2.17.4 KIND 24: LCR Adjust Code Table

Max. Table point range is 500 - 599
Max. Added prefix digits 20.
Use the "LCR Adjust Code Table" program when it is necessary to delete some prefix
digits and/or add digits from the user-dialed number.
For example, if the user manually dial a Carrier Access Code but the carrier is not the
least cost, modification is required. For example, to delete "1806" from the beginning of
the user-dialed number and add "1807",enter"-04" field, and enter "+1807" field.
When "1806-073721153" is dialed,
The 4 digits are deleted and "1807" is added.
"1807-073721153" is dialing out.
Keyphone programming:
KIND24
LCD display
000J-04+1807.......
....................P700
LCR Adjust Code Table 100
Item Pointer Adjust code
000 P500 -04+1807
001 P501 -00+......
002 P502 -03+006..
003 P503 -00+.......
004 P504 -00+......
005 P505 -00+......
: :
: :
099 P599 -00+......

2.17.5 KIND 25: ARS Group Table

Check all carriers available to call their CO line ARS groups or STA(station) ARS groups.
Fill ARS Group to LCR for ARS Group Table in sequence.
Keyphone programming:
KIND25
LCD display
000ARS001002
003004
000J : LCR Adjust Code Table，Item 000(P500)
-04 : the 4 digits are deleted
+1807: and "1807" is added
P700 : point to LCR ARS group Table，Item 000(P700)
Next Pointer
P700
P701
P702
P003
P000
P000
: :
: :
P000
000 : ARS Group Table 0, Item 000(P700)
ARS001002003004:
Program ARS group sequence 001002003004
If all line occupied in ARS group 001 system will check
ARS group 002,003,004.
The 4 digits are deleted and 1807 is added，then point to
LCR ARS group Table，Item 000(P700)
Number don't change，direct to LCR ARS group Table，
Item 001(P701)
The prefix 3 digits are deleted and 006 is added，then
point to LCR ARS group Table，Item 002(P702)
Direct dial-out from ARS003(P003)，if it is busy that
system will give up .
System dial-out from a available CO line
82
Remark
:
:
:
:
