6 How to Programme the Low Harmonic Drive
23-00 ON Time
Array [10]
Range:
Application
[Application dependant]
dependent*
23-01 ON Action
Arra [10]
Option:
6
[0] *
Disabled
[1]
No action
[2]
Select set-up 1
[3]
Select set-up 2
[4]
Select set-up 3
[5]
Select set-up 4
[10]
Select preset ref 0
[11]
Select preset ref 1
[12]
Select preset ref 2
[13]
Select preset ref 3
[14]
Select preset ref 4
[15]
Select preset ref 5
[16]
Select preset ref 6
[17]
Select preset ref 7
[18]
Select ramp 1
[19]
Select ramp 2
[22]
Run
[23]
Run reverse
[24]
Stop
[26]
DC Brake
[27]
Coast
[32]
Set digital out A low
[33]
Set digital out B low
[34]
Set digital out C low
[35]
Set digital out D low
[36]
Set digital out E low
[37]
Set digital out F low
[38]
Set digital out A high
[39]
Set digital out B high
[40]
Set digital out C high
[41]
Set digital out D high
[42]
Set digital out E high
120
Function:
Sets the ON time for the Timed Action.
NB!
The frequency converter has no back up of the clock function and the set date/
time will reset to default (2000-01-01 00:00) after a power down unless a Real
Time Clock module with back up is installed. In par. 0-79
to program for a Warning in case clock has not been set properly, e.g. after a
power down.
Function:
Select the action during ON Time. See par. 13-52
®
MG.20.T1.02 - VLT
is a registered Danfoss trademark
VLT AQUA Low Harmonic Drive Operating In-
Clock Fault it is possible
SL Controller Action for descriptions of the options.
structions
