Install the New LCM
1. Slide the new LCM into the empty slot, pushing it in until it is flush against the
chassis.
2. Using a #2 Phillips screwdriver, tighten the screws, shown in
LCM to the chassis.
3. Return the malfunctioning LCM to Spectra Logic as described in
Components on page
Install the Rear Cover
1. Lift the cover and align it so that the two nuts extending from the back of the cover
fit into the corresponding holes on either side of the chassis
If the cables to the drives and QIPs installed in
the library are routed from the...
top of the library
bottom of the library
Caution
Figure 6 Cover alignment nuts (one on each side).
2. Using your fingers or a #2 Phillips screwdriver, tighten the two screws to secure the
bottom of the cover to the chassis (see
14.
Make sure that cables are not pinched between the cover and
the chassis.
make sure that they fit into the cutout
in the...
top of the cover
bottom of the cover
Top cable cutout
Alignment
nut
Figure 3 on page 7).
Replacing the LCM
Figure 5, to secure the
Returning
(Figure 6).
