Power card
Motor Mains
96 97 98 91 92 93
PE
U V W L1 L2 L3
L1
L2
L3
Ground
M
Illustration 42: Cascade Controller Wiring Diagram
Danfoss A/S © 2020.01
01 02 03 04 05 06
From motor control circuitry
N
M
Control card
12 13 18 19 27 29 32
System System
start/ safety
stop interlock
M
Wiring Configuration Examples
33 20 39 42 50 53 54
Pressure
transmitter
4-20 mA,
P
24 V DC
AQ275556502253en-000101 / 130R0706| 91
55
