Wiring Diagram - Directed DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
(-) Push-to-Start: Gray or Brown, pin 12
18 17 16 15 14 13 12 11 10
36 35 34 33 32 31 30 29 28
19
Power Control Unit
(Lt. Blue conn. behind
cluster or right of steering column)
D2D Port
(-) Hood Input
(+) Starter Output
(AC) Tach Input
(-) Factory Alarm Rearm
(-) Parking Lights Output
(-) Ground
(-) Ground
(+) Accessory Output
(+) Ignition 2 Output
(+) Ignition 1 Output
(+) 12V Input
(+) 12V:
White, pin 1
1
(+) Ignition 1:
Blue, pin 1
1
2
(+) Ignition 2:
3
Green or Red, pin 2
4
(+) Accessory:
Orange, pin 4
Power Control Unit
(Green & White connectors right
of steering column
or behind the cluster)
6 403.HONDA56 3.40 2013 Acura RDX (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
(+) Starter: Gray or Orange, pin 9
B-CAN High: Pink, pin 3
9 8 7 6 5 4 3 2 1
27 26 25 24 23 22 21 20 19
B-CAN Low:
Blue, pin 2
Hood Pin
Headlight Switch
(White or Blue conn.
at headlight switch)
(-) Autolights, Orange, pin 1
6 5 4 3 2 1
12 11 10 9 8 7
(-) Parking Lights, Gray, pin 8
F-CAN High: White, pin 6
OBDII
Diagnostic 1 8
Connector
9 16
F-CAN Low: Red, pin 14
HS CAN 2 High: Tan/Black: 3
HS CAN 2 Low: Tan: 4
HS CAN 1 High: Orange/Green: 5
HS CAN 1 Low: Orange/Brown: 6
Ignition Interrupt (conn. side): Yellow: 8
Ignition Interrupt (vehicle side): Orange/Yellow: 9
(-) Push-to-Start Output: Green/Black: 2
(AC) Tach Output: Violet/White: 5
Immobilizer Data: Orange/Black: 11
Keyless Access
Control Unit
(Gray conn. right of
steering column)
Immobilizer Data:
Lt. Green, pin 28
Cut
Ignition:
Yellow, pin 32
).
XKD2D65
