6 How to Programme the Low Harmonic Drive
The Function Setup parameters are grouped in the following way:
Q3-10 Clock Settings
0-70 Set Date and Time
0-71 Date Format
0-72 Time Format
0-74 DST/Summertime
0-76 DST/Summertime Start
0-77 DST/Summertime End
Q3-20 Digital Reference
3-02 Minimum Reference
3-03 Maximum Reference
3-10 Preset Reference
5-13 Terminal 29 Digital Input
6
5-14 Terminal 32 Digital Input
5-15 Terminal 33 Digital Input
Q3-30 Feedback Settings
1-00 Configuration Mode
20-12 Reference/Feedb.Unit
3-02 Minimum Reference
3-03 Maximum Reference
6-20 Terminal 54 Low Voltage
6-21 Terminal 54 High Voltage
6-24 Terminal 54 Low Ref/Feedb Value
6-25 Terminal 54 High Ref/Feedb Value
6-00 Live Zero Timeout Time
6-01 Live Zero Timeout Function
6.1.6 Q5 Changes Made
Q5 Changes Made can be used for fault finding.
Changes made to get information about:
Select
• the last 10 changes. Use the up/down navigation keys to scroll between the last 10 changed parameters.
• the changes made since default setting.
Loggings to get information about the display line read-outs. The information is shown as graphs.
Select
Only display parameters selected in par. 0-20 and par. 0-24 can be viewed. It is possible to store up to 120 samples in the memory for later reference.
Please notice that the parameters listed in the below tables for Q5 only serve as examples as they will vary depending on the programming of the particular
frequency converter.
20-94 PID Integral Time
20-93 PID Proportional Gain
20-93 PID Proportional Gain
20-94 PID Integral Time
Analog Input 53
Analog Input 54
84
Q3-1 General Settings
Q3-11 Display Settings
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 Large
0-24 Display Line 3 Large
0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
Q3-2 Open Loop Settings
Q3-3 Closed Loop Settings
Q3-31 PID Settings
20-81 PID Normal/Inverse Control
20-82 PID Start Speed [RPM]
20-21 Setpoint 1
20-93 PID Proportional Gain
20-94 PID Integral Time
Q5-1 Last 10 Changes
Q5-2 Since Factory Setting
Q5-3 Input Assignments
MG.20.T1.02 - VLT
VLT AQUA Low Harmonic Drive Operating In-
Q3-12 Analog Output
6-50 Terminal 42 Output
6-51 Terminal 42 Output Min Scale
6-52 Terminal 42 Output Max Scale
Q3-21 Analog Reference
3-02 Minimum Reference
3-03 Maximum Reference
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-14 Terminal 53 Low Ref/Feedb. Value
6-15 Terminal 53 High Ref/Feedb. Value
®
is a registered Danfoss trademark
structions
Q3-13 Relays
Relay 1 ⇒ 5-40 Function Relay
Relay 2 ⇒ 5-40 Function Relay
Option relay 7 ⇒ 5-40 Function
Relay
Option relay 8 ⇒ 5-40 Function
Relay
Option relay 9 ⇒ 5-40 Function
Relay
