Danfoss VLT HVAC Drive FC 102 Operating Manual page 39

Operating Guide | VLT® HVAC Drive FC 102
1
2
3
4
L1
L2
L3
PE
5
L1
L2
L3
PE
IEC 60309
1 PLC
3 Control cables
5 Mains supply
7 Star washers
9 Motor cable (shielded)
Danfoss A/S © 2020.01
90
4
4
2 Minimum 16 mm
2
4 Minimum 200 mm (7.9 in) between control cables, motor
cables, and mains cables.
6 Bare (unpainted) surface
8 Brake cable (shielded)
10 Mains cable (unshielded)
Electrical Installation
- L C -
u
v
w
PE
(6 AWG)equalizing cable
AQ275556502253en-000101 / 130R0706| 37
6
7
10
8
9
11
12
13
14
15
16
17
18
