EXTENDER HDMI CAT 5E/6
1.1 BENEFITS
1) The length of HDMI cable is fixed and unchangeable after it is
produced. Because the HDMI connector can only be soldered or
terminated by the professional workers in factory, the users can
not reduce or increase by themselves. However CAT-5e/6 cables
are available everywhere and be processed easily by the user or
installer.
2) Because the header of the long HDMI cable is big, using it must in
hidden method. What's more, it is not easy to bend the HDMI cable
and to pull it through the in-wall tube or tray. However, CAT-5e/6
cable has no such problems.
3) Using this Extender together with UTP cable with cross stand
inside, the transmission distance can be up to 60 meters for 1080p.
For the general HDMI cables, they must be customized when the
length is over 10 meters.
1.2 FEATURES
This HDMI Extender has many features that enable it to perform in a
superior manner. Among those features you will find:
• One pair as a full functional module, no need of setting.
• One piece of CAT-5e/6 cable can substitute HDMI cable to achieve
long distance transmission.
• Follow the standard of IEEE-568B.
• Transmission distance can be up to 50 meters for 1080p using UTP
cable with cross stand inside.
• Auto-adjustment of feedback, equalization and amplify, the user
does not need to care about the length of the cable.
• Compact size.
• Supports highest video resolution 1080p.
• Supports 165MHz/1.65Gbps per channel (4.95Gbps all channel)
bandwidth.
• Supports 8bit per channel (24bit all channel) deep color.
• Supports uncompressed 2 channel audio such as LPCM
