Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
(For skip transponder programming, see following page.)
Ensure vehicle is in a safe location and cannot move forward during programming. For
1
vehicles equipped with a manual transmission, make sure the gearshift is in the neutral
position.
The harnesses must be connected in this exact order:
a) Connect the 14-pin.
2
b) Connect the 12-pin.
c) Connect the 10-pin.
When the LED turns ON solid red, proceed with the next step.
Disassemble the OEM FOB key to remove the battery or, if equipped, turn OFF the keyless
3
access system (main switch is found in the vehicle's glove box).
Important! Do not depress the brake pedal.
4
Place the OEM FOB key without battery next to the Push-to-Start (PTS) button and press the
PTS button twice (2) to turn the ignition ON.
5
The LED turns ON solid green for 3 seconds and shuts OFF.
6
Press the PTS button once (1) more to turn the ignition OFF.
Replace the battery and reassemble the OEM FOB key or, if equipped, turn ON the keyless
7
access system (main switch is found in the vehicle's glove box).
You have successfully completed the module programming sequence.
11
403.HONDA56 3.40 2013 Acura RDX (Smart Key)
