PointMax EtherNet/IP Adapter

5034-AENTR, 5034-AENTRXT

User Manual

Original Instructions

Table of Contents

Need help?

Do you have a question about the Allen-Bradley PointMax 5034-AENTR and is the answer not in the manual?

Questions and answers

Summary of Contents for Rockwell Automation Allen-Bradley PointMax 5034-AENTR

Page 1 PointMax EtherNet/IP Adapter 5034-AENTR, 5034-AENTRXT User Manual Original Instructions...
Page 2: Important User Information
Identiﬁes information that is useful and can help to make a process easier to do or easier to understand. Rockwell Automation recognizes that some of the terms that are currently used in our industry and in this publication are not in alignment with the movement toward inclusive language in technology.
Page 3: Table Of Contents
Browser Requirements........................................36 Access the Web Server Home Page................................... 36 Sign in to the Web Server......................................36 Web Server Security........................................39 Enable or Disable the Web Server....................................41 Navigate the Web Server......................................41 Reset the Adapter..........................................44 Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 4: Additional Resources
• Use of an EtherNet/IP network • Studio 5000 Logix Designer® application environment Additional Resources These documents contain additional information concerning related products from Rockwell Automation. You can view or download publications at rok.auto/literature. Table 1. Additional Resources Resources Description...
Page 5 An electrical system where the voltage level is considered safe under normal or fault conditions, as defined in the EN and IEC standards. Harsh Environment These modules have additional conformal coating and design considerations that add a greater degree of protection when exposed to harsh, corrosive environments. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 6: Pointmax Ethernet/Ip Adapter Overview
ﬁrmware updates. If the catalog number is not available, then no updates exist. IMPORTANT: Only download ﬁrmware and access product release notes from the Rockwell Automation PCDC. Do not download ﬁrmware from non-Rockwell Automation sites.
Page 7: Secure Access To The System
To secure access to the system, consider these options: Follow industry best practices to harden your personal computers and servers, including • anti-virus/anti-malware and application allow-list solutions. The recommendations are published at the Rockwell Automation technical support center in Knowledgebase Technote Rockwell Automation Customer Hardening Guidelines.
Page 8: Electronic Keying
Also, connections from other controllers can be broken. If an I/O connection to a device is interrupted, the result can be a loss of data. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 9: Protection Mode
◦ All other status indicators = Off ◦ Power down the device and restore previous values to the rotary switches. Power up the device to normal operation with Explicit Protection Mode enabled. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 10: Enable Or Disable Https Server (Web Server) And Snmp Server
Mode on page Enable the HTTPS Server in Studio 5000 Logix Designer In Studio 5000 Logix Designer application, select the adapter device from the Controller Organizer pane. Right-click on the adapter and select Properties. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 11 Select Apply to accept the changes. You do not need to cycle power to the adapter. ATTENTION: In order to decrease the possibility of a security breach, use Explicit Protection Mode and do not enable the HTTPS server. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 12: Enable The Snmp Server In Studio 5000 Logix Designer Application
Protection Mode and do not enable the SNMP server. See Knowledgebase article SNMP Password and MIB Conﬁguration, Document ID QA50173 available at Rockwell Automation technical support center for more information. To access technical support center, go to rok.auto/knowledgebase. Publication 5034-UM001A-EN-P - April 2025...
Page 13: Pointmax Adapter Power Requirements
Connect the external power supply to the removable terminal block (RTB) to provide MOD power and SA power. The adapters use different RTBs to connect power. PointMax EtherNet/IP adapters use one 6-terminal power RTB. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 14 For more information, see Switched Mode Power Supply Speciﬁcations Technical Data, publication 1606-TD002. You must use SELV-listed power supplies for SA power. • • You must connect SA power for safety I/O modules to provide the required safety function. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 15 Chapter 2 PointMax Adapter Power Requirements Backplane Power (BP) The backplane power is generated from module power by the adapter and expansion power . It internally powers the I/O modules in the system. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 16: Connect To The Ethernet/Ip Network
DHCP each time that power is cycled. PointMax adapters support the following methods to set/change the network address: Rotary Switches • FactoryTalk® Linx Software • BOOTP/DHCP utility • Ethernet/IP commissioning tool • Secure web server • Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 17: Set The Network Address With The Rotary Switches
IMPORTANT: To use the BOOTP/DHCP tool, you must know the Ethernet hardware address (MAC ID) of your module. Rockwell Automation assigns each module a unique 48-bit hardware address at the factory. The address is printed on a label on the side of your module. It consists of six hexadecimal digits that are separated by colons. This address is ﬁxed by the hardware and cannot be changed.
Page 18: Set The Network Address With Factorytalk Linx Software
The PointMax EtherNet/IP adapter supports two types of network redundancy: DLR (Device Level Ring) • PRP (Parallel Redundancy Protocol) • In these modes, all EtherNet/IP ports of the adapter are used to provide redundant network paths. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 19 IMPORTANT: You cannot switch the network redundancy mode while the adapter is running. A minor recoverable fault occurs to warn about the unintentional change to the network redundancy mode. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 20: Configure The Adapter
This example uses the 5034-AENTR adapter. Select your adapter from the search result. For some modules, the Select Major Revision dialog can appear. If this dialog appears, choose the major revision of the module and select OK Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 21 1…255. This field is enabled while offline, and in the Program, Remote Program, and Remote Run modes. It appears dimmed in Run mode or when the Electronic Keying is set to Disable Keying. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 22 Duplicated data at the physical level for each path. Protocol (PRP) Set the Chassis size to the number of modules including the adapter. For example, one adapter with 32 I/O modules is considered as Chassis size 33. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 23 For non-redundant controllers, the default value is Unicast when the target device supports unicast. Otherwise, the default value is Multicast. For redundant controllers, the default value is Multicast when the target device supports multicast. Otherwise, the default value is Unicast. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 24 Change the Studio 5000 Logix Designer application project to Run Mode. When prompted to change the controller mode to Remote Run, select Yes. Right-click on your adapter, and select Properties. From the Device Information view, select Port Conﬁguration. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 25 From the Module Properties view, select Internet Protocol. If needed, you can set Internet Protocol properties such as: Domain Name ◦ ◦ Host Name ◦ Gateway Address ◦ Primary DNS Server Address Secondary DNS Server Address ◦ Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 26 Chapter 4 Conﬁgure the Adapter On the Module Properties dialog, select OK. IMPORTANT: If you try to change the IP address on this page, the following alert appears: Save the project. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 27: Pointmax Adapter Troubleshooting
Complete one of the following: Factory default power up • Wait for the firmware update to finish. • • Recoverable fault • Cycle power to the module. Firmware update in progress • Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 28 The adapter is the active ring supervisor in a None DLR network and the ring is not broken. Flashing red The adapter is operating in PRP mode and a LAN None B warning has occurred. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 29: Troubleshoot With Studio 5000 Logix Designer
Figure 5. Fault Message in Status Bar If connection is faulted, go to the Connection view and check the error code in the Connection Fault area. Figure 6. Connection Fault Description with Error Code Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 30 If a base is faulted, go to the Base Details view and check the Diagnostics for the base to see the diagnostic condition. Figure 7. Base Details Diagnostics If a Time Sync fault is present, go to the Device Diagnostics dialog to check the Time Synchronization status and Grandmaster clock identity. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 31 PointMax Adapter Troubleshooting Figure 8. Device Diagnostics The Grandmaster clock identity must match with the network Grandmaster clock identity. Also, check the Time Synchronization status of the adapter in the adapter Device Diagnostics dialog. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 32: Module Tag Definitions
1 = A valid time master was detected on the backplane, but the time master has timed out. The module is using its local clock and can be drifting away from the last known time master. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 33 Discards, Out Errors, Alignment Errors, FCS Errors, Single Collisions, Multiple Collisions, SQE Test Errors, Deferred Transmissions, Late Collisions, Excessive Collisions, MAC Transmit Errors, Carrier Sense Errors, Frame Too Long, and MAC Receive Errors. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 34 PTP update is received. LocalClockOffsetTimestamp LINT The time when the Local Clock Offset was sampled. All values This value is initially zero, and the first timestamp occurs when the module synchronizes with the master clock. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 35 1 = Base not detected Basexx.RevisionFault BOOL Indicates that a hardware or firmware incompatibility • 0 = No revision fault detected with another part of the system is detected. 1 = Revision fault detected • Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 36: Secure Web Server
Many of the adapter features require you to sign in with the appropriate access. If you want to view the conﬁguration pages and make changes, you must sign in with your username and password. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 37 I/O connection. The ﬁrst time that you access the Conﬁguration page, the Change Password dialog appears as shown below. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 38 The newly set password must adhere to the following criteria: Does not contain spaces • Does not match the default password • • Password length must contain 8…64 characters • Username and password are case sensitive Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 39: Web Server Security
If there are no requests that are processed from the Conﬁguration pages for three minutes, the session times out. Web Server Security The web server employs HTTPS for secure and encrypted connections with clients. HTTPS uses SSL/TLS certiﬁcates to achieve its security goals. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 40: Generate A Self-Signed Certificate
The self-signed ECC certiﬁcate generates in approximately ﬁve seconds, whereas the RSA certiﬁcate generates in approximately 50 seconds. Once the certiﬁcate is generated, the web server restarts, and the generated certiﬁcate is used. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 41: Enable Or Disable The Web Server
Protection Mode helps to decrease the possibility of a security breach. Disable the web server on the Services page. Navigate the Web Server Navigate the web server pages by using the navigation panel on the left of the screen. Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 42: Port Configuration Page
Use the Port Conﬁguration page to complete the following tasks: • Enable or disable network ports • Select whether to conﬁgure the port setings automatically or manually • Select the port speed Select the port duplex mode • Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 43: Services Page
The Chassis page shows the information for I/O modules and mounting bases connected on the chassis. Use this page to view the following information: Module information • Module status • Base information • Base status • Rockwell Automation, Inc. Publication 5034-UM001A-EN-P - April 2025...
Page 44: Reset The Adapter
IMPORTANT: If you do not want to set the IP address via the rotary switches, set them to 999. After the adapter powers up, set the IP address. Power up the adapter. Publication 5034-UM001A-EN-P - April 2025 Rockwell Automation, Inc.
Page 45: Rockwell Automation Support
At the end of life, this equipment should be collected separately from any unsorted municipal waste. Rockwell Automation maintains current product environmental information on its website at rok.auto/pec. Allen-Bradley, expanding human possibility, FactoryTalk, FactoryTalk Linx, Logix 5000, PointMax, Rockwell Automation, Studio 5000 Logix Designer, and TechConnect are trademarks of Rockwell Automation, Inc.
