TAB LE OF CONTENTS 1. SYSTEM SPECIFICATIONS AND INSTALLATION ..................1 1.1 System Specifications ..........................1 1.2 Available Capacity .............................2 1.2.1 Capacity of ISDK-26 Basic KSU ......................2 1.2.2 Capacity of ISDK-26 Plus KSU ......................2 1.3 Specification of interfaces/ accessories .....................3 1.3.1 F9931 MPU Card ..........................3 1.3.2 F9858 DSP Card (For ISDK-26 Plus only) ..................3...
Page 3
1.10.3 F9858 DSP Card ..........................17 1.10.4 F0859 Four-Loops of VoIP card (IP-4) ..................18 1.10.5 F0854 4-Loops of VM Card (VM-4) .....................19 1.11 Connecting Instruction of Accessories ....................20 1.11.1 STA-SLT Converter Unit (SLT-2DA) ....................20 1.11.2 ISDK2-DISA ..........................20 1.11.3 DHU-A7 ............................21 2. PROGRAMMING GUIDE ...........................22 2.1 Programming Instruction .........................22 2.2 Set to Default Parameter/Value........................22 2.2.1 Method 1 - By the programming clear code ..................22...
Page 4
2.17.4 KIND 24: LCR Adjust Code Table ....................82 2.17.5 KIND 25: ARS Group Table ......................82 2.18 INPUT THE USER’S/CONTACT NAME ....................84 2.18.1 On ISDK-26 Basic .........................84 2.18.2 On ISDK-26 Plus ...........................84 3. RS-232 DATA FORM AND COMMAND ....................85 3.1 OUTPUT OF SIMPLE RUNNING ACCOUNT ..................85 3.1.1 Description of RS-232 form ......................85...
Page 5
3.3.2 Description for system response ......................87 3.3.3 To clear the programmed data after check-out ................87 3.3.4 Station class of service: check-out class..................87 3.4 ALARM (MORNING CALL) PROGRAM ....................87 3.4.1. Send "ALARM" command and station number to system.............87 3.4.2 Description for system response ......................88 3.4.3 To setup the alarm ..........................88 3.4.4 Description for system response ......................88 3.5 CHECK THE CURRENT TIME OF SYSTEM ..................88...
1. SYSTEM SPECIFICATIONS AND INSTALLATION 1.1 System Specifications MODEL ISDK-26 Basic ISDK-26 Plus Power Source AC 110V-240V, 50/60Hz Power Consumption (except stations) Max. DC Output Power External Back-up Battery 24V/7AH Max. Battery Charge Current 27. 6V/0.5A Max. CO + Stations 16 –...
1.2 Available Capacity 1.2.1 Capacity of ISDK-26 Basic KSU CO Line Digital Key Telephone Analog Phone Available Capacity 2/16+8x3 4/16+2+8x2 6/16+8x2 10/16+8 1. Basic Capacity: 2 CO Lines/16 Station Lines (2B+2D). 2. Each CPU including 2 CO lines and 8 Station lines that may connect with 16 pcs of digital key phones.
1.3 Specification of interfaces/ accessories 1.3.1 F9931 MPU Card Item Description Capacity 2 Loops 600 Ω Resistance of CO Line Loop Cabling Method 2 wires twist connection A. DTMF Dialing, time & signal could Line be programmed. Dialling Method B. Pulse Dialing, breaking ratio 1:2 Speed 10pps〜20pps Capacity 8 Loops...
1.3.4 F9953 Trunk Card (TRK-2) Item Description Capacity of Each Trunk Card 2 Loops 600 Ω Resistance of Loop Cabling Method 2 wires twist connection A. DTMF Dialing: dialing time & signal is programmable. Dialing Method B. Pulse Dialing: breaking ratio 1:2 Speed 10pps〜20pps Note: Each system can be installed 1pc of F9953 only.
1.3.7 F0038B Single Line Telephone Card (SLT-2) Item Description Capacity of each Card 2 Loops 600 Ω Resistance of Single Line Loop Cabling Method 2 wires twist connection Dialing Detection Way DTMF & Pulse Dialing Tip-Ring supply voltage -48V Message waiting light signal Low voltage LED On-hook transmission (for DTMF Caller ID mode) Ground-key detector...
1.3.11 ISDK2-DISA Auto-Attendant Unit Item Description Port Number 1 Port (2 channels) Voice Capacity 2064 sec External Battery DC 12V Power Consumption 90 mA, at DC 24V More than 10MΩ at DC 250V Isolation Resistance DTMF Signal LEBEL -6 dbm±1dbm Remark: Only 1 channel working when connect with 1B1D Station (STA) card.
1.3.15 Analog Doorphone Unit (DHU-A7) Item Description 600 Ω Resistance of Single Line Loop Cabling Method 2 wires twist connection to DHVR Communication Two-way, Handsfree Indicator Call Button Max. installing distance to DHVR card Dimension 90x143x35 (mm) 1.3.16 Digital Doorphone Unit (DHU-D3) Item Description 600 Ω...
1.4 Installation Instructions 1.4.1 Installation steps 1.4.1.1 Turn the AC power and back-up battery off. 1.4.1.2 Make sure the power supply is 100V to 260V or else please install the constant voltage regulator if the voltage instability or exceed the range. 1.4.1.3 F9934C is switching power card, no need to cut any Jumper;...
1.4.4.9 Far away from high frequency & noise condition. 1.3.4.10 The appropriate ground connection is recommended. 1.4.4.11 Set to default value after installation before first programming is recommended 1.4.5 After Installation Test 1.4.5.1 Turn the power on 1.4.5.2 Check LED indicator of each card/board. In working: The LED indicator keeps 1sec.
1.5 Connection Figure of ISDK-26 System Ground 2 CO connect to trunk lines F9953 Trunk Card UD-2150 Caller-ID Card -Red, Green F9802 Digital Station Card, -Yellow,Black F9953/F9803 Trunk Card, F0038/F9808C Single Line Telephone Card, F9910 STA8 (16) doorphone Card, F0854 Connect to digital Voice Mail Card, F0859 IP phones...
1.6 Connecting Instruction of MPU Card 1.6.1 F9931 MPU Card connect to 1st loop of CO line connect to 2nd loop of CO line Keyphone 1,2 Keyphone 3,4 Keyphone 5,6 Keyphone 7,8 Keyphone 9,10 Keyphone 11,12 Keyphone 13,14 Keyphone 15,16 Screw Hole of DSP card Reset...
1.6.2 Ribbon Cable Description of Ribbon connector: Description of Ribbon Cable: Copper Surface Copper Surface side of Ribbon Cable Blue side of Ribbon Cable Operating step of Ribbon connector Pull out the bar of connector Push down 2 ends of bar Flatten the bar of connector Insert the Ribbon cable Insert the cable into the connector...
1.7 Connecting Instruction of the digital station card 1.7.1 F9802 4-ports (8-channel) Digital Station Card Description: JP1, JP3 : Connect to JP3 & JP4 of MPU card or JP2 & JP4 of STA01,02 STA03,04 another expanding card by STA05,06 Ribbon cable. STA07,08 JP2, JP4 : Connect to next expanding card by Ribbon cable.
1.9 Connecting Instruction of Single Line Telephone Card 1.9.1 F0038 2-ports of Single Line Card (SLT-2) Description: P1,JP3: Connect to JP3 & JP4 of MPU card or JP2 & JP4 of next expanding card by Ribbon cable JP2,JP4 : Connect to next expanding card by Ribbon cable.
Pin4: Checking Switch (PT) of door status Electric Door lock (Open/close status) Installation of Doorphone(P3): Pin5,6: connect to P1(1,2), Please switch Uniphone Door Phone the wire as (2,1) if LED of the doorphone not light-on (polarity opposite). Pin7,8: number key 2-3 of door phone.
1.10.2 K9111C RS-232 Card RTS CTS RXD TXD Description: T1 R1 R0 T0 G NC J1: Vertical installed the card on P6 of CPU card. J2: Connect to SMDR unit, billing system or computer. Caution: Please use the isolation wire to prevent the line interference.
1.10.4 F0859 Four-Loops of VoIP card (IP-4) Description: LED3 LED4 P1 : Expanding Card F0658 (VM-4B) P4 : WAN port, LED5,10 will light-on when connecting. P8 : LAN port LED3,4 will light-on when connecting. LED10 JP1,3: Connect to JP3 & JP4 of CPU LED5 card or JP2 &...
1.10.5 F0854 4-Loops of VM Card (VM-4) Description: LED3 LED4 P1 : Expanding Card F0658 (VM-4B) P4 : WAN port, LED5,10 will light-on when connecting. P8 : LAN port LED3,4 will light-on when connecting. JP1,3: Connect to JP3 & JP4 of CPU card or JP2 &...
1.11 Connecting Instruction of Accessories 1.11.1 STA-SLT Converter Unit (SLT-2DA) INPUT OUTPUT CHANNEL SELECT DIGITAL LINE L0 L1 (L0&L1) (L1) (L2) Description: INPUT: Connected with the digital station port (2 wires) OUTPUT: Connect with the single line phone (normal phone) CHANNEL SELECT: L1- for L1 SLT;...
Standby: dim Red light Calling: bright Red light C: Screw D: Call Button E: Microphone Uniphone Wiring: P1: Connect to the pin5,6 of P3 of DHVR card. Please switch the wire as (2,1) if LED (B) of the doorphone not light-on (polarity...
2. PROGRAMMING GUIDE 2.1 Programming Instruction After finished the hardware installation, please set to default parameter/value before program the system. A. Set to default parameter/value. B. Access to system program by keyphone or PC-programming software. C. RS-232 is necessary if you want to program via PC-programming software. 2.2 Set to Default Parameter/Value 2.2.1 Method 1 - By the programming clear code Please note that this method only available on the first 15 minutes after turn the...
2.3.1 Program by Key Telephone The description of each function key when program by a key telephone PAGE TRAN SPKR REDIAL HOLD To confirm and copy this item to all the downward PAGE Copy of trunk lines or stations; It will return to the original physical location if press “page”...
2.4 SYSTEM PROGRAM : Kind 1 To program the system parameter, class of service, priority, restriction and ring of system. **PGM VER 6.XX** or setting Welcome ISDK SET password screen: Enter Kind Enter Item HOLD Number number Item Description Default Instruction 0: Null (depends on K1 item1,2,60,95) 1: Only active system auto-day/night transfer...
Kind 1 (11-25) Item Description Default Instruction 1-9999 ms To press “HOLD” key during set up the speed 11 Pause time 1000 dial number if there’s waiting time (eg. Waiting to press the extension number) on the speed dialling number. 0: 24-hour format 12 Time display format 1: 12-hour format...
Kind 1 (26-38) Item Description Default Instruction 0: Circulation (First STA – Last STA) 1: From the 1st STA 2: From the last STA 27 Route for auto-grabbing station 3. Circulation (Last STA – First STA) Related program: K2 item 73, function no.43 164-9999 ms 28 Time units of tone break bit Related program: K8, K18...
0 : Not available is not well on-hook When the station is off-hook, the warning tone will be heard for each setting interval time. For ISDK-26 Basic 0: From external source 1: From Music IC of MPU card Related program: K8...
Kind 1 (46-59) Item Description Default Instruction 10-9999 x 3.333 ms 49 The longest time of SLT flash The longest flash time when the single line telephone pressed "HOOK"/”FLASH” 0-9999 seconds The duration from dialling the prefix digit to the 50 Detecting time of trunk line dialling last digit of the telephone number.
Kind 1 (60-70) Item Description Default Instruction 0: Null (depends on K1 item1,2,60,95) 1: Only active system auto-day/night transfer (not include the station service class) 2: Only active station day/night transfer 3: Auto day/night transfer for system & station service class Relatives programs: K1 item 58,59 60 Day/Night transfer type for holiday The priority of transfer: A.
Kind 1 (91-105) Item Description Default Instruction 0:Auto-return to IDLE after active the queuing function, it will ring the queuing station as soon as the communication ended 91 Reserve/Queuing way 1:keep on waiting till the communication end and ringing directly. Application: Enable the caller to queue up a busy station instead of keeping dial the station.
Page 37
Kind 1 (106-120) Item Description Default Instruction Unmasked some prefix digits of the called 0~31 digits number while SMDR printing Application: Hotel/hostel/rental apartment that allow to select if print the complete called Masked suffix digits of the called number number. while SMDR printing 0: according to the setup of busy forwarding Incoming directive F168, the waiting time...
Kind 1 (138-167) Item Description Default Instruction Display FSK name to instead of telephone 0: No (Only display the FSK phone number) number 1: YES 0: No Dial out by PSTN line instead while IP line 1:Yes dial failed Relative program:K1 Item174 Only keep Fur Elise when setting value without Switch Music on hold of built-in DSP 0:012345...
Kind 1 (168-182) Item Description Default Instruction 0: No 171 Lighting on the button LED of UHK phone 1:Yes 0: No 173 Active SA/SB function of UHK phone 1: Yes Relative program: K2 Item197 174 PSTN Route while IP line dial failed K3 Item47 181 Auto-reboot time of DSP card 24-hour format...
2.5 STATION LINE PROGRAM : Kind 2 To program the station parameter, or individual ringing tone, class of service and functions. **PGM VER 2.20** or setting password screen: Welcome UD SET Enter Item Enter Kind HOLD number Number Item Description Default Instruction 0: in use...
Kind 2 (21-34) Item Description Default Instruction 0: "MIC" function key OFF 1: "MIC" function key ON 21 Status of manual full handsfree Related function no. 50 Only available for handsfree keyphone and K2 item 20 must to be set at “0” 0: Page/Broadcast 2: Station line 0:….
Kind 2 (35-49) Item Description Default Instruction 35 Incoming call ringing group on daytime ..… Default 16 stations Match to K2 item 33-34 36 Incoming call ringing group on nighttime ..… 00-63 scales (standard value: 40, unit: 1dB) 37 Ring volume Related function no.
0: No Allow the caller to active the MIC of 1: Yes receiver’s keyphone For Uniphone full handsfree keyphone only. Relative program: K2 Item20,120,151. 0:To recover the default (According to K2 To memorize the adjusted volume during item 103-106)
Kind 2 (66-83) Item Description Default Instruction 0: According to the class of service 1: Check Out (Lock class) 66 Check-In/ Check-Out status 2: Check In (Daytime class) Related programs: K2 item 39-41, function no. 62-63 Whether accept daytime/nighttime transfer 0: No after check-in 1: YES...
Kind 2 (84-97) Item Description Default Instruction 0: No 1: Yes Related function no. 88, 165 Accept "Hold" from the other party on Application: When the user transfers the call by intercom call holding the line but not transfer the line. It better to connect with display type phone if want to know the caller before answer the call.
Kind 2 (98-110) Item Description Default Instruction 0: mute (8) 98 The volume of key sound 7 scales (9-15) To recover the default setting of station by pressing " # " key and then "HOLD" key. 99 To recover the default setting of station ---- Application: When change the different type of keyphone or program disordered happened...
Kind 2 (111-123) Item Description Default Instruction 0-9999 x (K1 item 28) 111 Ringing time of called station's ring tone Match to program K2 item 3, 109, 112-114 112 Call to other stations, ringing source 1 The setting value refer to Appendix2 Related programs: K2 item 3, 109, 111-114 113 Call to other stations, ringing source 0 TP:0:0123456789 - >...
DSS key) For digital key phone ports only. 0: By Ring 1: By voice calls directly (for Uniphone key phone only) Application: For baby call/listening, 2-ways 128 Ring tone type of incoming call handsfree communication event. It enable to talk directly if adopting handsfree keyphone and K2 item 20 set as “1”;...
Kind 2 (132-142) Item Description Default Instruction 0-9999 ms Invalid dialing duration after the intercom 0001 Remark: The last display data will be keeping call is hung up until the setting time is over. 000: Do not implement LCR function 001-009: Select ARS group directly 100-299: Refer to K22 table 300-499: Refer to K23 table...
0: Start to communicate after pressing # or F80 156 Push-to-talk button 1: No use 0: No 157 Send the extension describer No. (IP line) 1: Yes Linemex/Uniphone system only 0: No 158 Whether to send the station billing 1: Yes 0: Null 161 Station call restriction...
Kind 2 (162-193) Item Description Default Instruction 00-99 groups Recording group of voice mail while on Application: Enable to group the stations into the recording same voice mail group, it will active the group voice mail while the station recording. Application: Enable to store the recording message on a specific station.
2.6 CO/ISDN/VoIP LINE PROGRAM: Kind 3 To program the parameter, class of service, priority, restriction and ring of trunk line. **PGM VER 6.XX** or setting Welcome ISDK SET password screen: CO line HOLD Item Kind 3 HOLD number Item Description Default Instruction 0: In use...
Kind 3 (12-21) Item Description Default Instruction 0: No (If connect CO line to another PBX) 1: Yes 12 Outward call restriction Related program: K1 item 33-38, K2 item 38-41. 0: Switch to "transfer" status (for conference call) While hunting a new CO line, hang up the 1: Auto hang up (The original line will hang up if last hunted CO line press new CO line key)
Kind 3 (22-31) Item Description Default Instruction According to flexible number plan (K6). Application: Enable the station user to grab the 22 Busy call forward on daytime ---- next designated idle CO line when the user pressed a busy CO key. This function is similar to the station call forward.
Kind 3 (32-41) Item Description Default Instruction 00-63 scales (standard value: 40, unit: 1 dB) Application: To adjust the transmission volume while active the CO-CO call forwarding Transmission volume of CO to CO call forwarding Volume Trunk P BX Trunk Adjus tment 00-63 scales (standard value: 40, unit: 1dB) Application: To adjust the transmission volume...
Kind 3 (42-55) Item Description Default Instruction 00-63 scales (standard value: 40, unit: 1dB) 44 Volume of DTMF dialling Application: If DTMF signal of CO line is too high or too low. 00-63 scales (standard value: 40,unit: 1dB) Application: If volume of incoming call is too high or too slow.
Kind 3 (56-75) Item Description Default Instruction 0/1: Detect by hardware 56 A/u Law type 2: u Law 3: A Law The system should be installed Caller-ID 57 Telephone no. of MSN (1) card (CID) 58 Telephone no. of MSN (2) Application: When the users accept some 59 Telephone no.
Kind 3 (76-97) Item Description Default Instruction Setting value: 0-16 84 The starting digit of Caller-ID It will not send the digit when the value is “16”. 0 1 2 3 4 5 6 7 8 9 *:11 #:12 A:13 B:14 C:15 D:10 Application: when the local CO incoming type 85 The ending digit of Caller-ID 1: 5...
Kind 3 (98-120) Item Description Default Instruction 0: No (call out directly without check) 1: Yes Remark: Firstly to pick the CO line and dial the Check ARS group while dialing out by number to execute LCR, the system will route to assigned CO line and also execute LCR the setting data and hang up the call if the number is on prohibited table.
Kind 3 (121-138) Item Description Default Instruction 0: Hot line 121 Day Class of VoIP trunk mode 1: Intercom only 122 Night Class of VoIP trunk mode 2-7: Match to K 1 item 33-38, function no. 15 0: Not allow 123 Whether allow to active VoIP page/broadcast 1: Allow 124 Daytime Group of IP card...
2.7 DOORPHONE PROGRAM: Kind 4 To program the parameter, class of service, priority, restriction and ring of doorphone. **PGM VER 6.XX** or setting Welcome ISDK SET password screen: Doorphone Item HOLD Kind 4 HOLD number Item Description Default Instruction 00 Usage status of doorphone 0: in use 1: Null 0: None 1: DTMF 2: Pulse 01 Dialling type...
Kind 4 (17-34) Item Description Default Instruction For 16-buttons doorphone only 23 Ringing group of 1 doorphone key Please refer to K2 item 46 0: Unlisted 1-99: Serial no 24 Sequential number of doorphone Application: If installed more than 1pc of doorphone.
Kind 4 (35-52) Item Description Default Instruction 0: No 1: Yes 35 Send warning tone of call waiting Application: To alert the on-line station there’s another incoming call waiting 0: No 36 Bill metering 1: Yes (send the simple running account) Only workable when install the RS-232 interface 00: Invalid 37 ARS Group...
Kind 4 (53-72) Item Description Default Instruction 00: Null 01-32 channel 53 Video channel of this line Application: Switch the channel of video controller when call incoming 0: CO to CO is prohibited 54 Duration for CO to CO call-forwarding 1-9999 seconds 00-99 groups Recording group of voice mail while on...
2.8 DSS PROGRAM: Kind 5 2.8.1 Connection Figure Station no. 25 Station no. 24 (DSS phone) (V005-L1) (V004-L0) physical locations of station lines Note: The master keyphone and DSS must be installed on the same station port- the master keyphone on L1 and 1 DSS on L0.
Page 68
System has reserved Installation position of 004 for 1 DSS console DSS ADR : 004 K000 : L Move cursor here and then press 2 switch to Station (shown code: L) after pressing HOLD DSS ADR : 004 L25 means station/extension no. 25 K000 : L25 K000 is for master keyphone Extension 25 is the master keyphone of this DSS console...
2.8.3 To change the collocated keyphone Application: Change a different extension to collocated with the DSS console. Notice: To modify the relatives program is necessary. or setting Kind 5 password Physical location HOLD of DSS key Original physical location of DSS console, please press HOLD twice DSS ADR : 004 when cursor is here K000 : L25...
2.9.2 To change the flexible function number: Enable the user to change/program the frequent function code. Line Type : STA12T V001 P20 when cursor is here HOLD Line Type : STA? V001 P21 when cursor is here Line Type : STA? F000_ P201 The prefix code switch to F Input the function number and then HOLD...
2.10 CALL RESTRICTION PROGRAM: Kind 7 To program the restricted dialing table to reject the incoming number or only accept the telephone number to dial-in. or setting Kind 7 HOLD password 0-5: Restricted dialing table (there are 30 sets number in each table.) Limit Table:0 6-8: Allowed dialing table (there are 30 sets number...
2.11 Tone Source / Make Break PROGRAM: Kind 8 or setting Kind 8 HOLD password T-n:00 When cursor is here press [HOLD] T-n:00 The item 00 application of the item see Appendix II (system tone source supply of physical location.) H: a-b (a: tone source of make break 1, b: tone source of make break 0) Make break 1: on / selection H: 240 channel Make break 0: off / selection –...
2.11.4 Tone source and default Item Description Default Remark 240 – 223 1111111111111110 00 Internal dialing tone Internal dialing tone with setting "Do Not 240 – 223 1110011111111110 Disturb" 240 – 241 1111000011110000 02 Dialing tone for call transfer 03 Dialing tone of LCR/ARS 247–...
Item: 33-56 Item Description Default Remark 245 – 223 1111111110000000 33 Special line call ringing tone 245 – 223 1111100000000000 34 CO call transfer ringing tone 245 – 223 1111100000000000 35 Un-discriminating ringing tone 245 – 223 1111100000000000 36 Recall ringing tone Tone time 243 –...
2.12 DSP-DISA PROGRAM: Kind 9 To program the parameter or record the greeting on built-in DISA. Please note that Kind 9 is only available to ISDK-26 Plus. Please set F128 on Kind 3 Item 10 to route incoming call through DISA. 2.12.1 Built-in DSP program or setting Kind 9...
Kind 9 (13-34) Item Description Default Instruction 0: Circulating (First operator– Last operator) 1: From the 1 operator (K2 item 73) 2: From the last operator 13 Route for calling operator 3. Circulation (Last operator – First operator) Related program: K2 item 31-32 set to 2 or 3 (operator), K2 item 73 14 Station number of fax machine Enter the station number...
Operating mode program (00-07) Description of acronym: D – Daytime; N – Nighttime; B – Lunch Break; S1 – Special event 1; S2 – Special event 2 Default Item Item name Description D N B S1 S2 Operator code 9 0-9, *, # or none Directory inquiry code 0-9, *, # or none 0: No...
Operating mode program (08-10) Default Item Item name Description D N B S1 S2 0: Play operator no-answer voice reminder first, and then hang up the line if there’s no dial-up again 1: Play operator no-answer voice reminder first, and then rings the original station Route for operator no-answer again if there’s no dial-up again 2: Play operator no-answer voice reminder...
2.Remote operating: To remote program/record/play the DISA from CO line Access Variable Password voice section CO incoming, hear the Enter Voice section default/existed greeting and then recording your greeting Press any key to stop 3: Save recording 3.Description of screen information Variable voice section 0: 2 Language (Chinese)
Page 80
Voice section Phase Description On-site Remote Hello, this is XXX Company. It’s our holiday now, 835 Special event 2 greeting please call again after we come back to our office. Sorry! The called station is busy. You can dial 836 Station on-busy announcement another extension number.
Voice section Phase Description On-site Remote Music 2 Music 3 Music 4 Music 5 Music 6 Self-recorded Music on Hold Voice section 009/929 would be the directory if 008-027 928-947 (MOH) voice section 008/928. 2.13 TONE SOURCE TIME PROGRAM: Kind 18 or setting Kind HOLD...
2.14 ACCOUNT CODE PROGRAM: Kind 11 Enable to program 400 sets 4/8 digits PIN code for account code feature. The preceding 4 digits can be printed by RS-232 simple running account. or setting Kind HOLD password Enter 4/8 digits of PIN code 0-99 sets: refer to the class of program K1 item 81.
2.15 CALLER-ID DISPLAY STATUS PROGRAM: Kind 14 or setting Kind HOLD password Group: 00-19 sets L00: 00 Identify the number length (00 means do not check) C: The prefix digit which need to be amend (available CT:00L00C……… amended number can be up to 7 digits. +………...
2.17 LCR (Least Cost Route) PROGRAM Least Cost Route is a system programmable feature that automatically selects the least cost route available at the time an outside call is made; LCR had associated with ARS (Automatic Route Selection) in the system. 5 different programming kinds for LCR table: K21:LCR Parameter Set K22:LCR Prefix Code Table...
Item Name Default Remark 05 ARS2 Hunting Mode Same as above 06 ARS3 Hunting Mode Same as above 07 ARS4 Hunting Mode Same as above 08 ARS5 Hunting Mode Same as above 09 ARS6 Hunting Mode Same as above 10 ARS7 Hunting Mode Same as above 11 ARS8 Hunting Mode Same as above...
2.17.3 KIND 23: LCR Time Table Max. Table pointer range is 300 - 349 Check all carriers available time list for fee charged. The system can select the least expensive available route and carrier at certain time. This table can set least cost time of some holiday or special day if provided from carrier. And disable to check month day when you fill "00-00"...
2.17.4 KIND 24: LCR Adjust Code Table Max. Table point range is 500 - 599 Max. Added prefix digits 20. Use the "LCR Adjust Code Table" program when it is necessary to delete some prefix digits and/or add digits from the user-dialed number. For example, if the user manually dial a Carrier Access Code but the carrier is not the least cost, modification is required.
Page 88
ARS Group Table 50 Item Pointer ARS/Group Remark If all line occupied in ARS001,search next P700 ARS001002003004 ARS002→003→004 Dial-out from ARS001, If all lines occupied in ARS001 P701 ARS001000000000 System will dial-out from normal CO line. If all line occupied in ARS009002003004, P702 ARS009002003004 System will indicate busy on screen of phone.
2.18 INPUT THE USER’S/CONTACT NAME The input method on ISDK-26 Basic and Plus are different. Input by ASCII code for ISDK-26 Basic but input from number of keyphone (same as mobile/colure phone) for ISDK-26 Plus. 1. Max. 8 characters 2. To input ***6 on keyphone (K 6 item 115), then key in the individual name 3.
3. RS-232 DATA FORM AND COMMAND 3.1 OUTPUT OF SIMPLE RUNNING ACCOUNT 3.1.1 Description of RS-232 form Refer to K1 item 52 & 53 and K3 item 20, 25 & 74 0123456789 0123456789 0123456789 0123456789 0123456789 0123456789 0123456789 0123456789 The printing form of simple running account: $TO:10/08/01 20 21 01 88673740801 0000 08:15:33 00168 00000 Description of RS-232 form:...
3. NoAnser T06 7 Sec NoAnser: No Answer T06: the 6 trunk line 7 Sec: ringing 7 second No incoming telephone number (without installed the CID card or caller didn’t send the number) 4. L20Anser T06 7 Sec NoAnser: No Answer L20: extension 20 7 Sec: ringing 7 second No incoming telephone number (without installed the CID card or caller didn’t...
3.3 CHECK-OUT (CO) PROGRAM 3.3.1 Send "CO" command and station number to system. Send “CO” command and station number with ended by 0DH, 0AH. The command will send simultaneously to RS-232 while the attendant telephone orders the “CO” command. Eg.: “CO 20" 0DH, 0AH : The Check-out station is 20. 3.3.2 Description for system response A.
3.4.2 Description for system response A. "OK SET ALARM", station No., time, 0DH, 0AH : the alarm setup is OK. B. "Over 60 minutes!", 07H, 07H, 0DH, 0AH : Minute error! Please enter 00-59 minutes. C. "Over 24 Hours!", 07H, 07H, 0DH, 0AH : Hour error! Please enter 00-23 hours. D.
4.GLOSSARY AND FEATURE PROGRAM 4.1 Glossary Abbreviated Dialing Also named Speed dialing. Absence Message Enable to display the absence reason on the caller’s digital key telephone. Account Call Let different class of users use the same station to call out by their individual password. It also able to manage the call cost more effectively if collocated with SMDR/Billing system.
Page 95
Call Pick-up Enables users in a programmed call pick-up group (e.g. call center in the same group) to answer calls for each other or a user can pick up a call at any extension by dialing a feature code or feature button.
5. Appendix 5.1 Appendix1: Incoming Directive Directive No. Application Remark F128 Built-in DISA (DSP) F168 CO/Station Common incoming directive F170 Doorphone Built-in VM/ External DISA F171 (ISDK2 –DISA/UDF2-DISA) F172 ISDN line Route to K26 (DDI) 5.2 Appendix2: List of Function number and operation code Function Operation Function...
F064-F153 Function Operation Function Operation Function Name Function Name Number Code Number Code F064 Night transfer *164 F065 F066 On-line point-out/teaching F067 F068 Morning call (DSS) F069 Display station DND status F070 F071 F072 F073 Alarm 2 F074 Alarm 3 F075 Alarm 4 F076 Alarm 5 F077 Alarm 6...
F154-F171 Function Operation Function Operation Function Name Function Name Number Code Number Code F154 F155 IP One-touch-dial/DSS Key *164 F156 IP Function number F157 IP Operation code Release the electric door lock (can’t F158 F159 use * or # key) F160 Speaker key F161 Page key F162 Transfer key...
