4.4 Settings Menu

4.4.1 Overview
After the power up sequence is complete, the normal
operating screen is displayed.
Press the MENU button to enter the settings mode.
Use the joystick to scroll through the menu options
Press the MENU button to enter a particular option
Go to position count - see Section 4.4.2.
Zero the selected axis - see Section 4.4.3.
Set the move velocity- see Section 4.4.4.
Set the jog step size- see Section 4.4.5.
Set the joystick mode - see Section 4.4.6.
Teach the go to positions - see Section 4.4.7.
