use the
◀ ▶
character. Use the and buttons to move the cursor. When a character is highlighted by the
cursor, this character can be changed. A character can be inserted by placing the cursor between
▲ ▼
two characters and pressing or .
®
MG.20.T1.02 - VLT is a registered Danfoss trademark
VLT AQUA Low Harmonic Drive Operating In-
Display Line 1.1 Small .
Display Line 1.1 Small .
Display Line 1.1 Small
Display Line 1.1 Small .
▲ ▼
or buttons on the LCP to change a
▼
or buttons on the LCP to change a character. A character
▲ ▼
or buttons on the LCP to change a
structions
Display
▲ ▼
or .
Display
