OWNER'S MANUAL
Operation
Maintenance
Specifications
All information in this Owner's Manual is current at the time
of publication. However, HYUNDAI reserves the right to make
changes at any time so that our policy of continual product
improvement may be carried out.
This manual applies to all HYUNDAI models and includes
descriptions and explanations of optional as well as standard
equipment. As a result, you may find material in this manual
that does not apply to your specific vehicle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elantra N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hyundai Elantra N

Summary of Contents for Hyundai Elantra N

  • Page 1 Maintenance Specifications All information in this Owner’s Manual is current at the time of publication. However, HYUNDAI reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all HYUNDAI models and includes descriptions and explanations of optional as well as standard equipment.
  • Page 2 Introduction CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the U.S.
  • Page 3 HYUNDAI VEHICLE OWNER PRIVACY POLICY Your Hyundai vehicle may be equipped with technologies and services that use information collected, generated, recorded or stored by the vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain how these technologies and services collect use and share this information.

  • Page 4: Table Of Contents

    Table of Contents Foreword Vehicle Information, Consumer Information and Reporting Safety Defects Seats & Safety System Instrument Cluster Convenience Features Driving Your Vehicle Driver Assistance System Emergency Situations Maintenance Index...

  • Page 5: Foreword

    1. Foreword Introduction..................... 1-2 Hyundai Motor America ................. 1-2 Guide to Hyundai Genuine Parts ..............1-3 How to Use This Manual .................1-4 Safety Messages .....................1-4 Fuel Requirements ..................1-5 Gasoline containing alcohol or methanol .............1-6 Using Fuel Additives (except Detergent Fuel Additives) ........1-6 Gasoline containing MMT ..................1-6...

  • Page 6: Introduction

    Your Owner’s Manual will introduce you to the features and operation of your new HYUNDAI. To become familiar with your new HYUNDAI, so that you can fully enjoy it, read this Owner’s Manual carefully before driving your new vehicle.

  • Page 7: Guide To Hyundai Genuine Parts

    In addition, any damage to or failure of HYUNDAI Genuine Parts caused by the installation or failure of an imitation, counterfeit or used salvage part is not covered by any HYUNDAI Warranty. 3. How can you tell if you are purchasing HYUNDAI Genuine Parts? Look for the HYUNDAI Genuine Parts Logo on the package (see below).

  • Page 8: How To Use This Manual

    Foreword HOW TO USE THIS MANUAL SAFETY MESSAGES We want to help you get the greatest Your safety, and the safety of others, possible driving pleasure from your is very important. This Owner’s vehicle. Your Owner’s Manual can assist Manual provides you with many safety you in many ways.

  • Page 9: Fuel Requirements

    CAUTION indicates a hazardous other than what has been specified. situation which, if not avoided, could result in minor or moderate injury. Consult an authorized HYUNDAI dealer for additional information. NOTICE WARNING NOTICE indicates a situation which, if not avoided, could result in vehicle Do not “top off”...

  • Page 10: Gasoline Containing Alcohol Or Methanol

    MMT (Methylcyclopentadienyl exceeding 15 percent. Manganese Tricarbonyl). HYUNDAI does not recommend the use NOTICE of gasoline containing MMT. To prevent damage to your vehicle’s This type of fuel can reduce vehicle...

  • Page 11: Operation In Foreign Countries

    VEHICLE MODIFICATIONS Detergent Fuel Additives This vehicle should not be modified. Modification of your vehicle could HYUNDAI recommends that you use affect its performance, safety or good quality gasolines treated with durability and may even violate detergent additives such as TOP TIER...

  • Page 12: Vehicle Data Collection And Event Data Recorders

    Foreword VEHICLE DATA COLLECTION AND EVENT DATA WARNING RECORDERS CALIFORNIA PROPOSITION 65 WARNING This vehicle is equipped with an event data recorder (EDR). The main purpose Items contained in motor vehicles or of an EDR is to record, in certain crash emitted from them are known to the or near crash-like situations, such as State of California to cause cancer and...

  • Page 13: Vehicle Information, Consumer Information And Reporting Safety Defects

    2. Vehicle Information, Consumer Information and Reporting Safety Defects Exterior Overview (I) ..................2-2 Exterior Overview (II) ..................2-3 Interior Overview (I) ..................2-4 Interior Overview (II) ..................2-5 Instrument Panel Overview (III) ..............2-6 Engine Compartment ..................2-7 Dimensions ..................... 2-8 Engine Specification ..................
  • Page 14 Vehicle Information, Consumer Information and Reporting Safety Defects Front view The actual shape may differ from the illustration. OCN7N011001N 1. Hood ............5-55 5. Sunroof ........... 5-51 2. Headlight ..........9-57 6. Front windshield wiper blades ....9-27 3. Tires and wheels ........9-32 7.
  • Page 15 Rear view The actual shape may differ from the illustration. OCN7N011002N 8. Door ............5-26 12. Defroster / Glass antenna ..5-104/5-113 9. Fuel filler door ........5-62 13. High mounted stop lamp ......9-61 10. Rear combination lamp......9-59 14. Antenna ..........5-113 11.
  • Page 16 Vehicle Information, Consumer Information and Reporting Safety Defects The actual shape may differ from the illustration. OCN7N011010N 1. Inside door handle ........ 5-26 8. Instrument panel illumination control switch ............4-5 2. Side view mirror control switch ... 5-46 9. Lane Safety button ........ 7-15 3.
  • Page 17 Manual transmission Dual clutch transmission The actual shape may differ from the illustration. OCN7N011009N 1. Instrument cluster ........4-4 7. Passenger’s front air bag ..... 3-33 2. Driver’s front air bag ......3-33 8. Glove box ..........5-106 3. Engine Start/Stop button ....... 6-5 9.
  • Page 18 Vehicle Information, Consumer Information and Reporting Safety Defects The actual shape may differ from the illustration. OCN7N011005N 1. Lighting control lever ......5-64 6. N1 button ..........6-43 2. Wiper and washer control lever....5-75 7. LCD display control ......4-25 3.

  • Page 19: Engine Compartment

    ENGINE COMPARTMENT 2.0 T-GDi The actual engine compartment in the vehicle may differ from the illustration. OCN7N091001 1. Engine coolant reservoir .......9-18 6. Windshield washer fluid reservoir ..9-23 2. Brake/clutch fluid reservoir ....9-22 7. Fuse box ..........9-48 3. Air cleaner ..........9-24 8.

  • Page 20: Dimensions

    Vehicle Information, Consumer Information and Reporting Safety Defects DIMENSIONS in. (mm) Items 184.05 (4,675) Overall length 71.85 (1,825) Overall width Overall height 55.71 (1,415) Front tread 245/35 ZR19 62.36 (1,584) Rear tread 245/35 ZR19 62.17 (1,579) Wheelbase 107.09 (2,720) ENGINE SPECIFICATION Item 2.0 T-GDi Displacement...

  • Page 21: Bulb Wattage

    BULB WATTAGE Light bulb Bulb type Wattage High Headlight Daytime running lamp (DRL)/ Position lamp Front Side marker Turn signal lamp PY21W Side repeater lamp (Outside mirror) Stop lamp Tail lamp Side marker Turn signal lamp PY21W Rear License plate lamp Reverse lamp W16W High mounted stop lamp...

  • Page 22: Tires And Wheels

    Vehicle Information, Consumer Information and Reporting Safety Defects TIRES AND WHEELS 2-10...

  • Page 23: Air Conditioning System

    17.6±0.9 (500±25) R-1234yf oz. (g) Compressor lubricant 3.4 ± 0.3 (100 ± 10) PAG (FD46XG) oz. (g) Contact an authorized HYUNDAI dealer for more details. VOLUME AND WEIGHT 2.0 T-GDi Items Gross vehicle weight 4,101 (1,860) 4,178 (1,895) lbs. (kg) Luggage volume 16.38 (464)

  • Page 24: Recommended Lubricants And Capacities

    Vehicle Information, Consumer Information and Reporting Safety Defects RECOMMENDED LUBRICANTS AND CAPACITIES To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy. These lubricants and fluids are recommended for use in your vehicle.

  • Page 25: Recommended Sae Viscosity Number

    Recommended SAE viscosity number CAUTION Always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant. This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads. Cleaning the plug and dipstick areas will prevent dirt and grit from entering the engine and other mechanisms that could be damaged.

  • Page 26: Vehicle Identification Number (Vin)

    Vehicle Information, Consumer Information and Reporting Safety Defects VEHICLE IDENTIFICATION VEHICLE CERTIFICATION LABEL VIN label (if equipped) OCN7010006 OCN7010010L The vehicle certification label attached The vehicle identification number (VIN) on the driver’s (or front passenger’s) is the number used in registering your side center pillar gives the vehicle vehicle and in all legal matters pertaining identification number (VIN).

  • Page 27: Engine Number

    ENGINE NUMBER AIR CONDITIONING REFRIGERANT LABEL OPDEN087012 The engine number is stamped on the OCN7N011021N engine block as shown in the drawing. The refrigerant label provides information such as refrigerant type and AIR CONDITIONER amount. (R-1234yf) COMPRESSOR LABEL OIG019029L A compressor label informs you the type of compressor your vehicle is equipped with such as model, supplier part number, production number, refrigerant...

  • Page 28: Consumer Information

    This consumer information has been prepared in accordance with regulations issued by the National Highway Traffic Safety Administration of the U.S. Department of Transportation.Your HYUNDAI dealer will help answer any questions you may have as you read this information. HYUNDAI motor vehicles are designed and manufactured to meet or exceed all applicable safety standards.

  • Page 29: Reporting Safety Defects

    If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or HYUNDAI MOTOR AMERICA. 2-17...
  • Page 30 3. Seats & Safety System This chapter provides you with important information about how to protect yourself and your passengers. It explains how to properly use your seats and seat belts, and how your air bags work. Additionally, this chapter explains how to properly restrain infants and children in your vehicle. Important Safety Precautions ...............

  • Page 31: Seats & Safety System

    Seats & Safety System IMPORTANT SAFETY PRECAUTIONS You will find many safety precautions Drivers can become distracted when and recommendations throughout this they take their eyes and attention off section, and throughout this manual. the road or their hands off the wheel to The safety precautions in this section are focus on activities other than driving.

  • Page 32: Seats

    SEATS The actual feature in the vehicle may differ from the illustration. OCN7N031142N Driver’s seat Front passenger’s seat (1) Forward and rearward (1) Forward and rearward (2) Seatback angle (2) Seatback angle (3) Seat height...

  • Page 33: Safety Precautions

    Seats & Safety System Safety Precautions NEVER place anything or anyone between the steering wheel and the Adjusting the seats so that you are sitting air bag. in a safe, comfortable position plays an Do not allow the front passenger to important role in driver and passenger place feet or legs on the dashboard safety together with the seat belts and...

  • Page 34: Front Seats

    Front Seats Manual adjustment The front seat can be adjusted by using the levers located on the outside of WARNING the seat cushion. Before driving, adjust Take the following precautions when the seat to the proper position so that adjusting your seat: you can easily control the steering wheel, foot pedals and controls on the NEVER attempt to adjust the seat...
  • Page 35 Seats & Safety System Seat belts must be snug against your hips and chest to work properly. When the seatback is reclined, the shoulder belt cannot do its job because it will not be snug against your chest. Instead, it will be in front of you. During an accident, you could be thrown into the seat belt, causing neck or other injuries.

  • Page 36: Rear Seats

    Rear seats - When returning the rear seatback from a folded to an upright position, hold the seatback and WARNING return it slowly. Ensure that the seatback is completely locked into Take the following precautions: its upright position by pushing Adjusting the seats on the top of the seatback.
  • Page 37 Seats & Safety System Folding the rear seat (if equipped) CAUTION The rear seatbacks can be folded to Do not allow your hands or fingers to facilitate carrying long items or to get caught in the seat mechanisms increase the luggage capacity of the while adjusting the seats.

  • Page 38: Head Restraints

    Head Restraints The vehicle’s rear seats have adjustable head restraints. The headrests provide comfort for passengers, but more importantly they are designed to help protect passengers from whiplash and other neck and spinal injuries during an accident, especially in a rear impact collision.
  • Page 39 Seats & Safety System NOTICE Rear seat head restraints To prevent damage, NEVER hit or pull on the head restraints. CAUTION When there is no occupant in the rear seats, adjust the height of the head restraint to the lowest position. The rear seat head restraint can reduce the visibility of the rear area.

  • Page 40: Seat Warmers

    Seat Warmers WARNING Front seat warmers NEVER place anything on the seat Seat warmers are provided to warm the that insulates against heat when the seats during cold weather. seat warmer is in operation, such as a blanket or seat cushion. This may cause the seat warmer to overheat, causing a WARNING burn or damage to the seat.
  • Page 41 Seats & Safety System Automatic temperature control The seat warmer starts to automatically control the seat temperature in order to prevent low-temperature burns after being manually turned ON. - Front seat LOW ( OCN7N031024 While the engine is running, push either of the switches to warm the driver’s seat You may manually press the switch to or front passenger’s seat.

  • Page 42: Seat Belts

    SEAT BELTS This section describes how to use the Do not latch the seat belt into the seat belts properly. It also describes buckles of other seats. some of the things to avoid when using NEVER unfasten the seat belt seat belts.

  • Page 43: Seat Belt Warning Light

    Seats & Safety System Seat Belt Warning Light Seat Belt Restraint System Seat belt warning WARNING Instrument cluster (Driver and front passenger’s seat) Improperly positioned seat belts may increase the risk of serious injury in an accident. Take the following precautions when adjusting the seat belt: Position the lap portion of the seat...
  • Page 44 NOTICE Seat Belt-Driver’s 3-point system with emergency locking retractor If you are not able to smoothly pull enough of the seat belt out from the retractor, firmly pull the seat belt out and release it. After release, you will be able to pull the belt out smoothly.
  • Page 45 Seats & Safety System To fasten your seat belt: Pull the seat belt out of the retractor and insert the metal tab into the buckle. There will be an audible “click” when the tab locks into the buckle. When not securing a child restraint, the seat belt operates in the same way as the driver’s seat belt (Emergency Locking Retractor Type).
  • Page 46 Rear center seat belt Pre-tensioner seat belt (Driver and front passenger) OCN7030027L When using the rear center seat belt, the OHI038143L buckle with the “CENTER” mark must be Your vehicle is equipped with driver’s used. and front passenger’s Pre-tensioner Seat Belts (Retractor Pre-tensioner). The purpose of the pre-tensioner is to make WARNING sure the seat belts fit tightly against the...
  • Page 47 SRS air bag is not malfunctioning. If the warning light does not illuminate, stays illuminated or illuminates when the vehicle is being driven, have an authorized HYUNDAI dealer inspect the pre-tensioner seat belts and SRS air bags as soon as possible.

  • Page 48: Additional Seat Belt Safety Precautions

    NOTICE Additional Seat Belt Safety Precautions Both the driver’s and front Seat belt use during pregnancy passenger’s pre-tensioner seat belts may be activated in certain frontal or The seat belt should always be used side collisions or rollovers. during pregnancy. The best way to When the pre-tensioner seat belts protect your unborn child is to protect are activated, a loud noise may be...
  • Page 49 Always have the LATCH system vehicle. inspected by your authorized HYUNDAI dealer after an accident. An accident can damage the LATCH system and may not Small children are best protected properly secure the child restraint.

  • Page 50: Care Of Seat Belts

    Additional questions concerning the rear seat or if the front or rear seats seat belt operation should be directed to are in a reclined position. an authorized HYUNDAI dealer. WARNING NEVER ride with a reclined seatback when the vehicle is moving.

  • Page 51: Child Restraint System (Crs)

    Federal Motor Vehicle Safety Standards (FMVSS 213). After an accident, have a HYUNDAI dealer check the child restraint Child restraint systems are generally system, seat belts, tether anchors designed to be secured in a vehicle seat and lower anchors.

  • Page 52: Selecting A Child Restraint System (Crs)

    Selecting a Child Restraint System (CRS) When selecting a CRS for your child, always: Make sure the CRS has a label certifying that it meets applicable Federal Motor Vehicle Safety Standards (FMVSS 213). Select a child restraint based on your child’s height and weight. The required label or the instructions for OCN7N031029 use typically provide this information.

  • Page 53: Installing A Child Restraint System (Crs)

    Seats & Safety System Installing a Child Restraint System (CRS) WARNING Before installing your child restraint system always: Read and follow the instructions provided by the manufacturer of the child restraint. Read and follow the instructions OCN7N031030 regarding child restraint systems in Forward-facing child restraints this manual.
  • Page 54 After selecting a proper child seat Lower Anchors and Tether for for your child, check to make sure it Children (LATCH System) fits properly in your vehicle. Follow The LATCH system holds a child restraint the instructions provided by the during driving and in an accident.
  • Page 55 If anchors according to the instructions necessary, have the vehicle inspected provided by the child restraint by an authorized HYUNDAI dealer. manufacturer. 4. Follow the child restraint instructions for properly adjusting and tightening the lower attachments on the child restraint to the lower anchors.
  • Page 56 Always have the LATCH system anchor. inspected by your authorized HYUNDAI dealer after an accident. Child restraint hook holders are located An accident can damage the LATCH on the rear of the seatbacks.
  • Page 57 Seats & Safety System OCN7N031031 OHI038145 To install the tether anchor: Automatic locking mode 1. Route the child restraint tether strap Since all passenger seat belts move over the child restraint seatback. freely under normal conditions and Route the tether strap under the only lock under extreme or emergency head restraint and between the head conditions (emergency locking mode),...
  • Page 58 To install a child restraint system on the rear seats, do the following: 1. Place the child restraint system on a rear seat and route the lap/ shoulder belt around or through the child restraint, following the restraint manufacturer’s instructions. Be sure the seat belt webbing is not twisted.
  • Page 59 Seats & Safety System If your CRS (child restraint system) manufacturer instructs or recommends you to use a tether anchor with the lap/ shoulder belt, refer to the previous pages for more information. Information When the seat belt is allowed to retract to its fully stowed position, the retractor will automatically switch from the “Automatic Locking”...
  • Page 60 The actual air bags in the vehicle may differ from the illustration. OCN7N031060N 1. Driver’s front air bag 2. Passenger’s front air bag 3. Side air bag 4. Curtain air bag 3-31...
  • Page 61 Seats & Safety System This vehicle is equipped with an Advanced Supplemental Air Bag System for the driver’s seat and front passenger’s seats. The front air bags are designed to supplement the three-point seat belts. For these air bags to provide protection, the seat belts must be worn at all times when driving. You can be severely injured or killed in an accident if you are not wearing a seat belt.

  • Page 62: Where Are The Air Bags

    Where Are the Air Bags? Driver’s front air bag Driver’s and passenger’s front air bags Your vehicle is equipped with an Advanced Supplemental Restraint System (SRS) and lap/shoulder belts at both the driver and passenger seating positions. The SRS consists of air bags which are located in the center of the steering wheel, in the driver’s side lower crash OCN7N031036...
  • Page 63 Seats & Safety System Side air bags WARNING Front seat To reduce the risk of serious injury or death from inflating front air bags, take the following precautions: Seat belts must be worn at all times to help keep occupants positioned properly.
  • Page 64 ON position as this may to deploy in all side impact or rollover cause the side air bags to inflate. situations. If the seat or seat cover is damaged, have the vehicle checked and repaired by an authorized HYUNDAI dealer. 3-35...

  • Page 65: How Does The Air Bag System Operate

    If (9) Side impact sensors (acceleration) necessary, have the air bag inspected (10) Side impact sensors (pressure) by an authorized HYUNDAI dealer. (11) Occupant classification system (12) Driver’s and front passenger’s seat belt buckle sensors...
  • Page 66 The light blinks when the engine is In addition to inflating in certain side running. collisions, vehicles equipped with a Have an authorized HYUNDAI dealer rollover sensor, side and curtain air inspect the SRS as soon as possible if bags will inflate if the sensing system any of these conditions occur.
  • Page 67 Seats & Safety System To help provide protection, the air WARNING bags must inflate rapidly. The speed To reduce the risk of serious injury or of air bag inflation is a consequence death from an inflating air bag, take the of extremely short time in which following precautions: to inflate the air bag between the...
  • Page 68 Driver’s front air bag (1) Driver’s front air bag (3) ODN8039077L ODN8039079L When the SRSCM detects a sufficiently Passenger’s front air bag severe impact to the front of the vehicle, it will automatically deploy the front air bags. Driver’s front air bag (2) ODN8039080L After complete inflation, the air bag immediately starts deflating, enabling...

  • Page 69: What To Expect After An Air Bag Inflates

    Always wash exposed skin areas thoroughly with cold water and mild soap. Always have an authorized HYUNDAI dealer replace the air bag immediately after deployment. Air bags are designed to be used only once. 3-40...

  • Page 70: Occupant Classification System (Ocs)

    Occupant Classification System Main components of the Occupant Classification System (OCS) A detection device located within the front passenger seat cushion. Electronic system to help determine whether the passenger air bag systems should be activated or deactivated. An indicator light located on the overhead console which illuminates the words “PASSENGER AIR BAG OFF”...
  • Page 71 Seats & Safety System Front passenger seat adult occupants The OCS may not function properly if the who are properly seated and wearing the passenger takes actions which can affect seat belt properly, should not cause the the classification system. These include: passenger air bag to be automatically Failing to sit in an upright position.
  • Page 72 Condition and operation in the front passenger Occupant Classification System Indicator/Warning light Devices Condition detected by the “PASSENGER SRS warning Front passenger occupant classification system AIR BAG OFF” light air bag indicator light 1. Adult Activated 2. Infant or child restraint system with 12 months old Deactivated *3 *4...
  • Page 73 Seats & Safety System WARNING Riding in an improper position or placing weight on the front passenger’s seat when it is unoccupied by a passenger adversely affects the OCS. To reduce the risk of serious injury or death: NEVER put a heavy load in the front seat or seatback pocket, or hang any items on the front passenger seat.
  • Page 74 Do not place any items under the front passenger seat. When changing or replacing the seat or seat cover, use original items only. The OCS has been developed based on using original HYUNDAI car seats only. Altering or changing the authentic parts may result in system malfunction and increase risk of injury when in collision.
  • Page 75 Seats & Safety System WARNING NEVER allow an adult passenger to ride in the front passenger seat when the “PASSENGER AIR BAG OFF” indicator is illuminated. During a collision, the air bag will not inflate if the indicator is illuminated. Have your passenger reposition themselves in the seat.

  • Page 76: Why Didn't My Air Bag Go Off In A Collision

    Do not install bumper guards or replace the bumper with a non- Always properly restrain children in genuine HYUNDAI parts. This may an appropriate child restraint in the adversely affect the collision and air rear seat of the vehicle.
  • Page 77 Seats & Safety System Air bag collision sensors OCN7N031045N/OCN7030046/OCN7N031047N/OCN7030048/OCN7N031062N 1. SRS control module / Rollover sensor 2. Front impact sensor 3. Side impact sensor (Acceleration) (B-PILLAR) 4. Side impact sensor (Pressure) (FR DOOR) 3-48...
  • Page 78 Air bag inflation conditions Side and curtain air bags Side and curtain air bags are designed to inflate when an impact is detected by side collision sensors depending on the severity, speed or angles of impact resulting from a side impact collision. Although the driver’s and front passenger’s air bags are designed to inflate in frontal collisions, they also may...
  • Page 79 Seats & Safety System Air bag non-inflation conditions OCN7N031144N Front air bags may not inflate in side OCN7N031051L impact collisions, because occupants In certain low-speed collisions the air move in the direction of the collision, bags may not deploy. The air bags are and thus in side impacts, front air bag designed not to deploy in such cases deployment would not provide additional...
  • Page 80 OCN7N031054L OCN7N031055 Just before impact, drivers often brake Air bags may not inflate if the vehicle heavily. Such heavy braking lowers the collides with objects such as utility poles front portion of the vehicle causing it or trees, where the point of impact is to “ride”...

  • Page 81: Srs Care

    HYUNDAI dealer. Do not place objects over or near Any work on the SRS system, such as the air bag modules on the steering...

  • Page 82: Additional Safety Precautions

    Modifications to accommodate disabilities. If you require modification to your vehicle to accommodate a disability, contact the HYUNDAI Customer Connect Center at 800-633- 5151. Adding equipment to or modifying your air bag equipped vehicle If you modify your vehicle by changing your vehicle’s frame, bumper system,...

  • Page 83: Instrument Cluster

    4. Instrument Cluster Instrument Cluster ..................4-4 Instrument Cluster Control ..................4-5 Instrument panel illumination ................4-5 Gauges and Meters ....................4-5 Speedometer ......................4-5 Tachometer ......................4-6 Engine Coolant Temperature Gauge ..............4-6 Fuel Gauge ......................4-7 Outside Temperature Gauge .................4-8 Odometer .......................4-8 Distance to empty ....................4-9 Fuel economy (Normal mode) ................4-9 CUSTOM mode settings ..................4-9...
  • Page 84 N Mode Indicator Light ..................4-20 CUSTOM Mode Indicator Light ................4-20 REV (Rev Matching) Indicator Light ..............4-20 Icy Road Warning Light ..................4-20 LCD Display Messages ....................4-21 Key not in vehicle (for smart key system) ............4-21 Key not detected (for smart key system).............4-21 Press START button with key (for smart key system) .........4-21 Press START button again (for smart key system) ..........4-21 Low Key Battery (for smart key system) ..............4-21...
  • Page 85 4. Instrument Cluster LCD Display ....................4-25 LCD Display Control ....................4-25 View Modes ......................4-26 Driving Assist mode ..................... 4-27 Sport view......................4-27 Trip computer mode .................... 4-29 Turn By Turn (TBT) mode ..................4-29 Master warning mode ..................4-30 User Settings Mode ....................4-31 Trip Computer......................

  • Page 86: Instrument Cluster

    Instrument Cluster INSTRUMENT CLUSTER Normal mode (Type A) N mode (Type B) The actual cluster in the vehicle may differ from the illustration. For more details, refer to the “Gauges and Meters” in this chapter. OOSN041001N/OCN7N041130N 1. Tachometer 4. Fuel gauge 2.
  • Page 87 Instrument Cluster Control Gauges and Meters Instrument panel illumination Speedometer Normal mode MPH, km/h OUS4041035L OCN7N041131N When the vehicle’s parking lights or N mode headlights are on, press the illumination control switch to adjust the brightness of the instrument panel illumination. When pressing the illumination control switch, the interior switch illumination intensity also adjusted.
  • Page 88 Instrument Cluster Tachometer Engine Coolant Temperature Gauge Normal mode Normal mode OCN7040007 OCN7040009 N mode N mode OCN7N041133N OCN7N041134N The tachometer indicates the This gauge indicates the temperature approximate number of engine of the engine coolant when the Engine revolutions per minute (RPM). Start/Stop button is in the ON position.
  • Page 89 Fuel Gauge Information Normal mode The fuel tank capacity is given in chapter 2. The fuel gauge is supplemented by a low fuel warning light, which will illuminate when the fuel tank is nearly empty. On inclines or curves, the fuel gauge pointer may fluctuate or the low fuel warning light may come on earlier than usual due to the movement of fuel in...

  • Page 90: Outside Temperature Gauge

    Instrument Cluster Outside Temperature Gauge Odometer Normal mode N mode Normal mode N mode OCN7N041129N OCN7N041124N OCN7040015N OCN7N041135N This gauge indicates the current outside The odometer indicates the total air temperatures either in Celsius (°C) or distance that the vehicle has been Fahrenheit.

  • Page 91: Distance To Empty

    Distance to empty Fuel economy (Normal mode) Normal mode N mode OCN7040016N OOSN041023N OCN7N041114N The distance to empty is the The average fuel economy (1) and instant estimated distance the vehicle can be fuel economy (2) is displayed at the driven with the remaining fuel.

  • Page 92: Transmission Shift Indicator

    Instrument Cluster Transmission Shift Indicator Normal mode Normal mode OOSN041036N N mode OCN7040013 N mode OBC3N040020 In the manual shift mode, this indicator OCN7N041138N informs which gear is desired while This indicator displays which shift lever driving to save fuel. position is selected.

  • Page 93: Warning And Indicator Lights

    In this case, have the vehicle 2. With the engine stopped, check inspected by an authorized HYUNDAI the brake fluid level immediately dealer. and add fluid as required (For more information, refer to "Brake Fluid" in chapter 9).

  • Page 94: Anti-Lock Brake System (Abs) Warning Light

    If the brakes fail while you are driving, In this case, have the vehicle shift to a lower gear for additional engine inspected by an authorized HYUNDAI braking and stop the vehicle as soon as it dealer. is safe to do so.

  • Page 95: Malfunction Indicator Lamp (Mil)

    Have the vehicle inspected by an If this occurs, have the vehicle authorized HYUNDAI dealer as soon as inspected by an authorized HYUNDAI possible. dealer. Information...

  • Page 96: Charging System Warning Light

    In this case, have the vehicle inspected by an authorized HYUNDAI dealer as Information soon as possible. If you travel approximately 30 ~ 60 miles (50 km ~100 km) after the engine warms up, after adding the engine oil, the warning light will go off.

  • Page 97: Engine Oil Pressure Warning Light

    If the warning light remains on after adding oil or if oil is not available, have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. This warning light illuminates: Continued driving with the warning When there is a malfunction in operation light on may cause engine failure.

  • Page 98: Low Tire Pressure Warning Light

    6. When there is a malfunction with the TPMS. In this case, have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. For more information, refer to "Tire Pressure Monitoring System (TPMS)" in chapter 8.

  • Page 99: Electronic Stability Control (Esc) Off Indicator Light

    If the smart key is in the vehicle and the Engine Start/Stop button is ON, but the vehicle cannot detect the smart key. In this case, have the vehicle inspected by an authorized HYUNDAI dealer. This indicator light blinks: When there is a malfunction with the immobilizer system.
  • Page 100 LED headlight. - The turn signal indicator light blinks If this occurs, have your vehicle rapidly inspected by an authorized HYUNDAI dealer. - The turn signal indicator light does not illuminate at all NOTICE...

  • Page 101: Forward Safety Warning Light

    For more details, refer to “Drive Mode Forward Collision-Avoidance Assist. In Integrated Control System” in chapter this case, have your vehicle inspected by an authorized dealer of HYUNDAI. For more information, refer to "Forward Collision-Avoidance Assist (FCA)" in chapter 7.

  • Page 102: Eco Mode Indicator Light

    Instrument Cluster ECO Mode Indicator Light (if Icy Road Warning Light (if equipped) equipped) This indicator light illuminates: This indicator light illuminates: When you select “ECO” mode as drive This warning light is to warn the driver mode. the road may be icy. For more details, refer to “Drive Mode When the temperature on the outside Integrated Control System”...

  • Page 103: Lcd Display Messages

    Engine Start/Stop If this occurs, attempt to start the engine button, have your vehicle inspected by by pressing the Engine Start/ Stop button an authorized HYUNDAI dealer. again. Low Key Battery (for smart key If the warning message appears each...

  • Page 104: Check Brake Switch Fuse (For Smart Key System And Dual Clutch Transmission)

    If the warning message appears after removing the non-factory electrical accessories, have the vehicle inspected by an authorized HYUNDAI dealer. OCN7N041018L This warning is displayed if you turn off the engine when the sunroof is open.

  • Page 105: Lights Mode

    Lights mode Low pressure OIK040075L OCN7N041026L This indicator displays which exterior This warning message is displayed if the light is selected using the lighting tire pressure is low. The corresponding control. tire on the vehicle will be illuminated. For more details, refer to “Tire Pressure Wiper mode Monitoring System (TPMS)”...

  • Page 106: Low Fuel

    We recommend that you have A corresponding bulb may need to be the vehicle inspected by an authorized replaced. HYUNDAI dealer. Make sure to replace the burned out bulb with a new one of the same wattage rating 4-24...

  • Page 107: Lcd Display

    LCD DISPLAY LCD Display Control OCN7N071128L The LCD display modes can be changed by using the control buttons. Switch Function MODE button for changing modes MOVE switch for changing items SELECT/RESET button for setting or resetting the selected item 4-25...

  • Page 108: View Modes

    Instrument Cluster View Modes View modes Symbol Explanation This mode displays the state of : - Lane Keeping Assist - Driver Attention Warning Driving Assist For more information, refer to “Lane Keeping Assist (LKA)", "Driver Attention Warning (DAW)" in chapter 7. The Sport menu displays Oil Temp./Engine Temp., Turbo/ Sport Torque, Lap Timer and G-Force.

  • Page 109: Driving Assist Mode

    Driving Assist mode Sport view OCN7N071141L OOSN041026N Oil Temp./Engine Temp. This mode displays the state of Lane This mode displays information related Keeping Assist. to your engine such as oil temperature (1) and engine temperature (2). For more details, refer to each function information in chapter 7.
  • Page 110 Instrument Cluster OBC3N040026 OBC3N040028 To reset (C): Press and hold the OK button for more than 1 second on the steering wheel when the lap timer has stopped counting the current lap (2). To save laps: Press the OK button shortly on the steering wheel while the lap timer is counting the current lap (2).

  • Page 111: Trip Computer Mode

    Trip computer mode OBC3N040029 G-Force OOSN041024N This mode displays the force delivered to The trip computer mode displays the vehicle laterally while the vehicle is information related to vehicle driving in motion. parameters including fuel economy, tripmeter information and vehicle speed. For more information, refer to "Trip Computer"...

  • Page 112: Master Warning Mode

    Instrument Cluster Master warning mode OCN7N041115L Tire Pressure OIG059097L This mode displays information related to This warning light informs the driver the Tire Pressure. following situations. For more details, refer to "Tire Pressure - Forward Collision-Avoidance Assist Monitoring System (TPMS)" in chapter malfunction - Blind-Spot Collision Warning malfunction (if equipped)

  • Page 113: User Settings Mode

    User Settings Mode Shift to P to edit settings / Engage parking brake to edit settings This warning message illuminates if you try to select an item from the User Settings mode while driving. Dual clutch transmission For your safety, change the User Settings after parking the vehicle, applying the parking brake and moving the shift level to P(Park).
  • Page 114 Instrument Cluster 1. Driver Assistance Items Explanation Driving Safety Automatically disabling of the driving safety systems when N mode is Auto OFF in N selected. mode To adjust the warning timing of the driver assistance system. Warning Timing Standard / Late To adjust the warning volume of the driver assistance system.
  • Page 115 2. Door Items Explanation Enable on Shift: All doors will be automatically locked if the automatic transmission/dual clutch transmission shift lever is moved from the P (Park) position to the R (Reverse), N (Neutral), or D (Drive) position. (Only when the engine is running) Auto Lock Enable on Speed: All doors will be automatically locked when the vehicle speed exceeds 9.3mph (15km/h).
  • Page 116 Instrument Cluster 4. Sound Items Explanation Cluster Voice To adjust the cluster voice guidance volume. Guidance Volume Welcome To activate or deactivate the welcome sound. sound 5. Convenience Items Explanation Off: The seat easy access function is deactivated. Normal/Extended: When you turn off the engine, the driver’s seat Seat Easy will automatically move rearward short (Normal) or long (Extended) Access...
  • Page 117 Information To use the service interval menu, we recommend that you consult an authorized HYUNDAI dealer. If the service interval is activated and the time and distance is adjusted, messages are displayed in the following situations each time the vehicle is turned on.
  • Page 118 Instrument Cluster 8. Other Items Explanation Off: The average fuel economy will not reset automatically whenever refueling. After ignition: When the engine has been OFF for 4 hours or longer the average fuel economy will reset automatically. Fuel Econ. Reset After refueling: The average fuel economy will reset automatically after adding 1.6 gallon (6 liters) of fuel or more and after driving speed exceeds 1 mph (1 km/h).

  • Page 119: Trip Computer

    Trip Computer The trip computer is a microcomputer- controlled driver information system that displays information related to driving. Information Some driving information stored in the trip computer (for example Average Vehicle Speed) resets if the battery is disconnected. OCN7N071128L To change the trip mode, toggle the " Trip modes "...
  • Page 120 Instrument Cluster Type A Type B Type A Type B OTMA040014 OOSN041027N OTMA040016 OOSN041028N Since refuel(l)ing Accumulated info Trip distance (1), average fuel economy Accumulated trip distance (1), average (2), and total driving time (3) after the fuel economy (2), and total driving time vehicle has been refueled are displayed.

  • Page 121: Setting Your Vehicle

    Vehicle Settings in the infotainment Setting Your Vehicle system provides user options for a variety of settings including door lock/ unlock features, convenience features, driver assistance settings, etc. OCN7N041093 1. Press the SETUP button on the main keyboard. OCN7N041122L Vehicle Settings menu - Driver Assistance - Cluster - Climate...

  • Page 122: Convenience Features

    Smart Key Precautions ..................... 5-9 Battery Replacement ....................5-10 Immobilizer System ....................5-11 Hyundai Digital Key ....................5-12 Operating Door Locks from Outside the Vehicle ..........5-27 Operating Door Locks from Inside the Vehicle ............ 5-28 Automatic Door Lock and Unlock Features ............5-30 Child-Protector Rear Door Locks ................
  • Page 123 Hood ......................5-56 Trunk ......................5-58 Emergency Trunk Safety Release ................5-59 Smart Trunk Release ....................5-60 Fuel Filler Door .....................5-63 Exterior Lights ....................5-65 Lighting Control...................... 5-65 High Beam Operation ....................5-66 Turn Signals And Lane Change Signals ..............5-67 Battery Saver Function ..................5-68 Headlight Delay Function ..................5-68 High Beam Assist (HBA) ................5-69 Detecting Sensor ....................5-69...
  • Page 124 5. Convenience Features Windshield Defrosting and Defogging ............5-101 Manual Climate Control System................5-101 Automatic Climate Control System..............5-102 Defogging Logic ....................5-103 Auto Defogging System (only for automatic climate control system) ....5-104 Defroster ........................5-105 Climate Control Additional Features ............5-106 Sunroof Inside Air Recirculation ................

  • Page 125: Smart Key

    Convenience Features SMART KEY Locking OCN7N051005N Your HYUNDAI uses a Smart Key, which OCN7N051078L you can use to lock or unlock a door (and To lock : trunk) and even start the engine. 1. Close all doors, engine hood and 1.

  • Page 126: Unlocking Your Vehicle (When The Two Press Unlock Feature Is Off)

    Even though you press the outside Unlocking your vehicle door handle button, the doors will not (When the Two Press Unlock lock and the chime will sound for three feature is off) seconds if any of the following occur: Button type The Smart Key is in the vehicle.
  • Page 127 Convenience Features Unlocking your vehicle Two Press Unlock Feature (When the Two Press Unlock The priority for unlocking the driver door feature is on) only, or unlocking all the doors with one press may be adjusted in the User 1. Make sure you have the smart key in Settings mode in the cluster LCD display.

  • Page 128: Trunk Unlocking

    Trunk Unlocking Remotely Starting Vehicle To unlock: You can start the vehicle using the Remote Start button (3) on the smart key. 1. Carry the smart key. To start the vehicle remotely: 2. Either press inside the trunk emblem or press the Trunk Unlock button (4) 1.

  • Page 129: Start-Up

    Always have the smart key with you the vehicle and remaining key to your when leaving the vehicle. If the smart authorized HYUNDAI dealer or tow the key is left near the vehicle, the vehicle vehicle, if necessary. battery may be discharged.

  • Page 130: Smart Key Precautions

    HYUNDAI dealer. Information If the smart key is in close proximity to your mobile phone, the signal could be...

  • Page 131: Battery Replacement

    If you suspect your smart key might have sustained some damage, or you feel OCN7N051006 your smart key is not working correctly, it is recommended that you contact an authorized HYUNDAI dealer. Information An inappropriately disposed battery can be harmful to the environment and human health.

  • Page 132: Immobilizer System

    If the system repeatedly does not interference that may cause undesired recognize the coding of the key, contact operation. your HYUNDAI dealer. 3. Changes or modifications not expressly approved by the party responsible Do not attempt to alter this system for compliance could void the user’s...

  • Page 133: Hyundai Digital Key

    Digital Key Application You can use the Digital Key NFC (Near Field Communication) function after To use Hyundai Digital Key mobile app, turning on your smartphone function in you should install Hyundai digital key the NFC settings. And you should unlock &...
  • Page 134 The saving process will begin ODN8A059240 automatically. Hyundai Digital Key (Smartphone) 5. Once the digital key save is complete, Pairing a message will be shown on the 1. Turn the vehicle on with the Smart key infotainment screen or cluster.
  • Page 135 If the infotainment or instrument ODN8A059130 cluster screen is changed during Hyundai Digital Key (Smartphone Key) enrollment, the saving process will Deletion be canceled. 1. Turn the vehicle on with the Smart...
  • Page 136 Note that you cannot lock your vehicle Set up main vehicle when you touch NFC antenna in the You can manage multiple digital keys smartphone to the door handle pad if from the Digital key app. From the list of any of the following occurs: digital keys you own, select the vehicle you want to make your priority vehicle.
  • Page 137 Note that you cannot lock your vehicle pad (wireless charger). Do not leave using the Hyundai digital key app if any unsupervised children or people who of the following occurs: are not aware of the system since it The POWER button is in ACC or ON can result in serious injury or death.
  • Page 138 Bluetooth connection or and the vehicle is off, press the Door performance degradation of the Lock button in the Hyundai Digital digital key. Key app then press the Remote Start If multiple users operate the remote button within 4 seconds.
  • Page 139 CAUTION If you change your smartphone or delete Do not leave the registered digital the Hyundai Digital Key App, please refer key (smartphone) and card key in to the following to set up your Digital your vehicle. Please carry around Key: your keys all the time.
  • Page 140 - Hyundai digital key app on the to the manufacturer while using a smartphone is deleted. (Required smartphone produced by domestic to reinstall the app) and foreign manufactures.
  • Page 141 ODN8A059131 screen or instrument cluster. Digital key (Card key) save 1. Install Hyundai digital key app in Information the digital key (smartphone). Please Once the card key registration mode refer to the registration method of the is activated, the process should be digital key (smartphone).
  • Page 142 To delete the saved digital key (card key), the smart key must be inside the vehicle. The deleted digital key (card key) can be re-registered before registering a new digital key (card key). If you register a new digital key (card key), the previously registered digital key (card key) cannot be used again.
  • Page 143 Convenience Features Inoperable condition If you do not touch the digital key (card key) to the center of the door handle authentication pad accurately. it may not work. In addition, if you overlap and use the key with NFC-enabled cards such as transportation card or credit card, it may not work.
  • Page 144 Start-up with Card key Type A After placing your registered card key onto the interior authentication pad (wireless charger), step on the brake and press the Engine Start/Stop button. WARNING If you do not place the digital key (card key) onto the center of the interior authentication pad (wireless charger) exactly, the card key may ODN8A059133...
  • Page 145 Convenience Features Profile link/unlinked CAUTION Profile link If you uncheck Enable digital keys, it is impossible to lock or unlock the doors or start up the vehicle with digital keys (Smartphone) on the infotainment such as smartphone and card key. If system menu.
  • Page 146 PRECAUTION for vehicle profile link and Vehicle personalization operation unlink The personalization function linked with When you link or unlink the profile of digital key works as following conditions: digital key, you should be careful of the following. the profile linked smart phone to lock Profile link is possible to use with the or unlock the doors (Personalization digital key.
  • Page 147 Convenience Features Vehicle personalization with digital key The available personalization function in the vehicle is as follows. System Personalization Item Setting up temperature unit, Block air inflow/ Air conditioning Automatic ventilation/Window defroster On/Off Information display on the cluster, Voice volume, Cluster Welcome sound Lamp...

  • Page 148: Operating Door Locks From Outside The Vehicle

    DOOR LOCKS Operating Door Locks from Information Outside the Vehicle Be careful when locking the door by Mechanical key mechanical key operation, only the driver’s door can be locked/unlocked. Refer to Chapter 5 “Operating door locks from inside the vehicle” to lock from inside the vehicle.

  • Page 149: Operating Door Locks From Inside The Vehicle

    Convenience Features Smart key Operating Door Locks from Inside the Vehicle With the door handle OCN7N051078L To lock the doors, press the button on the outside door handle while carrying OCN7050010 the smart key with you or press the door Front door lock button on the smart key.
  • Page 150 With the central door lock switch WARNING Driver’s door Do not leave the elderly, children or animals unattended in your vehicle. An enclosed vehicle can become extremely hot, causing death or serious injury to the elderly, unattended children or animals who cannot escape from the vehicle.

  • Page 151: Automatic Door Lock And Unlock Features

    Convenience Features Automatic Door Lock and Unlock Child-Protector Rear Door Locks Features Impact sensing door unlock system (if equipped) All doors will be automatically unlocked when an impact causes the air bags to deploy. Speed sensing door lock system (if equipped) All doors will be automatically locked OCN7N051129N...

  • Page 152: Rear Occupant Alert Operation

    Rear Occupant Alert helps prevent the WARNING driver from leaving a passenger in the Rear Occupant Alert provides rear seats. information to the driver to check the rear seats but it does not detect Rear Occupant Alert Operation whether there is an object or passenger. Always check the rear seats when leaving the vehicle.
  • Page 153 Convenience Features This system helps to protect your vehicle Information and valuables. The horn will sound and Do not lock the doors until all the hazard warning lights will blink passengers have left the vehicle. If the continuously if any of the following remaining passenger leaves the vehicle occur: when the system is armed, the alarm...

  • Page 154: Steering Wheel

    The steering wheel may become safe to do so. Have the system checked difficult to control or operate. Have by an authorized HYUNDAI dealer as your vehicle checked immediately, soon as possible. after moving the vehicle to a safe area.

  • Page 155: Tilt Steering / Telescope Steering

    Convenience Features Tilt Steering / Telescope Steering Information When adjusting the steering wheel to a Sometimes the lock release lever may not comfortable position, adjust the steering engage completely. This may occur when wheel so that it points toward your chest, the gears of the locking mechanism do not not toward your face.

  • Page 156: Mirrors

    MIRRORS Inside Rearview Mirror Day/night rearview mirror (if equipped) Before driving your vehicle, check to see that your inside rearview mirror is properly positioned. Adjust the rearview mirror so that the view through the rear window is properly centered. WARNING Make sure your line of sight is not obstructed.
  • Page 157 Convenience Features Electrochromic mirror (ECM) with Automatic-Dimming Night Vision Safety™ (NVS ) Mirror (if equipped) HomeLink® system (if equipped) ® The NVS® Mirror automatically reduces Your vehicle may be equipped with glare by monitoring light levels in the a Gentex Automatic-Dimming Mirror front and the rear of the vehicle.
  • Page 158 1. Programming HomeLink ® WARNING The following steps show how to Before programming HomeLink® to a program HomeLink. If you have any garage door opener or gate operator, questions or are having difficulty make sure people and objects are out programming your HomeLink buttons, of the way of the device to prevent refer to the HomeLink website or call the...
  • Page 159 Convenience Features 1) Programming Preparation 2) Programming a New HomeLink® OCN7050084N OCN7N051214N 1. When programming a garage door 1. Press and release the HomeLink opener, it is advised to park the button (1), (2) or (3), you would like vehicle outside of the garage. to program.
  • Page 160 3. While the HomeLink indicator light (7) is flashing orange, press and hold the hand-held remote button. Continue pressing the handheld remote button until the HomeLink indicator light (7) light changes from orange to green. You may now release the handheld remote button.
  • Page 161 Convenience Features 3) Two-Way Communication 2. On your garage door opener in your Programming (For select garage door garage, locate the “Learn” button openers) (usually near where the hanging antenna wire is attached to the garage If your garage door opener has the door opener).
  • Page 162 4) Canadian Programming 2. Operating HomeLink ® Canadian radio-frequency laws require 1) Operating HomeLink® transmitter remote signals to “time- out” (or quit) after a couple seconds of transmission, which may not be long enough for HomeLink to pick up the signal during programming.
  • Page 163 Convenience Features 2) Two-Way Communication Display If the indicator (4) flashes in Orange, Behavior it indicates that the garage door is “Closing”. The indicator (4) turns solid green once the garage door has closed. If the indicator (6) flashes in Orange, it indicates that the garage door is “Opening”.
  • Page 164 2) The following instructions will erase 3. Erasing HomeLink® Buttons ALL HomeLink® programming from 1) Erasing and Reprogramming a Single ALL buttons: HomeLink® Button: 1. Press and hold the desired HomeLink button you want to re-program. DO NOT release the button. 2.
  • Page 165 Convenience Features FCC (USA) and ISED (Canada) FCC (Htats-Unis) et ISED (Canada) This device complies with FCC rules Cet appareil est conforme aux part 15 and Innovation, Science, and règlements de la FCC, section 15, et Economic Development Canada RSS- 210.
  • Page 166 HomeLink 5 Programing Flow Chart ODL3A040518 5-45...

  • Page 167: Side View Mirrors

    Convenience Features Side View Mirrors WARNING Do not adjust or fold the side view mirrors while driving. This may cause loss of vehicle control resulting in an accident. NOTICE Do not scrape ice off the mirror face; this may damage the surface of the glass.
  • Page 168 Side View Mirror Adjustment Folding the side view mirrors OCN7N050001N OCN7N051022L 1. Press either the L (left side) or R (right To fold the side view mirrors, grasp the side) button (1) to select the side view housing of the mirror and then fold it mirror you would like to adjust.

  • Page 169: Windows

    Convenience Features WINDOWS OCN7N050002N (5) Window opening and closing (6) Automatic power window window switch (7) Power window lock switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch 5-48...

  • Page 170: Power Windows

    Power Windows Window opening and closing The Engine Start/Stop button must be in the ON position to be able to raise or lower the windows. Each door has a Power Window switch to control that Window Lock switch which can block the operation of rear passenger windows.
  • Page 171 If the power windows do not operate properly after resetting, have the system checked by an authorized HYUNDAI OCN7050026 dealer. If a window senses any obstacle while it...
  • Page 172 NOTICE WARNING Do not install any accessories on the NEVER leave the keys in your vehicle windows. The automatic reverse with unsupervised children, when feature may not operate. the engine is running. NEVER leave any child unattended in Power window lock switch the vehicle.

  • Page 173: Sunshade

    Convenience Features If your vehicle is equipped with a Sunshade sunroof, you can slide or tilt your sunroof with the sunroof switch located on the overhead console. OCN7050029 Use the sunshade to block direct sunlight coming through the sunroof glass. OCN7050028 Open or close the sunshade by hand.

  • Page 174: Tilt Open/Close

    Tilt Open/Close Slide Open/Close OCN7051144 OCN7N051031 Push the sunroof switch upward, the Push the sunroof switch rearward, sunroof glass tilts open. the sunshade and sunroof glass slide open. Push the sunroof switch forward when the sunroof glass is tilt opened, the Push the sunroof switch forward, only sunroof glass closes.

  • Page 175: Automatic Reversal

    Convenience Features NOTICE Automatic Reversal Do not continue to push the sunroof switch after the sunroof is fully opened, closed, or tilted. Damage to the sunroof motor could occur. Continuous operations such as slide open/close, tilt open/close, etc. may cause the motor or sunroof system to malfunction.

  • Page 176: Resetting The Sunroof

    Resetting the Sunroof 5. Once again push and hold the sunroof switch forward until the sunroof glass slides open and close. Do not release the switch until the operation is completed. If you release the switch during operation, start the procedure again from step 2.

  • Page 177: Hood

    Convenience Features HOOD Opening the hood OCN7050035 5. Hold the hood open with the support OCN7N051218N rod (3). 1. Park the vehicle and set the parking brake. WARNING 2. Pull the release lever to unlatch the hood. The hood should pop open Support rod slightly.
  • Page 178 Closing the hood WARNING 1. Before closing the hood, check the Before closing the hood, ensure following: all obstructions are removed from All filler caps in engine around the hood opening. compartment must be correctly Always double check to be sure that installed.

  • Page 179: Trunk

    Convenience Features TRUNK Opening the trunk Inside 1. Make sure the shift lever is in P (Park, for Dual clutch transmission) or first gear or R (Reverse, for manual transmission) and set the parking brake. Outside OCN7050037 - Use the trunk release lever. 3.

  • Page 180: Emergency Trunk Safety Release

    Emergency Trunk Safety Release WARNING You and your passengers must be aware of the location of the Emergency Trunk Safety Release lever in this vehicle and how to open the trunk in case you are accidentally locked in the trunk. NEVER allow anyone to occupy the trunk of the vehicle at any time.

  • Page 181: Smart Trunk Release

    Convenience Features Smart Trunk Release 1. Setting (if equipped) To activate the Smart Trunk release, go to User Settings Mode and select Smart Trunk on the LCD display. For more details, refer to “LCD Display” in this chapter. If your vehicle is equipped with additional navigation, please refer to the infotainment system manual separately supplied.
  • Page 182 How to deactivate the Smart Trunk release function using the smart key OCN7N051085N 3. Automatic opening The hazard warning lights will blink and OCN7050004 chime will sound 6 times and then the 1. Door Lock trunk will open. 2. Door Unlock 3.
  • Page 183 Convenience Features Detecting area Information If you press the door unlock button (2), the Smart Trunk release function will be deactivated temporarily. But, if you do not open any door for 30 seconds, the smart trunk function will be activated again. If you press the trunk open button (4) for more than 1 second, the trunk opens.

  • Page 184: Fuel Filler Door

    FUEL FILLER DOOR Opening the fuel filler door Information If the fuel filler door does not open because ice has formed around it, tap lightly or push on the door to break the ice and release the door. Do not pry on the door.
  • Page 185 If the fuel filler cap requires Use only approved portable plastic replacement, use only a genuine fuel containers designed to carry and HYUNDAI cap or the equivalent store gasoline. specified for your vehicle. An incorrect fuel filler cap can result...

  • Page 186: Exterior Lights

    EXTERIOR LIGHTS Lighting Control To operate the lights, turn the knob at the end of the control lever to one of the following positions: OCN7050055 AUTO headlight The parking lamp and headlight will be turned ON or OFF automatically depending on the amount of daylight as ODN8A059200 measured by the ambient light sensor on 1.

  • Page 187: High Beam Operation

    Convenience Features High Beam Operation ODN8A059202 Parking lamp ( ODN8A059205 The parking lamp, license plate lamp and To turn on the high beam headlight, push instrument panel lamp are turned ON. the lever away from you. The lever will return to its original position. The high beam indicator will light when the headlight high beams are switched To turn off the high beam headlight, pull...

  • Page 188: Turn Signals And Lane Change Signals

    Turn Signals And Lane Change Signals ODN8A059204 To flash the high beam headlight, pull the lever towards you, then release the lever. ODN8A059207 The high beams will remain ON as long To signal a turn, push down on the lever as you hold the lever towards you.

  • Page 189: Battery Saver Function

    Convenience Features Battery Saver Function Headlight Delay Function (if equipped) The purpose of this feature is to help prevent the battery from being If the Engine Start/Stop button is in the discharged. The system automatically ACC parking or the OFF position with turns off the parking lamp when the the headlights ON, the headlights (and/ driver turns the vehicle off and opens the...

  • Page 190: High Beam Assist (Hba)

    High Beam Assist Settings Setting features turn on High Beam Assist and deselect to turn off the function. OCN7050141N High Beam Assist will automatically adjust the headlight range (switches between high beam and low beam) depending on the brightness of detected vehicles and certain road conditions.

  • Page 191: High Beam Assist Malfunction And Limitations

    Have the corresponding lamp will turn on. vehicle inspected by an authorized When High Beam Assist is operating, HYUNDAI dealer. high beam switches to low beam if any of the following conditions occur: - When the headlight of an oncoming vehicle is detected.
  • Page 192 Limitations of High Beam Assist Information High Beam Assist may not work properly For more details on the limitations of the in the following situations: front view camera, refer to “Forward Light from an oncoming or front Collision-Avoidance Assist (FCA)” section vehicle is not detected because of in chapter 7.

  • Page 193: Interior Lights

    Convenience Features INTERIOR LIGHTS Front Lamps WARNING Do not use the interior lights when driving in the dark. The interior lights may obscure your view and cause an accident. NOTICE Do not use the interior lights for extended periods when the vehicle is turned off or the battery will discharge.

  • Page 194: Rear Lamp

    Front Door Lamp ( Rear Lamp The front or rear room lamps come on when the front or rear doors are opened if the engine is running or not. When doors are unlocked by the smart key, the front and rear lamps come on for approximately 30 seconds as long as any door is not opened.

  • Page 195: Luggage Compartment Lamp

    Convenience Features Luggage Compartment Lamp Vanity Mirror Lamp (if equipped) OCN7N051086N OCN7050058 The luggage compartment lamp comes Push the switch to turn the light on or off. on when the trunk is opened. : The lamp will turn on if this button is pressed.

  • Page 196: Welcome System

    Welcome System (if equipped) You can activate or deactivate the Welcome Light from the User Settings Welcome light Mode on the LCD display. For more details, refer to “LCD Display” in chapter 4. If your vehicle is equipped with additional navigation, please refer to the infotainment system manual separately supplied.

  • Page 197: Wipers And Washers

    Convenience Features WIPERS AND WASHERS Windshield wipers Type A Operates as follows when the Engine Start/Stop button is in the ON position. MIST : For a single wiping cycle, push the lever upward and release. The wipers will operate continuously if the lever is held in this position.

  • Page 198: Windshield Washers

    NOTICE Windshield Washers To prevent possible damage to the washer pump, do not operate the washer when the fluid reservoir is empty. To prevent possible damage to the wipers or windshield, do not operate the wipers when the windshield is dry.
  • Page 199 Convenience Features Type A OCN7050100N Type B OCN7050101N 1. Fan speed control knob 2. Temperature control knob 3. Mode selection knob 4. Front windshield defroster position 5. Rear window defroster button 6. Air intake control button 7. A/C (Air conditioning) button 5-78...

  • Page 200: Heating And Air Conditioning

    Heating and Air Conditioning When starting the vehicle in cold weather a more efficient way to heat the passen- 1. Start the engine. ger compartment is to do the following. 2. Set the mode to the desired position. - Turn off or lower the blower, right To improve the effectiveness of after starting the engine.
  • Page 201 Convenience Features Mode selection OCN7N051222N 5-80...
  • Page 202 Floor & Defrost (A, C, D, E) Most of the air flow is directed to the floor and the windshield with a small amount directed to the side window defrosters. Defrost-Level (A, D) Most of the air flow is directed to the OCN7050102 windshield with a small amount of air The mode selection knob controls the...
  • Page 203 Convenience Features Instrument panel vents Air intake control Type A OCN7050107 OCN7N051106N Type B Instrument panel vents The instrument panel vent air flow can be directed up/down or left/right using the vent adjustment lever. To close the vent, push the air vent lever in the opposite direction of the passenger.
  • Page 204 Recirculation mode WARNING When Recirculation mode Continued use of the climate control is selected, air from the system operation in Recirculation passenger compartment will mode for a prolonged period of be recirculated through the time may cause drowsiness to the system and heated or cooled occupants in the cabin.
  • Page 205 Convenience Features Fan speed control Air conditioning (if equipped) OCN7050108N OCN7050109 Turn the knob to the right to increase Press the A/C button to turn the air the fan speed and airflow. Turn the knob conditioning system on (indicator light to the left to decrease fan speed and will illuminate).

  • Page 206: System Operation

    System Operation Operation Tips Ventilation To help keep dust or unpleasant fumes from entering the vehicle through the 1. Select the Face Level mode. ventilation system, temporarily set the 2. Set the air intake control to fresh air intake control to the recirculation mode.
  • Page 207 Convenience Features Air conditioning Air conditioning system operation tips If the vehicle has been parked in HYUNDAI Air Conditioning Systems are direct sunlight during hot weather, filled with R-1234yf refrigerant. open the windows for a short time 1. Start the vehicle.

  • Page 208: System Maintenance

    Have the cabin air filter replaced by an authorized HYUNDAI dealer according to NOTICE the maintenance schedule. If the vehicle The refrigerant system should only...
  • Page 209 Convenience Features WARNING Vehicles equipped with R-1234yf Since the refrigerant is mildly flammable and operated at high pressure, the air conditioning system should only be serviced by trained and certified technicians. It is important that the correct type and amount of oil and OCN7N051087N refrigerant are used.
  • Page 210 OCN7050110L 3. AUTO (automatic control) button 4. SYNC button 5. OFF button 6. Front windshield defroster button 7. Air conditioning button 8. Air intake control button 9. Rear window defroster button 10. Fan speed control button 11. Mode selection button 12.

  • Page 211: Automatic Heating And Air Conditioning

    Convenience Features Automatic Heating and Air When you select the temperature to HI or LO in AUTO mode, the fan speed is set Conditioning Driver’s seat Passenger’s seat OCN7050112 OCN7050114 1. Press the AUTO button 2. Turn the temperature control knob The modes, fan speeds, air intake and to set the desired temperature.

  • Page 212: Manual Heating And Air Conditioning

    Manual Heating and Air Conditioning The heating and cooling system can be controlled manually by pushing buttons other than the AUTO button. In this case, the system works sequentially according to the order of buttons selected. When pressing any button except the AUTO button while using automatic operation, the functions not selected will be controlled automatically.
  • Page 213 Convenience Features Mode selection OCN7N051221N 5-92...
  • Page 214 Bi-Level (B, C, D, E) Air flow is directed towards the face and the floor. Floor-Level (A, C, D, E) Most of the air flow is directed to the floor, with a small amount of the air being directed to the windshield and side OCN7050115 window defrosters.
  • Page 215 Convenience Features Temperature control Driver’s seat Passenger’s seat OCN7050116 Defrost-Level (A, D) OCN7050114 Most of the air flow is directed to the The temperature will increase by turning windshield with a small amount of air the knob to the right. directed to the side window defrosters.
  • Page 216 Temperature conversion If the battery has been discharged or disconnected, the temperature mode display will reset to Centigrade. To change the temperature unit from °C to °F or °F to °C : - Automatic climate control system Press the AUTO button for 3 seconds while pressing the OFF button.
  • Page 217 Convenience Features Fan speed control Information Operating the system primarily in Fresh mode is recommended. Use Recirculation mode temporarily only when needed. Prolonged operation of the heater in Recirculation mode and without the A/C ON can cause fogging of the windshield. In addition, prolonged use of the A/C ON in Recirculation mode may result in excessively dry, dehumidified air in the...

  • Page 218: System Operation

    Air conditioning System Operation Ventilation 1. Select the Face Level mode. 2. Set the air intake control to fresh mode. 3. Set the temperature control to the desired position. 4. Set the fan speed control to the desired speed. Heating OCN7050119 1.
  • Page 219 Convenience Features Air conditioning Air conditioning system operation tips If the vehicle has been parked in HYUNDAI Air Conditioning Systems are direct sunlight during hot weather, filled with R-1234yf refrigerant. open the windows for a short time 1. Start the vehicle.

  • Page 220: System Maintenance

    Have the cabin air filter replaced by an authorized HYUNDAI dealer according to NOTICE the maintenance schedule. If the vehicle The refrigerant system should only...

  • Page 221: Convenience Features

    Convenience Features WARNING Vehicles equipped with R-1234yf Since the refrigerant is mildly flammable and operated at high pressure, the air conditioning system should only be serviced by trained and certified technicians. It is important that the correct type and amount of oil and OCN7N051087N refrigerant are used.

  • Page 222: Windshield Defrosting And Defogging

    WINDSHIELD DEFROSTING AND DEFOGGING Manual Climate Control System WARNING To defog inside windshield Windshield heating Do not use the position during cooling operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield could cause the outer surface of the windshield to fog up, causing loss of visibility.

  • Page 223: Automatic Climate Control System

    Convenience Features To defrost outside windshield Automatic Climate Control System To defog inside windshield OCN7050123N 1. Set the fan speed to the highest setting (knob rotated all the way to OCN7050124L the right). 1. Select desired fan speed. 2. Set the temperature control to the 2.

  • Page 224: Defogging Logic

    To defrost outside windshield Defogging Logic (if equipped) To help reduce the probability of fogging up the inside of the windshield, the air intake or air conditioning are controlled automatically according to certain conditions such as position. To cancel or return the defogging logic, do the following Manual climate control system 1.

  • Page 225: Auto Defogging System (Only For Automatic Climate Control System)

    Convenience Features Auto Defogging System (only To cancel or reset the Auto Defogging System for automatic climate control system, if equipped) Press the front windshield defroster button for 3 seconds when the Engine Start/Stop button is in the ON position. When the Auto Defogging System is canceled, defrost button indicator will blink 3 times.

  • Page 226: Defroster

    Defroster Information If there is heavy accumulation of snow NOTICE on the rear window, brush it off before operating the rear defroster. To prevent damage to the conductors bonded to the inside surface of the rear The rear window defroster window, never use sharp instruments or automatically turns off after window cleaners containing abrasives...

  • Page 227: Climate Control Additional Features

    Convenience Features CLIMATE CONTROL ADDITIONAL FEATURES Sunroof Inside Air Recirculation Automatic Ventilation (if (if equipped) equipped) When the sunroof is opened, outside The system automatically selects the (fresh) air will be automatically selected. fresh mode when the climate control At this time, if you press the air intake system operates over a certain period of control button, recirculated air position time (approximately 30 minutes) in low...

  • Page 228: Storage Compartment

    STORAGE COMPARTMENT Center Console Storage WARNING Never store cigarette lighters, propane cylinders, or other flammable/explosive materials in the vehicle. These items may catch fire and/or explode if the vehicle is exposed to hot temperatures for extended periods. WARNING ALWAYS keep the storage compartment covers closed securely while driving.

  • Page 229: Interior Features

    Convenience Features INTERIOR FEATURES Cup Holder WARNING Keep cans or bottles out of direct sun light and do not put them in a hot vehicle. It may explode. NOTICE Keep your drinks sealed while driving to prevent spilling your drink. If liquid spills, it may get into the vehicle’s electrical/electronic system and damage electrical/electronic parts.

  • Page 230: Sunvisor

    Sunvisor Power Outlet OCN7N051088N OCN7N051068 To use a sunvisor, pull it downward. The power outlet is designed to provide power for mobile telephones or other To use a sunvisor for a side window, pull devices designed to operate with vehicle it downward, unsnap it from the bracket electrical systems.

  • Page 231: Wireless Cellular Phone Charging System

    Convenience Features NOTICE Wireless Cellular Phone Charging System (if equipped) To prevent damage to the Power Outlets: Use the power outlet only when the engine is running and remove the accessory plug after use. Using the accessory plug for prolonged periods of time with the engine off could cause the battery to discharge.
  • Page 232 To charge a cellular phone Information The wireless cellular phone charging For some manufacturers’ cellular phones, system charges only the Qi-enabled the system may not warn you even though cellular phones ( ). Read the label on the cellular phone is left on the wireless the cellular phone accessory cover or charging unit.

  • Page 233: Clock

    Convenience Features Clock with a self-protection feature, the wireless charging speed may WARNING decrease and the wireless charging may stop. Do not attempt to adjust the clock while driving. Doing so may result in cover, the wireless charging may not distracted driving which may lead to be possible.

  • Page 234: Coat Hook

    Coat Hook OTM048095 These hangers are not designed to hold large or heavy items. WARNING OCN7050071 Do not hang other objects such as hangers or hard objects except clothes. Also, do not put heavy, sharp or breakable objects in the clothes pockets.

  • Page 235: Infotainment System

    Convenience Features INFOTAINMENT SYSTEM Antenna Information If you install an aftermarket HID headlight, your vehicle’s audio and electronic device may malfunction. Prevent chemicals such as perfume, cosmetic oil, sun cream, hand cleaner, and air freshener from contacting the interior parts because they may cause damage or discoloration.

  • Page 236: Steering Wheel Audio Control

    Steering Wheel Audio Control RADIO mode It will function as the AUTO SEEK select switch. It will SEEK until you release the switch. MEDIA mode It will function as the FF/REW switch. If the SEEK/PRESET toggle switch is moved up or down, it will function in the following modes.

  • Page 237: Infotainment System

    Convenience Features Infotainment System (if Bluetooth® Wireless Technology equipped) Hands-free (if equipped) If your vehicle is equipped with additional navigation, please refer to the infotainment system manual separately supplied. Voice Recognition (if equipped) OCN7N051075 OCN7N071129L Voice recognition allows you to command a variety of infotainment functions.

  • Page 238: How Vehicle Radio Works

    How Vehicle Radio Works AM (MW, LW) reception FM reception OJF045309L AM broadcasts can be received at OJF045308L greater distances than FM broadcasts. AM and FM radio signals are broadcast This is because AM radio waves are from transmitter towers located around transmitted at low frequencies.
  • Page 239 Convenience Features FM radio station These can result in certain listening conditions which might lead you to believe a problem exists with your radio. The following conditions are normal and do not indicate radio trouble : OJF045310L FM broadcasts are transmitted at high frequencies and do not bend to follow JBM004 broadcasts generally begin to fade at...
  • Page 240 Using a cellular phone or a twoway radio When a cellular phone is used inside the vehicle, noise may be produced from the audio system. This does not mean that something is wrong with the audio equipment. In such a case, use the cellular phone at a place as far as possible from the audio equipment.

  • Page 241: Driving Your Vehicle

    6. Driving Your Vehicle Before Driving ....................6-4 Before Entering the Vehicle ..................6-4 Before Starting ......................6-4 Engine Start/Stop Button ................6-5 Vehicle Auto-Shut Off .................. 6-11 Operating Conditions ..................... 6-11 Deactivating Conditions ..................6-11 System Operation ....................6-11 Manual Transmission ..................6-12 Manual Transmission Operation ................6-12 Good Driving Practices ...................6-14 Rev Matching ......................6-15 Dual Clutch Transmission ................
  • Page 242 Drive Mode Integrated Control System ............6-44 Drive Mode ......................6-44 N Mode ........................6-46 NGS (N Grin Shift) ....................6-48 Vehicle Characteristic ....................6-49 Performance Option ..................6-51 Performance Option Settings .................6-51 Launch Control ....................... 6-52 Shift Light ........................ 6-55 N Track Sense Shift (for DCT) ................6-57 N Power Shift (for DCT) ..................6-59 N Sound Equalizer ....................6-59 Maximum Performance Driving...
  • Page 243 If you hear a change in the sound of the exhaust or if you drive over something that strikes the underneath side of the vehicle, have the exhaust system checked as soon as possible by an authorized HYUNDAI dealer. Do not run the engine in an enclosed area.

  • Page 244: Before Driving

    Driving Your Vehicle BEFORE DRIVING Before Entering the Vehicle WARNING Be sure all windows, outside mirror(s), To reduce the risk of SERIOUS INJURY or and outside lights are clean and DEATH, take the following precautions: unobstructed. ALWAYS wear your seat belt. All Remove frost, snow, or ice.

  • Page 245: Engine Start/Stop Button

    ENGINE START/STOP BUTTON WARNING NEVER press the Engine Start/Stop button while the vehicle is in motion except in an emergency. This will result in the engine turning off and loss of power assist for the steering and brake systems. This may lead to loss of directional control and braking function, which could cause an accident.
  • Page 246 Driving Your Vehicle Engine Stop/Start button positions - Vehicle with manual transmission Button Action Notes Position To turn off the engine, stop the vehicle If the steering wheel is not locked and then press the Engine Start/Stop properly when you open the driver's button.
  • Page 247 Engine Stop/Start button positions - Vehicle with dual clutch transmission Button Action Notes Position To turn off the engine, press the If the steering wheel is not locked Engine Start/Stop with shift lever is in properly when you open the driver’s P (Park).
  • Page 248 Driving Your Vehicle Starting the engine Vehicle with manual transmission: 1. Always carry the smart key with you. 2. Make sure the parking brake is WARNING applied. Always wear appropriate shoes when 3. Make sure the shift lever is in neutral. operating your vehicle.
  • Page 249 NOTICE Emergency starting To prevent damage to the vehicle: If the engine stalls while you are in motion, do not attempt to move the shift lever to the P (Park) position. If traffic and road conditions permit, you may put the shift lever in the N (Neutral) position while the vehicle is still moving and press the Engine Start/Stop button in an attempt to...
  • Page 250 Driving Your Vehicle Remote start To start the vehicle remotely: 1. Press the door lock button within 10 m (32 feet) from the vehicle. 2. Press the remote start ( ) button for over 2 seconds within 4 seconds after locking the doors.

  • Page 251: Vehicle Auto-Shut Off

    If your vehicle is parked and the engine System Operation is left on for a long period of time, the engine will turn off automatically to help reduce fuel consumption and prevent accidents caused by carbon dioxide poisoning. Operating Conditions Vehicle Auto-Shut Off timer operates when all the following conditions are satisfied:...

  • Page 252: Manual Transmission Operation

    Driving Your Vehicle Manual Transmission Operation The manual transmission has 6 forward gears. The transmission is fully synchronized in all forward gears so shifting to either a higher or a lower gear is easily accomplished. WARNING Before leaving the driver’s seat, always make sure the shift lever is in OCN7N060001 1st gear when the vehicle is parked...
  • Page 253 Using the clutch Downshifting The clutch pedal should be depressed all Down shift to a lower gear when slowing the way before: down in heavy traffic or driving up a steep hill to prevent high engine loads. - Starting the engine Also, downshifting reduces the chance The engine will not start without of stalling and helps to reaccelerate the...

  • Page 254: Good Driving Practices

    In the event your vehicle leaves loss of vehicle control resulting in an the roadway, do not steer sharply. accident. Instead, slow down before pulling back into the travel lanes. HYUNDAI recommends you follow all posted speed limits. 6-14...

  • Page 255: Rev Matching

    Rev Matching 2. Select Drive Mode. The Rev Matching system automatically REV indicator helps synchronize engine rpm with the optimal speed of the gearabout to be engaged which reduces the impact of clutch connection and improves gear shift response. Information Fully depress the clutch pedal.
  • Page 256 Driving Your Vehicle DRIVE MODE button N1 button Use Rev Matching in normal driving conditions in below modes. When ECO mode is selected: - Rev Matching cannot be activated even if the driver presses the REV button. - REV indicator is off. When NORMAL mode is selected: - Rev Matching activates if Rev OCN7N061208...
  • Page 257 Rev Matching operation N button (N1/N2 button) Use Rev Matching when driving on race Engine speed is automatically tracks, etc. in N mode. synchronized with the next selected gear. The accelerator pedal does not When N mode (SPORT+) is selected: have to be depressed to speed up the - REV Matching is turned on engine RPM.

  • Page 258: Dual Clutch Transmission

    Driving Your Vehicle OCN7N061252L Depress the brake pedal and press the shift lever while moving the shift lever. Press the shift lever while moving the shift lever. The shift lever can freely operate. Dual Clutch Transmission Operation The dual clutch transmission has 8 forward speeds and one reverse speed. The individual speeds are selected automatically in the D (Drive) position.
  • Page 259 The dual clutch transmission gives the WARNING driving feel of a manual transmission, To reduce the risk of serious injury or yet provides the ease of a fully death: automatic transmission. Unlike a traditional automatic transmission, ALWAYS check the surrounding the gear shifting can be felt (and areas near your vehicle for people, heard) on the dual clutch transmission...

  • Page 260: Lcd Display For Transmission Temperature And Warning Message

    (D, R) on the cluster will blink. When the transmission is overheated, Contact an authorized HYUNDAI dealer the warning message will display and have the system checked. on the LCD. Follow the displayed message.
  • Page 261 DCT warning messages OCN7N061227N Transmission high temperature OCN7N061226L Under certain conditions, such as This warning message is displayed when repeated stop-and-go launches vehicle is driven slowly on a grade and on steep grades, sudden take off the vehicle detects that the brake pedal or acceleration, or other harsh is not applied.
  • Page 262 When possible, drive the vehicle smoothly. If any of the warning messages in the LCD display continue to blink, for your safety, contact an authorized HYUNDAI dealer and have the system checked. OCN7N061225L OCN7N061228L OCN7N061229L 6-22...
  • Page 263 Transmission ranges R (Reverse) Use this position to drive the vehicle The indicator in the instrument cluster backward. displays the shift lever position when the Engine Start/Stop button is in the ON position. NOTICE Always come to a complete stop before P (Park) shifting into or out of R (Reverse);...
  • Page 264 Driving Your Vehicle D (Drive) This is the normal driving position. The transmission will automatically shift through a 8-gear sequence, providing the best fuel economy and power. For extra power when passing another vehicle or driving uphill, depress the accelerator fully. The transmission will automatically downshift to the next lower gear (or gears, as appropriate).
  • Page 265 If you need to use the shift-lock release, from P (Park) into R (Reverse) unless the have the system inspected by an brake pedal is depressed. authorized HYUNDAI dealer immediately. To shift the transmission from P (Park) into R (Reverse): CAUTION 1.

  • Page 266: Parking

    Driving Your Vehicle Parking Paddle Shifter (Manual Shift Mode) (if equipped) Always come to a complete stop and continue to depress the brake pedal. Move the shift lever into the P (Park) position, apply the parking brake, and set the Engine Start/Stop button to the OFF position.

  • Page 267: Good Driving Practices

    HYUNDAI recommends you follow all posted speed limits. When driving in sports mode, slow down before shifting to a lower gear.

  • Page 268: Brake System

    Driving Your Vehicle BRAKE SYSTEM Power Brakes When descending down a long or steep hill, move the gear shift lever Your vehicle has power-assisted brakes to Manual Shift Mode and manually that adjust automatically through normal downshift to a lower gear in order usage.

  • Page 269: High Performance Brake

    Have the vehicle checked by an authorized Firmly depress the brake pedal. HYUNDAI dealer. Pull up the parking brake lever as far as If the vehicle has continuous possible. vibration or shudder in the steering...
  • Page 270 Driving Your Vehicle NOTICE Releasing the parking brake Do not apply the accelerator pedal while the parking brake is engaged. If you depress the accelerator pedal with the parking brake engaged, a warning will sound. Damage to the parking brake may occur. Driving with the parking brake on can overheat the braking system and cause premature wear or damage to...

  • Page 271: Anti-Lock Brake System (Abs)

    During that time, the ABS will go through self-diagnosis and the light will go off if everything is normal. If the light stays on, you may have a problem with your ABS. Contact an authorized HYUNDAI dealer as soon as possible. 6-31...

  • Page 272: Electronic Stability Control (Esc)

    To reduce the risk of serious going. ESC applies braking pressure injury or death, contact your HYUNDAI to any one of the vehicle's brakes and dealer as soon as possible. intervenes in the engine management...
  • Page 273 ESC operation Deactivating / Activating ESC ESC ON condition When the engine is turned off and then on again, ESC operation is enabled, and it is activated in the ESC operating mode (not in ESC Sport mode or ESC OFF mode) regardless of the ESC mode before turning off the engine.
  • Page 274 Driving Your Vehicle WARNING If you deactivate ESC, ESC no longer stabilizes the vehicle. There is an increased risk of skidding and an accident. When ESC SPORT mode is activated, the stability support from ESC will be less than in "ESC ON mode", there is a greater risk of skidding and an accident.
  • Page 275 ESC system. When this warning light illuminates, have the vehicle inspected by an authorized HYUNDAI dealer as soon as possible. The ESC OFF indicator light comes on when the ESC is turned off with the button.
  • Page 276 Driving Your Vehicle NOTICE Information Driving with wheels and tires with Turning the ESC off does not affect ABS different sizes may cause the ESC or standard brake system operation. system to malfunction. Before replacing tires, make sure all four tires and wheels Drive mode selection are the same size.

  • Page 277: Vehicle Stability Management (Vsm)

    Vehicle Stability Management CUSTOM mode (VSM) You may select the drive mode you prefer from the infotainment system The Vehicle Stability Management (VSM) screen. is a function of the Electronic Stability From the CUSTOM mode menu, select Control (ESC) system. It helps ensure the vehicle stays stable when accelerating or braking suddenly on wet, slippery You may directly go to the CUSTOM...

  • Page 278: Hill-Start Assist Control (Hac)

    This is normal and it means vehicle checked by an authorized your VSM is active. HYUNDAI dealer as soon as possible. Driving with wheels and tires with Information different sizes may cause the ESC system The VSM does not operate when: to malfunction.

  • Page 279: Good Braking Practices

    If the braking action does not return to normal, stop as soon as it is safe to do so and call an authorized HYUNDAI dealer for assistance. DO NOT drive with your foot resting on the brake pedal.
  • Page 280 System malfunction OOSN061011L Check Electronic Suspension When Electronic Control Suspension is not working properly, this warning message will appear on the cluster LCD display. If this occurs, have the system inspected by an authorized HYUNDAI dealer. 6-40...

  • Page 281: Electronic Limited Slip Differential

    ELECTRONIC LIMITED SLIP DIFFERENTIAL Electronic Limited Slip Differential refers CUSTOM mode to a feature equipped with a mechanism You may select the drive mode you that controls the differential functions of prefer from the infotainment system the wheels. screen. From the CUSTOM mode menu, select The Electronic Limited Slip Differential helps: You may directly go to the CUSTOM...

  • Page 282: Warning Messages

    Wait until the Limited Slip Differential system. Have vehicle cools down. the system checked by an authorized HYUNDAI dealer OOSN061014L Tire size mismatch. Check all tire sizes If your vehicle is equipped with different tires (size, type, etc.) on the front, the message will appear.

  • Page 283: N Button

    N BUTTON N1/N2 Button Settings N1 button N1 button OCN7N061230L N2 button OCN7N061208 N2 button OCN7N061231L Each of the N1/N2 button can be set: OCN7N071130L 1. N N1 button: Left N button, N2 button: Right N button 2. CUSTOM 1 The driver can set the N1/N2 button 3.

  • Page 284: Drive Mode Integrated Control System

    Driving Your Vehicle DRIVE MODE INTEGRATED CONTROL SYSTEM Drive Mode The drive mode may be selected according to the driver’s preference or Drive mode button road condition. The system resets to be in the NORMAL mode, when the engine is restarted. The mode changes, whenever the N1 or N2 button on the steering wheel or the Drive mode button is pressed.
  • Page 285 When the Drive Mode is set Limitation of ECO mode operation: to ECO mode, the engine and If the following conditions occur while transmission control logic are ECO mode is operating, the system changed to maximize fuel operation is limited even though there is efficiency.
  • Page 286 Driving Your Vehicle SPORT mode N Mode SPORT mode manages N1 button the driving dynamics by automatically adjusting the steering effort, the engine and transmission control logic for enhanced driving performance. When SPORT mode is selected by pressing the DRIVE MODE button, the SPORT indicator will illuminate.
  • Page 287 N mode CUSTOM mode N mode selects the proper The driver can set the two driving mode among SPORT types of CUSTOM mode and SPORT+ for each (CUSTOM 1/CUSTOM 2). In components that will effect CUSTOM mode, they can the performance of a high- select the drive mode for each performance vehicle.
  • Page 288 Driving Your Vehicle NGS (N Grin Shift) Activated Non-operating Controls engine / transmission to maximum performance when pressing NGS button on the steering wheel remote control in situations where rapid acceleration is required. Functional description and operating conditions OJSN040333 OOSN061052N CAUTION The driver has the responsibility to safely drive and control the vehicle...

  • Page 289: N Mode

    Vehicle Characteristic The characteristic of each components varies according to which drive mode is selected by pressing the N1 or N2 button on the steering wheel or the DRIVE MODE button. DRIVE MODE Button Component ECO mode NORMAL mode SPORT mode Engine NORMAL SPORT...
  • Page 290 Driving Your Vehicle DRIVE MODE Button Component ECO mode NORMAL mode SPORT mode Engine NORMAL SPORT Engine & Transmission* NORMAL SPORT Driving e-LSD* NORMAL NORMAL SPORT Suspension NORMAL NORMAL SPORT Chassis Steering NORMAL NORMAL SPORT ESC * NORMAL NORMAL NORMAL Sound Exhaust sound * NORMAL...

  • Page 291: Performance Option Settings

    CAUTION Please note that using high performance exhaust sound in a crowded public area, closed parking spaces, and/or residential area can cause disturbance to your neighbors. Performance Option Settings OCN7N061221L 2. Touch the performance option (3). Information Items of Performance option may differ depending on the transmission specification.

  • Page 292: Launch Control

    Driving Your Vehicle Launch Control Launch Control provides maximum acceleration on dry asphalt roads. Launch Control not to be used on any other surface. Excessive slip might occur and harm your vehicle. Prerequisite for activation Launch Control gets ready to be activated, when the following prerequisites are satisfied.
  • Page 293 Launch control on and off (For Launch control on and off (For Dual Manual transmission) clutch transmission) 1. Select N mode with ‘N’ button (N 1. Select N mode with 'N' button mode indicator will illuminate on (N-mode indicator lights up on the cluster) or select SPORT+ for the cluster) or select SPORT+ for the engine mode in CUSTOM mode.
  • Page 294 Driving Your Vehicle CAUTION (For Manual CAUTION transmission) Launch performance when using launch control in vehicle is highly dependent If you press the clutch pedal and the on the clutch connection technology, accelerator pedal at the same time tire friction and road conditions. In and then release the accelerator other words, the use of the launch pedal, the launch control function is...

  • Page 295: Shift Light

    Shift Light Normal mode OCN7N061241L 1. Press ‘Shift light’ tab in Performance OBC3N060029 options. N mode 2. Select drive mode to activate shift indicator. (ECO/NORMAL/SPORT/N/ CUSTOM) 3. Set up target RPM by pressing ‘< (Left)’ or ‘> (Right)’. (6000 RPM ~ 6700 RPM) 4.
  • Page 296 Driving Your Vehicle Shift Light operation table Blinking of all 5 LEDs, works only in the fixed shift mode where manual upshift is required. Shift lever LED step All LED blink (upshift Shift mode position lighting shift notification) Automatic shift mode N Grin Shift operation N Track Shift operation Temporary manual shift mode...

  • Page 297: N Track Sense Shift (For Dct)

    N Track Sense Shift (for DCT) How to set N Track Sense Shift N Track Sense Shift is automatically activated when dynamic driving condition with lots of cornering maneuver is detected. (for example, Race track driving). The program enables stress-free track driving by automatically shifting down at the entry of corner and maintains lower gear during cornering as if you are shifting manually in...
  • Page 298 Driving Your Vehicle Operating condition Non-operating conditions N Track Sense Shift is enabled in the N Track Sense Shift is disabled in Performance Options settings Performance Options settings Shift lever in D (Drive) position Shift lever position is in P/R/N Transmission mode is SPORT or Changing Transmission mode during SPORT+ (Including SPORT or N mode)

  • Page 299: N Power Shift (For Dct)

    N Power Shift (for DCT) N Sound Equalizer OCN7N061255N OCN7N061244L When the driver depresses the Driving sound master volume accelerator pedal fully (100%) in N mode for faster acceleration, it controls by (up- ) shifting with minimal energy loss. N Power Shift can be deactivated by pressing 'Activate' on the screen.
  • Page 300 CUSTOM N STANDARD It provides a sound with a sense of power HIGH PERPORMANCE an1d dynamics even in the low RPM range. CUSTOM It plays the sound of a HYUNDAI TCR CUSTOM vehicle. 6-60...

  • Page 301: Maximum Performance Driving (How To Drive With Octane Number Learning)

    Maximum Performance Driving (How to drive with Octane Number Learning) When the vehicle is refueled, ECU recognizes fueling conditions and determines the octane rating of the fuel. Maximum boost pressure is limited to protect the engine until the fuel is identified as premium fuel.

  • Page 302: Special Driving Conditions

    Driving Your Vehicle SPECIAL DRIVING CONDITIONS Hazardous Driving Conditions WARNING When hazardous driving elements If the vehicle is stuck and excessive are encountered such as water, snow, wheel spin occurs, the temperature ice, mud and sand, take the below of the tires can increase very quickly. suggestions: If the tires become damaged, a tire Drive cautiously and keep a longer...

  • Page 303: Smooth Cornering

    Smooth Cornering Driving in the Rain Avoid braking or gear changing in Rain and wet roads can make driving corners, especially when roads are wet. dangerous. Here are a few things to Ideally, corners should always be taken consider when driving in the rain or on under gentle acceleration.

  • Page 304: Driving In Flooded Areas

    Driving Your Vehicle Driving in Flooded Areas Information Avoid driving through flooded areas Never over-inflate your tires above the unless you are sure the water is no maximum inflation pressure, as specified higher than the bottom of the wheel hub. on your tires.

  • Page 305: Winter Driving

    WINTER DRIVING The severe weather conditions of winter Snow tires quickly wear out tires and cause other WARNING problems. To minimize winter driving problems, you should take the following Snow tires should be equivalent in size suggestions: and type to the vehicle’s standard tires. Otherwise, the safety and handling of Snow or Icy Conditions your vehicle may be adversely affected.
  • Page 306 HYUNDAI vehicle. Do not install studded tires without first checking local and municipal Be sure to follow the guidelines and...

  • Page 307: Winter Precautions

    8. The level of charge in your contacting the body, retighten the battery can be checked by an authorized chain to prevent contact with the HYUNDAI dealer or a service station. vehicle body. To prevent body damage, retighten Check spark plugs and ignition the chains after driving 0.3-0.6 miles...
  • Page 308 The manufacturer is not responsible for the damage caused Window washer anti-freeze is available by such placement. from an authorized HYUNDAI dealer and most auto parts outlets. Do not To keep locks from freezing use engine coolant or other types of...

  • Page 309: Vehicle Load Limit

    VEHICLE LOAD LIMIT Two labels on your driver's door sill show GAW (Gross Axle Weight) how much weight your vehicle was This is the total weight placed on each designed to carry: the Tire and Loading axle (front and rear) - including vehicle Information Label and the Certification curb weight and all payload.

  • Page 310: Tire Loading Information Label

    Driving Your Vehicle Tire Loading Information Label Seating capacity Total: 5 persons (Front seat : 2 persons, Rear seat : 3 persons) Seating capacity is the maximum number of occupants including a driver, your vehicle may carry. However, the seating capacity may be reduced based upon the weight of all of the occupants, and the weight of the cargo being carried or towed.
  • Page 311 Steps for determining correct load WARNING limit Do not overload the vehicle as there 1. Locate the statement "The combined is a limit to the total weight, or load weight of occupants and cargo should limit, including occupants and cargo, never exceed XXX kg or XXX lbs."...
  • Page 312 Driving Your Vehicle Example 1 Maximum Load Passenger Weight Cargo Weight (1400 lbs.) (150 lbs. × 2 = 300 lbs.) (1100 lbs.) (635 kg) (68 kg × 2 = 136 kg) (499 kg) Example 2 Maximum Load Passenger Weight Cargo Weight (1400 lbs.) (150 lbs.

  • Page 313: Trailer Towing

    Certification label Do not overload your vehicle. Overloading your vehicle can cause heat buildup in your vehicle’s tires and possible tire failure, increased stopping distances and poor vehicle handling-all of which may result in a crash. NOTICE Overloading your vehicle may cause damage.

  • Page 314: Driver Assistance System

    7. Driver Assistance System Driving Safety Forward Collision–Avoidance Assist (FCA) (Front view camera only) ....7-2 Lane Keeping Assist (LKA) ..................7-14 Blind-Spot Collision-Avoidance Assist (BCA) ............7-20 Safe Exit Warning (SEW) ..................7-34 Manual Speed Limit Assist (MSLA) ................7-40 Driver Attention Warning (DAW) ................7-43 Driving Convenience Cruise Control (CC) ....................7-50 Lane Following Assist (LFA) ..................
  • Page 315 If the detecting sensor has been replaced or repaired, have your vehicle inspected by an authorized OCN7N071084 HYUNDAI dealer. Forward Collision-Avoidance Assist is Never install any accessories or designed to help detect and monitor the stickers on the front windshield, or vehicle ahead or detect a pedestrian in tint the front windshield.
  • Page 316 If ‘Warning Only’ is selected, braking is not assisted. The driver can monitor Forward Collision-Avoidance Assist On/Off status from the Settings menu. If the warning light remains on when Forward Collision-Avoidance Assist is on, have the vehicle inspected by an authorized HYUNDAI dealer.

  • Page 317: Forward Collision-Avoidance Assist (Fca) (Front View Camera Only)

    Driver Assistance System Information Forward Collision-Avoidance Assist will turn off when ESC is turned off by pressing and holding the ESC OFF button. The warning light will illuminate on the cluster. Driving Safety system includes Forward Collision-Avoidance Assist, Lane Keeping Assist, Blind-Spot Collision-Avoidance Assist and Driver Attention Warning.
  • Page 318 Forward Collision-Avoidance Assist Operation Warning and control The basic feature of Forward Collision- Avoidance Assist is to warn and help control the vehicle depending on OCN7N071015L Emergency Braking To warn the driver that emergency braking will occur, the ‘Emergency on the cluster and an audible warning will sound.
  • Page 319 Driver Assistance System Forward Collision-Avoidance Assist does not operate in all situations and cannot avoid all collisions. The driver has the responsibility to control the vehicle. Do not solely depend on Forward Collision- Avoidance Assist. Rather, maintain a safe braking distance, and, if necessary, depress the brake pedal to reduce driving speed or to stop the vehicle.
  • Page 320 Have the vehicle inspected by an authorized Information HYUNDAI dealer. In a situation where collision is imminent, braking may be assisted by Forward Collision-Avoidance Assist when braking is insufficient by the driver.
  • Page 321 An object is placed on the dashboard obstruction (snow, rain, or foreign Your vehicle is being towed material) is removed, have the vehicle The surrounding is very bright inspected by an authorized HYUNDAI dealer. The surrounding is very dark, such as in a tunnel, etc. WARNING...
  • Page 322 Driving through steam, smoke or You are departing or returning to the shadow lane Only part of the vehicle, or pedestrian Unstable driving is detected You are on a roundabout and the The vehicle in front is a bus, heavy vehicle in front is not detected truck, truck with an unusually shaped You are continuously driving in a circle...
  • Page 323 Driver Assistance System There is a group of pedestrians or a WARNING large crowd in front Driving on a curved road The pedestrian is wearing clothing that easily blends into the background, making it difficult to detect The pedestrian is difficult to distinguish from the similarly shaped structure in the surroundings You are driving by a pedestrian,...
  • Page 324 Driving on an inclined road OADAS005SD OADAS006SD Forward Collision-Avoidance Assist OADAS009SD may detect a vehicle or pedestrian in the next lane or outside the lane when driving on a curved road. If this occurs, Forward Collision- Avoidance Assist may unnecessarily warn the driver and control the brake.
  • Page 325 Driver Assistance System Changing lanes OADAS033SD [A] : Your vehicle, OADAS032SD [B] : Lane changing vehicle, [A] : Your vehicle, [C] : Same lane vehicle [B] : Lane changing vehicle When a vehicle in front of you When a vehicle moves into your lane merges out of the lane, Forward from an adjacent lane, it cannot Collision-Avoidance Assist may not...
  • Page 326 Detecting vehicle WARNING When you are towing a trailer or another vehicle, we recommend that Forward Collision-Avoidance Assist is turned off due to safety reasons. Forward Collision-Avoidance Assist may operate if objects that are similar in shape or characteristics to vehicles and pedestrians are detected.

  • Page 327: Lane Keeping Assist (Lka)

    Driver Assistance System Lane Keeping Assist is designed to help Lane Keeping Assist Settings detect lane markings (or road edges) Setting features while driving over a certain speed. Lane Keeping Assist will warn the driver if the vehicle leaves the lane without using the turn signal, or will automatically assist vehicle from departing the lane.
  • Page 328 Driving Safety Auto Off in N mode OCN7N071002N Turning Lane Keeping Assist On/Off OCN7N071090L With the engine on and the Lane Safety With the engine on, select ‘Driver button is pushed, the function turns on and the white indicator appears on the cluster.
  • Page 329 Driver Assistance System Lane Keeping Assist Operation Lane Keeping Assist Warning and control To warn the driver that the vehicle is departing from the projected lane Lane Keeping Assist will warn and help in front, the green indicator control the vehicle with Lane Departure light will blink on the cluster, and the Warning and Lane Keeping Assist.
  • Page 330 WARNING Information The steering wheel may not be For more details on setting the assisted if the steering wheel is held functions in the infotainment system very tight or the steering wheel is Vehicle Settings, refer to “Vehicle steered over a certain degree. Settings”...
  • Page 331 If this or narrow occurs, have the vehicle inspected by an There is a road edge without a lane authorized HYUNDAI dealer. There is a boundary structure in the Limitations of Lane Keeping Assist roadway, such as a tollgate, sidewalk, curb, etc.
  • Page 332 If any other system’s warning WARNING message is displayed or audible Take the following precautions when warning is generated, Lane Keeping using Lane Keeping Assist: Assist warning message may not be displayed and audible warning may The driver has the responsibility to not be generated.

  • Page 333: Blind-Spot Collision-Avoidance Assist (Bca)

    Driver Assistance System Blind-Spot Collision-Avoidance Assist is designed to help detect and monitor blind spot area and warn the driver of a possible collision with a warning message and audible warning. In addition, if there is a risk of collision when changing lanes or driving forward out of a parking space, Blind-Spot Collision-Avoidance Assist can help avoid...
  • Page 334 Detecting sensor HYUNDAI dealer. Use only genuine HYUNDAI parts to repair the rear bumper where the rear corner radar is located. Do not apply license plate frame or objects, such as a bumper sticker, film or a bumper guard near the rear corner radar.
  • Page 335 Driver Assistance System Information For more details on the precautions of the front view camera, refer to “Forward Collision-Avoidance Assist (FCA)” section in chapter 7. Blind-Spot Collision-Avoidance Assist Settings Setting features OTM070097N When the engine is restarted with Blind- Spot Collision-Avoidance Assist off, message will appear on the cluster.
  • Page 336 Driving Safety Auto Off in N mode OCN7N071091L Warning Timing OCN7N071090L With the engine on, select ‘Driver With the engine on, select ‘Driver Settings menu to change the initial warning activation time for Blind-Spot whether to use the function. Collision-Avoidance Assist. When the vehicle is first delivered, is selected, Blind-Spot Collision- Avoidance Assist turns off...
  • Page 337 Driver Assistance System Blind-Spot Collision-Avoidance Assist Operation Warning and control OCN7N071092L Warning Volume With the engine on, select ‘Driver OCN7N071151 Settings menu to change the Warning Vehicle detection Blind-Spot Collision-Avoidance Assist. To warn the driver a vehicle is detected, the warning light on the If you change the Warning Volume, side view mirror will illuminate.
  • Page 338 Collision warning Information Collision Warning will operate when If the driver's seat is on the left side, the the turn signal is turned on in the collision warning may occur when you direction of the detected vehicle. turn left. Maintain a proper distance with the vehicles in the left lane.
  • Page 339 Driver Assistance System WARNING Collision-avoidance assist will be cancelled under the following circumstances: - Your vehicle enters the next lane by a certain distance - Your vehicle is away from the collision risk - The steering wheel is sharply steered OCN7N071124L - The brake pedal is depressed Collision-avoidance assist (while...
  • Page 340 Blind-Spot Collision-Avoidance Assist may not operate if the driver applies the brake pedal to avoid collision. When Blind-Spot Collision-Avoidance Assist is operating, braking control by the function will automatically cancel when the driver excessively depresses the accelerator pedal or sharply steers the vehicle. During Blind-Spot Collision- OCN7N071017L Avoidance Assist operation, the...
  • Page 341 Assist malfunction for several seconds, and the master ) warning light will illuminate on the cluster. If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer. OTM070099N When Blind-Spot Collision-Avoidance Assist is not working properly, the ‘Check...
  • Page 342 The rear corner radar is covered with removed, have the vehicle inspected by snow, rain, dirt, etc. an authorized HYUNDAI dealer. The temperature around the rear corner radar is high or low Driving on a highway ramp...
  • Page 343 Driver Assistance System The road pavement (or the peripheral The speed of the other vehicle is very ground) abnormally contains metallic fast that it passes by your vehicle in a components (for example, possibly short time due to subway construction) Your vehicle passes by the other There is a fixed object near the vehicle...
  • Page 344 WARNING attention is required in the following Driving on a curved road circumstances: The vehicle severely vibrates while driving over a bumpy road, uneven road or concrete patch Driving on a slippery surface due to snow, water puddle, ice, etc. The tire pressure is low or a tire is damaged The braking system has been modified...
  • Page 345 Driver Assistance System Driving where the road is merging/ Driving where the heights of the dividing lanes are different OCN7N071099L OCN7N072059N Blind-Spot Collision-Avoidance Blind-Spot Collision-Avoidance Assist may not operate properly Assist may not operate properly when driving where the road merges when driving where the heights of or divides.
  • Page 346 Information This device complies with Part 15 of the FCC rules. Operation is subject to the following three conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 347 Driver Assistance System Detecting sensor OHY050024 After the vehicle stops, when an OCN7N071054N approaching vehicle from the rear area [1] : Rear corner radar is detected after a passenger opens Refer to the picture above for the the door, Safe Exit Warning will warn detailed location of the detecting the driver with a warning message and sensors.

  • Page 348: Safe Exit Warning (Sew)

    Safe Exit Warning Settings Setting features OCN7N071092L Warning Volume With the engine on, select ‘Driver OCN7N071100L Safe Exit Warning Settings menu to change the Warning With the engine on, select ‘Driver Safe Exit Warning. If you change the warning volume, on Safe Exit Warning and deselect to turn the Warning Volume of other Driver off the function.
  • Page 349 Driver Assistance System Safe Exit Warning Operation WARNING Warning Take the following precautions when using Safe Exit Warning: For your safety, only change the Settings after parking the vehicle at a safe location. If any other system’s warning message is displayed or audible warning is generated, Safe Exit Warning's warning message may not be displayed and audible warning...
  • Page 350 When Safe Exit Warning is not working properly, the ‘Check Blind-Spot Safety the cluster for several seconds, and the master ( ) warning light will illuminate on the cluster. If the master warning light illuminates, have the vehicle inspected by an authorized HYUNDAI dealer. 7-37...
  • Page 351 If the master warning light temporarily limit or disable Safe Exit illuminates, have the vehicle inspected Warning. by an authorized HYUNDAI dealer. If this occurs, the ‘Blind-Spot Safety message will appear on the cluster. Safe Exit Warning will operate properly when such foreign material or trailer, etc., is removed, and then the engine is...
  • Page 352 Limitations of Safe Exit Warning WARNING Safe Exit Warning may not operate Even though the warning message properly, or it may operate unexpectedly does not appear on the cluster, under the following circumstances: Safe Exit Warning may not properly Getting out of the vehicle where trees operate.

  • Page 353: Manual Speed Limit Assist (Msla)

    Driver Assistance System Manual Speed Limit Assist Operation Setting speed limit OJK071213N (1) Manual Speed Limit Assist enabled indicator (2) Set speed OCN7N071006 You can set the speed limit when you do 1. Press and hold Driving Assist button not want to drive over a specific speed. at the desired speed.
  • Page 354 OCN7N071132L OJK071214N 2. Push the + switch up or - switch down, 3. The set speed limit will be displayed and release it at the desired speed. on the cluster. Push the + switch up or - switch down If you would like to drive over the and hold it.
  • Page 355 Driver Assistance System Temporarily pausing Manual Speed Turning off Manual Speed Limit Limit Assist Assist OCN7N071133L OCN7N071006 Push the switch to temporarily Press the Driving Assist button to turn pause the set speed limit. The set speed Manual Speed Limit Assist off. The limit will turn off but the Manual Speed Manual Speed Limit Assist enabled Limit Assist enabled (...

  • Page 356: Driver Attention Warning (Daw)

    Basic function Driver Attention Warning Settings Driver Attention Warning can help determine the driver's attention level Setting features by analyzing driving pattern and driving time while the vehicle is driven. Driver Attention Warning will recommend a falls below a certain level. Leading Vehicle Departure Alert function Leading Vehicle Departure Alert function...
  • Page 357 Driver Assistance System Driving Safety Auto Off in N mode OCN7N071091L Warning Timing OCN7N071090L With the engine on, select ‘Driver With the engine on, select ‘Driver Settings menu to change the initial warning activation time for Driver whether to use the function. Attention Warning.
  • Page 358 Driver Attention Warning on the scale of 1 to 5. The lower the Operation level is, the more inattentive the driver Basic function Display and warning The level decreases when the driver The basic function of Driver Attention does not take a break for a certain Warning is to inform the driver of their period of time.
  • Page 359 Driver Assistance System Leading Vehicle Departure Alert CAUTION function Driver Attention Warning may suggest a break depending on the driver’s driving pattern or habits, even if the driver doesn’t feel fatigued. Driver Attention Warning is a supplemental function and may not be able to determine whether the driver is inattentive.
  • Page 360 ) warning light will illuminate on the cluster. If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer. OADAS040SD OADAS042SD [A] : Your vehicle, [B] : Front vehicle...
  • Page 361 Driver Assistance System When the vehicle ahead sharply steers When a pedestrian or bicycle is between your vehicle and the vehicle ahead OADAS034SD [A] : Your vehicle, [B] : Front vehicle OADAS025SD If the vehicle in front makes a sharp If there is a pedestrian(s) or bicycle(s) turn, such as to turn left or right or in between your vehicle and the...
  • Page 362 When driving at a tollgate or intersection, etc. OCN7N071106L If you pass a tollgate or intersection with lots of vehicles or you drive where lanes are merged or divided frequently, Leading Vehicle Departure Alert may not operate properly. Information For more details on the precautions of the front view camera, refer to “Forward Collision-Avoidance Assist (FCA)”...
  • Page 363 Driver Assistance System Cruise Control Operation Setting speed 1. Accelerate to the desired speed, which must be more than 20 mph (30 km/h). OIK057157N (1) Cruise indicator (2) Set speed Cruise Control allows you to drive at speeds above 20 mph (30 km/h) without OCN7N071006 depressing the accelerator pedal.
  • Page 364 Increasing set speed Decreasing set speed OCN7N071134L OCN7N071135L Push the + switch up and release Push the - switch down and release it immediately. The set speed will it immediately. The set speed will increase by 1 mph (1 km/h) each time decrease by 1 mph (1 km/h) each time the switch is operated in this manner.
  • Page 365 ) indicator will stay on. using the button. Driving speed may sharply increase or decrease when you press the button. NOTICE If Cruise Control pauses during a situation that is not mentioned, have the vehicle inspected by an authorized HYUNDAI dealer. 7-52...
  • Page 366 Turning off Cruise Control WARNING Take the following precautions when using Cruise Control: Always set the vehicle speed under the posted speed limit. Keep Cruise Control off when the function is not in use, to avoid inadvertently setting a speed. Check that the Cruise ( ) indicator is off.
  • Page 367 Driver Assistance System Lane Following Assist is designed to help Lane Following Assist Settings detect lane markings and/or vehicles on Setting features to help center the vehicle in the lane. Detecting sensor OCN7N071137L Turning Lane Following Assist On/Off With the engine on, shortly press the Lane Driving Assist button located on the OCN7N071001N steering wheel to turn on Lane Following...
  • Page 368 Lane Following Assist Operation Warning and control OCN7N071092L Warning Volume With the engine on, select ‘Driver OCN7N071039N Lane Following Assist Settings menu to change the Warning If the vehicle ahead and/or both lane markings are detected and your vehicle Hands-off warning. speed is below 110 mph (180 km/h), the If you change the Warning Volume, green...
  • Page 369 Driver Assistance System WARNING The steering wheel may not be assisted if the steering wheel is held very tight or the steering wheel is steered over a certain degree. Lane Following Assist does not operate at all times. It is the responsibility of the driver to safely steer the vehicle and to maintain the vehicle in its lane.

  • Page 370: Lane Following Assist (Lfa)

    ‘Check Lane message will appear on the cluster for several seconds, and the master ) warning light will illuminate on the cluster. If this occurs, Have the vehicle inspected by an authorized HYUNDAI dealer. Limitations of Lane Following Assist OCN7N071142L OCN7N071143L...

  • Page 371: Rear View Monitor (Rvm)

    Driver Assistance System Rear View Monitor Settings Camera settings OCN7N071007N OCN7N071075N You can change Rear View Monitor by touching the setup icon ( ) on the screen while Rear View Monitor is operating, or selecting ‘Driver while the engine is on. In the Display Settings, you can OCN7N071152L Rear View Monitor shows the area...
  • Page 372 Rear View Monitor Operation Rear view Operating button Operating conditions Shift the gear to R (Reverse), the Type A image will appear on the screen. Press the Parking/View button (1) while the gear is in P (Park), the image will appear on the screen. When you touch the ( ) icon, the rear view is displayed on the screen.
  • Page 373 Driver Assistance System Extended Rear View Monitor Rear top view The rear view will maintain showing on the screen to help you when parking. Operating conditions Shift the gear from R (Reverse) to N (Neutral) or D (Drive), the rear view will appear on the screen.
  • Page 374 HYUNDAI dealer. Limitations of Rear View Monitor When the vehicle is stopped for a long time in winter or when the vehicle is...
  • Page 375 Driver Assistance System Rear Cross-Traffic Collision-Avoidance Detecting sensor Assist is designed to help detect vehicles approaching from the rear left and right side while your vehicle is reversing, and warn the driver that a collision is imminent with a warning message and an audible warning.
  • Page 376 Rear Cross-Traffic Collision- Avoidance Assist Settings Setting features OCN7N071091L Warning Timing With the engine on, select ‘Driver OCN7N071107N Settings menu to change the initial Rear Cross-Traffic Safety warning activation time for Rear Cross- With the engine on, select ‘Driver Traffic Collision-Avoidance Assist. When the vehicle is first delivered, to turn on Rear Cross-Traffic Collision- change the Warning Timing, the Warning...

  • Page 377: Rear Cross-Traffic Collision-Avoidance Assist (Rcca)

    Driver Assistance System CAUTION The setting of the Warning Timing and Warning Volume applies to all functions of Rear Cross-Traffic Collision-Avoidance Assist. Even though ‘Standard’ is selected for Warning Timing, if a vehicle from the left or right side approach at a high speed, the warning may seem late.
  • Page 378 Rear Cross-Traffic Collision- Collision Warning Avoidance Assist Operation To warn the driver of an approaching vehicle from the rear left/right side Warning and control of your vehicle, the warning light on Rear Cross-Traffic Collision-Avoidance the side view mirror will blink and a Assist will warn and help control the warning will appear on the cluster.
  • Page 379 Driver Assistance System Rear Cross-Traffic Collision-Avoidance Assist will operate when all the following conditions are satisfied: - The gear is shifted to R (Reverse) - The vehicle speed is below 5 mph (8 km/h) - The approaching vehicle is within approximately 5 ft.
  • Page 380 You may not hear the warning sound of Rear Cross-Traffic Collision- Avoidance Assist if the surroundings are noisy. Rear Cross-Traffic Collision- Avoidance Assist may not operate if the driver applies the brake pedal to avoid collision. During Rear Cross-Traffic Collision- Avoidance Assist operation, the vehicle may stop suddenly injuring OCN7N071035L...
  • Page 381 ( ) warning light will left and right vehicle approach. illuminate on the cluster. If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer. 7-68...
  • Page 382 ) warning light will illuminate on the or installing a trailer or carrier, it can cluster. If this occurs, have the vehicle reduce the detecting performance and inspected by an authorized HYUNDAI temporarily limit or disable Rear Cross- dealer. Traffic Collision-Avoidance Assist.
  • Page 383 Driver Assistance System Limitations of Rear Cross-Traffic WARNING Collision-Avoidance Assist Even though the warning message Rear Cross-Traffic Collision-Avoidance does not appear on the cluster, Rear Assist may not operate properly, or it Cross-Traffic Collision-Avoidance may operate unexpectedly under the Assist may not operate properly. following circumstances: Rear Cross-Traffic Collision- Departing from where trees or grass...
  • Page 384 When the vehicle is in a complex WARNING parking environment Driving near a vehicle or structure OHY059018 OHY059017 Rear Cross-Traffic Collision- [A] : Structure Avoidance Assist may detect vehicles which are parking or pulling out Rear Cross-Traffic Collision- Avoidance Assist may be limited near your vehicle (for example, a vehicle leaving beside your vehicle, when driving near a vehicle or...
  • Page 385 Driver Assistance System When the vehicle is parked When the vehicle is on or near a diagonally slope OHY059019 OCN7N071060 [A] : Vehicle Rear Cross-Traffic Collision- Avoidance Assist may be limited Rear Cross-Traffic Collision- when the vehicle is on an uphill or Avoidance Assist may be limited downhill slope, or near it, and may when backing up diagonally,...
  • Page 386 Pulling into the parking space where WARNING there is a structure When you are towing a trailer or another vehicle, we recommend that Rear Cross-Traffic Collision- Avoidance Assist is turned off due to safety reasons. Rear Cross-Traffic Collision- Avoidance Assist may not operate properly if interfered by strong electromagnetic waves.
  • Page 387 Driver Assistance System Reverse Parking Distance Warning can Reverse Parking Distance help warn the driver if an obstacle is Warning Settings detected within a certain distance when Warning Volume the vehicle is moving forward or in reverse at low speeds. Detecting sensor OCN7N071092L With the engine on, select ‘Driver Assistance...

  • Page 388: Reverse Parking Distance Warning (Pdw)

    Warning foreign material. If it still does not work indicator properly, have the vehicle inspected by Distance Warning when an authorized HYUNDAI dealer. from object sound driving The audible warning does not sound. backward The buzzer sounds intermittently. 24~48 in.
  • Page 389 Driver Assistance System Limitations of Reverse Parking WARNING Distance Warning Reverse Parking Distance Warning Reverse Parking Distance Warning is a supplemental function. The may not operate properly when: operation of Reverse Parking - Moisture is frozen to the sensor Distance Warning can be affected by several factors (including - Sensor is covered with substance, environmental conditions).
  • Page 390 Parking Distance Warning indicator may not occur sequentially depending on vehicle speed or obstacle shape. If Reverse Parking Distance Warning needs repair, have the vehicle inspected by an authorized HYUNDAI dealer. 7-77...
  • Page 391 Driver Assistance System The radio frequency components (Rear Corner Radar) complies: - For USA - For Canada OANATEL124 OANATEL123 7-78...

  • Page 392: Emergency Situations

    8. Emergency Situations Hazard Warning Flasher ................8-2 In Case of an Emergency While Driving ............8-2 If the Engine Stalls While Driving ................8-2 If the Engine Stalls at a Crossroad or Crossing ............8-2 If you Have a Flat Tire While Driving ............... 8-3 If the Engine Will not Start ................

  • Page 393: Hazard Warning Flasher

    Turn on your hazard warning flasher. Try to start the engine again. If your vehicle will not start, contact an authorized HYUNDAI dealer or seek other qualified assistance. OCN7070001 The hazard warning flasher serves as...

  • Page 394: If You Have A Flat Tire While Driving

    Normally but Doesn’t Start traffic. When changing a flat tire, follow the Check the fuel level and add fuel if instructions provided later in this necessary. chapter. If the engine still does not start, have your vehicle checked by an authorized HYUNDAI dealer.

  • Page 395: Jump Starting

    Emergency Situations JUMP STARTING Jump starting can be dangerous if done If acid gets into your eyes, flush your incorrectly. Follow the jump starting eyes with clean water for at least 15 procedure in this section to avoid serious minutes and get immediate medical injury or damage to your vehicle.
  • Page 396 In this event please seek qualified 7. Connect the second jumper cable to assistance. If the cause of your battery the black, negative (-) battery/jumper discharging is not apparent, have your terminal of the assisting vehicle (3). vehicle checked by an authorized HYUNDAI dealer.
  • Page 397 Emergency Situations Disconnect the jumper cables in the exact reverse order you connected them: 1. Disconnect the jumper cable from the black, negative (-) chassis ground of your vehicle (4). 2. Disconnect the other end of the jumper cable from the black, negative (-) battery/chassis ground of the assisting vehicle (3).

  • Page 398: If The Engine Overheats

    HYUNDAI dealer for has stopped. If there is no visible assistance. loss of engine coolant and no steam,...
  • Page 399 7. Proceed with caution, keeping alert for further signs of overheating. If overheating happens again, call an authorized HYUNDAI dealer for assistance. NOTICE Serious loss of coolant indicates a leak in the cooling system and have system be checked by an authorized HYUNDAI dealer.

  • Page 400: Check Tire Pressure

    Check Tire Pressure Type A OCN7N081002N OCN7N081056L Type B OCN7N081055L (1) Low Tire Pressure Telltale/TPMS OCN7N041115L Malfunction Indicator You can check the tire pressure in the (2) Low Tire Pressure Position Telltale Assist mode on the cluster. and Tire Pressure Telltale (Shown on Refer to the “LCD Display Modes”...
  • Page 401 Emergency Situations Tire Pressure Monitoring System Please note that the TPMS is not a substitute for proper tire maintenance, and it is the driver’s responsibility to WARNING maintain correct tire pressure, even if under-inflation has not reached the level Over-inflation or under-inflation can to trigger illumination of the TPMS low reduce tire life, adversely affect vehicle tire pressure telltale.

  • Page 402: Low Tire Pressure Position And Tire Pressure Telltale

    NOTICE Low Tire Pressure Telltale If any of the below happens, have the system checked by an authorized HYUNDAI dealer. Low Tire Pressure Position and 1. The Low Tire Pressure Telltale/ TPMS Tire Pressure Telltale Malfunction Indicator does not illuminate for 3 seconds when the Engine Start/Stop button is set to the ON position or engine is running.
  • Page 403 Emergency Situations If either telltale illuminates, immediately CAUTION reduce your speed, avoid hard cornering In winter or cold weather, the Low Tire and anticipate increased stopping Pressure Telltale may be illuminated if distances. You should stop and check the tire pressure was adjusted to the your tires as soon as possible.

  • Page 404: Tpms (Tire Pressure Monitoring System) Malfunction Indicator

    Have the system be checked by an authorized HYUNDAI dealer. It is recommended that you do not use a puncture-repairing agent not approved by a HYUNDAI dealer to repair and/or NOTICE inflate a low pressure tire. Tire sealant If there is a malfunction with the TPMS,...
  • Page 405 You must use the Tire Pressure Monitoring System TPMS specific wheels. Always have your (TPMS) components may interfere tires serviced by an authorized HYUNDAI with the system’s ability to warn the dealer. driver of low tire pressure conditions You may not be able to identify a tire and/or TPMS malfunctions.

  • Page 406: Introduction

    For this reason, you should avoid abrupt HYUNDAI dealer. steering or other driving maneuvers, especially if the vehicle is heavily loaded CAUTION or if a trailer is in use.

  • Page 407: Components Of The Tire Mobility Kit

    Emergency Situations Components of the Tire Mobility Kit OCN7H080007 0. Speed-restriction label 1. Sealant bottle and label with speed restriction 2. Filling hose 3. Connectors and cable for the power outlet direct connection 4. Holder for the sealant bottle 5. Compressor 6.

  • Page 408: Using The Tire Mobility Kit When A Tire Is Flat

    1. Shake the sealant bottle. WARNING Expired sealant Do not use the Tire sealant after the sealant has expired (i.e. pasted the expiration date on the sealant container). This can increase the risk of tire failure. WARNING Sealant Keep out of reach of children. OCN7070007 2.
  • Page 409 Emergency Situations 8. Switch off the compressor. 9. Detach the hoses from the sealant bottle connector and from the tire valve. Return the Tire Mobility Kit to its storage location in the vehicle. WARNING Carbon monoxide Do not leave your vehicle running in OCN7N081005 a poorly ventilated area for extended 5.
  • Page 410 Then repeat steps 11 to 14. Use of the TMK may be ineffectual for tire damage larger than approximately 0.16 in (4 mm). Please contact the nearest HYUNDAI dealership if the tire cannot be made OCN7N081093 roadworthy with the Tire Mobility Kit.

  • Page 411: How To Adjust Tire Pressure

    Emergency Situations NOTICE Information Do not let the compressor run for more When reinstalling the repaired or replaced than 10 minutes, otherwise the device tire and wheel on the vehicle, tighten the will overheat and may be damaged. wheel lug nut to 79~94 lbf·ft (11~13 kgf·m). How to Adjust Tire Pressure Information The pressure gauge may show higher than...

  • Page 412: Notes On The Safe Use Of The Tire Mobility Kit

    0.24 in (6 mm). Long time exposure to the sealant Please contact the nearest HYUNDAI may cause damage to bodily tissue dealership if the tire cannot be made such as kidney, etc.

  • Page 413: Towing

    Use a wheel lift or flatbed equipment. OCN7N081095L If emergency towing is necessary, have it done by an authorized HYUNDAI dealer or a commercial tow-truck service. Proper lifting and towing procedures are necessary to prevent damage to the vehicle. The use of wheel dollies or OCN7N081096L flatbed is recommended.

  • Page 414: Emergency Towing

    WARNING If towing is necessary, have it done by If your vehicle is equipped with a an authorized HYUNDAI dealer or a rollover sensor, set the Engine Start/ commercial tow truck service. Stop button in the OFF or ACC position when the vehicle is being towed.

  • Page 415: Emergency Towing

    OCN7N081105N communicate with each other If towing is necessary, have it done by frequently. an authorized HYUNDAI dealer or a commercial tow truck service. Before emergency towing, check that the hook is not broken or damaged. If towing service is not available in...
  • Page 416 NOTICE Accelerate or decelerate the vehicle in a slow and gradual manner while maintaining tension on the tow rope or chain to start or drive the vehicle, otherwise tow hooks and the vehicle may be damaged. NOTICE To avoid damage to your vehicle and vehicle components when towing: OCN7N081099L Use a towing cable or chain less than...

  • Page 417: Maintenance

    9. Maintenance Engine Compartment ..................9-3 Maintenance Services ...................9-4 Owner’s Responsibility ....................9-4 Owner Maintenance Precautions ................9-4 Owner Maintenance ..................9-5 Owner Maintenance Schedule ................9-5 Scheduled Maintenance Services ..............9-7 Normal Maintenance Schedule ................9-9 Maintenance Under Severe Usage Conditions .............9-12 Explanation of Scheduled Maintenance Items .......... 9-14 Dual clutch transmission fluid ................9-15 Drive Axle Shafts and Boots ...................9-15 Engine Oil .....................
  • Page 418 Tires and Wheels ..................9-33 Tire Care ........................9-34 Recommended Cold Tire Inflation Pressures ............9-34 Check Tire Inflation Pressure ................. 9-35 Tire Rotation ......................9-35 Wheel Alignment and Tire Balance ...............9-36 Tire Replacement ....................9-37 Wheel Replacement ....................9-38 Tire Traction ......................9-38 Tire Maintenance....................9-38 Tire Sidewall Labeling ....................9-38 Tire Terminology and Definitions ................9-41...

  • Page 419: Engine Compartment

    ENGINE COMPARTMENT 2.0 T-GDi The actual engine compartment in the vehicle may differ from the illustration. OCN7N091001 1. Engine coolant reservoir 5. Engine oil filler cap 2. Brake/clutch fluid reservoir 6. Windshield washer fluid reservoir 3. Air cleaner 7. Fuse box 4.

  • Page 420: Maintenance Services

    HYUNDAI’s high service quality procedures can be done only by an standards and receives technical support authorized HYUNDAI dealer with special from HYUNDAI in order to provide you tools. with a high level of service satisfaction. Your vehicle should not be modified in any way.

  • Page 421: Owner Maintenance

    The following lists are vehicle checks and WARNING inspections that should be performed Performing maintenance work on a by the owner or an authorized HYUNDAI vehicle can be dangerous. If you lack dealer at the frequencies indicated to sufficient knowledge and experience or...
  • Page 422 Maintenance While operating your vehicle: At least twice a year: (for example, every Spring and Note any changes in the sound of the Autumn) exhaust or any smell of exhaust fumes in the vehicle. Check radiator, heater and air conditioning hoses for leaks or Check for vibrations in the steering damage.

  • Page 423: Scheduled Maintenance Services

    SCHEDULED MAINTENANCE SERVICES Follow Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply. If any of the following conditions apply, you must follow the Maintenance Under Severe Usage Conditions. Repeatedly driving short distance of less than 5 miles (8 km) in normal temperature of less than 10 miles (16 km) in freezing temperature.
  • Page 424 Then, select ‘Yes’ when the message “Has the engine oil been changed? Press [Yes] to reset the oil life.” appears on the screen. - If there is no alert until the maximum maintenance interval, have the vehicle checked by an authorized HYUNDAI dealer.
  • Page 426 Maintenance 9-10...
  • Page 427 9-11...

  • Page 428: Maintenance Under Severe Usage Conditions

    Maintenance Maintenance Under Severe Usage Conditions The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Driving Maintenance item...
  • Page 429 Severe driving conditions A. Repeatedly driving short distance of less than 5 miles (8 km) in normal temperature of less than 10 miles (16 km) in freezing temperature. B. Extensive engine idling or low speed driving for long distances. C. Driving on rough, dusty, muddy, unpaved, graveled or salt- spread roads. D.

  • Page 430: Explanation Of Scheduled Maintenance Items

    Air Cleaner Filter Information A genuine HYUNDAI air cleaner filter is recommended when the filter is When you are inspecting the belt, turn the replaced. engine off. Spark Plugs...

  • Page 431: Dual Clutch Transmission Fluid

    With the vehicle stopped and the engine Have the Dual clutch transmission fluid off, check for excessive freeplay in the is changed by an authorized HYUNDAI steering wheel. Check the linkage for dealer according to the maintenance bends or damage. Check the dust boots schedule.

  • Page 432: Engine Oil

    Maintenance ENGINE OIL Checking the Engine Oil Level Engine oil is used for lubricating, cooling, and operating various hydraulic components in the engine. Engine oil consumption while driving is normal, and it is necessary to check and refill the engine oil regularly. Also, check and refill the oil level within the recommended maintenance schedule to prevent deterioration of oil performance.

  • Page 433: Checking The Engine Oil And Filter

    Have the engine oil if necessary. and filter changed by an authorized HYUNDAI dealer according to the Oil Life Management System Instructions or the Maintenance Schedule at the beginning of this chapter.
  • Page 434 Maintenance CAUTION The engine oil is very hot immediately after the vehicle has been driven and can cause burns during replacement. Replace the engine oil after the engine oil has cooled down. WARNING CALIFORNIA PROPOSITION 65 WARNING Engine oil contains chemicals known to the State of California to cause cancer, birth defects and reproductive harm.

  • Page 435: Engine Coolant

    ENGINE COOLANT The high-pressure cooling system has a Checking the Engine Coolant reservoir filled with year-round antifreeze Level coolant. The reservoir is filled at the factory. Check the antifreeze protection and coolant level at least once a year, at the beginning of the winter season and before traveling to a colder climate.
  • Page 436 Maintenance WARNING WARNING Make sure the coolant cap is properly Never remove the engine closed after refilling coolant. Otherwise coolant cap or the drain plug the engine could be overheated while while the engine and radiator driving. are hot. Hot coolant and steam may blow out under pressure, causing serious injury.
  • Page 437 Recommended engine coolant WARNING When adding coolant, use only The electric motor for the distilled (deionized) water for your cooling fan may continue to vehicle and never mix hard water in operate or start up when the the coolant filled at the factory. engine is not running and can An improper coolant mixture can cause serious injury.

  • Page 438: Changing Engine Coolant

    Maintenance Changing Engine Coolant Have coolant changed by an authorized HYUNDAI dealer according to the Maintenance Schedule at the beginning of this chapter. WARNING Do not use engine coolant or antifreeze in the washer fluid reservoir. Engine coolant can severely obscure...

  • Page 439: Brake/Clutch Fluid

    To maintain the best braking If the fluid level is excessively low, have performance and ABS/ESC the system be checked by an authorized performance, have you use genuine HYUNDAI dealer. brake/clutch fluid that conform to specifications. Information (Standard : SAE J1704 DOT-4 LV, ISO4925 CLASS-6 and FMVSS 116 Use only the specified brake/clutch fluid.

  • Page 440: Washer Fluid

    If the stroke is more or less than specified, have the system serviced by an authorized HYUNDAI WARNING dealer. To prevent serious injury or death, take Stroke : 5~7 “clicks’’...

  • Page 441: Air Cleaner

    AIR CLEANER Filter Replacement OCN7N091007 2. Replace the air cleaner filter. OCN7N091005 The air cleaner filter can be cleaned for inspection using compressed air. Do not attempt to wash or to rinse it, as water will damage the filter. If soiled, the air cleaner filter must be replaced.
  • Page 442 When removing the air cleaner filter, be careful that dust or dirt does not enter the air intake, or damage may result. Use HYUNDAI genuine parts or the equivalent specified for your vehicle. Use of parts without the matching quality could damage the air flow sensor.

  • Page 443: Cabin Air Filter

    CABIN AIR FILTER Filter Inspection The cabin air filter should be replaced according to the Maintenance Schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.

  • Page 444: Wiper Blades

    Maintenance WIPER BLADES Blade Inspection Blade Replacement Contamination of either the windshield When the wipers no longer clean or the wiper blades with foreign matter adequately, the blades may be worn or can reduce the effectiveness of the cracked, and require replacement. windshield wipers.
  • Page 445 Front windshield wiper service Blade replacement positions OCN7N091026L OGSR076067 This vehicle has a “hidden” wiper design 1. Raise the wiper arm. which means that the wipers cannot be lifted when they are in their bottom resting position. 1. Within 20 seconds of turning off the engine, lift and hold the wiper lever up to the MIST position for about 2 seconds until the wipers move to the...

  • Page 446: Battery

    Maintenance BATTERY If acid gets into your eyes, flush your WARNING eyes with clean water for at least 15 To prevent SERIOUS INJURY or DEATH minutes and get immediate medical to you or bystanders, always follow attention. If acid gets on your skin, these precautions when working near thoroughly wash the area.

  • Page 447: For Best Battery Service

    Be cautious when loading liquid in the trunk. 1. CMF60L-DIN: The HYUNDAI model name of battery Do not tilt the battery. 2. 12 V : The nominal voltage...

  • Page 448: Battery Recharging

    Always follow these instructions when have the AGM battery serviced by recharging your vehicle’s battery to an authorized HYUNDAI dealer. For avoid the risk of SERIOUS INJURY or charging your AGM battery, use only DEATH from explosions or acid burns:...

  • Page 449: Tires And Wheels

    The recommended cold tire non in powerful front-wheel drive pressure for your vehicle can be vehicles. Elantra N will act on this found in this manual and on the phenomenon with the traction control tire label located on the driver’s in all ESC modes with the main focus side center pillar.

  • Page 450: Tire Care

    “Cold tires” it checked by an authorized means the vehicle has not been HYUNDAI dealer. driven for at least three hours or has Over-inflation produces a harsh been driven for less than one mile ride, excessive wear at the center (1.6 km).

  • Page 451: Check Tire Inflation Pressure

    Check Tire Inflation Pressure Tire Rotation Check your tires, including the spare To equalize tread wear, HYUNDAI tire, once a month or more. recommends that the tires be rotated according to the maintenance schedule or sooner if How to check irregular wear develops.

  • Page 452: Wheel Alignment And Tire Balance

    Maintenance Wheel Alignment and Tire Without a spare tire Balance The wheels on your vehicle were aligned and balanced carefully at the factory to give you the longest tire life and best overall performance. In most cases, you will not need to have your wheels aligned again.

  • Page 453: Tire Replacement

    Regardless of the remaining tread, HYUNDAI recommends that tires be replaced after six (6) years of normal service. When replacing tires, it is...

  • Page 454: Wheel Replacement

    Maintenance Wheel Replacement When replacing the metal wheels for any reason, make sure the new wheels are equivalent to the original factory units in diameter, rim width and offset. Tire Traction Tire traction can be reduced if you drive on worn tires, tires that are improperly inflated or on slippery OLMB073028 road surfaces.
  • Page 455 3. Checking tire life (TIN : Tire Wheel size designation Identification Number) Wheels are also marked with important information that you need Any tires that are over six years old, if you ever have to replace one. The based on the manufacturing date, following explains what the letters (including the spare tire) should be and numbers in the wheel size...
  • Page 456 Maintenance 5. Maximum permissible inflation Tread wear pressure The tread wear grade is a comparative rating based on the This number is the greatest amount wear rate of the tire when tested of air pressure that should be put in under controlled conditions on a the tire.

  • Page 457: Tire Terminology And Definitions

    Tire Terminology and Definitions Temperature A, B & C The temperature grades are A (the Air Pressure highest), B and C representing the tire’s resistance to the generation The amount of air inside the tire of heat and its ability to dissipate pressing outward on the tire.
  • Page 458 Maintenance Curb Weight Kilopascal (kPa) This means the weight of a motor The metric unit for air pressure. vehicle with standard and optional equipment including the maximum Light truck (LT) tire capacity of fuel, oil and coolant, but A tire designated by its manufacturer without passengers and cargo.
  • Page 459 Occupant Distribution Pneumatic options weight The combined weight of installed Designated seating positions. regular production options weighing over 5 lb. (2.3 kg) in excess of the Outward Facing Sidewall standard items which they replace, An asymmetrical tire has a particular not previously considered in side that faces outward when curb weight or accessory weight,...

  • Page 460: All Season Tires

    Uniform Tire Quality Grading Standards is a tire information Summer Tires system that provides consumers HYUNDAI specifies summer tires on with ratings for a tire’s traction, some models to provide superior temperature and treadwear. performance on dry roads. Summer...

  • Page 461: Radial-Ply Tires

    Radial-Ply Tires Low Aspect Ratio Tires Radial-ply tires provide improved The aspect ratio is lower than 50 on tread life, road hazard resistance low aspect ratio tires. and smoother high speed ride. The Because low aspect ratio tires are radial-ply tires used on this vehicle optimized for handling and braking, are of belted construction, and are their sidewall is a little stiffer than...
  • Page 462 When there is an impact on a tire, inspect the tire condition. Or, you can contact an authorized HYUNDAI dealer. Inspect the tire condition and pressure every 8,000 miles (13,000 km) to prevent tire damage.

  • Page 463: Fuses

    Normal Blown Avoid using the system involved and immediately consult an authorized Cartridge type HYUNDAI dealer. WARNING NEVER replace a fuse with anything but another fuse of the same rating. A higher capacity fuse could cause damage and possibly cause a fire.

  • Page 464: Instrument Panel Fuse Replacement

    If it fits loosely, consult an suspected fuse location. authorized HYUNDAI dealer. In an emergency, if you do not have a spare fuse, use a fuse of the same rating from a circuit you may not need for operating the vehicle.

  • Page 465: Engine Compartment Panel Fuse Replacement

    If the multi fuse is blown, consult an 4. Check the removed fuse; replace it authorized HYUNDAI dealer. if it is blown. To remove or insert the fuse, use the fuse puller in the engine compartment fuse panel.

  • Page 466: Fuse/Relay Panel Description

    Maintenance Fuse/Relay Panel Description Information Instrument panel fuse panel Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label. OCN7N091012N Inside the fuse/relay box cover, you can find the fuse/relay label describing fuse/...
  • Page 467 Driver’s side fuse panel Fuse Rating Circuit Protected Fuse Name Driver/Passenger Power Outside Mirror, Instrument MEMORY1 Cluster, A/C Controller, A/C Control Module SRS Control Module AIR BAG2 Front View Camera, Crash Pad Switch, IBU, Front Console MODULE4 Switch, E-LSD Controller, ECS Controller 7.5A Rear Seat Warmer Control Module, IAU MODULE7...
  • Page 468 Maintenance Driver’s side fuse panel Fuse Rating Circuit Protected Fuse Name 7.5A MDPS Unit MDPS1 7.5A MODULE6 Rear Seat Warmer Control Module S/HEATER RR SAFETY P/ Driver Safety Power Window Module WINDOW DRV Power Window Main Switch, Passenger Power Window P/WINDOW Switch BRAKE...
  • Page 469 Driver’s side fuse panel Fuse Rating Circuit Protected Fuse Name Door Lock/Unlock Actuator DOOR LOCK 7.5A Sport Mode Switch, Stop Lamp Switch, M/F Switch, IAU MODULE3 7.5A Instrument Cluster, Air bag Indicator AIR BAG IND Multifunction Switch WASHER PCM/ECM, IBU WIPER Driver/Passenger Smart Key Outside Handle, Sport Mode Switch, Data Link Connector, Hazard Switch, Crash Pad...
  • Page 470 Maintenance Engine compartment fuse panel Information Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
  • Page 471 Engine compartment fuse panel Fuse Rating Circuit Protected Type Fuse Name [G4FM/G4FG/G4NA] Alternator, (Fuse - F33, F34, 180A F35, F37) MIDI [G4FP] Alternator, (Fuse - F33, F34, F35, F37) FUSE-3 100A MDPS Unit MDPS1 COOLING [G4FP] Cooling Fan Controller FAN2 MIDI Electronic Oil Pump FUSE-2...
  • Page 472 Maintenance Engine compartment fuse panel Fuse Rating Circuit Protected Type Fuse Name POWER Front Power Outlet OUTLET2 POWER Cigarette Lighter OUTLET3 VACUUM VACUUM PUMP, ESC PUMP1 VACUUM Electronic Vacuum Pump PUMP2 ECS Unit LSD Control Module E-LSD E-CVVT3 E-CVVT2 E/R Junction Block (RLY.14) E-CVVT1 FUSE [G4FP] TCM...
  • Page 473 Engine compartment fuse panel (PCB block) (Smartstream 2.5 GDI) Fuse Rating Circuit Protected Type Fuse Name ECS Unit ECS (15A) [G4FM] A/C Compressor Horn, Horn Switch HORN [G4FM/G4NA/G4FP] Ignition Coil #1~#4 IGN COIL [G4FG] Ignition Coil #1~#4 PCM/ECM, [MT] IGN LOCK CLUTCH SW ECU3 E/R Junction Block (RLY.8) SENSOR3...

  • Page 474: Light Bulbs

    Maintenance LIGHT BULBS Consult an authorized HYUNDAI dealer Information - Headlight to replace most vehicle light bulbs. It is desiccant (if equipped) difficult to replace vehicle light bulbs because other parts of the vehicle must This vehicle is equipped with desiccant to...

  • Page 475: Headlight, Position Lamp, Turn Signal Lamp And Daytime Running

    5. Insert a new bulb by inserting it into the system inspected by an authorized the socket and rotating it until it locks HYUNDAI dealer. into place. The LED lamps cannot be replaced as 6. Install the socket in the assembly by...

  • Page 476: Side Repeater Lamp Replacement

    OCN7N091030N (1) Stop lamp (LED) If the LED lamp (1) does not operate, have the vehicle checked by an (2) Tail lamp (LED ) authorized HYUNDAI dealer. (3) Turn signal lamp (4) Reverse lamp (5) Side marker (LED) Tail/Stop lamp...
  • Page 477 Turn signal lamp (Outer lamp) (Bulb type) 1. Open the trunk lid. OCN7N091034L [1] : Turn signal lamp 5. Remove the socket from the assembly by turning the socket counterclockwise until the tabs on OCN7080045 the socket align with the slots on the 2.

  • Page 478: High Mounted Stop Lamp Replacement

    HYUNDAI dealer. Pull the bulb out of the socket. 4. Insert a new bulb by inserting it into the socket and rotating it until it locks into place.

  • Page 479: License Plate Light Bulb Replacement

    License Plate Light Bulb Interior Light Bulb Replacement Replacement Map lamp OCN7080033 Room lamp OCN7N091015N 1. Using a flat-blade screwdriver gently pry the lens cover from the lamp housing. 2. Remove the bulb by pulling it straight out. 3. Install a new bulb. 4.
  • Page 480 Maintenance Sunvisor lamp OCN7050058 Trunk room lamp OCN7N091035N 1. Using a flat-blade screwdriver, gently pry the lens from the interior light housing. 2. Remove the bulb by pulling it straight out. WARNING Prior to working on the Interior Lights, ensure that the “OFF” button is depressed to avoid burning your fingers or receiving an electric shock.

  • Page 481: Appearance Care

    APPEARANCE CARE Exterior Care Finish maintenance Washing If you park your vehicle near a stainless steel sign or glass facade To help protect your vehicle’s finish from building, the vehicle’s exterior plastic rust and deterioration, wash it thoroughly parts such as a bumper, spoiler, and frequently at least once a month garnish, lamp or outside rearview with lukewarm or cold water.
  • Page 482 Maintenance NOTICE High-pressure washing When using high-pressure washers, make sure to maintain sufficient distance from the vehicle. Insufficient clearance or excessive pressure can lead to component damage or water penetration. Do not spray the camera, sensors or its surrounding area directly with a high pressure washer.
  • Page 483 Do not use steel wool, abrasive your vehicle maintained and repaired cleaners, or strong detergents by an authorized HYUNDAI dealer. Take containing highly alkaline or extreme care, as it is difficult to restore caustic agents on chrome-plated or the quality after the repair.
  • Page 484 HYUNDAI produces vehicles and exhaust system, even though they of the highest quality. However, this is have been treated with rust protection.
  • Page 485 High-corrosion areas To help prevent corrosion If you live in an area where your vehicle is Keep your vehicle clean regularly exposed to corrosive materials, The best way to prevent corrosion is corrosion protection is particularly to keep your vehicle clean and free of important.

  • Page 486: Interior Care

    Maintenance Keep your garage dry Interior Care Don’t park your vehicle in a damp, Interior general precautions poorly ventilated garage. This creates Prevent caustic solutions such as a favorable environment for corrosion. perfume and cosmetic oil, from This is particularly true if you wash your contacting the interior parts because vehicle in the garage or drive it into the they may cause damage or discoloration.
  • Page 487 Cleaning the upholstery and interior Leather (if equipped) trim Features of seat leather Vehicle interior surfaces (if equipped) - Leather is made from the outer skin of an animal, which goes through a Remove dust and loose dirt from interior special process to be available for surfaces with a whisk broom or a vacuum use.
  • Page 488 Maintenance Caring for the leather seats Cleaning the seat belt webbing - Vacuum the seat periodically to Clean the belt webbing with any remove dust and sand on the seat. It mild soap solution recommended for will prevent abrasion or damage of cleaning upholstery or carpet.

  • Page 489: Emission Control System

    The by an authorized HYUNDAI dealer in ORVR system is designed to allow the accordance with the maintenance vapors from the fuel tank to be loaded schedule in this manual.
  • Page 490 Maintenance 3. Exhaust Emission Control Do not operate the engine in confined or closed areas (such as garages) any System more than what is necessary to move The Exhaust Emission Control System is the vehicle in or out of the area. a highly effective system which controls When the vehicle is stopped in an exhaust emissions while maintaining...
  • Page 491 All inspections and control. It may present a fire risk adjustments must be made by an under certain conditions. authorized HYUNDAI dealer. Avoid driving with extremely low fuel level. If you run out of gasoline, it could cause the engine to misfire and result in excessive loading of the catalytic converter.

  • Page 492: California Perchlorate Notice

    Maintenance CALIFORNIA PERCHLORATE NOTICE Perchlorate Material-special handling may apply, See: “https://dtsc.ca.gov/perchlorate” Notice to California Vehicle Dismantlers: Perchlorate containing materials, such as air bag inflators, seatbelt pretensioners and keyless remote entry batteries, must be disposed of according to Title 22 California Code of Regulations Section 67384.10 (a).

This manual is also suitable for:

Elantra n 2022

Table of Contents

Save PDF
