IF2 I/O Interface to PDM
(Catalog Number 4100-IF2)
The IF2 I/O Interface to PDM is a printed circuit board intended for
use with the positioning drive modules (PDM). The purpose of this
board is to reverse the polarity of the I/O circuit to remove the
problem of compatibility that may arise from connecting any
external control conductors to the I/O.
.
Installation Instructions
Publication 4100-IN001A-EN-P- February 2001
See page:
2
3
4
4
5
6
7
7
8
8
10
10
11
11
Advertisement
Table of Contents
Related Manuals for Rockwell Automation Allen-Bradley IF2
Summary of Contents for Rockwell Automation Allen-Bradley IF2
-
Page 1: Table Of Contents
Installation Instructions IF2 I/O Interface to PDM (Catalog Number 4100-IF2) The IF2 I/O Interface to PDM is a printed circuit board intended for use with the positioning drive modules (PDM). The purpose of this board is to reverse the polarity of the I/O circuit to remove the problem of compatibility that may arise from connecting any external control conductors to the I/O. -
Page 2: Important User Information
IF2 I/O Interface to PDM Important User Information Those responsible for the application and use of this product must satisfy themselves that all necessary steps have been taken to assure that the application and use of this product meets all performance and safety requirements, including all applicable laws, regulation codes, and standards. -
Page 3: Allen-Bradley Support
See the Related Documentation section of this chapter for the publication numbers of other manuals that can help with this product. The Rockwell Automation Technical Support number is: 1-952-914-3990 On the Web For information about Allen-Bradley, visit the following World Wide Web site: http://www.ab.com/... -
Page 4: Compliance To The European Union Directive
IF2 I/O Interface to PDM Compliance to the European Union Directive This product doesn’t bear the CE mark because it has been defined as a component. It has been tested as part of a system and is included in the declaration of conformance for the system It has been designed and tested to meet the following directives. -
Page 5: Preventing Electrostatic Discharge
IF2 I/O Interface to PDM For specific information required by EN 60204, see the appropriate sections in this publication, as well as the following Allen-Bradley publications: • Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 • Automation Systems Catalog, publication B111 This equipment is classified as open equipment and must be installed (mounted) in an enclosure during operation as a means of reducing user exposure to hazards. -
Page 6: Overview
IF2 I/O Interface to PDM Overview The IF2 I/O Interface to PDM is a printed circuit board intended for use with the positioning drive modules (PDM). Figure 1 Front View of I/O Interface Board These drives are built with output stages which source current to their loads, and input stages which require a current sinking input to operate. -
Page 7: Installation
IF2 I/O Interface to PDM Installation The interface is a DIN rail mounting unit which has a terminal strip (1.5 mm screw clamp type) down each side. Mounting The Interface board has 2 mounting feet on the back to attach it to the DIN rail. -
Page 8: Wiring
IF2 I/O Interface to PDM Wiring The flying leads from the PDM drive is wired to the IF2 I/O Interface to PDM board using the connector marked P1. The flying leads from the external controller are wired to the connector marked P2 User. Each set of connectors have 26 slots available and the wiring is a 1 to 1 set up. - Page 9 IF2 I/O Interface to PDM If the terminals are: Do this: Open Go to step 4 3. Using a small, flat-head screwdriver, turn the clamping screw counter-clockwise several times. 4. Using a proper stripping tool, strip the wire insulation back on the cable lead.
-
Page 10: Wiring The P1 Connector
IF2 I/O Interface to PDM Wiring the P1 Connector The PDM side is designed to connect directly on a 1 for 1 basis to the I/O connectors on the PDM drive, as shown in the following diagram. Figure 4 Wiring Diagram. PDM Drive External Controller Publication 4100-IN001A-EN-P- February 2001... -
Page 11: Wiring The P2 User Connector
IF2 I/O Interface to PDM Conductor size must not be greater than 1.5 mm . The I/O circuits in the PDM drive are protected by a 1 amp fuse contained in the drive. Wiring the P2 Connector The P2 User I/O requires a separate clean 24 volt nominal DC supply. - Page 12 Publication 4100-IN001A-EN-P- February 2001 957464-20 2001 Rockwell International. All Rights Reserved. Printed in USA Supersedes Publication 68-0060 – January 1997...
