SR60 Hands Free Stand Instructions

Learning About the Hands Free Stand

The SR60 Hands Free Stand allows you to use AutoSense mode for the

SR60 scanner. When enabled, AutoSense detects when a bar code is

placed within range and automatically scans without the need to

manually trigger the scanner.

These instructions provide directions for adjusting the stand height,

installing and removing the scanner, and configuring the scanner.

Scanner cradle

To adjust the stand height

1 Pull and hold the retaining knob while sliding the top assembly to

the desired height.

2 Release the retaining knob and readjust the height so that the

retaining pins latch onto the retaining holes.

Retaining

pins

Retaining knob

Table of Contents

Do you have a question about the SR60 and is the answer not in the manual?

Page 1 SR60 Hands Free Stand Instructions Learning About the Hands Free Stand The SR60 Hands Free Stand allows you to use AutoSense mode for the SR60 scanner. When enabled, AutoSense detects when a bar code is placed within range and automatically scans without the need to manually trigger the scanner.
Page 2 To install the scanner 1 Place the top end of the scan window onto the stand. 2 Pivot the scanner by the handle into the cradle until the latch engages the indent on the cap. 3 Verify that the trigger is pushed down by visually checking that the bump on the stand cradle pushes on the trigger.
Page 3: Configuring The Scanner
Configuring the Scanner You can enable Autosense mode when you use the scanner with the stand. To set AutoSense mode On or Off 1 Scan the SET bar code. 2 Scan the bar code for the option you want to configure.
Page 4 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2005 Intermec Technologies Corporation. All rights reserved. SR60 Hands Free Stand Instructions *943-088-001* P/N 943-088-001...
