Ordering Information; Bill Of Materials - Analog Devices ADP5014-EVALZ User Manual

UG-1137

ORDERING INFORMATION

BILL OF MATERIALS

Table 3. Bill of Materials for the ADP5014-EVALZ
Qty Reference Designator
2 C1, C3
2 C2, C4
4 C5, C11, C17, C21
4 C6, C12, C18, C24
6 C7, C8, C13, C15, C19, C22
6 C9, C10, C14, C16, C20, C23
1 D1
1
2 L1, L2
2 L3, L4
6 R1, R2, R6, R9, R13, R25
1 R3
1 R4
6 R5, R10, R11, R14, R20, R29
2 R7, R8
2 R12, R17
1 R15
2 R16, R21
1 R18
3 R19, R22, R26
1 R23
1 R24
1 R27
1 R28
2 TP5, TP6
1 U1
4 J-EN1, J-EN2, J-EN3, J-EN4
13 J1, J2, J3, J4, J5, J6, J7, J8, J9, J10, S1,
S2, LK1
1
I is the saturation current of the inductor. DCR is the dc resistance of the inductor.
SAT
Description
Capacitor, 0.47 μF, 10 V, 0402
Capacitor, 47 μF, 16 V,1210
Capacitor, 10 μF, 16 V, 0603
Capacitor, 10 nF, 50 V, 0402
Capacitor, 47 μF, 10 V, 0805
Optional capacitor, 0805
Red, diffused LED, 0603, SMD
Chip inductor, 0.68 μH, I = 8.2 A, DCR = 9 mΩ
SAT
Chip inductor, 1.5 μH, I = 3.5A, DCR = 60 mΩ
SAT
Resistor, 0 Ω, 0402
Resistor, 10 Ω, 1%, 0603
Resistor, 82.5 kΩ, 1%,0402
Optional resistor, 0402
Resistor, 4.32 kΩ, 1%, 0402
Resistor, 2 kΩ, 1%, 0402
Resistor, 56.2 kΩ, 1%, 0402
Resistor, 10 kΩ, 1%, 0402
Resistor, 64.9 kΩ, 1%, 0402
Resistor, 100 kΩ, 1%, 0402
Resistor, 49.9 kΩ, 1%, 0402
Resistor, 19.6 kΩ, 1%, 0402
Resistor, 150 kΩ, 1%, 0402
Resistor, 182 kΩ, 1%, 0402
Test point, gold, 1206
Power management unit with quad synchronous
step-down regulators
Jumper, 0.1-inch header, three-way, Single Inline
Package 3 (SIP3)
Connector, 0.1-inch header, two-way, Single
Inline Package 2 (SIP2)
Rev. 0 | Page 10 of 11
ADP5014-EVALZ User Guide
Part Number/Vendor
GRM155R61A474KE15D/Murata
GRM32ER61C476KE15L/Murata
GRM188R61C106MA73D/Murata
GRM155R71H103KA/Murata
GRM21BR61A476ME15/Murata
Optional/Murata
SML-LX0603SRW-TR/Lumex
Opto/Components
744383560068/Wurth
DFE252012P-1R5M=P2/Murata
CRCW04020000Z0ED/Vishay Dale
CRCW060310R0FKEA/Vishay Dale
CRCW040282K5FKED/Vishay Dale
Optional/Vishay Dale
CRCW04024K32FKED/ Vishay Dale
CRCW04022K00FKED/ Vishay Dale
CRCW040256K2FKED/ Vishay Dale
CRCW040210K0FKED/ Vishay Dale
CRCW040264K9FKED/Vishay Dale
CRCW0402100KFKED/Vishay Dale
CRCW040249K9FKED/Vishay Dale
CRCW040219K6FKED/Vishay Dale
CRCW0402150KFKED/Vishay Dale
CRCW0402182KFKED/Vishay Dale
HK-1-G/MAC8
ADP5014ACPZ-R7/Analog Devices
M20-9990345/Harwin
M20-9990245/Harwin
