Operating Guide | VLT® HVAC Drive FC 102
Table 48: Fastener Torque Ratings
Location
Mains terminals
Motor terminals
Ground terminals
Brake terminals
Load sharing terminals
Regen terminals (Enclosures E1h/E2h)
Regen terminals (Enclosures E3h/E4h)
Relay terminals
Door/panel cover
Cable entry plate
Heat sink access panel
Serial communication cover
Danfoss A/S © 2020.01
Bolt size
Torque [Nm (in-lb)]
M10/M12
19 (168)/37 (335)
M10/M12
19 (168)/37 (335)
M8/M10
9.6 (84)/19.1 (169)
M8
9.6 (84)
M10/M12
19 (168)/37 (335)
M8
9.6 (84)
M10/M12
19 (168)/37 (335)
–
0.5 (4)
M5
2.3 (20)
M5
2.3 (20)
M5
2.3 (20)
M5
2.3 (20)
AQ275556502253en-000101 / 130R0706| 157
