Trusted TMR 24Vdc Digital Output Module – 40 Channel

2. Installation

2.1. Module Insertion and Removal

CAUTION:
The Module contains static sensitive parts. Static handling precautions must be
observed. Specifically ensure that exposed connector pins are not touched. Under no
circumstances should the Module housing be removed.
Before installation, visually inspect the Module for damage. Ensure that the Module housing
appears undamaged and inspect the I/O connector at the back of the Module for bent pins.
If the Module appears damaged or any pins are bent, do not install the Module. Do not try
to straighten bent pins. Return the Module for replacement.
Ensure that the Module is of the correct type.
Record the Module type, revision and serial number of the Module before installation.
To install the Module:
1. Ensure that the field cable assembly is installed and correctly located.
2. If I/O Module keys are used, verify that all keys are installed in the correct positions
and properly seated in their slots.
3. Release the ejector tabs on the Module using the release key. Ensure that the ejector
tabs are fully open.
4. Holding the ejectors, carefully insert the Module into the intended slot.
5. Push the Module fully home by pressing on the top and bottom of the Module fascia.
6. Close the Module ejectors, ensuring that they click into their locked position.
The Module should mount into the chassis with a minimum of resistance. If the Module
does not mount easily, do not force it. Remove the Module and check it for bent or
damaged pins. If the pins have not been damaged, try reinstalling the Module.

2.2. Cable Selection

I/O cables suitable for use with the Trusted TMR 24 Vdc Digital Output Module are detailed
in the following Product Descriptions.
• Trusted I/O Companion Slot Cables, publication
• Trusted TMR I/O SmartSlot Slot Cables, publication
Rockwell Automation Publication ICSTT-RM280N-EN-P
ICSTT-RM311 (PD-TC200)
ICSTT-RM313 (PD-TC500)
Issue 14
