Uniphone ISDK-26 Basic Installation & Programming Manual page 37

Kind 1 (106-120)
Item
106
Unmasked some prefix digits of the called
107
number while SMDR printing
Masked suffix digits of the called number
108
while SMDR printing
Incoming directive F168, the waiting time
109
for busy station forwarding.
110 DTMF waiting time
111 Printing type of RS-232 simple account
112 Max. group of call park
113 Operating route of Call-Park
114 Operating route of idle call-park key
115 Send the busy tone for auto-redial
Response route of built-in Voice Mail
116
(K3 Item10=Lxx)
Assigned a forwarded station for group
117
busy forward
To print the details billing after pressing
118
the account code
119 Sent 'HELP" message to RS-232
120 Ringing time for HELP function
Description Default
0~31 digits
0
Application: Hotel/hostel/rental apartment that
allow to select if print the complete called
0
number.
0: according to the setup of busy forwarding
0 1-9999sec: active busy forwarding after the
setting time
0~9999 seconds
0: Invalid.
0
It will implement the F168 incoming directive
after the setting time is out.
0: Normal
1: Different station printing (excluding the
0 remove station features)
When one station transfers the call to another
station, it will print the call duration separately.
00 00-40 groups
0: Circulating (First CO– Last CO)
0 1: From the 1st CO line
Notice: K3 Item 106 must be set as 1
0: Invalid
0 1: CO line grabbing
2: LCR grabbing
0: No
0
1:Yes
Setting
Forward
Direct forward
0
Busy forward
Busy forward
----- Extension number
0: No
1: Yes
0 Operating: Print after pressing "page" twice.
Collocated to computer system, but do not
collide with SMDR.
0: No
1:Yes
K2.46- K22 –V009 - 9999
0
Eg.: K22, physical location: 009, 9999: HELP
Application: Emergency button
60 0-9999sec
32
Instruction
0 1
Auto- Personal Auto-
Attendant VM Attendant
Auto- Personal Auto-
Attendant VM Attendant
Personal Personal Auto-
VM VM Attendant
2 3
Personal
VM
Personal
VM
Auto-
Attendant
