Operating Guide | VLT® HVAC Drive FC 102
5.9 E3h Terminal Dimensions
6X 148 (5.8)
1
90 (3.5)
50 (2.0)
0 (0.0)
1 Mains terminals
3 Motor terminals
Illustration 25:
E3h Terminal Dimensions (Front View)
50 | Danfoss A/S © 2020.01
2 Brake or regen terminals
4 Ground terminals, M8 and M10 nuts
Electrical Installation
2
256 (10.1)
3
4
33 (1.3)
AQ275556502253en-000101 / 130R0706
