OWNER'S MANUAL

Operation

Maintenance

Specifications

All information in this Owner's Manual is current at the time of

publication. However, HYUNDAI reserves the right to make

changes at any time so that our policy of continual product

improvement may be carried out.

This manual applies to all models of this vehicle and includes

descriptions and explanations of optional as well as standard

equipment.

As a result, you may find material in this manual that does not

apply to your specific vehicle.

Table of Contents

Chapters

Table of Contents

Need help?

Do you have a question about the Elantra 2024 and is the answer not in the manual?

Questions and answers

Галина

May 25, 2025

Куда вставляется ключ зажигания у хендая элантры 2024года (кнопка старт/стоп)

1 comments:

Mr. Anderson

May 26, 2025

In the 2024 Hyundai Elantra with a start/stop button (smart key), there is no ignition key insertion. The engine is started by pressing the brake pedal and then pressing the Push Button Start ignition switch.

This answer is automatically generated

Summary of Contents for Hyundai Elantra 2024

Page 1 Maintenance Specifications All information in this Owner’s Manual is current at the time of publication. However, HYUNDAI reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all models of this vehicle and includes descriptions and explanations of optional as well as standard equipment.
Page 2 CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the Department of Transportation and other government agencies in your country.
Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Page 4 Introduction CALIFORNIA PROPOSITION 65 WARNING Operating, servicing and maintaining a passenger vehicle or off-highway motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 5: Table Of Contents
Table of contents Introduction Picture index Seats & safety system Instrument Cluster Convenience features Driving your vehicle Driver assistance system Emergency situations Maintenance Vehicle information, reporting safety defects, and consumer information Index...
Page 7: Introduction
1. Introduction Introduction ........................1-2 HYUNDAI Motor America....................1-3 Safety messages.......................1-4 Vehicle modifications.......................1-5...
Page 8: Introduction
Congratulations, and thank you for choosing HYUNDAI. We are pleased to welcome you to the growing number of discerning people who drive HYUNDAI. We are very proud of the advanced engineering and high quality construction of each HYUNDAI we build.
Page 9: Hyundai Motor America
HYUNDAI Motor America Copyright 2023 HYUNDAI Motor America. All rights reserved. No part of this publication may be reproduced, stored in any retrieval system or transmitted in any form or by any means without the prior written permission of HYUNDAI Motor America.
Page 10: Safety Messages
Introduction Safety messages Your safety, and the safety of others, are very important. This Owner’s Manual provides you with many safety precautions and operating procedures. This information alerts you to potential hazards that may hurt you or others, and may damage your vehicle. Safety messages found on vehicle labels and in this manual describe these hazards and what to do to avoid or reduce the risks.
Page 11: Vehicle Modifications
Your HYUNDAI should not be modified in any way. Modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of safety and emissions regulations established by the U.S.
Page 13: Picture Index
2. Picture index Exterior overview (Front view)..................2-2 Exterior overview (Rear view)..................2-3 Interior overview......................2-4 Center console overview ....................2-5 Engine compartment overview ..................2-6...
Page 14 Picture index Exterior overview (Front view) Front view OCN7010001 The actual shape may differ from the illustration. (1) Hood ........................5-48 (2) Headlight .........................9-56 (3) Tires and wheels .....................9-33 (4) Side view mirror ......................5-38 (5) Sunroof ........................5-44 (6) Front windshield wiper blades ................9-28 (7) Windows ........................5-40 (8) Front radar ........................
Page 15 Exterior overview (Rear view) Rear view OCN7010002N The actual shape may differ from the illustration. (1) Door ......................... 5-25 (2) Fuel filler door ......................5-54 (3) Rear combination light ................... 9-57 (4) Trunk ........................5-49 (5) Defroster/Glass antenna ................5-88, 5-100 (6) High mounted stop light ..................9-60 (7) Antenna .........................
Page 16 Picture index Interior overview OCN7013003N The actual shape may differ from the illustration. (1) Inside door handle ....................5-26 (2) Side view mirror control switch ................5-39 (3) Central door lock switch ..................5-25 (4) Power window switches ..................5-40 (5) Power window lock button ..................5-43 (6) Steering wheel tilt/telescopic lever ...............5-31 (7) Steering wheel ......................5-30 (8) Instrument panel illumination control switch ............4-3...
Page 17 Center console overview OCN7013012N The actual shape may differ from the illustration. (1) Instrument cluster ....................4-2 (2) Driver’s front air bag ....................3-36 (3) Engine start button ....................6-9 (4) Key ignition switch ....................6-5 (5) Infotainment system .................... 5-100 (6) Hazard warning flasher switch ................8-2 (7) Climate control system .................
Page 18 Picture index Engine compartment overview Smartstream G 2.0 Atkinson OCN7080064L Smartstream G1.6 T-GDI OCN7083001N The actual engine room in the vehicle may differ from the illustration. (1) Engine coolant reservoir ..................9-21 (2) Brake fluid reservoir ....................9-23 (3) Air cleaner .......................9-25 (4) Engine oil dipstick ....................
Page 19 3. Seats & safety system This chapter provides you with important information about how to protect yourself and your passengers. It explains how to properly use your seats and seat belts, and how your airbags work. Additionally, this chapter explains how to properly restrain infants and children in your vehicle.
Page 20 SRS care ........................3-55 Additional safety precautions................... 3-56 Airbag warning labels....................3-56...
Page 21 Important safety Driver distraction Driver distraction presents a serious and precautions potentially deadly danger, especially for inexperienced drivers. Safety should be You will find many safety precautions and the first concern when behind the wheel recommendations throughout this and drivers need to be aware of the wide section, and throughout this manual.
Page 22 Seats & safety system Never drink or take drugs and drive. Drinking alcohol or taking drugs can reduce your ability to respond to changing conditions and emergencies. Do not drink or take drugs and drive, and do not let your friends drink or take drugs and drive.
Page 23 Seats OCN7033001N The information provided may differ depending on which functions are applicable to your vehicle. (1) Forward and rearward (2) Seatback angle (3) Seat height (4) Seat cushion angle (5) Lumbar support (Driver's seat) (6) Head restraint...
Page 24 Seats & safety system Safety precautions WARNING Adjusting the seats in a safe and To reduce the risk of serious injury or comfortable position plays an important death from an inflating airbag: role for the safety of driver and • Adjust the driver’s seat as far to the rear passengers.
Page 25 Front seats Reclining seatback Sitting in a reclined position when the WARNING vehicle is moving can be dangerous. Even when buckled up, the effectiveness of the To prevent serious injury or death: restraint system (seat belts and/or • Never attempt to adjust the seat while airbags) is greatly reduced by reclining the vehicle is moving.
Page 26 Seats & safety system Seatback angle Manual seats - Seat adjustments if equipped The front seat can be adjusted by using the levers located underneath the front part of the seat or on the outer side of the seat. Forward and rearward adjustment OCN7030003 To recline the seatback: 1.
Page 27 Forward and rearward adjustment Power seats - Seat adjustment if equipped The front seat can be adjusted by using the control switches located on the outside of the seat cushion. WARNING Never allow children to remain in the vehicle unattended. The power seats are operable when the vehicle is turned off.
Page 28 Seats & safety system Seat cushion tilt (1)/Seat height (2) Lumbar support (for driver’s seat) if equipped OCN7030007 To change the angle of the front part of OCN7030008 the seat cushion: To adjust the lumbar support: 1. Push the front portion of the control 1.
Page 29 Rear seats Seatback pocket if equipped Folding the rear seat if equipped The rear seatbacks can be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING • Never allow passengers to sit on top of the folded down seatback while the vehicle is moving.
Page 30 Seats & safety system 3. Pull out the seatback folding lever WARNING located in the trunk. When returning the rear seatback from a folded to an upright position, hold the seatback and return it slowly. Lock the seatback properly. In a collision or sudden stop, an unlocked seatback may allow cargo to move forward with great force and may result in serious injury or death.
Page 31 Armrest WARNING if equipped To help reduce the risk of serious injury or death in an accident, take the following precautions when adjusting your head restraints: • Always adjust the head restraints properly for all passengers BEFORE starting the vehicle. •...
Page 32 Seats & safety system Forward and rearward adjustment Front seat head restraints if equipped OCN7030064L OCN7030009 The driver’s and front passenger’s seats are equipped with adjustable head The head restraint can be adjusted restraint for the passengers safety and forward to 3 different positions by pulling comfort.
Page 33 Removal/Reinstallation To reinstall the head restraint: Type A Type A OCN7030012 OCN7030014 Type B Type B OCN7030013 OCN7030015 To remove the head restraint: 1. Recline the seatback. 1. Recline the seatback (2) with the 2. Put the head restraint poles (2) into the seatback angle lever or switch (1).
Page 34 Seats & safety system Removal/Reinstallation Rear seat head restraint OCN7033082N OCN7030065L To remove the head restraint: The rear seats are equipped with head 1. Raise the head restraint as far as it can restraint in all the seating positions for the passenger’s safety and comfort.
Page 35 Seat warmers NOTICE To prevent damage to the seat warmers Front seat warmers and seats: if equipped • Never use a solvent such as paint Seat warmers are provided to warm the thinner, benzene, alcohol, or gasoline seats during cold weather. to clean the seats.
Page 36 • Do not use a seat belt if the webbing or hardware is damaged. Have the seat belt replaced by an authorized HYUNDAI dealer. • Do not latch the seat belt into the buckles intended for other seating positions.
Page 37 Seat belt warning light • Make sure there is nothing in the buckle that could interfere with the seat belt latch mechanism from fastening Seat belt warning securely. Instrument cluster (Driver and front passenger’s seat) • Never modify seat belt or install devices that may prevent seat belt assembly from removing slack.
Page 38 Seats & safety system Seat belt restraint system Driver's seat belt – 3-point system with emergency locking retractor WARNING To fasten your seat belt: ORS031127 OHI038140 Improperly positioned seat belts may Pull the seat belt out of the retractor and increase the risk of serious injury in an insert the metal tab (1) into the buckle (2).
Page 39 To release your seat belt: Information If you cannot smoothly pull the seat belt out from the retractor, firmly pull the seat belt out and release it. After release, the belt may be pulled out smoothly. Height adjustment Adjust the height of the shoulder belt so that it lies across your chest and midway over your shoulder nearest the door, not over your neck.
Page 40 Seats & safety system To fasten your seat belt: To release your seat belt: Pull the seat belt out of the retractor and insert the metal tab into the buckle. An audible "click" sounds when the tab locks into the buckle. Pull the shoulder portion of the belt to snug the belt across your hips and remove slack.
Page 41 • Do not place anything near the buckle. • Always replace your pretensioner after activation or an accident. • Have the pretensioner inspected, serviced, repaired, or replaced by only an authorized HYUNDAI dealer. • Do not hit seat belt assemblies. 3-23...
Page 42 SRS control module inspected by an authorized HYUNDAI dealer as soon as possible. Information • The pretensioner seat belt system may be activated in certain frontal or side collisions or rollover situations.
Page 43 Additional seat belt safety Seat belt use and children precautions Infant and small children All 50 states have Child Restraint System Seat belt use during pregnancy laws that require children to travel in The seat belt should always be used approved Child Restraint System devices, during pregnancy.
Page 44 Seats & safety system Larger children Seat belt use and injured people Children under age 13 and who are too A seat belt should still be used when an large for a booster seat should always injured person is being transported. occupy the rear seat and use the available Consult a physician for specific lap/shoulder belts.
Page 45 This should be done even if no damage is rear seat than in the front seat. Even with visible. Consult an authorized HYUNDAI airbags, children can be seriously dealer for assistance. injured or killed. Children too large for a Child Restraint System must use the seat belts provided.
Page 46 • Do not use an infant carrier or a child safety seat that "hooks" over a seatback. It may not provide adequate protection in an accident. • After an accident, have an authorized HYUNDAI dealer check the Child Restraint System, seat belts, tether anchors, and lower anchors. 3-28...
Page 47 Rearward-facing Child Restraint System Forward-facing Child Restraint System OCN7030029 OCN7030030 With a rearward-facing Child Restraint A forward-facing Child Restraint System System, the collision forces are absorbed provides restraint for the child’s body by its shell instead of the child's body. The with a harness.
Page 48 Seats & safety system Installing a Child Restraint • Secure a child in the Child Restraint System. Make sure the child is properly System strapped in the Child Restraint System according to the Child Restraint System WARNING manufacturer’s instructions. Before installing your Child Restraint CAUTION System, always read and follow the instructions provided by the...
Page 49 Child Restraint System during OCN7030033 installation. If necessary, have the vehicle LATCH anchors have been provided in the inspected by an authorized HYUNDAI left and right outboard rear seating dealer. positions. Their locations are shown in the illustration. There are no LATCH anchors...
Page 50 • Always have the LATCH system anchor. inspected by an authorized HYUNDAI Tether anchors are located on the dealer after a collision. A collision can package tray.
Page 51 Securing a Child Restraint System 3. Check the Child Restraint System is secure by pushing and pulling the seat with a lap/shoulder belt forward and back and side-to-side. WARNING WARNING Always place a rearward-facing Child Take the following precautions when Restraint System in the rear seat of the installing the top tether: vehicle.
Page 52 Seats & safety system To install a Child Restraint System on the 3. Pull the shoulder portion of the seat belt rear seats: all the way out. When the shoulder portion of the seat belt is fully 1. Place the Child Restraint System on a extended, it shifts the retractor to the rear seat and route the lap/shoulder Automatic Locking (child restraint)
Page 53 6.Push and pull on the Child Restraint System to confirm that the seat belt is holding it firmly in place. If it is not, release the seat belt and repeat Step 2 through 6. 7. Double check that the retractor is in the Automatic Locking mode by attempting to pull more of the seat belt out of the retractor.
Page 54 Seats & safety system Supplemental restraint system - airbags OCN7033060 The actual airbags in the vehicle may differ from the illustration. (1) Driver’s front airbag (2) Passenger’s front airbag (3) Front side airbag (4) Rear side airbag (5) Curtain airbag 3-36...
Page 55 Your vehicle is equipped with a Supplemental Airbag System for the driver’s seat and front passenger’s seats. The front airbags are designed to supplement the three-point seat belts. For these airbags to provide protection, seat belts must be properly worn at all times when driving. You can be severely injured or killed in an accident if you are not wearing a seat belt.
Page 56 Seats & safety system SRS components OCN7033061N The SRS consists of the following components: (1) Driver's front airbag module (2) Passenger's front airbag module (3) Side airbag modules (front) (4) Side airbag modules (rear) (5) Curtain airbag modules (6) Retractor pretensioner (front and rear) (7) Airbag warning light (8) SRS control module (SRSCM)/Rollover sensor (9) Front impact sensors...
Page 57 Where are the airbags? are fastened. These sensors provide the ability to control the SRS deployment based on whether or not the seat belts are Driver’s and passenger’s front fastened, and how severe the impact is. airbags The SRS offers the ability to control the Driver’s front airbag airbag inflation within two levels.
Page 58 • If the seat or seat cover is damaged, OCN7033084N have the vehicle serviced by an The side airbags are designed to deploy authorized HYUNDAI dealer. during certain side impact collisions, depending on the crash severity. The side airbags on both sides of the vehicle are designed to deploy when a rollover is detected by a rollover sensor.
Page 59 Curtain airbags WARNING To reduce the risk of serious injury or death from an inflating curtain airbag: • All occupants must wear seat belts at all times to help keep occupants positioned properly. • Properly secure a Child Restraint System as far away from the door as possible.
Page 60 Seats & safety system How does the airbag system • The front airbags completely inflate and deflate in an instant. It is virtually operate? impossible for you to see the airbags The SRSCM (Supplemental Restraint inflate during an accident. It is much System Control Module) continually more likely that you simply see the monitors all SRS components while the...
Page 61 Driver’s front airbag (1) WARNING To reduce the risk of serious injury or death from an inflating airbag: • Never place a child restraint in the front passenger seat. Always properly restrain children under age 13 in the rear seats of the vehicle. •...
Page 62 ODN8039080L After complete inflation, the airbag soap. immediately starts deflating, enabling the • Have an authorized HYUNDAI dealer driver to maintain forward visibility and inspect your vehicle and replace steer or operate other controls. components as required before operating your vehicle again.
Page 63 • The light stays on after illuminating for about three to six seconds. • The light comes on while the vehicle is moving. • The light blinks when the engine is running. Have an authorized HYUNDAI dealer inspect the SRS as soon as possible. 3-45...
Page 64 Seats & safety system Occupant Classification For example, if a Child Restraint System is installed on the seat, the Occupant System (OCS) Classification System can detect it and turn off the front passenger airbag. Front passenger seat adult occupants who are properly seated and wearing the seat belt properly, should not cause the passenger airbag to be automatically turned off.
Page 65 Condition and operation in the front passenger Occupant Classification System Indicator/Warning light Devices Condition detected by the "PASSENGER SRS warning Front passenger occupant classification system AIR BAG OFF" light airbag indicator light Adult Activated Infant or child restraint system Deactivated with 12 months old *3 *4 Unoccupied...
Page 66 Seats & safety system • Never sit with your hips shifted toward WARNING the front of the seat. Riding in an improper position or placing weight on the front passenger’s seat when it is unoccupied by a passenger, adversely affects the OCS. To reduce the risk of serious injury or death: •...
Page 67 • Never lean on the door or center • Do not use car seat accessories such as console or sit on one side of the front thick blankets and cushions that cover passenger seat. up the car seat surface. OLMB033104 ODH035901K •...
Page 68 AIR BAG OFF" indicator is still on, ask the OCS has been developed based on passenger to move to the rear seat. using original HYUNDAI car seats only. Altering or changing the authentic parts WARNING may result in system malfunction and increase risk of injury in a collision.
Page 69 Never use a rearward facing Child • Have all airbag repairs are conducted Restraint on a seat protected by an by an authorized HYUNDAI dealer. ACTIVE AIRBAG in front of it. It may result in death or serious injury to the CHILD.
Page 70 Seats & safety system OCN7033045N (1) SRS control module/Rollover sensor (2) Front impact sensor (3) Side impact sensors (Acceleration) (4) Side impact sensors (Pressure) 3-52...
Page 71 Airbag inflation conditions severity of impact resulting from a side impact collision. Front airbags Although the driver’s and front passenger’s airbags are designed to inflate in frontal collisions and side and curtain airbags are designed to inflate in side impact collisions, airbags may inflate in other types of collisions if the sensors detect a sufficient impact.
Page 72 Seats & safety system OCN7033052 OCN7030053 Front airbags are not designed to inflate In an angled collision, the force of impact in rear collisions, because occupants are may direct the occupants in a direction moved backward by the force of the where the airbags would not be able to impact.
Page 73 • Replace inflated airbags by an authorized HYUNDAI dealer. • If components of the airbag system must be discarded, or if the vehicle must be scrapped, observe safety precautions. Consult an authorized HYUNDAI dealer for the necessary information. 3-55...
Page 74 Impact to the doors when the ignition switch is in the ON or START position may cause the airbags to inflate. Modifications to accommodate disabilities. If you require modification to your vehicle to accommodate a disability, contact the HYUNDAI Customer Connect Center at 800-633-5151. 3-56...
Page 75: Instrument Cluster
4. Instrument Cluster Instrument cluster ......................4-2 Instrument cluster control...................4-3 Gauges and meters......................4-3 Transmission shift indicator ..................4-8 Warning and indicator lights..................4-8 Cluster display messages..................4-19 Cluster display (Type A) ....................4-23 Cluster display control....................4-23 Cluster display modes ....................4-24 User settings mode....................4-27 Trip computer......................4-35 Cluster display (Type B) ....................
Page 76: Instrument Cluster
Instrument Cluster Instrument cluster Conventional cluster (Type A) OCN7043096N Full LCD cluster (Type B) OCN7043080N The actual cluster in the vehicle may differ from the illustration. For more information, refer to the "Gauges and meters" in this chapter. (1) Tachometer (2) Speedometer (3) Engine coolant temperature gauge (4) Fuel gauge...
Page 77: Instrument Cluster Control
Instrument cluster control Gauges and meters Adjusting instrument cluster Speedometer illumination Type A OCN7043097N OCN7040081N Type B When the vehicle's parking lights or headlights are on, press the illumination control button to adjust the brightness of the instrument panel illumination. When pressing the illumination control button, the interior switch illumination intensity is also adjustable.
Page 78 Instrument Cluster Tachometer Engine coolant temperature gauge Type A Type A OCN7043102N OCN7040008 Type B Type B OCN7040007 OCN7040009 The tachometer indicates the The engine coolant temperature gauge approximate number of engine indicates the temperature of the engine revolutions per minute (RPM). coolant when the ignition switch is in the ON position.
Page 79 WARNING Information Never remove the radiator cap or engine • The fuel tank capacity is given in coolant reservoir cap when the engine is chapter 10. hot. The engine coolant is under pressure • The fuel gauge is supplemented by a and may cause burn or injury.
Page 80 Instrument Cluster Outside temperature gauge Odometer Type A Type A OCN7043109N OCN7043110N Type B Type B ODN8A049031 OCN7040015N The outside ambient temperature The odometer indicates the total distance appears in the lower portion of the cluster that the vehicle has been driven and is display.
Page 81 Range Information Type A • The range may differ from the actual driving distance because it is only an estimate as it is an estimate of the available driving distance. • The range may differ significantly based on driving conditions, driving habits, and condition of the vehicle.
Page 82: Transmission Shift Indicator
• When there is a malfunction with the SRS. If the Airbag warning light remains illuminated while driving, have the vehicle inspected by an authorized HYUNDAI dealer. Seat belt warning light OCN7040013N The transmission shift indicator in the upper corner of the cluster display indicates the current gear or P (Park).
Page 83 • Whenever there is a malfunction with brakes do not operate properly, do not the ABS. drive the vehicle. Have the vehicle The hydraulic braking system still inspected by an authorized HYUNDAI operates even if there is a malfunction dealer. with the ABS. Dual-diagonal braking system...
Page 84 Avoid high speed driving and abrupt braking. AUTO HOLD indicator light Have the vehicle inspected by an if equipped authorized HYUNDAI dealer as soon as possible. This indicator light illuminates: Information • White: When you activate Auto Hold by When the ABS warning light is on or both pressing the AUTO HOLD switch.
Page 85 If there is a malfunction with either the HYUNDAI dealer. alternator or electrical charging system: 1. Drive carefully to the nearest safe Malfunction Indicator Lamp (MIL) location and stop your vehicle.
Page 86 • If the engine is not turned OFF have the system inspected by an immediately after the Engine Oil authorized HYUNDAI dealer. Pressure warning light is illuminated, Even if this light doesn’t come on after the severe damage could occur.
Page 87 TPMS. • Forward Collision-Avoidance Assist In this occurs, have the vehicle inspected malfunction by an authorized HYUNDAI dealer as soon as possible. • Forward Collision-Avoidance Assist radar blocked (if equipped) For more information, refer to the "Tire Pressure Monitoring System (TPMS)" in •...
Page 88 AUTO STOP indicator on the cluster the ESC system. Illuminates to white. If this occurs, have the vehicle For more information, refer to the "Idle inspected by an authorized HYUNDAI Stop and Go (ISG) system" section in dealer. chapter 6. This indicator light blinks: Information While the ESC is operating.
Page 89 This indicator light blinks for a few seconds: If any of these occur, have your vehicle inspected by an authorized HYUNDAI When the smart key is not in the vehicle, dealer. you cannot start the engine. This indicator light illuminates for 2...
Page 90 LED headlight related part. • Green: When High Beam Assist is If this occurs, have the vehicle inspected operating. by an authorized HYUNDAI dealer. If your vehicle detects oncoming or NOTICE preceding vehicles, High Beam Assist system switches the high beam to low Driving with the LED Headlight warning beam automatically.
Page 91 Forward Safety is set, inspected by an authorized HYUNDAI we recommend that your vehicle be dealer. inspected by an authorized HYUNDAI This warning light blinks: dealer.
Page 92 This indicator light illuminates: HYUNDAI dealer. When you select ‘’SMART" mode as drive This indicator light blinks: mode. • Yellow: Driver Attention Warning For more information, refer to the "Drive...
Page 93: Cluster Display Messages
Push Button Start If this occurs, the Push Button Start ignition switch, have the vehicle ignition switch goes to the ACC position. inspected by an authorized HYUNDAI dealer. Low key battery (with smart key) Press START button with key (with...
Page 94 HYUNDAI dealer. OCN7040018 This warning appears if you turn off the engine when the sunroof is open. Close the sunroof securely before leaving your vehicle.
Page 95 Low tire pressure Wiper OCN7040026L This warning message appears if the tire OAD048579N pressure is low. The corresponding tire on This indicator displays which wiper speed the vehicle illuminates. is selected using the wiper control. For more information, refer to the "Tire Pressure Monitoring System (TPMS)"...
Page 96 Replace the burned out bulb with a new one with the same wattage rating. Check headlight LED if equipped This message appears if there is a problem with the LED headlight. Have the vehicle inspected by an authorized HYUNDAI dealer. 4-22...
Page 97: Cluster Display (Type A)
Cluster display (Type A) Cluster display control OCN7040023L OCN7040023 Switch Function MODE button for changing modes. MOVE switch for changing items. SELECT/RESET button for setting or resetting the selected item. Information If equipped with an infotainment system, only the Settings menu in the infotainment system is supported and not the instrument cluster.
Page 98: Cluster Display Modes
Instrument Cluster Cluster display modes Modes Symbol Explanation Trip This mode displays driving information such as the tripmeter, Computer fuel economy, etc. Turn By This mode displays the navigation guidance. Turn (TBT) This mode displays: • Smart Cruise Control (if equipped) Driving Assist •...
Page 99 Trip computer group Driving Assist group LKA/SCC OCN7043100N The trip computer mode displays OCN7043092 information related to vehicle driving Displays the state of Smart Cruise Control parameters including fuel economy, trip (if equipped) and Lane Keeping Assist. meter information, and vehicle speed. For more information, refer to the each For more information, refer to the "Trip function information in chapter 7.
Page 100 Instrument Cluster Tire Pressure Master warning group OCN7080056N OTM050218N For more information, refer to the "Tire The Master Warning Light illuminates if Pressure Monitoring System (TPMS)" one or more of the following occurs: section in chapter 8. • Forward Collision-Avoidance Assist system malfunction •...
Page 101: User Settings Mode
Shift to P to edit settings/Engage parking User settings mode brake to edit settings This warning message appears if you try to select an item from the User Settings mode while driving. Change the settings after parking the vehicle, applying the parking brake, and shifting the gear to P (Park).
Page 102 Instrument Cluster 1. Driver Assistance Items Explanation • Smart Cruise Control To set the Distance, Acceleration, Reaction Speed of Smart Cruise Control. Driving Convenience For more information, refer to the "Smart Cruise Control (SCC)" section in chapter 7. To adjust Speed Limit Assist •...
Page 103 Items Explanation • Parking Distance Warning Auto ON To activate or deactivate Parking Distance Warning Auto On. For more information, refer to the "Forward/Reverse Parking Distance Warning (PDW)" section in chapter 7. Parking Safety • Rear Cross-Traffic Safety To activate or deactivate Rear Cross-Traffic Safety. For more information, refer to the"Rear Cross-traffic Collision-Avoidance Assist (RCCA)"...
Page 104 Instrument Cluster 2. Door Items Explanation • Enable on Shift: All doors will be automatically locked if the shift lever is moved from the P (Park) position to the R (Reverse), N (Neutral), or D (Drive) position. (Only when the engine is running) Auto Lock •...
Page 105 3. Lights Items Explanation To adjust the illumination level. Illumination • Level 1-20 • Off: The one touch turn signal function will be deactivated. One Touch • 3, 5, 7 Flashes: The turn signal indicator will blink 3, 5, or 7 times when the Turn Signal turn signal lever is moved slightly.
Page 106 Instrument Cluster 5. Convenience Items Explanation Rear • To activate or deactivate the rear occupant alert system. For more information, refer to the "Rear Occupant Alert (ROA)" section in Occupant chapter 5. Alert • On door unlock: The welcome light turns on automatically when the doors are unlocked.
Page 107 Interval Information To use the service interval menu, contact an authorized HYUNDAI dealer. If the service interval is activated and the time and distance is adjusted, messages are displayed in the following situations each time the vehicle is turned on.
Page 108 Instrument Cluster 8. Other Items Explanation • Off: The average fuel economy will not reset automatically whenever refueling. • After ignition: When the engine has been OFF for 4 hours or longer the Fuel Econ. average fuel economy will reset automatically. Reset •...
Page 109: Trip Computer
Trip computer Since Refueling Information Some driving information stored in the trip computer resets if the battery is disconnected. Current Trip OCN7043112N After the vehicle has been refueled, the trip distance, total driving time and average fuel economy appear. To reset manually, press the OK button on the steering wheel for more than 1 second when "Since Refueling"...
Page 110 Instrument Cluster Digital speedometer OIK047151N Displays the speed of the vehicle. Auto Stop accumulated time ODN8A049036 Displays the elapsed time of engine stop by the Idle Stop and Go system. For more information, refer to the "Idle Stop and Go (ISG) system" section in chapter 6.
Page 111: Cluster Display (Type B)
Cluster display (Type B) Cluster display control OCN7040023L OCN7040023 Switch Operation Function MODE button for changing view modes. MOVE switch for changing items. SELECT/RESET button for setting the selected item. SELECT/RESET button for retrieving assist information or Tap and hold resetting the selected item.
Page 112: View Modes
Instrument Cluster View modes View Modes Explanation This mode displays driving information such as the trip Utility group distance, fuel economy and etc. This mode displays: • Smart Cruise Control (if equipped) Driving assist group • Lane Keeping Assist • Lane Following Assist •...
Page 113 Trip computer group • Smart Cruise Control malfunction (if equipped) • Tire Pressure Monitoring System malfunction (if equipped) If the issue is resolved, the Master Warning Light and the Master Warning icon are turned off. Tire Pressure OCN7043100N The trip computer group displays information related to vehicle driving parameters including fuel economy, tripmeter information, and vehicle speed.
Page 114 Instrument Cluster Navigation group OCN7040042N Driving information summary (2) OIK047147N The current operation conditions of Turn-by-turn navigation and Cruise Control, Smart Cruise Control and distance/time to destination appear Highway Driving Assist. when the Navigation group is selected. Warning message group Driving info.
Page 115: Vehicle Settings (Infotainment System)
Vehicle settings Setting your vehicle (infotainment system) if equipped Vehicle Settings in the infotainment system provides user options for a variety of settings including door lock/unlock features, convenience features, driver assistance settings, etc. Vehicle Settings menu • Driver Assistance OCN7043094 •...
Page 117: Convenience Features
5. Convenience features Accessing your vehicle....................5-4 Remote key........................5-4 Smart key........................5-7 Immobilizer system.....................5-14 Hyundai digital key ......................5-14 Digital key (smartphone) ....................5-14 Digital key (Card key)....................5-19 Used vehicle/digital key maintenance ..............5-24 Limitations of the system ..................5-24 Door locks ........................5-25 Operating door locks from outside the vehicle ............
Page 118 Closing the hood ....................... 5-48 Trunk ..........................5-49 Emergency trunk safety release................5-50 Smart Trunk release ....................5-51 Fuel filler door ....................... 5-54 Opening the fuel filler door..................5-54 Closing the fuel filler door ..................5-54 Exterior lights ........................ 5-56 Lighting control ......................
Page 119 5. Convenience features System operation.......................5-85 System maintenance ....................5-86 Windshield defrosting and defogging .................5-88 Manual climate control system.................5-88 Automatic climate control system................5-89 Defogging logic......................5-90 Rear window defroster ....................5-91 Auto defogging system (only for automatic climate control system) ....5-91 Climate control additional features ................5-92 Sunroof inside air recirculation.................
Page 120: Accessing Your Vehicle
Two press unlock setting Your HYUNDAI uses a remote key that is If you press the door unlock button on the used to lock or unlock the driver’s and remote key again within four seconds, passenger’s doors or the trunk.
Page 121 Using panic alarm (4) Mechanical key The horn sounds and the hazard warning if equipped lights blink for about 30 seconds if this button is pressed for more than 1 second. To stop the horn and lights, press any button on the remote key. Information The word "HOLD"...
Page 122 HYUNDAI dealer. your remote key is not working correctly, If the remote key is in close proximity to contact an authorized HYUNDAI dealer. your mobile phone, the signals could be WARNING blocked by your mobile phone’s operational signals.
Page 123: Smart Key
Smart key Locking your vehicle (1) if equipped Button type Your HYUNDAI may be equipped with a smart key that can be used to lock or unlock the doors, trunk, and start the engine. Type A OCN7050078 To lock: 1. Close all doors.
Page 124 Convenience features 3. Touch the outer part of the door handle Information on or near the handle detent for about 1 second or until you hear the door locks Before you leave your vehicle with the actuate. The chime sounds and hazard Smart Key, verify that your vehicle is warning lights blink.
Page 125 Touch sensor type Unlocking your vehicle (2) Button type OCN7050093N To unlock: OCN7050078 1. Have the smart key with you. To unlock: 2. Grab the door handle to activate the 1. Have the smart key with you. door unlock touch sensor. The chime 2.
Page 126 Convenience features Setting the Two Press Unlock feature Information You can activate or deactivate the Two • During a car wash or rain, in order to Press Unlock feature from the Settings minimize unintentional operation of the menu in the instrument cluster or touch sensor, the touch sensor may infotainment system.
Page 127 Remotely starting the vehicle (5) Starting the vehicle Some models are equipped with a Button if equipped Start ignition switch instead of a key To start the vehicle remotely: cylinder. You can leave your smart key in 1. Press the door lock button on the smart your pocket or purse when you start your key.
Page 128 HYUNDAI dealer or tow the vehicle, if necessary. Smart key precautions The smart key may not work if any of the following occur: •...
Page 129 If you suspect your smart key might have NOTICE sustained some damage, or you feel your smart key is not working correctly, • Keep the smart key away from contact an authorized HYUNDAI dealer. electromagnetic materials that may block electromagnetic waves to the key WARNING surface.
Page 130: Immobilizer System
NOTICE 2. After selecting Digital Key > Set Up Avoid exposing the key to moisture, static Digital Key from the My Hyundai App in electricity, and rough handling. The the smartphone, register the digital key Immobilizer system may malfunction.
Page 131 Connections > NFC and contactless 2C_AVNRegisterSmartPhone payments. If you cannot register the digital key (smartphone) with the My Hyundai app, try registering from the infotainment system. 1. Turn off the vehicle, and then turn on the vehicle with a smart key and have your smart key with you in the vehicle.
Page 132 An active Digital charging pad). Key can be shared through the My Samsung smartphone Hyundai app with a different smartphone. • During the digital key saving process, the process may cancel when: - The smartphone is removed from the...
Page 133 • Touch the Door handle NFC Antenna Information position with the back of your smartphone. (In case of Apple WATCH, If a shared digital key (smartphone) is the watch face must be on the pad). used for the first time, the activating time may take longer.
Page 134 Convenience features Deleting all registered digital key Information (smartphone) • If the registered digital key (smartphone) is deleted, the digital key saved in the smartphone is also deleted. • If the digital key is deleted from the smartphone, the digital key (smartphone) registered in the vehicle is also deleted.
Page 135: Digital Key (Card Key)
Digital key (Card key) Information • Only one digital key (card key) can be How to register digital key (Card registered to the vehicle. If it must be Key) replaced, delete the existing card key To use the card key as a digital key, follow before registering the new card key.
Page 136 Convenience features NOTICE Information You cannot lock your vehicle using the • The digital key (card key) may not work digital key (card key) if any of the under the following conditions: following occurs: - The digital key (card key) is not •...
Page 137 How to unlink user profile Deleting your digital key (card key) Select Setup > User Profile > Profile Settings, and then deselect "Link Digital Key (Smartphone)" from Settings menu in the infotainment system. • Unlinking is possible only when user profile is linked.
Page 138 Convenience features Vehicle personalization operation • The personalization function linked with digital key works when the profile linked smartphone is placed on the outside door handle authentication pad to lock or unlock the doors. • The profile set by the digital key can be changed manually from the infotainment system.
Page 139 Vehicle personalization with digital key The available personalization function in the vehicle is as follows: System Personalization Item Lamp Blink number of one-touch signal lamps Information display on the cluster, Voice volume, Cluster Welcome sound Infotainment system vehicle Seat Seat position settings Door Automatic door lock/unlock, Two Press Unlock...
Page 140: Used Vehicle/Digital Key Maintenance
Convenience features Used vehicle/digital key Limitations of the system maintenance • HYUNDAI Digital Key app on the smartphone and card key may not work Purchasing used vehicle - Smartphone battery or the vehicle If any of the digital key devices battery is discharged.
Page 141: Door Locks
Door locks NOTICE • When removing the key cylinder cover, Operating door locks from avoid scratching or breaking the plastic material. outside the vehicle • If the key cylinder cover freezes and cannot be removed easily, lightly tap on Using the mechanical key the cover or try to warm the cover by placing your hands around it and blowing warm air on it.
Page 142: Operating Door Unlocks From Inside The Vehicle
Convenience features Operating door unlocks from With the central door lock/unlock switch inside the vehicle Driver’s door With the door inside handle OCN7050011 Front passenger’s door OCN7050010 Driver door & Passenger door If the inner door handle is pulled when the door is locked, the door is unlocked and opened.
Page 143 In case of an emergency WARNING Do not leave the elderly, children, or animals unattended in your vehicle. An enclosed vehicle can become extremely hot and the elderly, unattended children or animals who cannot escape the vehicle may be seriously injured or killed. WARNING Always park your vehicle properly.
Page 144: Auto Door Lock/Unlock Features
Convenience features Auto door lock/unlock Child-protector rear door features locks Impact sensing door unlock system All doors are automatically unlocked when an impact causes the airbags to deploy. Speed sensing door lock system if equipped All doors will be automatically locked when vehicle speed exceeds 9 mph (15 OCN7053129 km/h).
Page 145: Theft-Alarm System
Theft-alarm system Information This system helps protect your vehicle • Do not lock the doors until all and valuables. The horn sounds and the passengers have left the vehicle. If a hazard warning lights blinks continuously door is opened after the system is if any of the following occur: armed, the alarm is activated.
Page 146: Rear Occupant Alert (Roa)
"Check motor driven power steering" illuminate on the instrument cluster, you can continue to steer the vehicle, but it requires increased effort. Contact an authorized HYUNDAI dealer and have the system inspected as soon as possible. OCN7050135L WARNING Information...
Page 147: Tilt/Telescopic Steering
Have the Horn system inspected by an authorized HYUNDAI dealer as soon as possible. Tilt/telescopic steering Adjust the steering wheel toward your chest, not toward your face. Make sure you can see the instrument cluster warning lights and gauges.
Page 148: Mirrors
Convenience features Mirrors Day/night rearview mirror if equipped Inside rearview mirror Before driving your vehicle, check to see that your inside rearview mirror is properly positioned. Adjust the rearview mirror so that the view through the rear window is properly centered. WARNING Make sure your line of sight is not obstructed.
Page 149 Automatic-Dimming Night Vision Safety™ Electrochromic mirror (ECM) with (NVS®) Mirror HomeLink® system if equipped if equipped The NVS® Mirror automatically helps reduce glare by monitoring light levels in the front and the rear of the vehicle. Any object that obstructs either light sensor will degrade the automatic dimming control feature.
Page 150 Convenience features Programing WARNING To program most devices, follow these Before programing HomeLink® to a instructions: garage door opener or gate operator, make sure people and objects are out of the way of the device to prevent potential harm or damage. Do not use the HomeLink®...
Page 151 5. However, the indicator (4) flashes in HomeLink® should now activate your Green continuously, but if the garage rolling code equipped device. door opener does not operate, please Gate operator & Canadian programing continue to follow the step 6 and 7 During programing, your handheld ("Rolling Code Programing"...
Page 152 Convenience features Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following three conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired OCN7050087N operation.
Page 153 4. Once the garage door is stopped, press and release the "Learn" or "Smart" button on the Garage door opener within 1 minute from the time of pressing the programed HomeLink button on mirror. OCN7050089N 2. The indicator (4) and (5) operates as below: •...
Page 154: Side View Mirrors
Convenience features Side view mirrors Recalling Garage Door Status Homelink mirror with two way communication provides a way to view the last stored message from the garage door opener. In order to recall the last known status of the last activated device, press the buttons "1 and 2"...
Page 155 Folding the side view mirrors NOTICE • Do not scrape ice off the mirror face; this may damage the surface of the glass. • If the mirror is jammed with ice, do not adjust the mirror by force. Use an approved de-icer (not radiator antifreeze) spray, or a sponge or soft cloth with very warm water, or move...
Page 156: Windows
Convenience features Windows OCN7N050002N (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window (7) Power window lock button 5-40...
Page 157: Power Windows
If the power windows do not operate properly after resetting, contact an To close: authorized HYUNDAI dealer. Pull the window switch up to the first detent position (5). Release the window switch when you want the window to stop.
Page 158 Convenience features Automatic reversal Information if equipped The automatic reverse feature is active only when the "Auto Up" feature is used by fully pulling up the switch to the second detent. NOTICE Do not install any accessories on the windows. The automatic reverse feature may not operate.
Page 159 Power window lock button NOTICE • To prevent possible damage to the power window system, do not open or close two windows or more at the same time. This also ensures the longevity of the fuse. • Never try to operate the main switch on the driver’s door and the individual door window switch in opposite directions at the same time.
Page 160: Sunroof
Convenience features Sunroof Sunshade if equipped If your vehicle is equipped with a sunroof, you can slide or tilt your sunroof with the sunroof switch located on the overhead console. OCN7050029 Use the sunshade to block direct sunlight coming through the sunroof glass. Open or close the sunshade by hand.
Page 161: Tilt Open/Close
Tilt open/close Slide open/close OCN7051144 OCN7N051031 (1) Tilt open • Push the sunroof switch rearward. The sunroof glass slides open. If the (2) Tilt close sunshade is closed, the sunshade • Push the sunroof switch up to tilt the opens first and then the sunroof glass sunroof glass open.
Page 162: Automatic Reversal
Convenience features Automatic reversal NOTICE if equipped • Do not continue to push the sunroof switch after the sunroof is fully opened, closed, or tilted. Damage to the sunroof motor may occur or may cause the motor or sunroof system to malfunction.
Page 163: Resetting The Sunroof
Resetting the sunroof Sunroof open warning if equipped OCN7053032N To reset the Sunroof: OCN7040018 If the driver turns off the engine when the 1. Start the vehicle in P (Park). sunroof is not fully closed, the warning 2. Make sure the sunroof glass are in the chime sounds for several seconds and the fully closed position.
Page 164: Hood
Convenience features Hood Opening the hood 1. Park the vehicle and apply the parking brake. 2. Pull the release lever to unlatch the hood. The hood pops open slightly. OCN7050035 WARNING • Grasp the hood support rod in the area wrapped in rubber when the engine is hot to protect you from burn or injury.
Page 165: Trunk
Trunk WARNING • Before closing the hood, ensure all Opening the trunk obstructions are removed from around the hood opening. 1. Make sure the shift lever is in P (Park) • Always double check to make sure that and set the parking brake. the hood is firmly latched before driving 2.
Page 166: Emergency Trunk Safety Release
Convenience features 3. Lift the trunk lid up. WARNING • You and your passengers must be Closing the trunk aware of the location of the Emergency Lower the trunk lid and press down until it Trunk Safety Release lever in this locks.
Page 167: Smart Trunk Release
Smart Trunk release 1. Setting To activate the Smart Trunk release, go if equipped to User Settings Mode and select Smart Trunk on the cluster display. For more information, refer to the "Cluster display (Type A)" section in chapter 4. If your vehicle is equipped with additional navigation, please refer to the infotainment system manual separately supplied.
Page 168 Convenience features How to deactivate the Smart Trunk release function using the smart key Type A OCN7053041 3. Automatic opening The hazard warning lights will blink and OCN7053005 chime will sound 6 times and then the Type B trunk will open. WARNING •...
Page 169 Detecting area Information • If you press the door unlock button (2), the Smart Trunk release function will be deactivated temporarily. But, if you do not open any door for 30 seconds, the smart trunk function will be activated again. •...
Page 170: Fuel Filler Door
Convenience features Fuel filler door Information If the fuel filler door does not open Opening the fuel filler door because ice has formed around it, tap lightly or push on the door to break the ice and release the door. Do not pry on the door.
Page 171 • If the cap needs to be replaced, only ignite fuel vapors causing a fire. use a genuine HYUNDAI cap or the fuel • When using an approved portable fuel system or emission control system may container, be sure to place the malfunction.
Page 172: Exterior Lights
Convenience features Exterior lights AUTO headlight Lighting control To operate the lights, turn the knob at the end of the control lever to one of the following positions: OCN7050055 The headlights and parking lights are turned ON or OFF automatically depending on the amount of daylight as measured by the ambient light sensor (1) in front of the instrument panel.
Page 173: High Beam Operation
High beam operation Parking light ( ) ODN8A059202 ODN8A059205 The parking light, license plate light, and To turn on the high beam headlight, push instrument panel light are turned ON. the lever away from you. The lever returns to its original position. The high beam indicator illuminates when Headlight ( ) the headlight high beams are switched...
Page 174: Turn Signals And Lane Change Signals
Convenience features Turn signals and lane change Information signals • For more information on the cluster type Settings menu, refer to the "Cluster display (Type A)" section in chapter 4. • The infotainment system may change after software updates. For more information, refer to the user’s manual provided in the infotainment system and the quick reference guide.
Page 175: Interior Lights
Interior lights Select: • User Settings > Lights > Headlight Delay (for instrument cluster type) WARNING • Settings > Vehicle > Lights > Headlight Do not use the interior lights when driving Delay (for infotainment system type) in the dark. The interior lights may obscure your view and result in a collision.
Page 176: Mood Lamp
Convenience features Rear room lamp Door lamp ( ): The front or rear room lamps come on when the front or rear doors are opened. When doors are unlocked by the remote key or smart key, the front and rear lamps come on for about 30 seconds as long as any door is not opened.
Page 177: Luggage Compartment Lamp
Welcome system Luggage compartment lamp if equipped OCN7053059 The luggage compartment lamp comes OCN7053054 on when the trunk is opened and off when Welcome system helps keep the driver the trunk is closed. visible by turning on vehicle lights when the driver approaches the vehicle.
Page 178: Headlight And Parking Light
Convenience features High Beam Assist (HBA) Headlight and parking light When the headlight switch is in the headlight or AUTO position and all doors (and trunk) are locked and closed, the parking lights and headlights come on for 15 seconds when the door unlock button is pressed on the remote key or smart key.
Page 179: High Beam Assist Operation
High Beam Assist turns off. OIG059097L When High Beam Assist is not working properly, the "Check High Beam Assist (HBA) system" warning message may appear, and the warning light may illuminate on the instrument cluster. Contact an authorized HYUNDAI dealer. 5-63...
Page 180 Convenience features Limitations of High Beam Assist Information High Beam Assist may not work properly For more information on the limitations of in the following situations if: the front view camera, refer to the • The headlights from an oncoming or "Forward Collision Avoidance Assist (FCA) front vehicle is damaged or out of the (Sensor fusion)"...
Page 181: Wipers And Washers
Wipers and washers Windshield wipers Operates as follows when the ignition switch is turned ON. MIST: For a single wiping cycle, move the lever up (MIST) and release it. The wipers operate continuously if the lever is held in this position. OFF: Wipers are not in operation.
Page 182: Front Windshield Washers
Convenience features Front windshield washers WARNING When the outside temperature is below freezing, always warm the windshield using the defroster to prevent the washer fluid from freezing on the windshield and obscuring your vision that could lead to a collision resulting in serious injury or death.
Page 183: Manual Climate Control System
Manual climate control system if equipped Type A OCN7050100N Type B OCN7050101N (1) Fan speed control knob (2) Temperature control knob (3) Mode selection knob (4) Front windshield defroster position (5) Rear window/side view mirror defroster (if equipped) button (6) Air intake control button (7) A/C (Air conditioning) button 5-67...
Page 184: Heating And Air Conditioning
Convenience features Heating and air conditioning 1. Start the engine. 2. Set the mode to the desired position. To improve the effectiveness of heating and cooling, select: • Heating: • Cooling: 3. Set the temperature control to the desired position. 4.
Page 185 Mode selection OCN7050134N 5-69...
Page 186 Convenience features Floor & Defrost (A, C, D, E) Most of the air flow is directed to the floor and the windshield with a small amount directed to the side window defrosters. Defrost-Level (A, D) Most of the air flow is directed to the OCN7050102 windshield with a small amount of air The mode selection knob controls the...
Page 187 Instrument panel vents Air intake control Type A OCN7050106 OCN7050107 The instrument panel vent air flow can be Type B directed up/down or left/right using the vent adjustment lever. To close the vent, push the air vent lever in the opposite direction of the passenger.
Page 188 Convenience features Outside (fresh) air position WARNING Type A To prevent serious injury or death: • Continued climate control system operation in the recirculated air position may allow humidity to increase WCN7-503 inside the vehicle that could fog the Type B windshield and the side windows and obscure visibility.
Page 189: System Operation
Air conditioning (A/C) Heating 1. Select the Floor Level mode. if equipped 2. Set the air intake control to the outside (fresh) air position. 3. Set the temperature control to the desired position. 4. Set the fan speed control to the desired speed.
Page 190 Convenience features Air conditioning system operation tips Air conditioning 1. Start the engine. Press the air • If the vehicle has been parked in direct conditioning button. sunlight during hot weather, open the windows for a short time to let the hot 2.
Page 191: System Maintenance
SAE Standard J2842. • When the air flow rate suddenly decreases, have the system inspected by an authorized HYUNDAI dealer. WARNING Checking the amount of air conditioner refrigerant and compressor lubricant If the amount of refrigerant is too low or too high, the performance of the air conditioning is reduced.
Page 192 Convenience features Air conditioning refrigerant label OCN7053060 You can find out which air conditioning refrigerant is applied to your vehicle on the label located inside of the hood. Example OHYK059001 Each symbols and specification on the air conditioning refrigerant label is represented as the following: 1.
Page 193: Automatic Climate Control System
Automatic climate control system if equipped OCN7050110L (1) Driver’s temperature control knob (2) Passenger’s temperature control knob (3) AUTO (automatic control) button (4) SYNC button (5) OFF button (6) Front windshield defroster button (7) Air conditioning button (8) Air intake control button (9) Rear window/side view mirror (if equipped) defroster button (10)Fan speed control button (11) Mode selection button...
Page 194: Automatic Heating And Air Conditioning
Convenience features Automatic heating and air 2. Turn the temperature control knob to set the desired temperature. If the conditioning temperature is set to the lowest setting The Automatic Climate Control System is (Lo), the air conditioning system controlled by setting the desired operates continuously.
Page 195: Manual Heating And Air Conditioning
Manual heating and air conditioning The heating and cooling system can be controlled manually by pushing buttons other than the AUTO button. In this case, the system works sequentially according to the order of buttons selected. When pressing any button except the AUTO button while using automatic operation, the functions not selected is controlled automatically.
Page 196: Convenience Features
Convenience features Mode selection OCN7050103N 5-80...
Page 197 Floor & Defrost (A, C, D, E) Most of the air flow is directed to the floor and the windshield with a small amount directed to the side window defrosters. Defrost-Level (A, D) OCN7050115 The mode selection button controls the direction of the air flow through the ventilation system.
Page 198 Convenience features Adjusting the temperature equally Temperature control Driver’s seat OCN7050117 OCN7050114_1 • Press the SYNC button (indicator light Passenger’s seat ON) to adjust the driver and passenger side temperature equally. • Turn the driver side temperature control knob. The driver and passenger side temperature is adjusted equally.
Page 199 Temperature conversion Air intake control If the battery has been discharged or Recirculated air position disconnected, the temperature mode display is reset to Celsius. To change the temperature unit from °C to °F or °F to °C: • Automatic climate control system With the recirculated air position Press the AUTO button for 3 seconds selected, air from the passenger...
Page 200 Convenience features Air conditioning WARNING To prevent serious injury or death: • Continued climate control system operation in the recirculated air position may allow humidity to increase inside the vehicle that could fog the windshield and the side windows and obscure visibility.
Page 201: System Operation
2. Set the air intake control to the outside (fresh) air position. Air conditioning 3. Set the temperature control to the HYUNDAI Air Conditioning Systems are desired position. filled with R-1234yf refrigerant. 4. Set the fan speed control to the desired 1.
Page 202: System Maintenance
• When the air flow rate suddenly vehicle by operating the air decreases, have the system inspected conditioning system with the windows by an authorized HYUNDAI dealer. and sunroof closed. • During air conditioning system operation, you may occasionally notice...
Page 203 Air conditioning refrigerant label NOTICE • The refrigerant system should only be serviced by trained and certified technicians in a well-ventilated area to ensure proper and safe operation. • Never repair the air conditioning evaporator (cooling coil) or replace with the one removed from a used or salvaged vehicle.
Page 204: Windshield Defrosting And Defogging
Convenience features Windshield defrosting Manual climate control system and defogging To defog inside windshield WARNING Do not use the defrost-level position during the cooling operation in extremely humid weather. The outer surface of the windshield may fog and reduce visibility, causing a collision that results in serious injury or death.
Page 205: Automatic Climate Control System
Automatic climate control To defrost outside windshield system To defog inside windshield OCN7052123C 1. Set the fan speed to the highest (extreme right) position. 2. Set the temperature to the hottest OCN7050124L position. 1. Select the desired fan speed. 3. Select the position.
Page 206: Defogging Logic
Convenience features To defrost outside windshield Manual climate control system 1. Turn the ignition switch to the ON position. 2. Select defroster mode ( 3. Press the air intake control button at least 5 times within 3 seconds. The process should be completed within 10 seconds after the defroster mode ( is selected.
Page 207: Rear Window Defroster
Rear window defroster Side view mirror defroster if equipped NOTICE The side view mirror defrosters operate when you turn on the rear window Never use sharp instruments or window defroster. cleaners containing abrasives to clean the window to prevent damage to the rear window defroster.
Page 208: Climate Control Additional Features
Convenience features Climate control Step 1) A/C button turns on. Step 2) Air intake control changes to additional features outside (fresh) air position under low outside temperature. Step 3) Defrost-level is selected. Sunroof inside air Step 4) Fan speed increases. recirculation To cancel or reset the Auto Defogging if equipped...
Page 209: Automatic Controls For The Driver Based On Climate Control System Settings
Storage compartment Automatic controls for the driver based on climate control system settings WARNING Never store cigarette lighters, propane if equipped The temperature of the driver’s seat cylinders, or other flammable/explosive warmer is automatically controlled materials in the vehicle. These items may depending on the inside and outside catch fire and/or explode if the vehicle is temperature of the vehicle when the...
Page 210: Center Console Storage
Convenience features Interior features Center console storage Cup holder Front OCN7050062 To open: Grab and hold the latch on the armrest then lift the lid. OCN7050065 Rear Glove box OCN7050066 Cups or small beverages cups may be OCN7050064 placed in the cup holders. To open: WARNING Pull the lever (1).
Page 211: Sunvisor
Power outlet NOTICE • Keep your drinks sealed while driving to prevent spilling. • When cleaning spilled liquids, do not use hot air to blow out or dry the cup holder. • Keep cans or bottles out of direct sun light and do not put them in a hot vehicle.
Page 212: Usb Charger
Convenience features USB charger NOTICE Front seat To prevent damage to the power outlets: • Use the power outlet only when the engine is running and remove the accessory plug after use. Using the accessory plug for an extended period of time with the engine off may cause the battery to discharge.
Page 213: Wireless Smartphone Charging System
Wireless smartphone Information charging system • Disconnect the USB cable from the USB if equipped port after use. • The battery charging state may be monitored on the electrical device. • A smartphone or a tablet PC may get warmer during the charging process. It does not indicate any malfunction with the charging system.
Page 214 Convenience features 3. Place the smartphone on the center of Information the wireless charging pad. The indicator light is orange when the • The wireless smart phone charging smartphone is charging and turns system may not support smartphones green when phone charging is that do not meet the ( ) specification.
Page 215: Clock
Coat hook • If the smartphone is not completely contacting the charging pad, wireless charging may not operate properly. • Some magnetic items such as credit cards, phone cards, or transit cards may be damaged if left with the smartphone during the charging process.
Page 216: Infotainment System
Convenience features Infotainment system Antenna NOTICE • Do not install an aftermarket HID headlight. Your vehicle’s audio and electronic devices may not function properly. • Prevent chemicals such as perfume, cosmetic oil, sun cream, hand cleaner, and air freshener from contacting the interior parts because they may cause damage or discoloration.
Page 217: Steering Wheel Audio Controls
SEEK/PRESET ( ) (2) Information If the SEEK/PRESET switch is pressed up • Avoid adding metallic coatings such as or down and held for 0.8 seconds or Nickel, Cadmium, etc. These can more, it functions in the following modes: degrade the receiving AM and FM broadcast signals.
Page 218: Infotainment System
Convenience features Infotainment system Bluetooth® wireless technology if equipped For more information, refer to the infotainment system manual. Voice recognition OCN7053075 OCN7050081 For more information, refer to the separately supplied infotainment system manual. OCN7050076 (1) Call/Answer/Call end button (2) Left Microphone (3) Right Microphone (if equipped) For more information, refer to the infotainment system manual.
Page 219: How Vehicle Radio Works
How vehicle radio works AM (MW, LW) reception FM reception OJF045309L AM broadcasts can be received at greater distances than FM broadcasts. This is OJF045308L because AM radio waves are transmitted AM and FM radio signals are broadcast at low frequencies. These long, low from transmitter towers located around frequency radio waves can follow the your city.
Page 220 Convenience features These can result in certain listening signal. If this occurs, select another conditions which might lead you to station with a stronger signal. believe a problem exists with your radio. • Multi-Path Cancellation Radio signals The following conditions are normal and being received from several directions do not indicate radio trouble : can cause distortion or fluttering.
Page 221: Driving Your Vehicle
6. Driving your vehicle Before driving ........................6-4 Before entering the vehicle..................6-4 Before starting ......................6-4 Vehicle break-in process .....................6-5 Key ignition switch ......................6-5 Key ignition switch positions ..................6-7 Starting the engine ......................6-8 Turning off the engine ....................6-8 Push button start ignition switch ...................6-9 Push button start ignition switch positions .............
Page 222 Hill-start Assist Control (HAC) ................... 6-41 Good braking practices..................... 6-42 Idle Stop and Go (ISG) system ..................6-42 Auto stop........................6-42 Auto start ........................6-43 Operating conditions ....................6-44 Deactivating the ISG ....................6-44 ISG malfunction ......................6-45 Smart ISG features ....................6-45 Drive mode integrated control system ...............
Page 223 Run the engine only long enough to start the engine and to move the vehicle out of the garage.oon as possible by an authorized HYUNDAI dealer. Avoid idling the engine for an extended period of time with people inside the vehicle.
Page 224: Before Driving
Driving your vehicle Before driving WARNING To reduce the risk of serious injury or Before entering the vehicle death: • Always wear your seat belt. All • Make sure all windows, outer side view passengers must be properly belted mirror(s), and outside lights are clean whenever the vehicle is moving.
Page 225: Vehicle Break-In Process
Key ignition switch Vehicle break-in process By following a few simple precautions for if equipped the first 600 mi. (1,000 km), you can add to the performance, economy, and life of WARNING your vehicle. To reduce the risk of serious injury or •...
Page 226 Driving your vehicle WARNING • Never turn the ignition switch to the LOCK or ACC position while the vehicle is moving except in an emergency. This may result in the engine turning off and loss of power assist for the steering and brake systems.
Page 227: Key Ignition Switch Positions
Key ignition switch positions Switch Action Notes Position To turn the ignition switch to the LOCK Always stop the vehicle before turning position, push the key in at the ACC the ignition switch to the LOCK position and turn the key towards the position.
Page 228: Starting The Engine
Driving your vehicle Starting the engine NOTICE WARNING To prevent damage to the vehicle: • Do not hold the ignition key in the • Always wear appropriate shoes when START position for more than 10 operating your vehicle. Unsuitable seconds. Wait 5 to 10 seconds before shoes such as high heels, ski boots, trying again.
Page 229: Push Button Start Ignition Switch
Push button start ignition WARNING switch To turn off the vehicle in an emergency: Press and hold the Push Button Start if equipped ignition switch for more than two WARNING seconds. Or rapidly press and release the Push Button Start ignition switch three To reduce the risk of serious injury or times (within three seconds).
Page 230: Push Button Start Ignition Switch Positions
Driving your vehicle Push button start ignition switch positions Button Action Notes Position To turn off the engine, press the Push Always stop the vehicle before Button Start ignition switch with the pressing the Push Button Start vehicle shifted to P (Park). ignition switch to the OFF position.
Page 231: Starting The Engine
Starting the engine 1. Always carry the smart key with you. 2. Make sure the parking brake is applied. WARNING 3. Make sure the shift lever is in P (Park). • Always wear appropriate shoes when 4. Depress the brake pedal. operating your vehicle.
Page 232: Turning Off The Engine
Driving your vehicle Remotely starting the engine Information if equipped OCN7063004L OCN7063005 If the smart key battery is weak or the You can start the vehicle using the smart key does not work correctly, press Remote Start button of on the smart key. the Push Button Start ignition switch with To start the vehicle remotely: the smart key.
Page 233: Vehicle Auto-Shut Off
Vehicle Auto-Shut Off System operation if equipped If your vehicle is parked and the engine is left on for a long period of time, the engine turns off automatically to help reduce fuel consumption and prevent carbon dioxide poisoning. Operating conditions Vehicle Auto-Shut Off timer operates when all the following conditions are OJK041087N...
Page 234: Intelligent Variable Transmission
Driving your vehicle Intelligent Variable Transmission if equipped OCN7063202N [A] Shift release button [B] Shift lever [C] DS mode, manual shift mode Depress the brake pedal and press the shift release button while moving the shift lever. Press the shift release button while moving the shift lever. The shift lever can freely operate.
Page 235: Intelligent Variable Transmission Operation
Intelligent Variable P (Park) Transmission operation Always come to a complete stop before shifting into P (Park). The Intelligent Variable Transmission To shift from P (Park), depress the brake (IVT) has no actual fixed gears. The pedal firmly and make sure your foot is varying gear ratios are selected not depressing the accelerator pedal.
Page 236 Driving your vehicle R (Reverse) The DRIVE MODE switch, located on the shift lever console or on the left side of Use this position to drive the vehicle the dashboard, allows the driver to switch backward. from NORMAL mode to SPORT or SMART NOTICE mode (if equipped).
Page 237 - (Down), the transmission may not flathead screw-driver). shift if the next gear is outside of the If you need to use the shift lock release, allowable engine RPM range. have the vehicle inspected by an authorized HYUNDAI dealer immediately. 6-17...
Page 238: Parking
Driving your vehicle Good driving practices NOTICE • Never shift the gear from P (Park) or N Be careful not to damage the trim around (Neutral) to any other gear when the the shift lever while removing the shift accelerator pedal is depressed. lever boots.
Page 239 • In the event your vehicle leaves the roadway, do not steer sharply. Instead, slow down before pulling back into the travel lanes. • HYUNDAI recommends you follow all posted speed limits. 6-19...
Page 240: Dual Clutch Transmission
Driving your vehicle Dual Clutch Transmission if equipped OCN7N063008N [A] Shift release button [B] Shift lever [C] DS mode, manual shift mode Depress the brake pedal and press the shift release button while moving the shift lever. Press the shift release button while moving the shift lever. The shift lever can freely operate.
Page 241: Dual Clutch Transmission Operation
Dual Clutch Transmission • When D (Drive) is selected, the transmission will automatically shift operation through the gears similar to a The dual clutch transmission has 7 conventional automatic transmission. forward speeds and one reverse speed. Unlike a traditional automatic The individual speeds are selected transmission, the gear shifting can automatically in the D (Drive) position.
Page 242 P (Park), apply the parking indicator (D, R) on the cluster will blink. brake, and turn the wheels toward the Contact an authorized HYUNDAI dealer curb to prevent the vehicle from rolling and have the system checked. downhill.
Page 243 N (Neutral) DS (Drive Sporty) mode Use N (Neutral) if you need to restart a To shift into DS mode, move the shift stalled engine, or if it is necessary to stop lever from D (Drive) to the center of the with the engine ON.
Page 244 2. Start the engine or place the ignition have the vehicle inspected by an switch in the ON position. authorized HYUNDAI dealer immediately. 3. Depress the brake pedal. press the shift NOTICE release button, and put the gear in R (Reverse).
Page 245: Dct Warning Messages
Wait until the transmission is sufficiently cooled down. • If the above warning message is displayed continuously, contact an authorized HYUNDAI dealer. 2C_DCTWarningMessageInCluster_2 Repeated stop-and-go launches on steep grades, sudden take off or acceleration, or other harsh driving conditions may increase the clutch and transmission temperature.
Page 246: Parking
Driving your vehicle Cooling... Remain parked for 00 min. Parking Always come to a complete stop and continue to depress the brake pedal. Shift the gear to the P (Park) position, apply the parking brake, and place the ignition switch in the LOCK/OFF position. Take the key with you when exiting the vehicle.
Page 247: Paddle Shifter (Manual Shift Mode)
Paddle shifter (Manual shift Good driving practices mode) • Never shift the gear from P (Park) or N (Neutral) to any gear when the if equipped accelerator pedal is depressed. • Never shift the gear into P (Park) when the vehicle is moving. •...
Page 248: Braking System
This is normal travel lanes. and does not indicate a problem with • HYUNDAI recommends you follow all your brakes. posted speed limits. • While driving on a road with deicing...
Page 249: Disc Brakes Wear Indicator
Disc brakes wear indicator WARNING When your brake pads are worn and new Take the following precautions: pads are required, you may hear a high • Do not drive with your foot resting on pitched warning sound from your front or the brake pedal.
Page 250 Driving your vehicle Releasing the parking brake NOTICE • Do not apply the accelerator pedal while the parking brake is engaged. If you depress the accelerator pedal with the parking brake engaged, a warning will sound. Damage to the parking brake may occur.
Page 251: Electronic Parking Brake (Epb)
EPB is used for emergency 1. Depress and hold the brake pedal. braking, have the system inspected by an 2. Pull up the EPB switch. authorized HYUNDAI dealer. Make sure the Parking Brake warning light comes on. Releasing the parking brake...
Page 252 • Always come to a complete stop and released, have the system inspected by continue to depress the brake pedal an authorized HYUNDAI dealer. before parking, shift the gear into P • Do not drive your vehicle with EPB (Park), pull up the EPB switch, and applied.
Page 253 ON, the EPB may have malfunctioned. If this occurs, have the system inspected by an authorized HYUNDAI dealer. The EPB warning light may illuminate when the ESC indicator light comes on to indicate that ESC is not working properly,...
Page 254: Auto Hold
Repeat this one more time. If the EPB warning does not go off, have your vehicle towed on a flatbed tow truck to an authorized HYUNDAI dealer. Parking brake warning light OCN7H063007 1. Press the AUTO HOLD switch. The white AUTO HOLD indicator comes on and the system is in standby.
Page 255 The AUTO HOLD indicator turns off. If the AUTO HOLD indicator changes to yellow, Auto Hold does not work properly. WARNING Contact an authorized HYUNDAI dealer. To prevent unintended vehicle movement, always depress your foot on the brake pedal to cancel the Auto Hold before you: •...
Page 256: Anti-Lock Brake System (Abs)
Driving your vehicle AUTO HOLD turning Off! Press brake Warning messages pedal Parking brake automatically engaged OCN7060152L OCN7060153L When the conversion from Auto Hold to When EPB is applied while Auto Hold is EPB is not working properly, a warning activated, a warning sounds and a sounds and a message appears.
Page 257 Using ABS injury or death, contact your authorized To obtain the maximum benefit from your HYUNDAI dealer as soon as possible. ABS in an emergency situation, do not attempt to modulate your brake pressure and do not try to pump your brakes.
Page 258: Electronic Stability Control (Esc)
Driving your vehicle Electronic Stability Control ESC operation (ESC) ESC ON condition When the ignition switch is in the ON position, ESC and the ESC OFF indicator lights illuminate for about three seconds. After both lights go off, ESC is enabled. When operating When ESC is operating, the ESC indicator light blinks:...
Page 259 Both the traction control HYUNDAI dealer as soon as possible. function of ESC (engine management) The ESC OFF indicator light comes on and the brake control function of ESC when ESC is turned off.
Page 260: Vehicle Stability Management (Vsm)
Driving your vehicle Vehicle Stability Management ESC OFF usage (VSM) When Driving Vehicle Stability Management is a The ESC OFF mode should only be used function of the Electronic Stability briefly to help free the vehicle if stuck in Control (ESC) system. It helps the vehicle snow or mud, by temporarily stopping stay stable when accelerating or braking operation of ESC, to maintain wheel...
Page 261: Hill-Start Assist Control (Hac)
If the ESC ( ) indicator light or MDPS ) warning light stays illuminated or blinks, your vehicle may have a malfunction with the VSM system. Have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. 6-41...
Page 262: Good Braking Practices
It does not mean the system has If the braking action does not return to malfunctioned. normal, stop as soon as it is safe to do so and contact an authorized HYUNDAI dealer for assistance. Auto stop DO NOT drive with your foot resting on If you depress the brake pedal and the the brake pedal.
Page 263: Auto Start
Auto start The engine will stop and the green Auto Stop ( ) indicator on the instrument When the engine stops automatically by cluster will appear. ISG, the engine will restart if the driver takes one of the following actions: NOTICE •...
Page 264: Operating Conditions
Driving your vehicle The engine will also restart NOTICE automatically without any driver actions if the following occurs: • If the ISG system does not meet the operation condition, the ISG system is • The brake vacuum pressure is low. deactivated.
Page 265: Isg Malfunction
ISG malfunction Smart ISG features Early Engine Restart If the engine was stopped automatically by ISG, Early Engine Restart can automatically restart the engine from ISG without driver action when the vehicle ahead pulls away and the front view camera detects the preceding vehicle’s movement.
Page 266 Driving your vehicle OCN7063195N OCN7063196N (1) Timer If a STOP, YIELD or Roundabout sign is (2) Auto Start: vehicle ahead is driving detected and the ISG system is away deactivated by ISG inhibition at traffic signs, a message will appear on the NOTICE cluster display (if equipped) when the "AUTO STOP"...
Page 267 ISG inhibition from turn signal ISG inhibition from turn signal can deactivate the ISG system and keep the engine on when the turn signal is on and the front view camera does not detect a preceding vehicle. If the ISG system is deactivated by ISG inhibition from turn signal, a message will appear on the cluster display when the "AUTO STOP"...
Page 268 Driving your vehicle overturned, or the side of the vehicle WARNING is visible, etc. Limitations of Smart ISG features - The front vehicle's ground clearance is low or high • Smart ISG features may not operate normally, or may operate - A vehicle, pedestrian or cyclist unexpectedly, under the following suddenly cuts in front...
Page 269: Drive Mode Integrated Control System
Drive mode integrated The mode changes whenever the DRIVE MODE button is pressed. control system ↔ ↔ • NORMAL SPORT SMART if equipped When the NORMAL mode is selected, it does not appear on the instrument cluster. Selecting drive mode The drive mode will change to NORMAL Type A mode when the engine is restarted.
Page 270: Normal, Sport, Smart Mode Features
Driving your vehicle NORMAL, SPORT, SMART Information mode features • When using the SMART mode, if your acceleration pedal input is gradual, the NORMAL mode drive mode maximizes the fuel NORMAL mode provides smooth driving efficiency. and comfortable riding. • When your vehicle is in SMART mode and your driving style is more aggressive so that your acceleration SPORT mode...
Page 271: Smart Shift On Trip Computer
Special driving conditions SMART mode deactivates automatically SMART mode may deactivate if: • The driver manually shifts gears. Hazardous driving conditions • Cruise Control may deactivate the When hazardous driving conditions are SMART mode. When a higher speed is encountered such as water, snow, ice, set by Cruise Control, it starts to control mud, and sand: the vehicle speed and deactivates the...
Page 272: Smooth Cornering
Driving your vehicle • Keep your headlights clean and WARNING properly aimed. Dirty or improperly aimed headlights can make it much Always turn off the ESC system before more difficult to see at night. rocking the vehicle. If the vehicle is stuck and excessive wheel spin occurs, the •...
Page 273: Driving In Flooded Areas
Highway driving Hydroplaning If the road is wet enough and you are driving fast enough, your vehicle may Tires have little or no contact with the road Adjust the tire inflation pressure, as surface and actually ride on the water. specified.
Page 274: Winter Driving
If tire chains must front. be used, use genuine HYUNDAI Parts and Apply the brakes gently. Speeding, rapid install the tire chains after reviewing the acceleration, sudden brake applications, instructions provided with the tire chains.
Page 275: Winter Precautions
NOTICE and cables, as specified in chapter 9. The battery charging level can be checked by When using tire chains: an authorized HYUNDAI dealer or in a • Wrong size chains or improperly service station. installed chains may damage your vehicle’s brake lines, suspension, body,...
Page 276 Window washer anti-freeze compartment may cause an engine solution is available from an authorized failure or a fire, because they may block HYUNDAI dealer, and most vehicle the engine cooling. Such damage is not accessory outlets. covered by the manufacturer’s warranty.
Page 277: Trailer Towing
Trailer towing Vehicle load limit Do not use this vehicle for trailer towing. Two labels on your driver’s door sill show how much weight your vehicle was designed to carry: the Tire and Loading Information Label and the Certification Label. Before loading your vehicle, familiarize yourself with the following terms for determining your vehicle’s...
Page 278: The Loading Information Label
Driving your vehicle GVW (Gross Vehicle Weight) Type C This is the Base Curb Weight plus actual Cargo Weight plus passengers. GVWR (Gross Vehicle Weight Rating) This is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo).
Page 279 Seating capacity 4.The resulting figure equals the available amount of cargo and Total: 5 persons (Front seat: 2 luggage load capacity. For persons, Rear seat: 3 persons) example, if the "XXX" amount Seating capacity is the maximum equals 1400 lbs. and there will be number of occupants including a five 150 lb passengers in your driver that your vehicle may carry.
Page 280 Driving your vehicle ≥ Example 1 Passenger Weight Maximum Cargo Weight (150 lbs. × 2= 300 Load (1400 (1100 lbs.) lbs.) (68 kg × 2= 136 lbs.) (635 kg) (499 kg) ≥ Example 2 Passenger Weight Maximum Cargo Weight (150 lbs. × 5 = 750 Load (1400 (650 lbs.) lbs.) (68 kg ×...
Page 281 Certification label WARNING • Never exceed the GVWR for your vehicle, the GAWR for the front or rear axle and the vehicle capacity weight. Exceeding these ratings may affect your vehicle's handling and braking ability, and cause a collision. • Do not overload your vehicle. Overloading your vehicle may cause heat buildup in your vehicle's tires, possible tire failure, increased...
Page 283: Driver Assistance System
7. Driver assistance system Before using driver assistance system................7-4 Driver assistance system settings ................7-5 Forward Collision Avoidance Assist (FCA) (Front view camera only) ......7-6 Forward Collision-Avoidance Assist settings............. 7-6 Forward Collision-Avoidance Assist operation............7-7 Forward Collision-Avoidance Assist malfunction and limitations......7-9 Forward Collision Avoidance Assist (FCA) (Sensor fusion)..........
Page 284 Blind-spot View Monitor malfunction ..............7-63 Cruise Control (CC) ......................7-63 Cruise Control operation ...................7-63 Smart Cruise Control (SCC)................... 7-67 Smart Cruise Control settings ................... 7-67 Smart Cruise Control operation ................7-68 Smart Cruise Control malfunction and limitations ..........7-76 Navigation-based Smart Cruise Control (NSCC)............7-82 Navigation-based Smart Cruise Control settings ............7-82 Navigation-based Smart Cruise Control operation ..........7-83 Limitations of Navigation-based Smart Cruise Control .........
Page 285 7. Driver assistance system Reverse Parking Collision-Avoidance Assist operation...........7-115 Reverse Parking Collision-Avoidance Assist malfunction and limitations ... 7-116 Driver assistance system sensors................7-120 Cameras........................7-120 Radars .........................7-121 Ultrasonic sensors..................... 7-122 Declaration of conformity.................... 7-123 Front radar.........................7-123 Rear corner radar ......................7-124...
Page 286: Before Using Driver Assistance System
Driver assistance system Before using driver Limitations of driver assistance system assistance system Nearby vehicles, road conditions, or other factors may delay the response from WARNING Driver Assistance system or cause these systems not to function, including: Always maintain a safe distance from the •...
Page 287: Driver Assistance System Settings
Driver assistance system • Driving Safety Priority: Lowers all other audio volumes when the Driving Safety settings system sounds a warning. • Parking Safety Priority: Lowers all Warning Methods other audio volumes when the Parking Type A Assist view is active. CAUTION For safety, the warning method is different depending on each function of...
Page 288: Forward Collision Avoidance Assist (Fca) (Front View Camera Only)
Driver assistance system Forward Collision Forward Collision-Avoidance Assist settings Avoidance Assist (FCA) (Front view camera only) Forward Safety if equipped OCN7073262N With the ignition switch ON, go to User OCN7061112L Settings > Driver Assistance > Driving Forward Collision-Avoidance Assist uses Safety from the settings menu in the the front view camera to help detect a instrument cluster or Settings >...
Page 289: Forward Collision-Avoidance Assist Operation
Forward Safety Warning Timing Information You can set the following Warning Methods: • Warning Volume/Haptic Warning/Driving Safety Priority For more information, refer to the "Driver assistance system settings" section in this chapter. Forward Collision-Avoidance OCN7073261N Assist operation With the ignition switch ON, go to User Forward Collision-Avoidance Assist may Settings >...
Page 290 Driver assistance system Emergency Braking Depress the brake pedal immediately and check the surroundings. • Braking control ends about 2 seconds after your vehicle is stopped following an Emergency Braking event. WARNING Forward Collision-Avoidance Assist may not operate in all situations and cannot avoid all collisions.
Page 291: Forward Collision-Avoidance Assist Malfunction And Limitations
Have the vehicle that determines the risk level: inspected by an authorized HYUNDAI dealer. - Condition of other vehicles - The direction vehicles are driven - Vehicle speed - Surroundings •...
Page 292 HYUNDAI dealer. • The camera lens is contaminated due to tinted, filmed or coated windshield, damaged glass, or sticky foreign material (sticker, bug, etc.) on the glass.
Page 293 • The vehicle or powered two-wheeler in • Your vehicle is being towed. front steers in the opposite direction of • The surrounding is very bright. your vehicle to avoid a collision. • The surrounding is very dark, such as in •...
Page 294 Driver assistance system • The pedestrian or cyclist in front has WARNING impaired mobility. • Driving on a curved road • The pedestrian or cyclist in front is moving intersected with the driving direction. • There is a group of pedestrians, cyclists or a large crowd in front.
Page 295 OADAS005SD OCN7073244L Forward Collision-Avoidance Assist may not detect other vehicles, powered two-wheeler, pedestrians or cyclists in front of you when driving on a curve and may not activate a warning or brake your vehicle when needed. When driving on a curved road, always maintain a safe distance from others on the road.
Page 296 Driver assistance system • Driving on an inclined road OCN7073246L Forward Collision-Avoidance Assist OADAS063SD may not detect other vehicles, powered two-wheeler, pedestrians or cyclists in front of you while driving uphill or downhill. This may result in unnecessary warning or braking assist, or no warning or braking assist when needed.
Page 297 • Changing lanes OADAS033SD OADAS032SD [A] Your vehicle [B] Lane changing vehicle [A] Your vehicle [C] Same lane vehicle [B] Lane changing vehicle When a vehicle or powered When a vehicle moves into your lane two-wheeler in front of you merges out from an adjacent lane, it cannot be of the lane, Forward detected by the sensor until it is in the...
Page 298 Driver assistance system • Detecting a vehicle WARNING • When you are towing a trailer or another vehicle, turn off Forward Collision-Avoidance Assist. • Forward Collision-Avoidance Assist may operate if objects that are similar in shape or characteristics to vehicles, powered two-wheelers, pedestrians are detected.
Page 299: Forward Collision Avoidance Assist (Fca) (Sensor Fusion)
Forward Collision Junction Turning function Avoidance Assist (FCA) (Sensor fusion) if equipped Basic function OCN7061111L Junction Turning function can help avoid a collision with an oncoming vehicle in an adjacent lane when turning left at a crossroad with the turn signal on by applying emergency braking.
Page 300: Forward Collision-Avoidance Assist Settings
Driver assistance system WARNING Information Forward Collision-Avoidance Assist When the engine is restarted, Forward (Sensor fusion) uses the following Collision-Avoidance Assist will always sensors: turn on. • Front view camera However, if Forward Safety is deselected, the driver should always be •...
Page 301: Forward Collision-Avoidance Assist Operation
Collision Warning WARNING • Even though Standard is selected for Forward Safety Warning Timing if the vehicle ahead of you suddenly stops, the initial warning activation time may not seem late. • Select Late for Forward Safety Warning Timing when traffic is light and your vehicle speed is slow.
Page 302 Driver assistance system Junction Turning function • Vehicle or powered two-wheeler: Junction Turning function will warn and Driving Stopped help control the vehicle depending on the vehicle vehicle collision risk level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping Weak Approximately 6-125 mph vehicle and ending brake control'.
Page 303 Emergency Braking Stopping vehicle and ending brake control OCN7073158L OCN7073156L If Forward Collision-Avoidance Assist • After your vehicle has stopped judges avoiding a collision may be following an Emergency Braking event, difficult, it applies higher brake force that the "Drive carefully" warning message may help avoid a collision with the may appear on the instrument cluster.
Page 304 Driver assistance system Emergency Braking Direct Oncoming function Direct Oncoming function will warn and control the vehicle depending on the collision risk level: ‘Collision Warning’, ‘Emergency Braking’ and ‘Stopping vehicle and ending brake control’. Collision Warning OCN7073155L • To warn the driver that emergency braking will be assisted, Forward Safety warning light ( ) blinking, the...
Page 305 Stopping vehicle and ending brake control WARNING Forward Collision-Avoidance Assist may not operate in all situations and cannot avoid all collisions. To prevent serious injury or death: • Only change the settings after parking your vehicle at a safe location. •...
Page 306: Forward Collision-Avoidance Assist Malfunction And Limitations
Have the vehicle • Forward Collision-Avoidance Assist will inspected by an authorized HYUNDAI operate under certain conditions by dealer. judging the risk level based on the...
Page 307 HYUNDAI dealer. • The camera lens is contaminated due to tinted, filmed or coated windshield, damaged glass, or sticky foreign material (sticker, bug, etc.) on the glass.
Page 308 Driver assistance system • A material is near that reflects very well • Your vehicle is being towed. on the front radar, such as a guardrail, • The surrounding is very bright. nearby vehicle, etc. • The surrounding is very dark, such as in •...
Page 309 • The adverse road conditions cause excessive vehicle vibrations while driving. • Your vehicle height is low or high due to heavy loads, abnormal tire pressure, etc. • Driving through a narrow road where trees or grass or overgrown. • There is interference by electromagnetic waves, such as driving in an area with strong radio waves or ORS071178...
Page 310 Driver assistance system OADAS016SD OCN7073203 OADAS017SD OADAS018SD Forward Collision-Avoidance Assist may not detect other vehicles, powered two-wheelers, pedestrians or cyclists in front of you when driving on a curved roads adversely affecting the performance of the sensors. This may result in no warning, braking assist when necessary.
Page 311 • Driving on an inclined road OADAS011SD Forward Collision-Avoidance Assist OADAS012SD may not detect other vehicles, powered two-wheelers, pedestrians or cyclists in front of you while driving uphill or downhill adversely affecting the performance of the sensors. This may result in unnecessary warning or braking assist, or no warning or braking assist when needed.
Page 312 Driver assistance system • Changing lanes OADAS031SD OADAS030SD [A] Your vehicle [B] Lane changing vehicle [A] Your vehicle [C] Same lane vehicle [B] Lane changing vehicle When a vehicle in front of you departs When a vehicle moves into your lane the lane, Forward Collision-Avoidance from an adjacent lane, it cannot be Assist may not immediately detect...
Page 313 • Detecting a vehicle WARNING • When you are towing a trailer or another vehicle, turn off Forward Collision-Avoidance Assist. • Forward Collision-Avoidance Assist may operate if objects that are similar in shape or characteristics to vehicles, powered two-wheeler, pedestrians and cyclists are detected.
Page 314: Lane Keeping Assist (Lka)
Driver assistance system Lane Keeping Assist (LKA) Lane Keeping Assist settings Lane Keeping Assist uses the front view Lane Safety camera to help detect lane markings (or road edges) while driving over a certain speed. Lane Keeping Assist may warn you if your vehicle leaves the lane without using the turn signal and may steer the vehicle to help prevent it from departing...
Page 315: Lane Keeping Assist Operation
Warning and control Information Left You can set the following Warning Methods: • Warning Volume/Haptic Warning/Lane Safety Audible Warning Off/Driving Safety Priority For more information, refer to the "Driver assistance system settings" section in this chapter. Lane Keeping Assist operation OCN7073205 Right Turning Lane Keeping Assist On/Off...
Page 316 Driver assistance system Lane Keeping Assist WARNING If your vehicle detects it is departing from Lane Keeping Assist may not operate in all the projected lane ahead, the green situations and cannot avoid all collisions. indicator light blinks on the instrument cluster, and the steering wheel makes To prevent serious injury or death: adjustments to keep your vehicle inside...
Page 317: Lane Keeping Assist Malfunction And Limitations
"Check Lane Safety system" message may appear and the yellow indicator light may illuminate on the instrument cluster. Have the vehicle inspected by an authorized HYUNDAI dealer. OCN7073160 Limitations of Lane Keeping Assist • The images and colors in the...
Page 318 Driver assistance system • The lane number increases or WARNING decreases, or the lane markings (or road edges) are crossing. • Lane Keeping Assist may be canceled or may not work properly depending on • The lane markings (or road edges) are the road conditions and the complicated or a structure substitutes surroundings.
Page 319: Blind-Spot Collision-Avoidance Assist (Bca)
Blind-spot Collision-Avoidance Assist (BCA) if equipped Blind-Spot Collision-Avoidance Assist uses the front view camera and the rear corner radar to help detect approaching vehicles in the driver’s blind spot areas and warn you of a possible collision with a warning message and audible warning. OHY059002 Blind-Spot Collision-Avoidance Assist If there is a collision risk when driving...
Page 320 Driver assistance system Information Blind-Spot Collision-Avoidance Assist uses the following sensors: • Front view camera • Rear corner radars Refer to the "Driver assistance system sensors" section in this chapter for the location. B0320EU02 When the engine is restarted with Blind-spot Blind-Spot Collision-Avoidance Assist Collision-Avoidance Assist...
Page 321: Blind-Spot Collision-Avoidance Assist Operation
Blind-spot WARNING Collision-Avoidance Assist • The detection range of the rear corner operation radar is determined by a standard road width. On narrow roads, the function Driving-Warning may detect other vehicles in the next lane and warn you. On wide roads, the function may not be able to detect a vehicle driving in the next lane and may not warn you.
Page 322 Driver assistance system • Even if there is a problem with Blind-Spot Collision-Avoidance Assist, your vehicle’s braking system operates normally. • Control your vehicle at all times. Always maintain a safe distance from the vehicles ahead and adjust your vehicle speed depending on the road conditions.
Page 323: Blind-Spot Collision-Avoidance Assist Malfunction And Limitations
) warning light will appear on Radar blocked" warning message may the instrument cluster. Have the vehicle appear on the instrument cluster. be inspected by an authorized HYUNDAI The function operates normally when dealer. such foreign material, trailer, or carrier is removed, and the engine is restarted.
Page 324 Driver assistance system • You are driving in large, open areas WARNING where there are few vehicles or structures (e.g. desert, meadow, empty • Blind-Spot Collision-Avoidance Assist parking lot). may not operate properly even if there is no warning message or warning light •...
Page 325 Blind-Spot Collision-Avoidance Assist may not assist braking when: • Your vehicle severely vibrates while driving over a bumpy road, uneven road, or concrete patch. • You are driving on a slippery surface due to snow, water puddle, ice, etc. • The tire pressure is low or any tire is damaged.
Page 326 Driver assistance system • Driving on hills • Driving where the heights of the lanes are different OCN7063049N OCN7073219 Blind-Spot Collision-Avoidance Assist may not detect a vehicle in an adjacent Blind-Spot Collision-Avoidance Assist lane or may incorrectly detect the may not operate properly when driving ground or another object when driving where the heights of the lanes are on hills and activate a warning or brake...
Page 327: Safe Exit Warning (Sew)
Safe Exit Warning (SEW) Safe Exit Warning settings if equipped Exit Warning OHY050024 OCN7073164N Safe Exit Warning uses the rear corner With the ignition switch ON, go to User radars to help detect a vehicle settings > Driver Assistance > Driving approaching the rear of your vehicle, after Safety >...
Page 328: Safe Exit Warning Operation
Driver assistance system Safe Exit Warning operation WARNING Safe Exit Warning may not operate in all Collision warning when exiting your situations and cannot avoid all collisions. vehicle To prevent serious injury or death: • Always check the surroundings before you or your passengers exit your vehicle.
Page 329: Safe Exit Warning Malfunction And Limitations
If the function does not operate normally after anything covering or blocking the sensors is removed, have the vehicle inspected by an authorized HYUNDAI dealer. B0322EU02 When the side view mirror warning light is not working properly, the "Check side...
Page 330 Driver assistance system Limitations of Safe Exit Warning WARNING Safe Exit Warning may not operate • Safe Exit Warning may not operate normally, or may operate unexpectedly if: properly even if there is no warning • Trees or grass near your vehicle are message or warning light on the overgrown.
Page 331: Manual Speed Limit Assist (Msla)
Manual Speed Limit Manual Speed Limit Assist operation Assist (MSLA) Setting speed limit 1. Press and hold the Driving Assist ) button at the desired speed. The Manual Speed Limit Assist ( indicator light illuminates on the instrument cluster. OJX1070150N (1) Manual Speed Limit Assist enabled indicator (2) Set speed...
Page 332 Driver assistance system Temporarily pausing Manual Speed Limit Assist OCN7060144 Push and hold to increase or decrease to the nearest multiple of five (multiple OCN7060063 of ten in km/h), and then increase or Press the button to temporarily decrease by 5 mph (10 km/h). cancel the set speed limit.
Page 333: Intelligent Speed Limit Assist (Isla)
Intelligent Speed Limit Turning off Manual Speed Limit Assist Assist (ISLA) if equipped Intelligent Speed Limit Assist uses information of road signs detected from the front view camera and uses the navigation system data to inform you of the speed limit and help maintain within the speed limit on the road.
Page 334: Intelligent Speed Limit Assist Settings
Driver assistance system Intelligent Speed Limit Assist • Speed Limit Assist: Intelligent Speed Limit Assist will inform the driver of settings speed limit and additional road signs. In addition, Intelligent Speed Limit Assist Speed Limit will inform the driver to change set speed of Manual Speed Limit Assist and/or Smart Cruise Control to help the driver stay within the speed limit.
Page 335 Displaying speed limit Changing set speed OCN7073170N OCN7073251N Speed limit information appears on the If the speed limit changes when using instrument cluster. Manual Speed Limit Assist or Smart Cruise Control, an arrow in the direction • If the speed limit information of the of up or down appears to inform you to road cannot be recognized, "---"...
Page 336: Intelligent Speed Limit Assist Malfunction And Limitations
Intelligent Speed Limit may illuminate on the instrument cluster. Assist may not operate properly. Have the vehicle inspected by an authorized HYUNDAI dealer. Information • For more information on Manual Speed Limit Assist operation, refer to the "Manual Speed Limit Assist (MSLA)"...
Page 337 • The numbers or pictures in the road been uncovered or unblocked, have the sign is incorrectly recognized as the vehicle inspected by an authorized speed limit. HYUNDAI dealer. • Road signs on adjacent roads are incorrectly recognized as road signs WARNING you are driving on.
Page 338: Driver Attention Warning (Daw)
Driver assistance system Driver Attention Warning • You are driving on a road that is sharply curved or continuously curved. (DAW) • You are driving through speed bumps, or driving up and down, or left to right on steep inclines. Basic function •...
Page 339: Driver Attention Warning Operation
Driver Attention Warning Leading Vehicle Departure Alert operation Basic function The basic function of Driver Attention Warning is to warn the driver "Consider taking a break". Taking a break OCN7073173N If Leading Vehicle Departure Alert is selected, the function informs you when a detected vehicle in front departs from a stop.
Page 340 Driver assistance system Leading Vehicle Departure Alert CAUTION function • Driver Attention Warning may suggest a break depending on your driving pattern or habit, even if you do not feel fatigued. • Driver Attention Warning is a supplemental function only and does not determine if you are paying attention to the driving task.
Page 341: Driver Attention Warning Malfunction And Limitations
WARNING warning light may illuminate on the instrument cluster. Have the vehicle • Driver Attention Warning may not inspected by an authorized HYUNDAI properly operate in an area (e.g. open dealer. terrain) where any objects are not detected right after turning ON the engine.
Page 342 Driver assistance system Limitations of Driver Attention • When the vehicle ahead sharply steers Warning Driver Attention Warning may not work properly in the following situations: • The vehicle is driven violently • The vehicle intentionally crosses over lanes frequently •...
Page 343 • When a pedestrian or bicycle is • When driving at a tollgate or between you and the vehicle ahead intersection, etc. OADAS025SD OADAS026SD If there is a pedestrian(s) or bicycle(s) in If you pass a tollgate or intersection between you and the vehicle in front, with lots of vehicles or you drive where Leading Vehicle Departure Alert may lanes are merged or divided frequently,...
Page 344: Blind-Spot View Monitor (Bvm)
Driver assistance system Blind-spot View Monitor Blind-spot View Monitor settings (BVM) if equipped Blind-Spot View Left side With the ignition switch ON, go to Setup > Vehicle > Driver Assistance > Driving Safety > Blind-Spot View (for infotainment system type) from the Settings menu to turn on and off Blind-Spot View Monitor.
Page 345: Blind-Spot View Monitor Malfunction
Blind-spot View Monitor malfunction if equipped When Blind-Spot View Monitor is not working properly, have the vehicle inspected by an authorized HYUNDAI dealer. WARNING • Always turn your head and look to determine if there is enough distance to change lanes. The perceived distance...
Page 346 Driver assistance system Accelerating temporarily 3. Release the accelerator pedal. Vehicle speed maintains the set speed If you want to accelerate temporarily even when the accelerator pedal is not when Cruise Control is on, depress the depressed. accelerator pedal. To return to the set speed, take your foot Information off the accelerator pedal.
Page 347 ) indicator light will stay on. Your vehicle speed may rapidly increase NOTICE or decrease when you press the button. If Cruise Control cancels during a situation not listed above, have the vehicle inspected by an authorized HYUNDAI dealer. 7-65...
Page 348 Driver assistance system Turning off Cruise Control WARNING To prevent serious injury or death: • Keep Cruise Control off when not in use, to avoid inadvertently setting a speed. Check that the Cruise Control ) indicator light is off. • Always drive defensively and pay attention to the driving task.
Page 349: Smart Cruise Control (Scc)
Smart Cruise Control Smart Cruise Control settings (SCC) Smart Cruise Control if equipped Basic function Smart Cruise Control uses the front view camera and front radar to help detect a vehicle ahead and maintain the desired speed and distance between your vehicle and the vehicle ahead.
Page 350: Smart Cruise Control Operation
Driver assistance system Operating conditions for Acceleration Smart Cruise Control Assist operation Overtaking Acceleration Assist operates when the turn signal indicator is turned on Operating conditions to the left while Smart Cruise Control is operating, and the following conditions Basic function are satisfied: Smart Cruise Control operates when the •...
Page 351 Turning on Smart Cruise Control Setting vehicle distance OCN7073167 OCN7060069 Each time the button is pressed, the • Press the Driving Assist ( ) button. The vehicle distance changes as follows: speed is set to the current speed on the instrument cluster.
Page 352 Driver assistance system Increasing set speed Decreasing set speed OCN7060061 OCN7060062 • Push the + switch up and release it • Push the - switch down and release it immediately to increase the cruising immediately to decrease the cruising speed by 1 mph (1 km/h). speed by 1 mph (1 km/h).
Page 353 Temporarily cancelling Smart Cruise Turning off Smart Cruise Control Control OCN7073167 OCN7060120 Press the Driving Assist ( ) button to turn Press the button or depress the brake off Smart Cruise Control. pedal to temporarily cancel Smart Cruise Information Control. If your vehicle is equipped with Manual Resuming Smart Cruise Control Speed Limit Assist, press and hold the...
Page 354 Driver assistance system When operating Information • The distance from the front vehicle on the instrument cluster appears according to the actual distance between your vehicle and the vehicle ahead. • The target distance may differ depending on the vehicle speed and the set distance level.
Page 355 WARNING WARNING Be careful when accelerating temporarily, Always maintain a safe distance from the because Smart Cruise Control is not vehicles ahead and adjust your vehicle controlling the speed and distance even if speed to the road conditions. When there is a vehicle in front of you. Smart Cruise Control is temporarily canceled, it is not controlling the speed Always maintain a safe distance from the...
Page 356 Driver assistance system In traffic situation Warning road conditions ahead OCN7070054L OCN7073178L In traffic, your vehicle stops if the vehicle The "Watch for surrounding vehicles" ahead of you stops. Also, if the vehicle warning message may appear on the ahead of you starts moving, your vehicle instrument cluster, and an audible starts moving as well.
Page 357 Collision Warning WARNING Smart Cruise Control is not a substitute for proper and safe driving. To prevent serious injury or death: • Always maintain a safe distance from the vehicles ahead and adjust your vehicle speed to the road conditions. Smart Cruise Control may not recognize unexpected and sudden situations or complex driving...
Page 358: Smart Cruise Control Malfunction And Limitations
Have started or when the front view camera the vehicle inspected by an authorized and front radar are initialized. HYUNDAI dealer. Information You may hear sounds when Smart Cruise Control is braking your vehicle. This is normal and does not indicate a malfunction.
Page 359 • Sunlight, streetlight, or light from an uncovered or unblocked, have the vehicle oncoming vehicle is reflected on the inspected by an authorized HYUNDAI wet road surface such as a puddle on dealer. the road.
Page 360 Driver assistance system • Your vehicle height is low or high due to • The front vehicle’s ground clearance is so low or high. heavy loads, abnormal tire pressure, etc. • Your vehicle is being towed. • You are driving through steam, smoke, •...
Page 361 • Driving on a curved road • Driving on an inclined road OADAS014SD OADAS012SD During uphill or downhill driving, Smart Cruise Control may not detect a moving vehicle in your lane, and cause your vehicle to accelerate to the set speed. Also, your vehicle speed rapidly decreases when a vehicle ahead is detected suddenly.
Page 362 Driver assistance system • Changing lanes • Situations when detecting are limited OCN7071130L OADAS030SD [A] Your vehicle OCN7073218 [B] Lane changing vehicle Some vehicles in your lane or in be When a vehicle moves into your lane detected by the sensor: from an adjacent lane, it cannot be detected by the sensor until it is in the - Vehicles offset to one side...
Page 363 - Making sharp steering inputs when driving - Driving on narrow or sharply curved roads Brake as needed to reduce your driving speed. OHI058323L • Always look out for pedestrians when your vehicle is maintaining a distance with the vehicle ahead. OHI058322L •...
Page 364: Navigation-Based Smart Cruise Control (Nscc)
Driver assistance system Navigation-based Smart Navigation-based Smart Cruise Control settings Cruise Control (NSCC) if equipped Highway Auto Speed Change Navigation-based Smart Cruise Control helps maintain the speed depending on the road conditions when driving on highways by using information from the navigation system while Smart Cruise Control is operating.
Page 365: Navigation-Based Smart Cruise Control Operation
Navigation-based Smart Temporarily canceled or interrupted by the driver Cruise Control operation If Navigation-based Smart Cruise Control Navigation-based Smart Cruise Control cannot control the vehicle, such as when may be available when: Smart Cruise Control is temporarily • Highway Auto Speed Change is canceled or the navigation system is selected from the settings menu.
Page 366: Limitations Of Navigation-Based Smart Cruise Control
Driver assistance system Highway Auto Curve Slowdown • The navigation system cannot detect the current vehicle position (e.g. • Depending on the curve ahead on the elevated roads including overpass highway (or motorway), your vehicle adjacent to general roads or nearby decelerates, and after passing the roads exist in a parallel way).
Page 367 • When the vehicle's driving route is recognized as the main road by maintaining the main road instead of the navigation set route, Highway Curve Zone Auto Slowdown function will operate. Depending on the distance to the curve and the current vehicle speed, vehicle deceleration may not be sufficient or may decelerate rapidly.
Page 368 Driver assistance system • Navigation-based Smart Cruise Control Information may not operate depending on the configuration of vehicles detected • There may be a gap in time between the ahead on the road. navigation system’s guidance and when the Navigation-based Smart •...
Page 369: Lane Following Assist (Lfa)
Lane Following Assist Information (LFA) You can set the following Warning Methods: Lane Following Assist uses the front view • Warning Volume/Driving Safety Priority camera to help detect lane markings and/or vehicles on the road, and to For more information, refer to the "Driver provide steering assist to center the assistance system settings"...
Page 370 Driver assistance system Hands-off warning WARNING Always safely steer your vehicle and maintain the position of your vehicle in its lane. To prevent serious injury or death: • Always have your hands on the steering wheel while driving. • Lane Following Assist may not steer if the steering wheel is held too tightly, or the steering wheel is turned too far left or right.
Page 371: Lane Following Assist Malfunction And Limitations
Following Assist system" message may appear, and the warning light may illuminate on the instrument cluster. Have the vehicle inspected by an authorized HYUNDAI dealer. OCN7073210 Limitations of Lane Following Assist • The images and colors in the For more information on Lane Following instrument cluster may differ Assist's limitations, refer to the "Lane...
Page 372: Highway Driving Assist (Hda)
Driver assistance system Highway Driving Assist Information (HDA) Highway Driving Assist uses the following sensors: if equipped • Front view camera Highway Driving Assist uses the front • Front radar view camera and front radar to: Refer to the "Driver assistance system •...
Page 373: Highway Driving Assist Operation
• When there is a problem with Highway Driving Assist, the function cannot be set from the Settings menu. Have the vehicle inspected by an authorized HYUNDAI dealer. • When the engine is restarted, the function maintains the last setting. WARNING...
Page 374 Driver assistance system Hands-off warning Information • For more information on Smart Cruise Control and Lane Following Assist, refer to the "Smart Cruise Control (SCC)" and "Lane Following Assist (LFA)" sections in this chapter. • The images and colors in the instrument cluster may differ depending on the cluster type or theme selected from the settings menu.
Page 375: Highway Driving Assist Malfunction And Limitations
Have the vehicle inspected by an conditions. authorized HYUNDAI dealer. • You may not hear the audible warning WARNING of Highway Driving Assist if the surrounding environment is too noisy.
Page 376: Rear View Monitor (Rvm)
Driver assistance system Rear View Monitor (RVM) Limitations of Highway Driving Assist if equipped Highway Driving Assist may not operate Rear View Monitor uses the wide-rear normally or may not operate if: view camera to display the area behind • The map information differs from the your vehicle to assist you when parking or actual road conditions because the backing up.
Page 377: Rear View Monitor Settings
Rear View Monitor settings Information You can set the following Warning Camera settings Methods: • Parking Safety Priority For more information, refer to the "Driver assistance system settings" section in this chapter. Rear View Monitor operation Parking/View button To change the settings of Rear View Monitor's Display Contents or Display Settings, press the setup icon ( ) on the...
Page 378 Driver assistance system Maintaining rear view Rear top view The rear view will maintain showing on the screen to help you when parking. However, parking guidance is not displayed. Turns on if: You shift the gear from R (Reverse) to N (Neutral) or D (Drive).
Page 379: Rear View Monitor Malfunction And Limitations
HYUNDAI dealer. when parking. • Parking Assist View provides various Limitations of Rear View Monitor view modes of your vehicle's When your vehicle is stopped for a long surroundings.
Page 380: Surround View Monitor Settings
Driver assistance system Surround View Monitor Top View Parking Guidance settings When the Top View Parking Lines (Top view reference lines) is selected, parking guidance is displayed on the right side of Camera settings the Surround View Monitor screen. Information The horizontal guideline of the Rear Top View Parking Guidance shows the distance of 1.6 ft.
Page 381: Surround View Monitor Operation
Surround View Monitor Turns on if: operation • The gear is in N (Neutral) or D (Drive), and your vehicle speed is 6 mph (10 km/h) or less. Parking/View button • You press the Parking/View button (1) when the gear is in N (Neutral) or D (Drive) and your vehicle speed is 6 mph (10 km/h) or less.
Page 382 Driver assistance system Rear view 3D view The rear view appears on the screen when The 3D view shows the image around the the gear is in R (Reverse) or P (Park) to vehicle from various angles. assist parking. The rear view has top view, You can change angles by tapping the front view, and side view.
Page 383: Surround View Monitor Malfunction And Limitations
Assist uses the rear corner radars to help normally, have the vehicle inspected by detect vehicles approaching from the left an authorized HYUNDAI dealer. or right while your vehicle is reversing, and to warn you that a collision is imminent with a warning message and an Limitations of Surround View audible warning.
Page 384: Rear Cross-Traffic Collision-Avoidance Assist Settings
Driver assistance system Rear Cross-traffic Information Collision-Avoidance Assist You can set the Warning Timing and settings following Warning Methods: • Warning Volume/Haptic Warning Rear Cross-Traffic Safety For more information, refer to the "Driver assistance system settings" section in this chapter. Rear Cross-traffic Collision-Avoidance Assist operation...
Page 385 Emergency Braking OCN7073223N To warn you of an approaching vehicle OCN7060116 from the rear left or right of your vehicle, the warning light on the side view mirror may blink, a warning message may appear on the instrument cluster, and an audible warning may sound.
Page 386 Driver assistance system Stopping vehicle and ending brake If a collision is imminent, emergency braking is assisted to help prevent control collision with approaching vehicles from the left and right side or your vehicle. Emergency braking may operate if: • The gear is shifted to R (Reverse). •...
Page 387 • You may not hear the audible warning WARNING of Rear Cross-Traffic Collision-Avoidance Assist if the Braking is not assisted and only a warning surrounding environment is too noisy. is provided when: • During Rear Cross-Traffic • The ESC (Electronic Stability Control) Collision-Avoidance Assist operation, warning light is on.
Page 388: Rear Cross-Traffic Collision-Avoidance Assist Malfunction And Limitations
If the function does not operate normally after anything covering or blocking the sensors is removed, have the vehicle inspected by an authorized HYUNDAI dealer. B0322EU02 When the side view mirror warning light is not working properly, the "Check side...
Page 389 WARNING WARNING • Rear Cross-Traffic Collision-Avoidance • Driving near a vehicle or structure Assist may not operate properly even if there is no warning message or warning light on the instrument cluster. • Rear Cross-Traffic Collision-Avoidance Assist may not operate properly in open areas where no objects are detected (e.g.
Page 390 Driver assistance system • When your vehicle is in a complex • When your vehicle is parked parking environment diagonally OHY059018 OHY059019 Rear Cross-Traffic Collision-Avoidance [A] Vehicle Assist may detect vehicles that are Rear Cross-Traffic Collision-Avoidance parking or pulling out near your vehicle Assist may be limited when backing up (e.g.
Page 391 • Pulling into the parking space where WARNING there is a structure • Rear Cross-Traffic Collision-Avoidance Assist may not operate normally if there is interference from strong electromagnetic waves. • Rear Cross-Traffic Collision-Avoidance Assist may not operate for 3 seconds right after your vehicle is started or when the rear corner radars are initialized.
Page 392: Forward/Reverse Parking Distance Warning (Pdw)
Driver assistance system Forward/Reverse Parking Forward/Reverse Parking Distance Warning operation Distance Warning (PDW) if equipped Parking Safety button Forward/Reverse Parking Distance Warning uses the front and rear ultrasonic sensors to detect and warns you if a person, animal, or object is within a certain distance when your vehicle is stopped or driving at low speed.
Page 393 • The shape of the indicator in the Information illustration may differ from the actual vehicle. • Forward Parking Distance Warning operates only when the vehicle’s forward speed is below 6 mph (10 Reverse Parking Distance Warning km/h). Reverse Parking Distance Warning may •...
Page 394: Forward/Reverse Parking Distance Warning Malfunction And Precautions
(including trailer, carrier, etc., from the • The "Parking sensor error or blockage" rear bumper), have the vehicle inspected warning message may appear on the by an authorized HYUNDAI dealer. instrument cluster. Forward/Reverse Parking Distance Warning precautions • Parking Distance Warning may not...
Page 395 • If the Parking Distance Warning does square column not operate properly, have the vehicle - Objects, which tend to absorb sensor inspected by an authorized HYUNDAI frequency, such as clothes, spongy dealer. material or snow. - Objects smaller than 40 in. (100 cm) in length and narrower than 6 in.
Page 396: Reverse Parking Collision-Avoidance Assist (Pca)
Driver assistance system Reverse Parking Reverse Parking Collision-Avoidance Assist Collision-Avoidance settings Assist (PCA) Parking Safety if equipped Reverse Parking Collision-Avoidance Assist uses the wide-rear view camera and rear ultrasonic sensors to help detect pedestrians or objects when backing up. The function may warn you or assist you with braking to help reduce the possibility of a collision when backing up.
Page 397: Reverse Parking Collision-Avoidance Assist Operation
Reverse Parking • Vehicle speed is below 6 mph (10 km/h). (detecting pedestrians) Collision-Avoidance Assist operation • Vehicle speed is below 1.8 mph (3 km/h). (detecting objects) • Parking Collision-Avoidance Assist Turning Parking Collision Avoidance components such as the rear view Assist On/Off camera and the rear ultrasonic sensors are in normal conditions.
Page 398: Reverse Parking Collision-Avoidance Assist Malfunction And Limitations
"Check Parking Collision-Avoidance Assist system" warning message may appear on the instrument cluster, and Reverse Parking Collision-Avoidance Assist may turn off automatically. Have the vehicle be inspected by an authorized HYUNDAI dealer. 7-116...
Page 399 Reverse Parking Limitations of Reverse Parking Collision-Avoidance Assist disabled Collision-Avoidance Assist Reverse Parking Collision-Avoidance Rear view camera Assist may not assist braking or warn you even if there are pedestrians or objects if: • Any non-factory equipment or accessory is installed on the rear of your vehicle.
Page 400 Driver assistance system • Objects generating excessive noise, • Size, thickness, height, or shape of the object does not reflect ultrasonic waves such as vehicle horns, loud motorcycle well (e.g., pole, bush, curbs, carts, edge engines, or truck air brakes, are near of a wall, etc.).
Page 401 Reverse Parking Collision-Avoidance Assist may not operate properly if the wide angle cameras or the ultrasonic sensor(s) is forcibly moved out of proper alignment. Have the vehicle inspected by an authorized HYUNDAI dealer. 7-119...
Page 402: Driver Assistance System Sensors
Driver assistance system Driver assistance system Information sensors Reverse Parking Collision-Avoidance Assist can detect a pedestrian or an The Driver Assistance system on your object when: vehicle uses cameras and sensors to • A pedestrian is standing behind the detect potential hazards in the vicinity of vehicle.
Page 403: Radars
• Never disassemble the camera sensors or camera sensor assemblies. • Only have the detecting sensor replaced or repaired by an authorized HYUNDAI dealer. • Never install any accessories, stickers, or tint the front windshield. • Always keep the camera dry.
Page 404: Ultrasonic Sensors
• If the radars have been replaced or repaired, have the vehicle inspected by an authorized HYUNDAI dealer. • Use only genuine HYUNDAI parts to repair the bumper where the radar is located. • Do not install a license plate frame or...
Page 405: Declaration Of Conformity
Any non-factory installed equipment or accessories may also interfere with the sensor performance. • If the ultrasonic sensors have been forcibly moved out of proper alignment or are damaged, have the vehicle inspected by an authorized HYUNDAI dealer. OANATEL125 7-123...
Page 406: Rear Corner Radar
Driver assistance system Rear corner radar • For Canada • For USA OANATEL124 • For Canada OANATEL126 OANATEL123 7-124...
Page 407: Emergency Situations
8. Emergency situations Hazard warning flasher ....................8-2 In case of an emergency while driving ................8-2 If the engine stalls while driving ................. 8-2 If the engine stalls at a crossroad or crossing............8-2 If you have a flat tire while driving................8-3 If the engine does not start.....................8-3 Jump starting........................8-4 If the engine overheats ....................8-6...
Page 408: Hazard Warning Flasher
• Turn on your hazard warning flasher. • Try to start the engine again. If your OCN7070001 vehicle does not start, contact an authorized HYUNDAI dealer or seek The hazard warning flashers warn other other qualified assistance. drivers to exercise extreme caution when approaching, overtaking, or passing your vehicle.
Page 409: If You Have A Flat Tire While Driving
If you are If the vehicle still does not start, contact on a divided highway, do not park in the an authorized HYUNDAI dealer for median area between the two traffic assistance. lanes.
Page 410: Jump Starting
Emergency situations Jump starting If acid gets into your eyes, flush your eyes with clean water for at least 15 minutes Jump starting can be dangerous if done and get immediate medical attention. If incorrectly. Follow the jump starting acid gets on your skin, thoroughly wash procedure in this section to avoid serious the area.
Page 411 If your vehicle does not start after a few attempts, it probably requires service. Have your vehicle inspected by an OCN7083097 authorized HYUNDAI dealer. 5. Connect the jumper cables in the exact Disconnect the jumper cables in the exact sequence shown in the illustration. First...
Page 412: If The Engine Overheats
5. If the water pump drive belt is broken or engine coolant is leaking out, stop the engine immediately and call the nearest authorized HYUNDAI dealer for assistance.
Page 413 NOTICE WARNING • Serious loss of coolant indicates a leak in the cooling system. Have the system inspected by an authorized HYUNDAI dealer as soon as possible. Never remove the radiator cap, engine • When the engine overheats from low...
Page 414: Tire Pressure Monitoring System (Tpms)
Emergency situations Tire Pressure Monitoring Check tire pressure System (TPMS) OCN7083056N • You can check the tire pressure in the Driving Assist mode in the instrument OCN7073020N cluster. Refer to the "View modes" section in chapter 4. • Tire pressure appears after a few minutes of driving.
Page 415: Tire Pressure Monitoring System
Driving on a Have the system inspected by an significantly under-inflated tire causes authorized HYUNDAI dealer if: the tire to overheat and can lead to tire 1. The Low Tire Pressure Telltale/TPMS failure.
Page 416: Low Tire Pressure Warning Light
Emergency situations Low tire pressure warning If either telltale illuminates, immediately reduce the vehicle speed, avoid hard light cornering and anticipate increased stopping distances. Stop and check your tires as soon as possible. Inflate the tires to the proper pressure as indicated on the vehicle’s placard or tire inflation pressure label located on the driver’s side center pillar outer panel.
Page 417: Tpms Malfunction Indicator
If you have a flat tire, the Low Tire Pressure and Position telltales come on. Have the flat tire repaired by an OIK083054 authorized HYUNDAI dealer as soon as The TPMS Malfunction Indicator possible or replace the flat tire with the illuminates after it blinks for about one spare tire.
Page 418 • If you feel any vehicle instability, If the indicators do not turn off after a few immediately take your foot off the minutes, visit an authorized HYUNDAI accelerator pedal, apply the brakes dealer. gradually with light force, and slowly move to a safe position off the road.
Page 419: If You Have A Flat Tire
If you have a flat tire Turn the winged hold down bolt counterclockwise to remove the spare tire. WARNING Store the spare tire in the same Follow the instructions in this section compartment by turning the winged hold when replacing a tire to reduce the risk of down bolt clockwise.
Page 420: Jack Label
Emergency situations Jack label OHYK065011 The actual jack label in the vehicle may differ from the illustration. For more detailed specifications, refer to the label attached to the jack. 1. Model Name 2. Maximum allowable load 3. Always apply the parking brake before using a jack. 4.
Page 421: Changing Tires
Changing tires WARNING Because the vehicle may slip or roll off of a jack causing serious injury or death, take the following safety precautions: • NEVER place any portion of your body under the vehicle that is supported by a jack.
Page 422 Double-check each wheel nuts until they are tight. After changing tires, have an authorized HYUNDAI dealer tighten the wheel nuts to their proper torque as soon as possible. Tighten the wheel nuts to 79-94 lbf.ft (11-13 kgf.m).
Page 423 Contact an authorized HYUNDAI dealer • The compact spare tire’s tread life is for assistance. shorter than a regular tire. Inspect your •...
Page 424: Towing
• Do not use tire chains on the compact If towing is necessary, contact an spare tire. Because of the smaller size, a authorized HYUNDAI dealer or a tire chain will not fit properly. commercial tow-truck service. • Do not use the compact spare tire on...
Page 425: Removable Towing Hook
WARNING If your vehicle is equipped with a rollover sensor, place the ignition switch in the LOCK/OFF or ACC position when the vehicle is being towed. The side impact and curtain air bag may deploy if the sensor detects the situation as a rollover. OCN7073012N •...
Page 426: Emergency Towing
OCN7083102 removable hook is not broken or If emergency towing is necessary, damaged. contact an authorized HYUNDAI dealer or • Fasten the towing cable or chain a commercial tow-truck service. securely to the hook. If a tow-truck service is not available in an •...
Page 427 NOTICE To avoid damage to your vehicle and vehicle components when towing: • Always pull straight ahead when using the towing hooks. Do not pull from the side or at a vertical angle. • Do not use the towing hooks to pull the vehicle out of mud, sand, or other conditions from which the vehicle cannot be driven out under its own...
Page 429 9. Maintenance Engine Compartment......................9-4 Maintenance services .....................9-5 Guide to hyundai genuine parts..................9-5 Owner’s responsibility ....................9-6 Owner maintenance precautions ................9-6 Owner maintenance......................9-7 Owner maintenance schedule ..................9-7 Scheduled maintenance services...................9-9 Normal maintenance schedule.................. 9-11 Maintenance under severe usage conditions............9-15 Explanation of scheduled maintenance items .............9-17...
Page 430 Changing coolant ...................... 9-23 Brake fluid........................9-23 Checking the brake fluid level .................. 9-23 Parking brake......................... 9-24 Checking the parking brake..................9-24 Washer fluid........................9-25 Checking the washer fluid level ................9-25 Air cleaner........................9-25 Filter replacement ..................... 9-25 Cabin air filter .........................9-27 Filter inspection ......................9-27 Filter replacement ......................9-27 Wiper blades........................
Page 431 9. Maintenance Radial-ply tires ......................9-44 Low aspect ratio tires ....................9-44 Fuses..........................9-45 Instrument panel fuse replacement ................ 9-46 Engine compartment panel fuse replacement............9-46 Fuse/Relay panel description................... 9-48 Light bulbs........................9-55 Headlight, parking light, Daytime Running Light, turn signal light, side marker replacement .......................9-56 Side repeater light replacement ................
Page 432: Engine Compartment
Maintenance Engine Compartment Smartstream G2.0 OCN7080064L Smartstream G1.6 T-GDI OCN7083001N The actual engine compartment in the vehicle may differ from the illustration. (1) Engine coolant reservoir (2) Brake fluid reservoir (3) Air cleaner (4) Engine oil dipstick (5) Engine oil filler cap (6) Windshield washer fluid reservoir (7) Fuse box (8) Battery...
Page 433: Maintenance Services
HYUNDAI dealer. An authorized HYUNDAI dealer meets HYUNDAI’s high service quality standards and receives technical support from HYUNDAI in order to provide you with a high level of service satisfaction. A100A02L 2. Why Hyundai Genuine Parts?
Page 434: Owner's Responsibility
Owner’s responsibility 3. How can you tell if you are purchasing HYUNDAI Genuine Parts? Maintenance service and record Look for the HYUNDAI Genuine Parts retention are the owner’s responsibility. Logo on the package (see below). Retain documents that show proper...
Page 435: Owner Maintenance
• Check the windshield washer fluid and equipment to do the work, have it level. done by an authorized HYUNDAI dealer. • Check for low or under-inflated tires. Before performing maintenance: • Park your vehicle on level ground. Shift...
Page 436 Maintenance At least monthly: At least once a year: • Check the coolant level in the engine • Clean the body and door drain holes. coolant reservoir. • Lubricate the door hinges and hood • Check the operation of all exterior hinges.
Page 437: Scheduled Maintenance Services
Scheduled maintenance services If any of the following conditions apply, follow the Maintenance Under Severe Usage Conditions. • Repeated driving short distance of less than 5 mi. (8 km) in normal temperature or less than 10 mi. (16 km) in freezing temperature •...
Page 438 Then, select ‘Yes’ when the message "Has the engine oil been changed? Press [Yes] to reset the oil life." appears on the screen. - If there is no alert until the maximum maintenance interval, have the vehicle checked by an authorized HYUNDAI dealer. 9-10...
Page 439: Normal Maintenance Schedule
*3 If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available from your authorized HYUNDAI dealer along with information on how to use them. Do not mix other additives. *4 The drive belt should be replaced when cracks occur or tension is reduced excessively.
Page 440 Maintenance Information • As it is normal for engine oil to be consumed during driving, the amount of engine oil should be checked regularly. • The replacement cycle of engine oil is set by the period which the performance of our recommended engine oil is maintained.
Page 441 Months 12 24 36 48 60 72 84 96 108 120 132 144 156 MAINTENANCE Miles×1,000 8 16 24 32 40 48 56 64 96 104 INTERVALS Km×1,000 13 26 39 52 65 78 91 104 117 130 143 156 169 MAINTENANCE ITEM At first, replace at 120,000 mi.
Page 442 If there are some important safety matters like fuel flow restriction, surging, loss of power, hard starting problem etc, replace the fuel filter immediately regardless of maintenance schedule and consult an authorized HYUNDAI dealer for details. R: Replace or change.
Page 443: Maintenance Under Severe Usage Conditions
Maintenance under severe usage conditions The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Maintenance Maintenance item...
Page 444 Maintenance Maintenance Maintenance Maintenance item Driving condition operation intervals Inspect more frequently Cabin air filter C, E, G depending on the condition Intelligent variable Replace every A, C, D, E, F, G, H, transmission fluid (if 60,000 mi. I, K equipped) (90,000 km) Replace every...
Page 445: Explanation Of Scheduled Maintenance Items
If there is fuel flow restriction, such as radiator, coolant reservoir, hoses, surging, loss of power, or hard starting, and connections for leakage and damage. contact an authorized HYUNDAI dealer to Replace any damaged parts. have the fuel filter replaced immediately. 9-17...
Page 446: Engine Coolant
Have the Intelligent variable transmission Drive shaft and related fluid changed by an authorized HYUNDAI Check the drive shaft, boots, clamps, dealer according to the maintenance rubber couplings, and center-bearing schedule.
Page 447: Engine Oil
Engine oil Smartstream G1.6 T-GDI Checking the engine oil level Engine oil is used for lubricating, cooling, and operating various hydraulic components in the engine. Engine oil consumption while driving is normal, and it is necessary to check and refill the engine oil regularly.
Page 448: Checking The Engine Oil And Filter
Allow the engine to cool before replacing engine oil will gradually degrade during the oil. its use. Have the engine oil and filter changed by an authorized HYUNDAI dealer according to the Oil Life NOTICE Management System instructions or the Maintenance Schedule at the Never add any additives to the engine oil.
Page 449: Engine Coolant
MAX reservoir filled with year-round antifreeze mark. If frequent additions are required, coolant. contact an authorized HYUNDAI dealer. Check the antifreeze protection and WARNING coolant level at least once a year, before the winter season or before traveling to a colder climate.
Page 450 Maintenance WARNING Keep hands, clothing, and tools away from the rotating fan blades of the cooling fan. Always turn off the vehicle unless the OJX1099046 vehicle has to be inspected with the engine on. The cooling fan may operate automatically if the negative (-) battery Recommended coolant terminal is not disconnected.
Page 451: Changing Coolant
Have the coolant changed by an If the level is low, add the specified brake authorized HYUNDAI dealer according to fluid to the MAX level. If the fluid level is the Maintenance Schedule. excessively low or frequent additions are...
Page 452: Parking Brake
If the stroke is more or less than specified, have the system be inspected by an authorized HYUNDAI dealer. Stroke : 5-8 "clicks’’ at a force of 44 lbs (20 kg, 196 N)
Page 453: Washer Fluid
Washer fluid Air cleaner Checking the washer fluid Filter replacement level Type A OCN7090010N OCN7080007 Type B (N Line) Check the fluid level in the washer fluid reservoir and add fluid if necessary. Plain water can be used during summer months if washer fluid is not available.
Page 454 • When removing the air cleaner filter, be careful that dust or dirt does not enter the air intake. It may cause damage. • Use HYUNDAI genuine parts or the equivalent specified for your vehicle. Use of non-genuine parts may damage the air flow sensor.
Page 455: Cabin Air Filter
Cabin air filter 5. Replace the cabin air filter. Filter inspection The cabin air filter must be replaced according to the Maintenance Schedule. If the vehicle operates in severely air-polluted cities or on dusty rough roads for a long time, have it inspected more frequently and replaced immediately.
Page 456: Wiper Blades
Maintenance Wiper blades Front windshield wiper blade replacement This vehicle has a "hidden" wiper design Blade inspection that cannot be lifted when in their bottom resting position. Contamination of the windshield or wiper 1. Within 20 seconds of turning off the blades with foreign substances may engine, lift and hold the wiper lever up reduce the effectiveness of the...
Page 457: Battery
Battery WARNING To prevent serious injury or death to you or bystanders when working near or handling the battery: Always read and follow instructions carefully when handling a battery. OGSR076066 5. Remove the wiper blade from the wiper arm. Wear eye protection designed to protect the eyes from acid splashes.
Page 458: For Longer Battery Life
Maintenance • Lift a battery with a battery carrier or NOTICE with your hands on opposite corners. When lifting a plastic-cased battery, To prevent battery damage: excessive pressure on the case may • Always fully charge the battery and cause battery acid to leak. store indoors when you do not plan to •...
Page 459: Battery Capacity Label
OCN7093041N plenty of ventilation. • CMF60L-DIN/AGM70L-DIN: The • Wear eye protection when checking the HYUNDAI model name of battery battery during charging. Do not contact • 12V: The nominal voltage the battery. This may result in serious 9.60Ah (20HR)/70Ah (20HR): The injury.
Page 460: Reset Items
The vehicle may not maintenance-free and should be serviced restart if you shut it off before the battery by an authorized HYUNDAI dealer. Only had a chance to adequately recharge. charge using fully automatic battery Refer to the "Jump starting"...
Page 461: Tires And Wheels
Tires and wheels Tire care For proper maintenance, safety, and WARNING maximum fuel economy, always maintain the recommended tire Tire failure may cause loss of vehicle inflation pressures and stay within control and result in a collision. To the load limits and weight reduce risk of serious injury or death: distribution recommended for your •...
Page 462: Check Tire Inflation Pressure
HYUNDAI dealer. If you overfill the tire, release air by • Over-inflation produces a harsh pushing on the metal stem in the ride, excessive wear at the center of center of the tire valve.
Page 463: Tire Rotation
Tire rotation WARNING To equalize tread wear, HYUNDAI • Do not use the compact spare tire recommends that the tires be rotated for tire rotation. according to the maintenance • Do not mix bias ply and radial ply schedule or sooner if irregular wear tires under any circumstances.
Page 464: Tire Replacement
• Tires degrade over time, even when they are not being used. Regardless of the remaining tread, HYUNDAI recommends that tires be replaced after six (6) years. • Driving in hot climates or excessive loading may accelerate the tire OLMB073027 aging process.
Page 465: Wheel Replacement
Wheel replacement When replacing the metal wheels for any reason, make sure the new wheels are equivalent to the original factory units in diameter, rim width, and offset. Tire traction Tire traction can be reduced if you B0464EU01 drive on worn tires or the tires that are improperly inflated, or on slippery 1.
Page 466 Maintenance Wheel size designation 3. Checking tire life (TIN: Tire Identification Number) Wheels are also marked with Any tires that are over six years old, important information that you need based on the manufacturing date, if you ever have to replace one. (including the spare tire) must be Example wheel size designation: replaced by new ones.
Page 467 Tread wear 5. Maximum permissible inflation pressure The tread wear grade is a This number is the greatest amount comparative rating based on the of air pressure that should be put in wear rate of the tire when tested the tire. Do not exceed the maximum under controlled conditions on a permissible inflation pressure.
Page 468: Tire Terminology And Definitions
Maintenance Temperature - A, B & C Tire terminology and definitions The temperature grades are A (the highest), B and C representing the tire’s resistance to the generation of Air pressure heat and its ability to dissipate heat The amount of air inside the tire when tested under controlled pressing outward on the tire.
Page 469 Cold tire pressure Kilopascal (kPa) The amount of air pressure in a tire, The metric unit for air pressure. measured in pounds per square inch (psi) or kilopascals (kPa) before a tire Light Truck (LT) tire has built up heat from driving. A tire designated by its manufacturer as primarily intended for use on Curb weight...
Page 470 Maintenance Occupant distribution Recommended inflation pressure Designated seating positions. Vehicle manufacturer’s recommended tire inflation pressure as shown on the tire placard. Outward facing sidewall An asymmetrical tire has a particular Radial ply tire side that faces outward when mounted on a vehicle. The outward A pneumatic tire in which the ply facing sidewall bears white lettering cords that extend to the beads are...
Page 471: All Season Tires
All season tires UTQGS Uniform Tire Quality Grading HYUNDAI specifies all season tires on Standards is a tire information system some models to provide good that provides consumers with ratings performance for use all year round, for a tire’s traction, temperature and including snowy and icy road treadwear.
Page 472: Maintenance
Consult your tire dealer for tire damage with your eyes. If any radial-ply tire repairs. damage is found, contact your authorized HYUNDAI dealer to WARNING replace the tire. Do not mix bias ply and radial ply tires under any circumstances. This may...
Page 473: Fuses
Always replace a blown fuse with one of the same rating. If the replacement fuse blows, this indicates an electrical problem. Avoid using the system involved and contact an authorized HYUNDAI dealer. WARNING 2C_FuseType Never replace a fuse with anything but Cartridge type another fuse of the same rating.
Page 474: Instrument Panel Fuse Replacement
Instrument panel fuse If the headlight, turn signal lights, tail lights, interior lamps does not work and replacement the fuses are undamaged, contact an authorized HYUNDAI dealer. Engine compartment panel fuse replacement Blade fuse OCN7080017 1. Turn off the vehicle.
Page 475 NOTICE Always securely install the fuse panel cover. Water may contact the fuse and cause an electrical failure. Multi fuse (Main fuse) OCN7080020 If the multi fuse or midi fuse is blown, contact an authorized HYUNDAI dealer. 9-47...
Page 476: Fuse/Relay Panel Description
Maintenance Fuse/Relay panel description Instrument panel fuse panel OCN7080024 Inside the fuse panel cover, you can find the label describing fuse names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle. When you inspect the fuse panel on your vehicle, refer to the fuse panel label.
Page 477 Driver’s side fuse panel Fuse Name Fuse Rating Circuit Protected Instrument Cluster, A/C Controller, A/C Control Module, MEMORY1 DRV/PASS Folding Outside Mirror, Crash Pad Switch, Surround View Monitor AIR BAG2 SRS Control Module Lane Keeping Assist Unit (LINE), Crash Pad Switch, IBU, MODULE4 A/T Shift Lever Indicator, Front Console Switch, Surround View Monitor...
Page 478 Maintenance Driver’s side fuse panel Fuse Name Fuse Rating Circuit Protected E/R Junction Block (Power Outlet Relay), AMP, IBU, IAU, Audio, Power Outside Mirror Switch, DC-DC Converter MODULE2 (Smartstream G 2.0 Atkinson ISG only), A/V & Navigation Head Unit, Surround View Monitor SRS Control Module, Passenger Occupant Detection AIR BAG1 Sensor...
Page 479 Engine compartment fuse panel ODN8089017 Inside the fuse panel cover, you can find the panel label describing fuse names and ratings. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle. When you inspect the fuse panel on your vehicle, refer to the fuse panel label. OCN7093029N 9-51...
Page 480 Maintenance Engine compartment fuse panel Type Fuse Name Fuse Rating Circuit Protected [Smartstream G 2.0 Atkinson with AMS2] Alternator, (Fuse - ABS1, ABS2, EOP1, POWER OUTLET1) [Smartstream G 2.0 Atkinson & 150A180A MULTI Smartstream G1.6 T-GDi without AMS2] FUSE-3 Alternator, (Fuse - ABS1, ABS2, POWER OUTLET1) MDPS1 MDPS Unit...
Page 481 Engine compartment fuse panel Type Fuse Name Fuse Rating Circuit Protected POWER Front Power Outlet OUTLET2 COOLING Cooling Fan (Smartstream G 2.0 Atkinson FAN1 only) DCT1 [G4FP] TCM DCT2 [G4FP] TCM ICU Junction Block (Fuse - AIR BAG2, IBU1, BRAKE SWITCH, DOOR LOCK, IAU, MODULE1, SUNROOF,Power Window Relay) Battery Sensor TCU1...
Page 482 Maintenance Engine compartment fuse panel Fuse Name Fuse Rating Circuit Protected WIPER Wiper Motor ECU4 PCM/ECM [G4FM] A/C Compressor (Smartstream G 2.0 Atkinson only) HORN Horn IGN COIL Ignition Coil #1~#4 ECU3 PCM/ECM SENSOR3 E/R Junction Block (Fuel Pump Relay) ECU2 PCM/ECM (Smartstream G1.6 T-GDi only) [G4NS] Variable Intake Solenoid Valve, Oil Pump...
Page 483: Light Bulbs
Light bulbs NOTICE Contact an authorized HYUNDAI dealer to • Be sure to replace the burned-out bulb replace most vehicle light bulbs. It is with one of the same wattage to difficult to replace vehicle light bulbs prevent damage to the fuse or electrical because other parts of the vehicle must wiring system.
Page 484: Headlight, Parking Light, Daytime Running Light, Turn Signal Light, Side Marker Replacement
Headlight/Daytime running light (DRL)/Parking light/Turn signal light/Side marker (LED type) If the LED light does not operate, contact an authorized HYUNDAI dealer for replacement. The LED light cannot be replaced as a single unit. A skilled technician should check or repair the LED light, for it may damage related parts of the vehicle.
Page 485: Side Repeater Light Replacement
OCN7093030N OCN7080074L Type B If the LED light (1) does not operate, contact an authorized HYUNDAI dealer for replacement. The LED light cannot be replaced as a single unit. A skilled technician should check or repair the LED light, for it may damage related parts of the vehicle.
Page 486 Maintenance Tail light/Stop light/Turn signal 6. Remove the socket from the assembly light/Side marker (Outer lamp) (Bulb by turning the socket counterclockwise type) until the tabs on the socket align with the slots on the assembly. 1. Turn off the engine. 7.
Page 487 Stop/Tail light/Rear side marker (LED type) If the LED light does not operate, contact an authorized HYUNDAI dealer for replacement. The LED light cannot be replaced as a single unit. A skilled technician should check or repair the LED light, for it may damage related parts of the vehicle.
Page 488: High Mounted Stop Light Replacement
Maintenance High mounted stop light License plate light bulb replacement replacement OCN7083035 OCN7080032 1. Turn off the engine. 2. Using a flat-blade screwdriver gently pry the lens cover from the lamp housing. 3. Remove the bulb by pulling it straight out.
Page 489: Interior Light Replacement
Interior light replacement Trunk room lamp Map lamp, room lamp, sunvisor lamp, and trunk room lamp (Bulb type) Map lamp OCN7053059 1. Turn off the engine. 2. Using a flat-blade screwdriver, gently pry the lens from the interior lamp housing. 3.
Page 490: Appearance Care
OCN7C052041 Finish maintenance If the LED light does not operate, contact an authorized HYUNDAI dealer for Washing replacement. To help protect your vehicle’s finish from The LED light cannot be replaced as a rust and deterioration, wash it thoroughly single unit.
Page 491 NOTICE WARNING After washing the vehicle, dry the brakes Matte paint finish vehicle (if equipped) by applying them lightly while To prevent damage the matte finish: maintaining a slow forward speed. • Do not go through an automatic car wash with rotating brushes. •...
Page 492 If the vehicle is frame members have drain holes that must not be allowed to clog with dirt. damaged and painting is required, Trapped water in these areas may cause contact an authorized HYUNDAI dealer. rusting. 9-64...
Page 493 By using the most advanced design and construction practices to combat High temperatures may also accelerate corrosion, HYUNDAI produces vehicles of corrosion of parts that are not properly the highest quality. However, this is only ventilated so the moisture can be part of the job.
Page 494: Interior Care
Maintenance To help prevent corrosion Keep paint and trim in good condition Keep your vehicle clean Scratches or chips in the finish must be covered with "touch-up" paint as soon as The best way to prevent corrosion is to possible to reduce the possibility of keep your vehicle clean and free of corrosion.
Page 495 Leather Cleaning the upholstery and interior trim if equipped • Features of seat leather Vehicle interior surfaces - Leather is made from the outer skin if equipped of an animal, which goes through a Remove dust and loose dirt from interior special process to be available for surfaces with a whisk broom or a vacuum use.
Page 496 Maintenance Cleaning the seat belt webbing - Use of proper leather protector may prevent abrasion of the cover and Clean the belt webbing with any mild helps maintain the color. Be sure to soap solution recommended for cleaning read the instructions and consult a upholstery or carpet.
Page 497: Emission Control System
The Evaporative Emission Control System inspected and maintained by an is designed to prevent fuel vapors from authorized HYUNDAI dealer in escaping into the atmosphere. The ORVR accordance with the maintenance system is designed to allow the vapors schedule in this manual.
Page 498: Exhaust Emission Control System
Maintenance 3. Exhaust emission control Operating precautions for catalytic converters system if equipped The Exhaust Emission Control System controls exhaust emissions while WARNING maintaining good vehicle performance. The exhaust system and catalytic system When the engine starts or fails to start, are very hot while the engine is running or excessive attempts to restart the engine immediately after the engine is turned off.
Page 499: Fuel Requirements
• Do not modify or tamper with any part of the engine or emission control system. Have all inspections and adjustments made by an authorized Gasoline engine HYUNDAI dealer. • Avoid driving with an extremely low Unleaded fuel level. Your new vehicle is designed to perform...
Page 500 New Vehicle Limited Warranty. Never add any fuel system cleaning agents or other additives to the fuel tank Gasoline containing MMT other than HYUNDAI fuel additives to prevent damage to the engine and engine Some gasoline contains harmful components.
Page 501: California Perchlorate Notice
The airbag module, safety belt pretensioners, and remote batteries must be disposed of according to Title 22 California Code of Regulations Section 67384.10 (a). Special handling may be necessary. See: www.dtsc.ca.gov/hazardouswaste/perch lorate. Contact an authorized HYUNDAI dealer for handling and disposal. 9-73...
Page 503 Refrigerant label ......................10-11 Air conditioner compressor label .................10-11 Fuel label ........................10-12 Operation in foreign countries ..................10-13 Hyundai vehicle owner privacy policy ................10-14 Vehicle data collection and event data recorders ............. 10-15 Reporting safety defects....................10-16 FCC statement ......................10-17 Consumer information ....................10-18...
Page 504 Vehicle information, reporting safety defects, and consumer information Dimensions Items in. (mm) Overall length 185.4 (4,710) Overall width 72 (1,825) Overall height 55.7 (1,415) 195/65R15 62.7 (1,593) 205/55R16 62.4 (1,585) Front tread 225/45R17 62.2 (1,579) 235/40R18 61.7 (1,566) 195/65R15 63.1 (1,604) 205/55R16 62.8 (1,596) Rear tread...
Page 505: Engine Specification
Engine specification Smartstream Smartstream Item G 2.0 Atkinson G1.6 T-GDi Displacement 121.99 (1,999) 97.52 (1,598) cu. in. (cc) Bore x Stroke 3.19 X 3.81 (81.0 X 97.0) 2.98 X 3.50 (75.6 X 89.0) in. (mm) Firing order 1-3-4-2 1-3-4-2 No. of cylinders 4, in-line 4, in-line 10-3...
Page 506: Bulb Wattage
Vehicle information, reporting safety defects, and consumer information Bulb wattage Light bulb Bulb type Wattage High Headlight Type A Daytime Running Light (DRL)/Parking light High Headlight Type B Front Daytime Running Light (DRL)/Parking light Bulb type Side marker LED type Turn signal light PY21W Side repeater light (Outside mirror)
Page 507 Light bulb Bulb type Wattage Map lamp W10W Room lamp FESTOON Interior Vanity mirror lamp FESTOON Trunk room lamp FESTOON Mood lamp 10-5...
Page 508: Tires And Wheels
Vehicle information, reporting safety defects, and consumer information Tires and Wheels Inflation pressure psi (kPa) Wheel lug nut torque Item Tire Size Wheel Size lbf·ft (kgf·m, N·m) Front Rear 195/65 6.0Jx15 34 (235) 31 (215) 205/55 6.5Jx16 34 (235) 31 (215) Full size tire 225/45...
Page 509: Air Conditioning System
Refrigerant 17.6±0.88 (500±25) R-1234yf oz. (g) Compressor lubricant 3.4 ± 0.3 (100 ± 10) PAG (FD46XG) oz. (g) Contact an authorized HYUNDAI dealer for more information. Volume and weight Smartstream Smartstream G2.0 Atkinson G1.6 T-GDi Items Gross vehicle weight 3,858 (1,750) 4,012 (1,820) lbs.
Page 510: Recommended Lubricants And Capacities
NOTICE Severe engine and transmission damage may result from the use of poor quality fuels and lubricants that do not meet HYUNDAI specifications. Always use high quality fuels and lubricants that meet the specifications listed in the recommended table. 10-8...
Page 511: Recommended Sae Viscosity Number
Recommended SAE viscosity number NOTICE • Always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant. This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads. Cleaning the plug and dipstick areas will prevent dirt and grit from entering the engine and other mechanisms that could be damaged.
Page 512: Vehicle Identification Number (Vin)
Vehicle information, reporting safety defects, and consumer information Vehicle Identification Tire specification and Number (VIN) pressure label Vin label OCN7010009L OCN7010010L The tires supplied on your new vehicle are The VIN is also on a plate attached to the chosen to provide the best performance top of the left side dashboard.
Page 513: Engine Number
Engine number Refrigerant label Smartstream G2.0 Atkinson if equipped OCN7010007L OCN7053060 Smartstream G1.6 T-GDI The refrigerant label provides information such as refrigerant type and amount. (R-1234yf) Air conditioner compressor label OCN7N010020 The engine number is stamped on the engine block as shown in the drawing. OIG019029L A compressor label informs you the type of compressor your vehicle is equipped...
Page 514: Fuel Label
Vehicle information, reporting safety defects, and consumer information Fuel label if equipped The fuel label is attached on the fuel filler door. OTM013030L A. Octane rating of unleaded Gasoline (Petrol) 1. RON/ROZ : Research Octane Number 2. (R+M)/2, AKI : Anti Knock Index B.
Page 515: Operation In Foreign Countries
Operation in foreign countries If you are going to drive your vehicle in another country, be sure to: • Observe all regulations regarding registration and insurance. • Determine that acceptable fuel is available. 10-13...
Page 516: Hyundai Vehicle Owner Privacy Policy
Vehicle information, reporting safety defects, and consumer information Hyundai vehicle owner privacy policy Your Hyundai vehicle may be equipped with technologies and services that use information collected, generated, recorded, or stored by the vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain how these technologies and services collect use and share this information.
Page 517: Vehicle Data Collection And Event Data Recorders
Vehicle data collection and event data recorders This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 518: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying HYUNDAI MOTOR AMERICA. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-9153);...
Page 519: Fcc Statement
FCC statement The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this vehicle: This device complies with Part 15 of the FCC Rules and with Innovation, Science and Economic Development Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1.
Page 520: Consumer Information
This consumer information has been prepared in accordance with regulations issued by the National Highway Traffic Safety Administration of the U.S. Department of Transportation. Your HYUNDAI dealer will help answer any questions you may have as you read this information.
Page 521: Open Source Software Notice
HYUNDAI Motor Company will provide the open source code to you in storage medium such as CD-ROM for minimum charge covering the cost of performing source distribution upon email request to opensource@hyundai.com within a period of 3 years from the date of product purchase.
Page 523 Index...
Page 524 Index Accessing your vehicle ....................... 5-4 Immobilizer system ........................5-14 Remote key ..........................5-4 Smart key .............................5-7 Air cleaner ..........................9-25 Filter replacement ........................9-25 Air conditioner compressor label .................... 10-11 Air conditioning system ......................10-7 Appearance care ........................9-62 Exterior care ..........................
Page 525 Power-assist brakes ......................... 6-28 Vehicle Stability Management (VSM) ..................6-40 Bulb wattage ..........................10-4 Cabin air filter ..........................9-27 Filter inspection ........................9-27 Filter replacement ........................9-27 California perchlorate notice ....................9-73 Center console overview ......................2-5 Child Restraint System (CRS) ....................3-27 Children always in the rear .......................3-27 Installing a Child Restraint System ..................
Page 526 Index Ultrasonic sensors ........................7-122 Driver Attention Warning (DAW) ....................7-56 Driver Attention Warning malfunction and limitations ............7-59 Driver Attention Warning operation ..................7-57 Driver Attention Warning settings ....................7-56 Driving Your Vehicle ........................6-1 Dual Clutch Transmission ......................6-20 Dual Clutch Transmission operation ..................6-21 Good driving practices ......................6-27 Paddle shifter (Manual shift mode) ..................6-27 Parking ............................
Page 527 Highway Driving Assist settings ....................7-90 Hood ............................5-48 Closing the hood ........................5-48 Opening the hood ........................5-48 Hyundai digital key ........................5-14 Digital key (Card key) ........................5-19 Digital key (smartphone) ......................5-14 Limitations of the system ......................5-24 Used vehicle/digital key maintenance ..................5-24...
Page 528 Index HYUNDAI Motor America ......................1-3 Hyundai vehicle owner privacy policy ................... 10-14 Idle Stop and Go (ISG) system ....................6-42 Auto start ........................... 6-43 Auto stop ........................... 6-42 Deactivating the ISG ........................ 6-44 ISG malfunction ........................6-45 Operating conditions ....................... 6-44 Smart ISG features ........................
Page 529 Good driving practices ......................6-18 Intelligent Variable Transmission operation ................6-15 Parking ............................6-18 Interior features .........................5-94 Clock ............................5-99 Coat hook ..........................5-99 Cup holder ..........................5-94 Power outlet ..........................5-95 Sunvisor ............................. 5-95 USB charger ..........................5-96 Wireless smartphone charging system ................... 5-97 Interior lights ..........................5-59 Interior lights auto off .......................
Page 530 Index Maintenance services ......................... 9-5 Guide to hyundai genuine parts ....................9-5 Owner maintenance precautions ....................9-6 Owner’s responsibility ........................ 9-6 Manual climate control system ....................5-67 Heating and air conditioning ....................5-68 System maintenance .........................5-75 System operation ........................5-73 Manual Speed Limit Assist (MSLA) ..................7-49 Manual Speed Limit Assist operation ..................
Page 531 Refrigerant label ........................10-11 Reporting safety defects ......................10-16 FCC statement ......................... 10-17 Reverse Parking Collision-Avoidance Assist (PCA) ...............7-114 Reverse Parking Collision-Avoidance Assist settings ........7-114, 7-115, 7-116 Safe Exit Warning (SEW) ......................7-45 Safe Exit Warning malfunction and limitations ...............7-47 Safe Exit Warning operation ....................
Page 532 Index Slide open/close ........................5-45 Sunroof open warning .......................5-47 Sunshade ........................... 5-44 Tilt open/close .......................... 5-45 Supplemental restraint system - airbags ................3-36 Additional safety precautions ....................3-56 Airbag warning labels ....................... 3-56 How does the airbag system operate? ................... 3-42 Occupant Classification System (OCS) ...................
Page 533 Emergency towing ........................8-20 Removable towing hook ......................8-19 Towing service .......................... 8-18 Trailer towing ..........................6-57 Trunk ............................5-49 Emergency trunk safety release ....................5-50 Smart Trunk release ........................5-51 Vehicle Auto-Shut Off ........................6-13 Deactivating conditions ......................6-13 Operating conditions .........................6-13 System operation ........................6-13 Vehicle certification label .......................

Hyundai Elantra 2024 Owner's Manual

Table of Contents

4. Instrument Cluster

5. Convenience Features

6. Driving Your Vehicle

7. Driver Assistance System

8. Emergency Situations

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Hyundai Elantra 2024

Summary of Contents for Hyundai Elantra 2024
