6.4.23 Parameter Lists - Group 27-**
Par. Parameter description
No. #
27-0* Control & Status
27-01 Pump Status
27-02 Manual Pump Control
27-03 Current Runtime Hours
27-04 Pump Total Lifetime Hours
27-1* Configuration
27-10 Cascade Controller
27-11 Number Of Drives
27-12 Number Of Pumps
27-14 Pump Capacity
27-16 Runtime Balancing
27-17 Motor Starters
27-18 Spin Time for Unused Pumps
27-19 Reset Current Runtime Hours
27-2* Bandwidth Settings
27-20 Normal Operating Range
27-21 Override Limit
27-22 Fixed Speed Only Operating Range
27-23 Staging Delay
27-24 Destaging Delay
27-25 Override Hold Time
27-27 Min Speed Destage Delay
27-3* Staging Speed
27-30 Auto Tune Staging Speeds
27-31 Stage On Speed [RPM]
27-32 Stage On Speed [Hz]
27-33 Stage Off Speed [RPM]
27-34 Stage Off Speed [Hz]
27-4* Staging Settings
27-40 Auto Tune Staging Settings
27-41 Ramp Down Delay
27-42 Ramp Up Delay
27-43 Staging Threshold
27-44 Destaging Threshold
27-45 Staging Speed [RPM]
27-46 Staging Speed [Hz]
27-47 Destaging Speed [RPM]
27-48 Destaging Speed [Hz]
Default value
[0] Ready
[0] No Operation
0 h
0 h
[0] Disabled
1 N/A
SR
100 %
[0] Balanced Priority 1
[0] Direct Online
SR
[0] Do not reset
SR
100 %
SR
15 s
15 s
10 s
SR
[1] Enabled
SR
SR
SR
SR
[0] Disabled
10.0 s
2.0 s
SR
SR
0 RPM
0.0 Hz
0 RPM
0.0 Hz
®
