6-pin 2.54mm NXP S12Z BDM Debug Adapter

This debug adapter is used to connect the iC5000 and the iC5700 BlueBox to NXP S12Z based
target featuring 6-pin 2.54mm pitch target debug connector with the S12Z BDM pinout.
The debug adapter connects to the 25cm 40-pin ribbon cable coming from the BlueBox and to
the target debug connector on the other side. Refer to the BlueBox User Manual for more details
on connecting the debug adapter.
The following pinout is valid on the target side:
Signal direction
I/O
I
I
Signal Direction is described from the BlueBox perspective.
When connecting the BlueBox to a target for the first time, double check that the debug
adapter pinout matches the Target connector. A mismatch can result in a hardware
failure.
Signal Pin
BGND 1
PDO 3
PDOCLK 5
6-pin S12Z BDM pinout
Ordering code
Pin
2
4
6
IC50141
Signal Signal direction
GND
RESET
VTref
I/O
I
