2. Using your fingers or a #2 Phillips screwdriver, loosen but do not remove the
captive screws that secure the bottom of the cover to the chassis.
Figure 3 The rear panel cover and screws (T380 shown).
3. Lift the cover outward and away from the chassis to disengage the two nuts
extending from the back of the cover from the holes on either side of the chassis
(see Figure 4).
Figure 4 Align the cover alignment nuts (one on each side) with
the holes in the chassis.
Discontinue Backups
If the LCM is malfunctioning, you have no control of the library through the Library
Controller (LC) on the front panel or through the Remote Library Controller (RLC). A
malfunctioning LCM can also affect robotics, drives, and QIPs. Backups are interrupted
if the robotics, drives, or QIPs are affected and cannot be restarted until after the LCM
is replaced.
Cover
Preparing for Maintenance
Knurled screw
Top cable cutout
Alignment
nut
