Appendix C Specifications and Associated Parts
C.1 Specifications
Parameter
Piezoelectric Output (SMC)
Voltage Output
External Input (SMA CHA, CHB)
Input Type
Input Voltage
Output Configuration
Output Pulses
I/O 1 and I/O 2 Connectors
Joystick
User I/O Connector
USB Connector Type
USB Connection Speed
Input Power Requirements
Voltage
Current
General Data
Housing Dimensions Excluding
Baseplate (W x D x H)
Weight:
Rev E June 2023
Appendix C Specifications and Associated Parts
Value
85 to 125 V DC/channel
Single Ended, Analog
-10 to 10 V ±2%
-10 V gives nominally 2kHz pulses backwards
10 V gives nominally 2 kHz pulses forwards
0 V gives zero movement
Individual Channels: Ch 1, Ch2, Ch3, Ch4
Paired Channels: Ch 1 and 2, Ch 3 and 4
Frequency: 1 Hz to 2 kHz
Voltage: Peak 85 to 125 V Adjustable
TTL Input, TTL Output, 5V Level
2-axis, Spring-loaded, Center return
Velocity Control of Selected Axis
Menu Control in Setup Mode
15 Pin DIN
5 V @ 150 mA User Supply with 0 V Return
Qty 8 Limit Switch Inputs - Multiplexed
USB 3.0
USB 1.1 Full Speed (12 Mbps)
15 VDC
121 x 60 x 47 mm (4.8 x 2.4 x 1.8 in.)
390 g
2 A
