  • Page 1 Programmer’s Reference Manual SR60 Scanner...
  • Page 2 Intermec Technologies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2006 by Intermec Technologies Corporation. All rights reserved.
  • Page 3 Document Change Record This page records changes to this document. The document was originally released as version 001. Version Number Date Description of Change 6/2006 Revised to support RoHS compliance. New information includes an updated list of supported interface cables, scanners supported interfaces, and minor changes to the factory default configuration settings.
  • Page 4 SR60 Scanner Programmer’s Reference Manual...

  • Page 5: Table Of Contents

    Contacting Intermec Product Support ........12...
  • Page 6 Contents Wand Emulation Settings ........14 Wand Emulation Pre/Post-Noise Settings .
  • Page 7 Contents Enabling and Configuring Symbologies ....69 All Symbologies Supported by All Interfaces ....... 70 Enabling Symbologies .
  • Page 8 Contents Check Digit ........96 Gap Check .
  • Page 9 Contents Read Verification ........128 IATA Options .
  • Page 10 Contents Full ASCII Chart ..........165 ASCII Extended Chart .

  • Page 11: Before You Begin

    Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at www.intermec.com and click Service & Support > Warranty.

  • Page 12: Telephone Support

    Before You Begin Visit the Intermec technical knowledge base (Knowledge Central) at intermec.custhelp.com to review technical information or to request technical support for your Intermec product. Telephone Support These services are available from Intermec Technologies Corporation. In the U.S.A. and...

  • Page 13: Who Should Read This Manual

    2 Click Service & Support > Manuals. 3 In the Select a Product field, choose the product whose documentation you want to download. To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor. SR60 Scanner Programmer’s Reference Manual...
  • Page 14 Before You Begin SR60 Scanner Programmer’s Reference Manual...

  • Page 15: Learning About Programming The Sr60 Scanner

    • About the Scanner LEDs and Beeper • Integrating the Scanner With Your Host System • Changing the Interface Cable • Restoring Factory Default Settings • Trouble Scanning the Bar Codes in This Manual • Contacting Intermec Product Support SR60 Scanner Programmer’s Reference Manual...

  • Page 16: What Is The Sr60

    Chapter 1 — Learning About Programming the SR60 Scanner What Is the SR60? The Intermec SR60 is a laser scanner that is available in a standard range (SR) version or extended long-range (XLR) version. The XLR version allows you to scan bar code labels from as far away as 11 m (36 ft) depending on the labels you are using.

  • Page 17: How To Program The Sr60 Scanner

    Chapter 1 — Learning About Programming the SR60 Scanner How to Program the SR60 Scanner There are two ways for you to program the scanner: • You can scan programming bar codes to modify the scanner’s programmable features and options. This manual provides the bar codes and instructions necessary to configure the features and options.
  • Page 18 • Intermec recommends that you limit each programming session to one feature at a time. If you make a mistake in the programming sequence, it can be difficult to discover where an error has been made if several features are programmed at once.

  • Page 19: Three Sample Programming Sequences

    Chapter 1 — Learning About Programming the SR60 Scanner 3 Scan the END bar code to save any new settings and exit Programming mode. The scanner sounds a beep and resets upon exiting Programming mode, and the green LED returns to its usual state (on steady or off ).
  • Page 20 Chapter 1 — Learning About Programming the SR60 Scanner ITEM TAG ITEM VALUE END/RESET ENABLE NEW FEATURE 3 4 5 ENABLE NEW FEATURE USING THE FOLLOWING SETTINGS... ONE BAR CODE CONTAINS SET + ITEM TAG + ITEM VALUE + END Three Sample Programming Sequences Sample B Programming sample B demonstrates how to enter a range value.

  • Page 21: Roadmap For Programming The Scanner

    Chapter 1 — Learning About Programming the SR60 Scanner This type of format may require up to six programming bar codes and is necessary to allow flexible programming with larger item- value numeric ranges. Sample C Programming sample C lets you scan a single, extended length bar code.

  • Page 22: Scanner Beeper

    Integrating the Scanner With Your Host System Your scanner must be equipped with the correct hardware to properly communicate with your host system. Contact your local Intermec representative if you have questions about your scanner hardware compatibility. Intermec offers the following interface cables for the SR60 scanner: •...

  • Page 23: Changing The Interface Cable

    Chapter 1 — Learning About Programming the SR60 Scanner Note: The part numbers for the keyboard wedge cables available from Intermec are listed in the “PC Keyboard Interfaces and Cables Supported ” table on page 20. Changing the Interface Cable...

  • Page 24: Reconfiguring The Interface Settings

    Chapter 1 — Learning About Programming the SR60 Scanner 3 Holding the scanner handle and end cap together in one hand, pull the connector out of the handle end cap to free the interface cable. 4 Connect the new interface cable at the scanner and rotate the forked cable retainer to secure it.

  • Page 25: Restoring Factory Default Settings

    Chapter 1 — Learning About Programming the SR60 Scanner Restoring Factory Default Settings You can restore the factory default settings at any time by scanning the Return to Factory Default Settings bar code in this section. This bar code is typically used to return the scanner to a known operating state when the present programming status is not known, faulty, or suspect.

  • Page 26: Trouble Scanning The Bar Codes In This Manual

    “Configuring the Marker Beam” on page 144. Contacting Intermec Product Support If you need to contact Intermec Product Support for help with your SR60 scanner, follow the instructions in “Global Services and Support” on page xi. Make sure you have this information before you contact Intermec Product Support: •...

  • Page 27: Configuring Interface Settings

    Configuring Interface Settings This chapter contains the programming bar codes for selecting an interface and programming the related interface settings. You will find these sections in this chapter: • Wand Emulation Interface • Keyboard Wedge Interface • RS-232 Communication Parameters •...

  • Page 28: Wand Emulation Interface

    Chapter 2 — Configuring Interface Settings Wand Emulation Interface Scan the following bar codes to enable the Wand Emulation Interface. Note: Wand Emulation Interface is not supported by the USB interface. SET------------------------------------- Enable Wand Emulation --------- END------------------------------------ Wand Emulation Settings Scan the following bar codes to configure the settings for the Wand Emulation Interface.
  • Page 29 Chapter 2 — Configuring Interface Settings Polarity Space Low, Bar High --------- Space High, Bar Low --------- Signal Speed Low (660 μs) --------- High (330 μs) --------- Data Format Transmit in Normal Format --------- Transmit in C39 Format --------- Transmit in C39 Full ASCII Format --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 30 Chapter 2 — Configuring Interface Settings Transmit in C128 Format --------- Idle State --------- High --------- Transmit C128 Function Characters Enable --------- Disable --------- END------------------------------------ SR60 Scanner Programmer’s Reference Manual...

  • Page 31: Wand Emulation Pre/Post-Noise Settings

    Chapter 2 — Configuring Interface Settings Wand Emulation Pre/Post-Noise Settings You can independently configure the number of noise transitions generated prior to or following label transitions. To disable transmitting pre-noise or post-noise transitions 1 Scan the SET bar code. 2 Scan either the Don’t Transmit Pre-Noise bar code on this page or the Don’t Transmit Post-Noise bar code on page 18.
  • Page 32 Chapter 2 — Configuring Interface Settings Use the bar codes in “Keypad Bar Codes” on page 160 to scan two digits representing the number of Pre-Noise Transitions padded with leading zeros. For example, 03 = three transitions, 08 = eight, and 15 = fifteen.

  • Page 33: Keyboard Wedge Interface

    Chapter 2 — Configuring Interface Settings Keyboard Wedge Interface This section describes these PC Keyboard Wedge interface parameters: • Interface Selection • Connect to a Laptop • Caps Lock • Country Mode • Intercharacter Delay • Quiet Interval For help changing other settings for this interface, see: •...
  • Page 34 P/N 321-636-002 PS/55 5530T with 104 keyboard P/N 321-635-002 P/N 321-636-002 Intermec recommends that you disconnect power before plugging or unplugging cables to avoid any possibility of equipment damage. Scan the following bar codes to select the interface type you identified from the previous table, “PC Keyboard Interfaces and...
  • Page 35 Chapter 2 — Configuring Interface Settings --------- --------- --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 36: Connect To A Laptop Or Pc And Send Control/Function Characters

    Chapter 2 — Configuring Interface Settings END------------------------------------ Connect to a Laptop or PC and Send Control/Function Characters You need to know if the scanner will be connected to a laptop (with an integrated keyboard), connected to a PC (with an external keyboard), or operated with no external keyboard.
  • Page 37 Chapter 2 — Configuring Interface Settings SET------------------------------------- Connect to Laptop or PC Laptop/No External Keyboard --------- Keyboard Attached --------- Send Control/Function Characters Enable Control Characters --------- Enable Function Characters --------- Disable --------- END------------------------------------ SR60 Scanner Programmer’s Reference Manual...

  • Page 38: Caps Lock

    Chapter 2 — Configuring Interface Settings Caps Lock You can set three Caps Lock settings: • The Caps Lock Off bar code sends character data to the host in normal format. • The Caps Lock On bar code sends character data to the host in reverse case: •...

  • Page 39: Country Mode

    Chapter 2 — Configuring Interface Settings END------------------------------------ Country Mode You can select the following countries only when the scanner is configured for Interface Type E: • Belgium • Britain • Denmark • France • Germany • Italy • Japanese 106-Key •...
  • Page 40 Chapter 2 — Configuring Interface Settings Belgium --------- Britain --------- Denmark --------- France --------- Germany --------- Italy --------- Japanese 106-Key --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 41 Chapter 2 — Configuring Interface Settings Norway --------- Portugal --------- Spain --------- Sweden --------- Switzerland --------- U.S.A. --------- END------------------------------------ SR60 Scanner Programmer’s Reference Manual...

  • Page 42: Intercharacter Delay

    Chapter 2 — Configuring Interface Settings Intercharacter Delay Intercharacter Delay refers to the pause, if any, between each character before it is sent to the host. This time delay controls the flow of data from the scanner. Scan the following bar codes to select the Intercharacter Delay.

  • Page 43: Quiet Interval

    Chapter 2 — Configuring Interface Settings 40 Milliseconds --------- 60 Milliseconds --------- 80 Milliseconds --------- 90 Milliseconds --------- END------------------------------------ Quiet Interval Quiet Interval is the amount of time to look for keyboard activity before the scanner breaks the keyboard connection in order to transmit data to the host.
  • Page 44 Chapter 2 — Configuring Interface Settings 10 Milliseconds --------- 20 Milliseconds --------- 50 Milliseconds --------- 100 Milliseconds --------- 200 Milliseconds --------- 500 Milliseconds --------- 1 Second --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 45: Rs-232 Communication Parameters

    Chapter 2 — Configuring Interface Settings END------------------------------------ RS-232 Communication Parameters This section describes these RS-232 communication parameters: • Baud Rate • Data Format Settings: Data Bit, Parity Bit, and Stop Bit(s) • Handshaking • Hardware Handshaking (CTS/RTS) • Software Handshaking (XON/XOFF) •...
  • Page 46 Chapter 2 — Configuring Interface Settings Baud Rate = 1200 --------- Baud Rate = 2400 --------- Baud Rate = 4800 --------- Baud Rate = 9600 --------- Baud Rate = 19200 --------- Baud Rate = 38400 --------- END------------------------------------ SR60 Scanner Programmer’s Reference Manual...

  • Page 47: Data Format Settings

    Chapter 2 — Configuring Interface Settings Data Format Settings Scan the following bar codes to select the data format configuration needed to communicate with your system. SET------------------------------------- Data Bit Seven --------- Eight --------- Parity Bit None --------- Even --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 48 Chapter 2 — Configuring Interface Settings --------- Mark --------- Space --------- Stop Bit(s) --------- --------- END------------------------------------ SR60 Scanner Programmer’s Reference Manual...

  • Page 49: Handshaking

    Chapter 2 — Configuring Interface Settings Handshaking Review your system documentation to identify handshaking requirements, and scan the following bar codes to change the settings if required. The following descriptions briefly explain each selection. Hardware Handshaking You can choose either CTS/RTS Flow Control or CTS Scan Control: •...
  • Page 50 Chapter 2 — Configuring Interface Settings Note: Each handshaking feature requires a series of bar codes in the sequence given. That is, you must enter Programming mode by scanning the SET bar code, scan the Step #1 bar code, scan the Step #2 bar code, and then scan the END bar code.

  • Page 51: Software Handshaking

    Chapter 2 — Configuring Interface Settings Step #1 --------- Step #2 --------- END------------------------------------ Software Handshaking XON/XOFF is software handshaking that allows the host to control data transmission. If the host sends an XOFF command to the scanner, the scanner does not send the bar code data until it receives an XON command from the host.
  • Page 52 Chapter 2 — Configuring Interface Settings Step #2 --------- END------------------------------------ Disable both CTS/RTS and XON/XOFF Control SET------------------------------------- Step #1 --------- Step #2 --------- END----------------------------------- SR60 Scanner Programmer’s Reference Manual...

  • Page 53: Rs-232 Ack/Nak Options

    Chapter 2 — Configuring Interface Settings To disable either CTS/RTS Control or XON/XOFF Control 1 Disable both CTS/RTS Flow Control and XON/XOFF Control. 2 Enable one handshaking feature: • To enable CTS/RTS Flow Control, see page 36. • To enable XON/XOFF Control, see page 37. RS-232 ACK/NAK Options Scan the following bar codes to configure the RS-232 ACK/NAK parameters for your scanner.

  • Page 54: Rs-232 Intercharacter Delay

    Chapter 2 — Configuring Interface Settings Enable for Bar Code Transmission and Host Command Acknowledge --------- END------------------------------------ RS-232 Intercharacter Delay Intercharacter Delay refers to the pause, if any, between each character before it is sent to the host. This time delay controls the flow of data from the scanner.
  • Page 55 Chapter 2 — Configuring Interface Settings 30 Milliseconds --------- 40 Milliseconds --------- 50 Milliseconds --------- 100 Milliseconds --------- 200 Milliseconds --------- 500 Milliseconds --------- 1 Second --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 56: Usb Interface

    Chapter 2 — Configuring Interface Settings END------------------------------------ USB Interface Scan the following bar codes to enable the USB interface and configure the keyboard country code. If you have the USB interface, you must scan these bar codes to enable the interface, or certain conditions will result in data corruption.
  • Page 57 Chapter 2 — Configuring Interface Settings Keyboard Country Code for USB Interface (continued) Code for Code for Country Windows 98/XP/2000 IMAC Spain Switzerland United Kingdom United States START--------------------------------- Enable USB and Configure Keyboard Country Code --------- Use the bar codes on the next page to specify the three-digit keyboard country code you identified in Step 1.
  • Page 58 Chapter 2 — Configuring Interface Settings Digits --------- --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 59 Chapter 2 — Configuring Interface Settings --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 60 Chapter 2 — Configuring Interface Settings SR60 Scanner Programmer’s Reference Manual...

  • Page 61: Configuring Label Transmit Settings

    Configuring Label Transmit Settings This chapter contains the programming bar codes for configuring the optional prefix, suffix, and label ID which may be sent in addition to bar code data if your SR60 scanner is configured for the RS-232 or Keyboard Wedge interface. You will find these sections in this chapter: •...

  • Page 62: When To Configure Label Transmit Settings

    How to Use the Prefix, Suffix, and Label ID The following table shows how you can use the prefix, suffix, and label ID characters. Note: Using these features requires a thorough understanding of your specific system requirements. For help, contact Intermec Product Support. Label ID Label ID...

  • Page 63: Setting Global Prefixes And Suffixes

    Interface” on page 54. Setting Global Prefixes You may add one or two prefix characters to the standard label format. To add more than two prefix characters, contact Intermec Product Support for Full Label Edit (FLE) options. To set global prefixes 1 Identify your specific system requirements.

  • Page 64: Setting Global Suffixes

    END------------------------------------ Setting Global Suffixes You may add one or two suffix characters to the standard label format. To add more than two suffix characters, contact Intermec Product Support for Full Label Edit (FLE) options. SR60 Scanner Programmer’s Reference Manual...
  • Page 65 Chapter 3 — Configuring Label Transmit Settings To set global suffixes 1 Identify your specific system requirements. 2 Using the ASCII table on page 164, identify the ASCII character(s) and the corresponding hex code(s) for the ASCII characters you plan to use as suffixes. 3 Scan the SET bar code below.

  • Page 66: Disabling A Global Prefix Or Suffix

    Chapter 3 — Configuring Label Transmit Settings Set Suffix --------- Use the ASCII table on page 164 to identify the ASCII character(s) and the corresponding hex code(s) for the suffix. Then use the bar codes on page 160 to scan the four digits corresponding to the hex values.

  • Page 67: Setting A Prefix Or Suffix

    Chapter 3 — Configuring Label Transmit Settings Set Suffix --------- --------- END------------------------------------ Setting a Prefix or Suffix The method you use to set a prefix or suffix depends on your scanner interface: • USB Interface • Wand Emulation, Keyboard Wedge, RS-232, or Decoded Interface The scanner does not transmit a prefix or suffix character if its hex value is set to zero.

  • Page 68: Setting A Prefix Or Suffix For A Usb Interface

    Chapter 3 — Configuring Label Transmit Settings Setting a Prefix or Suffix for a USB Interface Use this procedure to set a prefix or suffix. To set a prefix or suffix for a USB interface 1 Scan these bar codes. Code 39 Min Length = 1 Start Lower Case = Enable...
  • Page 69 Chapter 3 — Configuring Label Transmit Settings 4 Scan these bar codes. Code 39 Min Length = 2 To clear the prefix and suffix 1 Scan this bar code. Start 2 Scan this bar code to clear the Preamble (prefix) and Postamble (suffix).

  • Page 70: Setting An Eom For A Usb Interface

    Chapter 3 — Configuring Label Transmit Settings Setting an EOM for a USB Interface For the USB interface, the global character that is added at the end of every scan is an End of Message (EOM) character, not a Postamble (suffix). However, if you use an EOM without a suffix, the EOM acts as the suffix.
  • Page 71 Chapter 3 — Configuring Label Transmit Settings EOM=Tab + EOM=Return EOM=LF EOM=Field Advance EOM=None 3 Scan this bar code. SR60 Scanner Programmer’s Reference Manual...

  • Page 72: Setting A Prefix Or Suffix For A Multi Or Decoded Interface

    Chapter 3 — Configuring Label Transmit Settings Setting a Prefix or Suffix for a Multi or Decoded Interface Use this procedure to set a prefix or suffix that has only one character. Do not use this procedure if you have a USB interface. For a USB interface, see “Setting a Prefix or Suffix for a USB Interface”...

  • Page 73: Setting A Label Id

    Chapter 3 — Configuring Label Transmit Settings Setting a Single Character Prefix/Suffix SET------------------------------------- Set Prefix --------- Set Suffix --------- END------------------------------------ Setting a Label ID Setting the Label ID feature can be a complex task that requires multiple steps to enable all necessary options. About Symbology-Specific Label Identifiers Symbology-specific label identifiers consist of one or two ASCII characters that can precede or follow the bar code label data as it...
  • Page 74 Chapter 3 — Configuring Label Transmit Settings Industry standards have been established for symbology-specific label identifiers, which are listed in the next table. Most scanners have factory default identifiers preset to these standards. Industry Standard Label Identifiers (Prefixes) Symbology Identifier (ID) UPC-A UPC-E EAN-8...

  • Page 75: Setting The Label Id Location

    Chapter 3 — Configuring Label Transmit Settings Setting the Label ID Location You can specify the location where Label ID characters are to be placed in relation to scanned label data. The location you choose will be applied universally to all symbologies; you cannot specify a symbology-specific label ID location.

  • Page 76: Setting A Symbology-Specific Label Id

    Chapter 3 — Configuring Label Transmit Settings Position Label ID as Suffix --------- END------------------------------------ Setting a Symbology-Specific Label ID You can configure a label ID for each symbology. To set a symbology-specific label ID 1 Using the ASCII table on page 164, identify the ASCII character(s) and the corresponding hex code(s) for the ASCII characters you plan to use as the label ID.

  • Page 77: Selecting The Symbology

    Chapter 3 — Configuring Label Transmit Settings 5 Scan the END bar code. You have changed the default Label ID for UPC-A from A to A1. Selecting the Symbology This section contains bar codes that represent each symbology. You scan these bar codes when, for example, you configure a symbology-specific label ID.
  • Page 78 Chapter 3 — Configuring Label Transmit Settings Interleaved 2 of 5 --------- Codabar --------- UPC-A --------- UPC-A (2 digit add-ons) --------- UPC-A (with 5 digit add-ons) --------- UPC-A (with C128 add-ons) --------- UPC-E --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 79 Chapter 3 — Configuring Label Transmit Settings UPC-E (with 2 digit add-ons) --------- UPC-E (with 5 digit add-ons) --------- UPC-E (with C128 add-ons) --------- EAN-13 --------- EAN-13 (with 2 digit add-ons) --------- EAN-13 (with 5 digit add-ons) --------- EAN-13 (with C128 add-ons) --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 80 Chapter 3 — Configuring Label Transmit Settings EAN-8 --------- EAN-8 (with 2 digit add-ons) --------- EAN-8 (with 5 digit add-ons) --------- EAN-8 (C128 add-ons) --------- Code 93 --------- Standard 2 of 5 --------- MSI/Plessey --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 81: Setting A Single-Character Label Id

    Chapter 3 — Configuring Label Transmit Settings END------------------------------------ Setting a Single-Character Label ID The scanner does not transmit a label ID character if its hex value is set to zero. If you need a Label ID that contains only a single character, you can set a single-character label ID.

  • Page 82: Disabling A Symbology-Specific Label Id

    Chapter 3 — Configuring Label Transmit Settings 6 Scan the END bar code. Disabling a Symbology-Specific Label ID To disable a symbology-specific label ID, you follow the steps in the “To set a single-character label ID” procedure on page 67, except you must scan four zeros in Step 5.

  • Page 83: Enabling And Configuring Symbologies

    Enabling and Configuring Symbologies This chapter explains that all symbologies are supported by all the interfaces, describes the symbologies, and contains programming bar codes for configuring symbology features and options. You will find these sections in this chapter: • All Symbologies Supported by All Interfaces •...

  • Page 84: All Symbologies Supported By All Interfaces

    Chapter 4 — Enabling and Configuring Symbologies All Symbologies Supported by All Interfaces You can enable any bar code symbology described in this chapter because all the symbologies in this chapter are supported by all the SR60 scanner interface types. Identify the symbologies you want to enable.
  • Page 85 Chapter 4 — Enabling and Configuring Symbologies • The Enable Code 128 bar code on page 73 selects Code 128 as an active symbology. The scanner is preset to recognize all Code 128 bar codes that have between 1 and 50 characters. •...
  • Page 86 Chapter 4 — Enabling and Configuring Symbologies • The Enable Standard 2 of 5 bar code on page 74 selects Standard 2 of 5 as an active symbology. Options for this symbology are similar to Interleaved 2 of 5 features. •...
  • Page 87 Chapter 4 — Enabling and Configuring Symbologies Enable PharmaCode 39 --------- Enable Code 128 --------- Enable UCC/ EAN 128 --------- Enable Interleaved 2 of 5 --------- Enable Codabar --------- Enable UPC-A --------- Enable UPC-E --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 88 Chapter 4 — Enabling and Configuring Symbologies Enable EAN-13 --------- Enable EAN-8 --------- Enable Code 93 --------- Enable Standard 2 of 5 --------- Enable IATA --------- Enable MSI/ Plessey --------- END------------------------------------ SR60 Scanner Programmer’s Reference Manual...

  • Page 89: Code 39/Pharmacode 39 Options

    Chapter 4 — Enabling and Configuring Symbologies After enabling one or more symbologies, you can use the bar codes in the following sections to configure the symbology options and features. Code 39/PharmaCode 39 Options This section describes the Code 39 options and contains the programming bar codes you can use to configure those options.

  • Page 90: Code 39 Emulate Function Keys

    Chapter 4 — Enabling and Configuring Symbologies Code 39 Emulate Function Keys (USB interface only) Code 39 Emulate Function Keys converts Code 39 character pairs to their equivalent ASCII extended values. For example, with this feature enabled, if you scan a Code 39 bar code that contains a period and capital N (.N), you get the F1 keyboard function.

  • Page 91: Minimum Label Length

    Chapter 4 — Enabling and Configuring Symbologies Start/ Stop Don’t Transmit --------- Transmit --------- Code 39 Full ASCII Enable --------- Disable --------- END------------------------------------ Minimum Label Length The following procedure explains how to set the Code 39 Minimum Label Length. To set Code 39 Minimum Label Length 1 Identify the minimum label length setting you want to make.
  • Page 92 Chapter 4 — Enabling and Configuring Symbologies Note: For this symbology, the scanner decodes up to 48 characters, but the actual length read varies depending upon interface type, bar code physical size, and print quality. Code 39 bar codes containing one or more full ASCII characters can also limit the amount of characters that are decoded;...
  • Page 93 Chapter 4 — Enabling and Configuring Symbologies Digits --------- --------- --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 94: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies --------- --------- --------- Read Verification Scan the following bar codes to set the minimum number of reads required to verify Code 39/Pharmacode 39 symbologies. Note: The more times the scanner is required to read and compare the bar code data, the longer the scanner takes to validate and transmit a label.

  • Page 95: Code 39 Emulate Function Keys

    Chapter 4 — Enabling and Configuring Symbologies Set to Two Reads --------- Set to Three Reads --------- Set to Four Reads --------- END------------------------------------ Code 39 Emulate Function Keys (USB interface only) Scan the following bar codes to enable or disable Code 39 Emulate Function Keys. START--------------------------------- Enable Code 39 Emulate Function Keys...

  • Page 96: About Pharmacode 39 Options

    Chapter 4 — Enabling and Configuring Symbologies END------------------------------------ About PharmaCode 39 Options PharmaCode 39 symbology has the following programmable features: • Transmit Check Digit • Start/Stop Characters Transmit Check Digit Transmit Check Digit selects whether the check digit is transmitted to the host terminal. Start/Stop Characters Start/Stop Characters directs the scanner to either Send or Don’t Send depending on your host interface requirement.

  • Page 97: Code 128 And Ucc/Ean 128 Options

    Chapter 4 — Enabling and Configuring Symbologies Start/Stop Don’t Transit --------- Transmit --------- END------------------------------------ Code 128 and UCC/EAN 128 Options This section describes the Code 128 and UCC/EAN 128 options and contains the programming bar code labels you can use to configure those options.

  • Page 98: Configuring The Code 128/And Ucc/Ean 128 Options

    Chapter 4 — Enabling and Configuring Symbologies Configuring the Code 128/and UCC/EAN 128 Options Scan the following bar codes to configure the Code 128 and UCC/EAN 128 options. Minimum Label Length You can set the Code 128 and UCC/EAN 128 Minimum Label Length.
  • Page 99 Chapter 4 — Enabling and Configuring Symbologies END------------------------------------ Digits --------- --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 100: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies --------- --------- --------- --------- Read Verification Scan the following bar codes to set the minimum number of reads required to verify Code 128 and UCC/EAN 128 symbologies. Note: The more times the scanner is required to read and compare the bar code data, the longer the scanner takes to validate and transmit a label.

  • Page 101: Interleaved 2 Of 5 Options

    Chapter 4 — Enabling and Configuring Symbologies Set to One Read --------- Set to Two Reads --------- Set to Three Reads --------- Set to Four Reads --------- END------------------------------------ Interleaved 2 of 5 Options This section describes the Interleaved 2 of 5 options and contains the programming bar codes you can use to configure those options.

  • Page 102: Check Digit

    Chapter 4 — Enabling and Configuring Symbologies Check Digit Check Digit calculates the check digit to verify that the check digit contained in the bar code label is correct. If you enable this feature, your bar codes must contain a check digit. If the check digit is not calculated, the digit will be sent regardless of settings for transmit or don’t transmit.

  • Page 103: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies • The Set Second Fixed Length bar code on page 93 instructs the scanner that the next two programming labels scanned will define the second fixed label length. This setting can be any even number of characters between 02 and 50 characters.

  • Page 104: Label Length Format

    Chapter 4 — Enabling and Configuring Symbologies Don’t Transmit --------- Transmit --------- END----------------------------------- Label Length Format The next two sections explain how to set the Interleaved 2 of 5 Label Length Format to either the Variable Length or Fixed Length Format. Variable Length Format You can set the Interleaved 2 of 5 symbology to Variable Length Format.

  • Page 105: Fixed Length Format

    Chapter 4 — Enabling and Configuring Symbologies Note: To set a label length less than ten, you must scan a zero digit first and then the length digit (such as 04, 06, or 08). 6 Scan the END bar code. Variable Length Format SET------------------------------------ Enable Variable...
  • Page 106 Chapter 4 — Enabling and Configuring Symbologies 4 Scan the Set First Fixed Length bar code. 5 Using the Digits bar codes on page 93, scan the digits to set the first fixed label length. The length must be an even number.
  • Page 107 Chapter 4 — Enabling and Configuring Symbologies Set Second Fixed Length --------- No Second Fixed Length --------- END------------------------------------ Digits --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 108 Chapter 4 — Enabling and Configuring Symbologies --------- --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 109: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies Read Verification Scan the following bar codes to set the number of reads to verify Interleaved 2 of 5 symbology. Note: The more times the scanner is required to read and compare the bar code data, the longer the scanner takes to validate and transmit a label.

  • Page 110: Codabar Options

    Chapter 4 — Enabling and Configuring Symbologies Codabar Options This section describes the Codabar options and contains the programming bar codes you can use to configure those options. About Codabar Options The Codabar symbology has the following programmable features: • Check Digit •...

  • Page 111: Start/Stop Characters

    Chapter 4 — Enabling and Configuring Symbologies Note: For this symbology, the scanner decodes up to 50 characters, but the actual length read varies depending upon the interface type, bar code physical size, and print quality. • The Enable Variable Length Format bar code on page 100 directs the scanner to read all labels from minimum label length to 50.

  • Page 112: Start/Stop Format

    Chapter 4 — Enabling and Configuring Symbologies Start/Stop Format Start/Stop Format can be set to one of four standard format options: ABCD/TN*E, ABCD/ABCD, abcd/tn*e, or abcd/abcd. This setting must match your system requirements. If you select one of these options, it determines how the ASCII characters A, B, C, D (used for Start/Stop characters) are translated before being sent to the host.

  • Page 113: Label Length Format

    Chapter 4 — Enabling and Configuring Symbologies Gap Check Enable --------- Disable --------- END------------------------------------ Label Length Format The following two sections explain how to set the Codabar Label Length Format to either the Variable Length or Fixed Length Format. Variable Length Format You can set the Codabar symbology to Variable Length Format.

  • Page 114: Fixed Length Format

    Chapter 4 — Enabling and Configuring Symbologies Note: To set a label length less than ten, you must scan a zero digit first and then the length digit (such as 04, 06, or 08). 6 Scan the END bar code. Variable Length Format SET------------------------------------ Enable Variable...
  • Page 115 Chapter 4 — Enabling and Configuring Symbologies Note: To set a label length less than ten, you must scan a zero digit first and then the length digit (such as 04, 06, or 08). • If you need to set a second fixed length, continue with Step 6.
  • Page 116 Chapter 4 — Enabling and Configuring Symbologies No Second Fixed Length --------- END------------------------------------ Digits --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 117 Chapter 4 — Enabling and Configuring Symbologies --------- --------- --------- --------- --------- Start/Stop Characters SET------------------------------------ Match Not Required --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 118 Chapter 4 — Enabling and Configuring Symbologies Match Required --------- Don’t Transmit --------- Transmit (Requires a format. For help, see the next Note.) --------- Format = ABCD/ TN*E --------- Format = abcd/ tn*e --------- Format = ABCD/ ABCD --------- Format = abcd/ abcd --------- END------------------------------------...

  • Page 119: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies Read Verification Scan the following bar codes to set the number of reads to verify Codabar symbology. Note: The more times the scanner is required to read and compare the bar code data, the longer the scanner takes to validate and transmit a label.

  • Page 120: Upc/Ean Options

    Chapter 4 — Enabling and Configuring Symbologies UPC/EAN Options This section describes the UPC/EAN options and contains the programming bar codes you can use to configure those options. About UPC/EAN Options The UPC/EAN symbologies have the following programmable features: • Data Format Settings •...

  • Page 121: Price/Weight Check Digit

    Chapter 4 — Enabling and Configuring Symbologies • Optional means scanner reads UPC/EAN bar codes with or without add-ons. • Disable directs the scanner not to recognize or read add-on portions of UPC/EAN labels, but to read the main body of the label.
  • Page 122 Chapter 4 — Enabling and Configuring Symbologies SET------------------------------------ UPC-A Send Check Digit --------- Don’t Send Check Digit --------- Send NSD --------- Don’t Send NSD --------- UPC-E Send Check Digit --------- Don’t Send Check Digit --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 123: Ean Data Format Settings

    Chapter 4 — Enabling and Configuring Symbologies Send NSD --------- Don’t Send NSD --------- END------------------------------------ Note: If UPC-E is expanded to UPC-A, the transmission of the check digit and the NSD is determined by the UPC-A settings on this page. EAN Data Format Settings These settings affect EAN data format.

  • Page 124: Upc/Ean Expansion

    Chapter 4 — Enabling and Configuring Symbologies Send NSD --------- Don’t Send NSD --------- EAN-8 Send Check Digit --------- Don’t Send Check Digit --------- END------------------------------------ UPC/EAN Expansion Scan the following bar codes to activate UPC/EAN Expansion: • Expand UPC-A to EAN-13 •...
  • Page 125 Chapter 4 — Enabling and Configuring Symbologies Note: If you choose Expand for any of the following features, the transmission of the prefix, suffix, check digit, and NSD will be controlled by your selections for the symbology expanded to rather than the symbology expanded from. For example, if you expand OPC-E to UPC-A, the settings for UPC-A determine how the scanner sends the bar code contents.

  • Page 126: Upc/Ean Add-Ons

    • The leading digits of the base labels affected can be specified. Note: These settings represent only a small portion of the options available for this feature. For help with advanced add-on settings, contact Intermec Product Support. SR60 Scanner Programmer’s Reference Manual...
  • Page 127 Note: Due to the structure of add-on codes, selecting the optional setting makes it impossible to ensure that the scanner will always read the add-on portion of the label. Intermec makes no guarantee, either written or implied, that scanners with optional add-on decoding enabled will perform with the speed and accuracy required for any given application.

  • Page 128: Custom Add-Ons

    Custom Add-ons A wide array of add-on options are available to streamline your installation to its best advantage. For help with custom add-ons, contact Intermec Product Support. Price/Weight Check Digit The Price/Weight Check Digit selections allow you to specify whether the scanner should calculate an extra check digit based on a four or five-digit price/weight block and compare it with the price/weight check digit contained in the bar code.

  • Page 129: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies Enable 5-Digit --------- Enable Euro 4- Digit --------- Enable Euro 5- Digit --------- END------------------------------------ Read Verification You can set the number of minimum reads required to verify UPC/EAN symbologies. To set the number of minimum reads 1 Scan the SET bar code.
  • Page 130 Chapter 4 — Enabling and Configuring Symbologies Read Verification SET------------------------------------- Verify UPC-A --------- Verify UPC-E --------- Verify EAN-13 --------- Verify EAN-8 --------- Verify Instore Label --------- Number of Reads to Verify One Read --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 131: Code 93 Options

    Chapter 4 — Enabling and Configuring Symbologies Two Reads --------- Three Reads --------- Four Reads --------- END------------------------------------ Code 93 Options This section describes the Code 93 options and contains the programming bar codes you can use to configure those options. About Code 93 Options The Code 93 symbology has the following programmable features:...

  • Page 132: Configuring The Code 93 Options

    Chapter 4 — Enabling and Configuring Symbologies Configuring the Code 93 Options Scan the following bar codes to configure the Code 93 options. Minimum Label Length You can set the Minimum Label Length. Note: For this symbology, the scanner decodes up to 50 characters, but the actual length read varies depending upon interface type, bar code physical size, and print quality.
  • Page 133 Chapter 4 — Enabling and Configuring Symbologies Use the Digits bar codes to specify the two-digit minimum length value you identified in Step 1. END----------------------------------- Digits --------- --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 134: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies --------- --------- --------- --------- Read Verification Scan the following bar codes to set the number of reads to verify Code 93 symbology. Note: The more times the scanner is required to read and compare the bar code data, the longer the scanner takes to validate and transmit a label.

  • Page 135: Standard 2 Of 5/Iata Options

    Chapter 4 — Enabling and Configuring Symbologies Set to Two Reads --------- Set to Three Reads --------- Set to Four Reads --------- END------------------------------------ Standard 2 of 5/IATA Options This section describes the Code 39 options and contains the programming bar codes you can use to configure those options. About Standard 2 of 5/IATA Options The Standard 2 of 5/IATA symbologies have the following programmable features:...

  • Page 136: Label Length Format

    Chapter 4 — Enabling and Configuring Symbologies If the check digit is not calculated, the digit will be sent regardless of settings for transmit or don’t transmit. For example, if you choose to transmit check digit, but not calculate it, the scanner sends the check digit encoded in the bar code without verifying its accuracy.

  • Page 137: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies • The No Second Fixed Length bar code on page 126 configures the scanner to recognize only the first fixed length. Read Verification Read Verification is the number of times the scanner is required to read the bar code data before sending the label data to the host.

  • Page 138: Label Length Format

    Chapter 4 — Enabling and Configuring Symbologies Label Length Format The next two sections let you set the Standard 2 of 5/IATA label length format to either Variable Length or Fixed Length format. Variable Length Format You can set the Standard 2 of 5/IATA symbology to read Variable Length Format.

  • Page 139: Fixed Length Format

    Chapter 4 — Enabling and Configuring Symbologies END------------------------------------ Fixed Length Format All interfaces that are shipped with the standard factory configuration are set to read variable length labels. If you switch from variable length to fixed length format, the default fixed labels are 14 characters and 8 digits.
  • Page 140 Chapter 4 — Enabling and Configuring Symbologies Fixed Length Format SET------------------------------------- Enable Fixed Length Format --------- Set First Fixed Length --------- Set Second Fixed Length --------- No Second Fixed Length --------- END------------------------------------ SR60 Scanner Programmer’s Reference Manual...
  • Page 141 Chapter 4 — Enabling and Configuring Symbologies Digits --------- --------- --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 142: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies --------- --------- --------- Read Verification Scan the following bar codes to set the number of reads to verify Standard 2 of 5/IATA symbologies. Note: The more times the scanner is required to read and compare the bar code data, the longer the scanner takes to validate and transmit a label.

  • Page 143: Iata Options

    Chapter 4 — Enabling and Configuring Symbologies Set to Three Reads --------- Set to Four Reads --------- END------------------------------------ IATA Options IATA is a special symbology subset of Standard 2 of 5. Enabling IATA selects this custom code as the active Standard 2 of 5 symbology.

  • Page 144: Msi/Plessey Options

    132 specifies either one or two check digits. Label Length Format Label length format permits the selection between variable length or fixed length formats. For best performance, Intermec recommends that you use the Fixed Length settings when your application requires only one or two label lengths.

  • Page 145: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies length to 16. If you select variable length format, there is one more bar code label to scan: • The Set Minimum Label Length bar code on page 133 selects the minimum label length that the scanner will recognize.

  • Page 146: Label Length Format

    Chapter 4 — Enabling and Configuring Symbologies Calculate --------- Don’t Calculate --------- Transmit --------- Don’t Transmit --------- One Check Digit --------- Two Check Digits --------- END----------------------------------- Label Length Format The next two sections explain how to set the MSI/Plessey label length format to either the Variable Length or Fixed Length format.

  • Page 147: Fixed Length Format

    Chapter 4 — Enabling and Configuring Symbologies To set the MSI/Plessey to read Variable Length Format 1 Identify the minimum length setting you want to make. The selectable range is 04 to 16 characters. 2 Scan the SET bar code. 3 Scan the Enable Variable Length Format bar code.
  • Page 148 Chapter 4 — Enabling and Configuring Symbologies To set the MSI/Plessey symbology to fixed length format 1 Identify the fixed length setting(s) you wish to make. Fixed lengths can be set from 04 to 16 characters. 2 Scan the SET bar code. 3 Scan the Enable Fixed Length Format bar code.
  • Page 149 Chapter 4 — Enabling and Configuring Symbologies Set First Fixed Length --------- Set Second Fixed Length --------- No Second Fixed Length --------- END------------------------------------ Digits --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 150 Chapter 4 — Enabling and Configuring Symbologies --------- --------- --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 151: Read Verification

    Chapter 4 — Enabling and Configuring Symbologies Read Verification Scan the following bar codes to set the number of reads to verify MSI/Plessey symbologies. Note: The more times the scanner is required to read and compare the bar code data, the longer the scanner takes to validate and transmit a label.
  • Page 152 Chapter 4 — Enabling and Configuring Symbologies SR60 Scanner Programmer’s Reference Manual...

  • Page 153: Configuring General Features

    Configuring General Features This chapter explains how to configure the scanner features that are common to all interfaces. You will find these sections in this chapter: • Configuring the Green LED Idle State • Configuring the Beeper Settings • Configuring the Marker Beam •...

  • Page 154: Configuring The Green Led Idle State

    141 enable or disable the beep upon completion of a good read. Note: Intermec strongly recommends that you do not disable this feature. The good read beep provides the best scanning status feedback to the user. You cannot disable error tones.
  • Page 155 Chapter 5 — Configuring General Features Note: For the loudest beep signal, set the beeper volume to 3 and the good read beep frequency to high. • The Good Read Beep Frequency bar codes on page 142 adjust the pitch of the beeper to low, medium, or high. •...
  • Page 156 Chapter 5 — Configuring General Features Beep On --------- Power-up Beep Enable --------- Disable --------- Beep Volume Volume 1 --------- Volume 2 --------- Volume 3 --------- Good Read Beep Frequency --------- Medium --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 157 Chapter 5 — Configuring General Features High --------- Good Read Beep Duration Short --------- Medium --------- Long --------- When to Beep After Decode --------- After Transmission to Host --------- After CTS Activation (RS-232 Only) --------- END------------------------------------ SR60 Scanner Programmer’s Reference Manual...

  • Page 158: Configuring The Marker Beam

    Chapter 5 — Configuring General Features Configuring the Marker Beam The Marker Beam feature provides the user with a spotter beam for improved aiming at distant bar code labels and/or in extremely bright environments. A Marker Beam can also be useful when scanning through showcase glass or scanning bar code menus containing bar codes printed with little space between them.
  • Page 159 Chapter 5 — Configuring General Features Marker Beam Duration 0 Seconds --------- 0.2 Seconds --------- 0.3 Seconds --------- 0.4 Seconds --------- 0.5 Seconds --------- 0.6 Seconds --------- 0.8 Seconds --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 160: Configuring The Low Power Mode

    However, the microcontroller must reboot with every trigger pull, which causes a very small delay in scanning. Intermec recommends that you use this mode only when the scanner is connected to a battery-powered terminal.
  • Page 161 Chapter 5 — Configuring General Features To enable or disable the Low Power mode 1 Scan the SET bar code. 2 Scan the both the Step #1 and Step #2 bar codes to enable or disable the option. 3 Scan the END bar code. SET------------------------------------- Enable Step #1 ---------...

  • Page 162: Configuring The Low Power Shutdown Delay

    The following bar codes provide for transition times of 0 (no delay), 2, 5, or 10 seconds delay. For other Low Power Shutdown Delay settings, contact Intermec Product Support. To set the Low Power Shutdown Delay option 1 Scan the SET bar code.

  • Page 163: Configuring The Half Angle

    Chapter 5 — Configuring General Features 10 Seconds --------- END------------------------------------ Configuring the Half Angle When enabled, the Half Angle feature causes the scanner to scan with a scan angle that is approximately half the standard setting. Disabling the feature returns the scanner to the standard scan width.
  • Page 164 Chapter 5 — Configuring General Features SET------------------------------------- Enable --------- Disable --------- END------------------------------------ SR60 Scanner Programmer’s Reference Manual...

  • Page 165: Factory Default Configuration

    Factory Default Configuration This appendix lists the factory default configuration values and provides a worksheet for you to record the configuration changes you make. SR60 Scanner Programmer’s Reference Manual...

  • Page 166: Factory Default Configuration

    Appendix A — Factory Default Configuration Factory Default Configuration The following tables list most of the default configuration values for the SR60 scanner. These tables also serve as a worksheet where you can record the changes you make. For help restoring your scanner to these values, see “Restoring Factory Default Settings”...
  • Page 167 Appendix A — Factory Default Configuration RS-232 Interface Defaults Feature Default Your Setting Baud Rate 9600 Data Bit Parity Even Stop Bit Hardware Handshaking Disable Software Handshaking Disable ACK/NAK Options Disable Intercharacter Delay USB Interface Defaults Feature Default Your Setting Terminal/Keyboard Settings Return Prefix...
  • Page 168 Appendix A — Factory Default Configuration Symbology Defaults Feature Default Your Setting Code 39 Enable Calculate Check Digit Don’t Calculate Transmit Check Digit Transmit Start/Stop Don’t Transmit Code 39 Full ASCII Disable Minimum Label Length Read Verification Code 39 Emulate Function Disable Keys (USB interface only) PharmaCode 39...
  • Page 169 Appendix A — Factory Default Configuration Symbology Defaults (continued) Feature Default Your Setting Read Verification UPC-E Disable Check Digit Send NSD Option Send NSD Read Verification EAN-13 Disable Check Digit Send NSD Option Send NSD Read Verification EAN-8 Disable Check Digit Send NSD Option Send NSD...
  • Page 170 Appendix A — Factory Default Configuration General Features Defaults Feature Default Your Setting Green LED Idle State Beep On or Off Power-up Beep Enable Beep Volume High Good Read Beep Frequency High Good Read Beep Duration 100 ms When to Beep After Decode Marker Beam Enable/Disable Enable (XLR version) Disable (SR version)

  • Page 171: Reference Information

    Reference Information This appendix contains information you may find useful while programming your SR60 scanner. In this appendix, you will find these sections: • Sample Bar Codes • Keypad Bar Codes • RS-232 Host Commands • ASCII Character Set • Full ASCII Chart •...

  • Page 172: Sample Bar Codes

    Appendix B — Reference Information Sample Bar Codes Code 39 Code 128 C o d e 1 2 8 T e s Interleaved 2 of 5 0 1 2 3 4 5 6 7 8 9 Codabar A $ 9 9 . 9 5 A UPC-A 0 0 1 1 2 2 3 3 4 4 SR60 Scanner Programmer’s Reference Manual...
  • Page 173 Appendix B — Reference Information UPC-A with 2-digit add-ons 6 0 9 9 2 0 1 1 1 8 UPC-A with 5-digit add-ons 6 9 0 0 0 0 8 0 2 9 5 1 0 4 1 UPC-E 9 9 8 8 7 5 EAN-13 1 1 0 1 2 3 4 5 6 7 8 9 1 EAN-8...

  • Page 174: Keypad Bar Codes

    Appendix B — Reference Information Code 93 Code 93.test Standard 2 of 5 9 8 7 6 5 4 3 2 1 0 MSI/Plessey 14476925 Keypad Bar Codes To configure some features, you need to select numbers and letters. You can use these bar codes. --------- --------- ---------...
  • Page 175 Appendix B — Reference Information --------- --------- --------- --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...
  • Page 176 Appendix B — Reference Information --------- --------- --------- --------- --------- SR60 Scanner Programmer’s Reference Manual...

  • Page 177: Rs-232 Host Commands

    Appendix B — Reference Information RS-232 Host Commands The following table describes the commands that the RS-232 interface accepts from the host. Overview of RS-232 Commands ASCII Command Character Description Disable Places the scanner in an operational Scanner mode in which the scanner does not accept bar code data input from the scan optics.

  • Page 178: Ascii Character Set

    Appendix B — Reference Information ASCII Character Set This table contains a set of ASCII characters and corresponding hex values. You need these hex values when you configure symbology-specific label identifiers, as well as when you enable custom prefix and suffix characters. ASCII ASCII ASCII...
  • Page 179 Appendix B — Reference Information Full ASCII Chart SR60 Scanner Programmer’s Reference Manual...
  • Page 180 Appendix B — Reference Information SR60 Scanner Programmer’s Reference Manual...
  • Page 181 Appendix B — Reference Information " SR60 Scanner Programmer’s Reference Manual...
  • Page 182 Appendix B — Reference Information & SR60 Scanner Programmer’s Reference Manual...
  • Page 183 Appendix B — Reference Information SR60 Scanner Programmer’s Reference Manual...
  • Page 184 Appendix B — Reference Information < > SR60 Scanner Programmer’s Reference Manual...
  • Page 185 Appendix B — Reference Information SR60 Scanner Programmer’s Reference Manual...
  • Page 186 Appendix B — Reference Information SR60 Scanner Programmer’s Reference Manual...
  • Page 187 Appendix B — Reference Information SR60 Scanner Programmer’s Reference Manual...
  • Page 188 Appendix B — Reference Information SR60 Scanner Programmer’s Reference Manual...
  • Page 189 Appendix B — Reference Information ASCII Extended Chart Field Exit Field Advance Enter Send SR60 Scanner Programmer’s Reference Manual...
  • Page 190 Appendix B — Reference Information Return Reset Restore Home Right Arrow Left Arrow Up Arrow Down Arrow Clear SR60 Scanner Programmer’s Reference Manual...
  • Page 191 Appendix B — Reference Information SR60 Scanner Programmer’s Reference Manual...
  • Page 192 Appendix B — Reference Information SR60 Scanner Programmer’s Reference Manual...

This manual is also suitable for:

Sr60blSr60bxSr61tSr61t1dSr60

Table of Contents
